UHF Wireless System
USER GUIDE SUPPLEMENT MD (800–820 MHz)
27B8667(AA)
2001, Shure Incorporated Printed in U.S.A.

2
SPECIFICATIONS
RF Carrier Frequency Range
800–820 MHz
Working Range
U1, U2: 152.4 m, minimum, under typical conditions; 487.6 m line of sight
U1H: 275 m, minimum, under typical conditions; 975 m line of sight
NOTE: Actual working range depends on RF signal absorption, reflection and
interference
Audio Frequency Response
50 to 15,000 Hz, ±2 dB. NOTE: Overall system frequency response depends on the
microphone element
Gain Adjustment Range
U1, U1H: 0 to 40 dB
U2: 0 to 26 dB
Modulation
±45 kHz deviation compressor-expander system with pre-and de-emphasis
RF Power Output
U1, U2: 10 mW maximum
U1H: 50 mW maximum
Dynamic Range
>102 dB, A-weighted
RF Sensitivity
U4S U4D
–110 dBm
12 dB SINAD –107 dBm 12 dB SINAD
–105 dBm
30 dB SINAD –102 dBm 30 dB SINAD
Image Rejection
90 dB typical
Spurious Rejection
75 dB typical
Ultimate Quieting (ref. 45 kHz deviation)
>100 dB, A-weighted
Audio Polarity
Positive pressure on microphone diaphragm (or positive voltage applied to tip of
WA302 phone plug) produces positive voltage on pin 2 with respect to pin 3 of
low impedance output and the tip of the high impedance 1/4-inch output
System Distortion (ref. ±45 kHz deviation, 1 kHz modulation)
0.3% Total Harmonic Distortion typical
Power Requirements
U1, U1H, U2: 1.5V AA alkaline battery (Duracell MN1500 recommended); Nicad
optional
U4: 90 to 230 Vac , 50/60 Hz
Power Consumption:
U4S: 9.6 W min., 13.2 W max.
U4D: 12 W min.,16 W max.
UA840: 15 W min., 16 W max.
Battery Life (Typical)
U1, U2: 12 hours (with Duracell MN1500 1.5V AA alkaline battery)
U1H: 6 hours (with Duracell MN1500 1.5V AA alkaline battery)

3
Operating Temperature Range
-20°to 50°C NOTE: Battery characteristics may limit this range
Overall Dimensions
U1: 92.2 mm L x 64.7 mm W x 24.2 mm D
U2/58:254 mm L x 50.8 mm Dia.
U2/BETA 58: 254 mm L x 53.2 mm Dia.
U2/87:228.6 mm x 49.2 mm Dia.
U2/BETA 87: 216 mm L x 50.8 mm Dia
U4S/U4D: 44.5 mm H x 482.6 mm W x 295.3 mm D
Net Weight
U1, U1H: 175.2 g without battery
U2/58, U2/BETA 58: 375.6 g without battery
U2/87, U2/BETA 87: 303.1 g without battery
U4S: 3.30 kg
U4D: 3.85 kg
Certification
U1*, U2: BAPT Type Approved to FTZ 17TR 2019 and BAPT 122 R1; EMC
Approved to ETS 300 445.
U4S, U4D: VDE Certified to EN 60 950. BAPT Type Approved to FTZ 17TR 2019
and BAPT 122 R1; EMC Approved to ETS 300 445. Meets Low Voltage
Directive.
UHF Type Approved and EMC Approved systems are eligible to carry the CE
marking.
*The U1H transmitter does not carry the same approvals as the U1 transmitter.
U1, U1H Transmitter Input
Connector: Switchcraft TA4F Tini Q-G or
LEMO connector (optional)
Input Configuration: Unbalanced, active
Actual Impedance: 18 kΩwith lavalier microphone
1 MΩwith instrument cable
Maximum Input Level: 6 Vp–p (+7 dBV) for 1% THD at minimum gain
setting using 1 kHz signal.
TA4F Tini Q.G. Connector Pin
Assignments:
Pin 1: Tied to Ground
Pin 2: Tied to +5 V
Pin 3: Tied to Audio
Pin 4: Tied thru 20kΩResistor to Ground.
(On instrument adapter cable, Pin 4 floats)
LEMO Connector
Pin Assignments:
Pin 1: Tied to Pin 3 and 10 kΩ to Ground
Pin 2: +5V
Pin 3: Tied to Pin 1
Pin 4: Tied to Shield (Ground for Positive Bias)
Voltage for Remote Power: +5 V supplied to microphone cartridge
U1, U1H Transmitter Output (Figure 1)
Connector: SMC
Actual Impedance: 50 Ω
Nominal Output Level: +10 dBm (+17 dBm for U1H)
Maximum Output Level: +11 dBm (+18 dBm for U1H)
Pin Assignments: Shell = Ground
Center = Signal

4
27 pF
20K Ω
27 pF
+5 V
AUDIO
GROUND
U1/U1H MIC JACK BOARD
2
1
4
500 Ω
500 Ω
MICROPHONE
ELEMENT
3
2
1
3
4
NOTE: LAVALIER MIC TIES PINS 3 AND 4
TOGETHER; GUITAR CABLE DOES NOT.
27 pF
499 Ω
499 Ω
3
27 pF
10K Ω
AUDIO
SHIELD
U1L (LEMO 4 PIN) MIC JACK BOARD
1
4
2BIAS
FIGURE 1
U2 Transmitter Input
Input Configuration: Unbalanced, active
Actual Impedance: 20 kΩ
Maximum Input Level: 3 Vp–p (0.5 dBV) for 1% THD at minimum gain setting
using 1 kHz signal.
U2 Transmitter Output
Connector: SMC
Actual Impedance: 50 Ω
Nominal Output Level: +10 dBm
Maximum Output Level: +11 dBm
Pin Assignments: Shell = Ground
Center = Signal

5
U4S and U4D Receiver Input
Connector: Antenna Power Input Network Interface
Connector Type: BNC IEC 25–Pin D
Actual Impedance: 50 Ω–– ––
Nominal Input
Level: –95 to –30 dBm 90–230 VAC, 50/60 Hz CMOS Logic
Maximum Input
Level: +6 dBm (–20 dBm
recommended)
230 VAC, 50/60 Hz ––
Pin Assignments: Shell = Ground
Center = Signal IEC Standard ––
Voltage for
Remote Power: 12 Vdc, 150 mA maximum –– 5V, 700 mA max.
U4S and U4D Receiver Output
Connector: Monitor Power
Output High Z Audio Low Z Audio* Network Interface
Output
Configuration: Unbalanced
mono, 1/4 inch –– Un- balanced Balanced See Appendix
Actual
Impedance: 300 Ω–– 1 kΩ30 ΩSee
Appendix
Nominal
Input Level: –– 90 to 230
VAC, 5A –– –– CMOS Logic
Pin
Assignments: Tip = Hot
Ring = Hot
Sleeve = Gnd
IEC
Standard Tip = Hot Ring/
Sleeve =
Gnd
1 = Ground
2 = Hot
3 = Hot
See
Appendix
Voltage/
Current/
Phantom
Power
Protection?
Yes –– Yes Yes 5V, 700 mA
resettable
polyfuse
*Output Level: Microphone Level = Line Level – 30 dB
FURNISHED ACCESSORIES
Microphone Stand Adapter (U2) WA370A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Zipper Bag (U1) 26A13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Zipper Bag (U2) 26A14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screwdriver 80A498. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coaxial Antenna Cable (2 ft) UA802. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1/2 Wave Antenna UA820A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmitter Carrying Case 65A8257. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Carrying Case Insert 29B1577. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6
OPTIONAL ACCESSORIES
Instrument Adapter Cable (U1) WA302. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switchcraft TA4F Female 4–Pin Connector (U1) WA330. . . . . . . . . . . . . . . . . . . . . . . .
In-Line Audio Switch (U1) WA360. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.8 Meter (6 ft) Receiver-Mixer Cable (1/4” phone to XLR) WA410. . . . . . . . . . . . . . . .
7.6 Meter (25 ft) Antenna Extension Cable UA825. . . . . . . . . . . . . . . . . . . . . . . . . . . .
15.2 (50 ft) Meter Antenna Extension Cable UA850. . . . . . . . . . . . . . . . . . . . . . . . . . .
In–Line Active Remote Antenna Kit (800 – 830 MHz) UA830C. . . . . . . . . . . . . . . . . .
Antenna/Power Distribution System, 230 Vac UA845MB. . . . . . . . . . . . . . . . . . . . . . .
Directional Antenna UA870MB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REPLACEMENT PARTS
Hardware Kit (screwdriver, mounting feet, cable clamps) 90VL1371. . . . . . . . . . . . .
Bulkhead Adapters for Front–Mounting Antennas 95A8647. . . . . . . . . . . . . . . . . . . .
230 VAC Power Cord (Schuko mains connector) 95A8247. . . . . . . . . . . . . . . . . . . . .
304 mm (12 in.) Daisy–Chain Power Cord (230 V) 95A8678. . . . . . . . . . . . . . . . . . . .
SM58 Cartridge with Grille (U2/58) R158. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BETA 58A Cartridge with Grille (U2/BETA 58) R179. . . . . . . . . . . . . . . . . . . . . . . . . . .
SM87 Cartridge with Grille (U2/87) R165. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BETA 87 Cartridge with Grille (U2/BETA 87) R166. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Matte Silver Grille (U2/58) RK143G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Matte Silver Grille (U2/BETA 58) RK265G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Matte Silver Grille (U2/BETA 87 RK313G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Black Grille (U2/87) RK214G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Black Grille (U2/BETA 58) RK323G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Black Grille (U2/BETA 87) RK324G. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Belt Clip (U1) 53A8247A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antenna (U1) 95A8646. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antenna (U2) 95A2029. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7
FREQUENCY SELECTION GUIDE
The Shure UHF Wireless System is designed for maximum flexibility and ver-
satility in a variety of applications. Up to 19 Shure UHF Wireless Systems can be
operated simultaneously in a single installation using the frequency compatibility
groups. Please contact Shure Brothers Incorporated if you need additional infor-
mation or assistance in frequency selection and setup.
Compatibility Groups
The Shure UHF Wireless System includes 12 groups of compatible channels. If you
are using more than one receiver in the same area, we recommend that you set the
receivers to different frequencies within the same group.
Compatible Frequency List
The following table lists the frequencies in each of the twelve compatibility
groups.
GROUP
GRP 1 GRP 2 GRP 3 GRP 4 GRP 5 GRP 6 GRP 7 GRP 8 GRP 9 GRP 10 GRP 11 GRP 12
1800,375 800,375 800,500 800,475 800,225 801.300 800,600 800.400 800.800 800.100 800.100 800.100 2801,500 801,625 801,750 801,350 800,850 803.100 801.600 801.100 801.300 800.700 800.700 800.700
C
3802,000 802,375 802,500 801,975 801,725 803.700 802.100 802.600 802.600 801.900 801.600 801.900
C4802,875 803,375 803,500 803,225 802,225 804.600 802.900 803.300 803.300 802.500 802.200 802.800
H5804,000 804,125 804,250 805,600 802,975 805.200 803.300 804.400 804.900 803.400 803.400 803.400
H
A6804,500 804,625 804,750 806,475 803,975 806.400 805.700 805.100 806.200 804.000 804,000 804.600
A
N
7805,750 805,375 805,500 806,975 805,350 807.000 806.500 806.500 806.800 805.200 804.900 805.200
N
N
8806,750 807,125 807,250 807,725 805,975 808.500 807.000 807.300 807.800 805.800 805.500 808.200
N9807,250 808,125 808,250 808,725 807,475 812.100 807.800 810.700 813.400 808.800 808.500 808.800
E10 808,375 808,625 808,750 810,225 809,350 813.000 810.400 811.600 814.000 809.400 810.000 810.000
E
L11 809,250 809,375 809,500 811,225 812,975 813,600 814.600 813.100 815.200 810.600 810.600 810.600
L
12 809,750 809,875 810,000 814,475 813,850 814.800 815.400 813.800 815.800 811.200 811.800 811.500
13 813,375 811,375 811,500 815,225 814,350 815.400 815.900 815.200 816.700 812.100 812.400 812.100
14 816,000 813,625 813,750 815,725 815,475 816.300 816.700 817.800 817.900 812.700 813.300 813.300
15 817,250 816,125 816,250 816,475 816,225 818.400 818.300 818.400 818.500 813.900 813.900 813.900
16 817,750 816,625 817,750 817,475 817,350 819.300 819.500 819.400 819.700 814.500 817.500 818.700
17 818,875 817,625 819,000 818,225 818,975
18 819,750 818,875 819,775 819,475 819,725
19 819,875

8
Master Frequency List
The Master List (Groups A1 through A8) covers all frequencies in 25 kHz
increments within the 800 to 820 MHz band.
MASTER
FREQ. GRP. CHAN.
800.100 A1 1
800.125 A1 2
800.150 A1 3
800.175 A1 4
800.200 A1 5
800.225 A1 6
800.250 A1 7
800.275 A1 8
800.300 A1 9
800.325 A1 10
800.350 A1 11
800.375 A1 12
800.400 A1 13
800.425 A1 14
800.450 A1 15
800.475 A1 16
800.500 A1 17
800.525 A1 18
800.550 A1 19
800.575 A1 20
800.600 A1 21
800.625 A1 22
800.650 A1 23
800.675 A1 24
800.700 A1 25
800.725 A1 26
800.750 A1 27
800.775 A1 28
800.800 A1 29
800.825 A1 30
800.850 A1 31
800.875 A1 32
MASTER
FREQ. GRP. CHAN.
800.900 A1 33
800.925 A1 34
800.950 A1 35
800.975 A1 36
801.000 A1 37
801.025 A1 38
801.050 A1 39
801.075 A1 40
801.100 A1 41
801.125 A1 42
801.150 A1 43
801.175 A1 44
801.200 A1 45
801.225 A1 46
801.250 A1 47
801.275 A1 48
801.300 A1 49
801.325 A1 50
801.350 A1 51
801.375 A1 52
801.400 A1 53
801.425 A1 54
801.450 A1 55
801.475 A1 56
801.500 A1 57
801.525 A1 58
801.550 A1 59
801.575 A1 60
801.600 A1 61
801.625 A1 62
801.650 A1 63
801.675 A1 64

9
MASTER
FREQ. GRP. CHAN.
801.700 A1 65
801.725 A1 66
801.750 A1 67
801.775 A1 68
801.800 A1 69
801.825 A1 70
801.850 A1 71
801.875 A1 72
801.900 A1 73
801.925 A1 74
801.950 A1 75
801.975 A1 76
802.000 A1 77
802.025 A1 78
802.050 A1 79
802.075 A1 80
802.100 A1 81
802.125 A1 82
802.150 A1 83
802.175 A1 84
802.200 A1 85
802.225 A1 86
802.250 A1 87
802.275 A1 88
802.300 A1 89
802.325 A1 90
802.350 A1 91
802.375 A1 92
802.400 A1 93
802.425 A1 94
802.450 A1 95
802.475 A1 96
802.500 A1 97
802.525 A1 98
802.550 A1 99
MASTER
FREQ. GRP. CHAN.
802.575 A2 1
802.600 A2 2
802.625 A2 3
802.650 A2 4
802.675 A2 5
802.700 A2 6
802.725 A2 7
802.750 A2 8
802.775 A2 9
802.800 A2 10
802.825 A2 11
802.850 A2 12
802.875 A2 13
802.900 A2 14
802.925 A2 15
802.950 A2 16
802.975 A2 17
803.000 A2 18
803.025 A2 19
803.050 A2 20
803.075 A2 21
803.100 A2 22
803.125 A2 23
803.150 A2 24
803.175 A2 25
803.200 A2 26
803.225 A2 27
803.250 A2 28
803.275 A2 29
803.300 A2 30
803.325 A2 31
803.350 A2 32
803.375 A2 33
803.400 A2 34
803.425 A2 35

10
MASTER
FREQ. GRP. CHAN.
803.450 A2 36
803.475 A2 37
803.500 A2 38
803.525 A2 39
803.550 A2 40
803.575 A2 41
803.600 A2 42
803.625 A2 43
803.650 A2 44
803.675 A2 45
803.700 A2 46
803.725 A2 47
803.750 A2 48
803.775 A2 49
803.800 A2 50
803.825 A2 51
803.850 A2 52
803.875 A2 53
803.900 A2 54
803.925 A2 55
803.950 A2 56
803.975 A2 57
804.000 A2 58
804.025 A2 59
804.050 A2 60
804.075 A2 61
804.100 A2 62
804.125 A2 63
804.150 A2 64
804.175 A2 65
804.200 A2 66
804.225 A2 67
804.250 A2 68
804.275 A2 69
804.300 A2 70
MASTER
FREQ. GRP. CHAN.
804.325 A2 71
804.350 A2 72
804.375 A2 73
804.400 A2 74
804.425 A2 75
804.450 A2 76
804.475 A2 77
804.500 A2 78
804.525 A2 79
804.550 A2 80
804.575 A2 81
804.600 A2 82
804.625 A2 83
804.650 A2 84
804.675 A2 85
804.700 A2 86
804.725 A2 87
804.750 A2 88
804.775 A2 89
804.800 A2 90
804.825 A2 91
804.850 A2 92
804.875 A2 93
804.900 A2 94
804.925 A2 95
804.950 A2 96
804.975 A2 97
805.000 A2 98
805.025 A2 99
805.050 A3 1
805.075 A3 2
805.100 A3 3
805.125 A3 4
805.150 A3 5
805.175 A3 6
