Shure SM58 User manual

MODEL SM58£
UNIDIRECTIONAL DYNAMIC MICROPHONE
The Shure SM58£is a unidirectional (cardioid) dynamic vo-
cal microphone designed for professonal vocal use in sound re-
inforcement and studio recording. A highly effective, built-in,
spherical filter minimizes wind and breath “pop” noise. A car-
dioid pickup pattern isolates the main sound source while mini-
mizing unwanted background noise. The SM58 has a tailored
vocal response for a sound which is a world standard. Rugged
construction, a proven shock mount system, and a steel mesh
grille ensure that even with rough handling, the SM58 will per-
form consistently. Outdoors or indoors, singing or speech—the
SM58 is the overwhelming choice of professionals worldwide.
Features
SFrequency response tailored for vocals, with brightened
midrange and bass rolloff
SUniform cardioid pickup pattern isolates the main sound
source and minimizes background noise
SPneumatic shock-mount system cuts down handling noise
SEffective, built-in spherical wind and pop filter
SSupplied with break-resistant stand adapter which rotates 180_
SLegendary Shure quality, ruggedness, and reliability
Variations
SM58
SM58S (With On/Off Switch)
PROXIMITY EFFECT
When the sound source is less than 6 mm (1/4in.) from the
microphone, the microphone boosts bass frequencies (by 6 to
10 dB at 100 Hz), creating a warmer and richer bass sound
than when farther away. This effect, known as proximity effect,
happens only in unidirectional dynamic microphones like the
SM58. The SM58 low-frequency roll-off provides greater con-
trol, allowing the user to take full advantage of proximity effect.
APPLICATIONS AND PLACEMENT
The SM58 is ideal for close-up vocals and can be held in the
hand or mounted on a stand. Some of the most common applica-
tions and placement techniques are listed in the following table.
Keep in mind that microphone technique is largely a matter of
personal taste—there is no one “correct” microphone position.
APPLICATION SUGGESTED MICROPHONE
PLACEMENT
TONE QUALITY
Lead &
Backup
Vocals
Lips less than 150 mm (6 in.)
away or touching the wind-
screen, on axis to microphone.
Robust sound,
emphasized
bass, maximum
isolation from oth-
er sources.
Speech 150 mm (6 in.) to .6 m (2 ft)
away from mouth, just above
nose height.
Natural sound,
reduced bass.
200 mm (8 in.) to .6 m (2 ft)
away from mouth, slightly off
to one side.
Natural sound,
reduced bass
and minimal “s”
sounds.
1 m (3 ft) to 2 m (6 ft) away. Thinner; distant
sound;
ambience.
STAGE MONITOR & P.A. LOUDSPEAKER PLACEMENT
Place the stage monitor directly behind the microphone (see
Figure 1). Locate the P.A. loudspeakers so that they point away
from the rear of the microphone. With the speakers located in
these positions, the possibility of feedback is greatly reduced.
Always check the stage setup before a performance to ensure
optimum placement of microphone and monitors.
180q
90q
0q
90q
STAGE
MONITOR
P.A.
LOUDSPEAKERS
MICROPHONE SOUND
SOURCE
RECOMMENDED LOUDSPEAKER PLACEMENT
FIGURE 1
GENERAL RULES FOR MICROPHONE USE
1. Aim the microphone toward the desired sound source and
away from unwanted sources.
2. Locate the microphone as close as practical to the desired
sound source.
3. Work close to the microphone for extra bass response.
4. Use only one microphone per sound source.
5. Locate microphones at least three times as far from other
microphones as from the sound source.
6. Use as few microphones as practical.
7. Place microphones far from sound-reflecting surfaces.
8. Add a windscreen when using the microphone outdoors, for
closeup speech, or vocals.
9. Avoid excessive handling to minimize mechanical noise.
Model SM58£User Guide
27A2902 (Rev. 1)
E2003, Shure Incorporated Printed in U.S.A.

2
SPECIFICATIONS
Type
Dynamic (moving coil)
Frequency Response
50 to 15,000 Hz (see Figure 2)
TYPICAL FREQUENCY RESPONSE
FIGURE 2
Polar Pattern
Unidirectional (cardioid), rotationally symmetrical about mi-
crophone axis, uniform with frequency (see Figure 3)
TYPICAL POLAR PATTERNS
FIGURE 3
Sensitivity (at 1,000 Hz Open Circuit Voltage)
–54.5 dBV/Pa (1.85 mV)
1 Pa = 94 dB SPL
Impedance
Rated impedance is 150 W(300 Wactual) for connection to
microphone inputs rated low impedance
Polarity
Positive pressure on diaphragm produces positive voltage on
pin 2 with respect to pin 3
Internal Connections (Figure 4)
CARTRIDGE
CODED TERMINAL
TRANSFORMER
GREEN
YELLOW
BLUE
RED BLACK
1
2
3
SWITCH (SM58S ONLY)
GREEN
YELLOW
INTERNAL CONNECTIONS
FIGURE 4
Connector
Three-pin professional audio connector (male XLR type)
Case
Dark gray, enamel-painted, die cast metal; matte-finished,
silver colored, spherical steel mesh grille
Overall Dimensions (Figure 5)
51 mm
(2 in.)
162 mm
(6 3/8in.)
23 mm
(29/32in.)
OVERALL DIMENSIONS
FIGURE 5
Swivel Adapter
Positive-action, break-resistant, adjustable through 180q,
with standard 5/8in.–27 thread
Net Weight
298 grams (10.5 oz)
CERTIFICATION
Eligible to bear CE Marking. Conforms to European EMC Di-
rective 89/336/EEC. Meets applicable tests and performance
criteria in European Standard EN55103 (1996) parts 1 and 2,
for residential (E1) and light industrial (E2) environments.
FURNISHED ACCESSORIES
Swivel Stand Adapter A25D. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Bag 26A13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPTIONAL ACCESSORIES
Windscreen A58WS Series (8 colors available)
. . . . . . . . . . .
Desk Stand S37A, S39A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Isolation Mount A55M. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dual Mount A26M. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cable (7.6 m [25 ft] C25E, C25F. . . . . . . . . . . . . . . . . . . . . . .
REPLACEMENT PARTS
Cartridge R59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen and Grille Assembly RK143G. . . . . . . . . . . . . . . . . .
For additional service or parts information, please contact
Shure’s Service department at 1-800-516-2525. Outside the
United States, please contact your authorized Shure Service
Center.
