Shuttle’s next generation, high performance platform promise to revolutionize the way you work, live and play. Delivering
the very latest in high performance computing, the Shuttle SX38P2 Pro features the latest high-end Intel® X38 Express
Chipset, with optimized system memory capabilities, chipset over-speed protection removed for maximum over-clocking
and Intel® Turbo Memory Technology, providing faster boot and application load times and additional power savings.
With the latest PCI-Express Gen 2.0 interface supporting ATi CrossFire™ and DirectX® 10 delivering the most hardcore
gaming platform with awesome performance, stunning visual effects and breathtaking HD audio effects brought to you
by 7.1 channel Dolby® Digital Live! and DTS™ Connect.
SX38P2 Pro also provides an added layer of security with the integrated biometric Fingerprint Recognition Technology
ensures your personal documents and information are kept safe. In addition, data sharing is much faster and more
convenient than before with e-SATA and innovative USB Speed-Link feature, which easily connects and shares data
between 2 PCs.
SX38P2 Pro
Specification
* The specifications and pictures might varies or change without prior notice.
* All brand names and products are registered trademarks of their respective companies.
Revolution of Hardcore Platform
SX38P2 Pro
Intel® X38 Express Chipset
Optimized system memory capabilities, chipset over-speed
protection removed for maximum over-clocking performance
and Intel® Turbo Memory for improved system responsive-
ness, faster application loading and concurrent
performance enhancement. The high-end Intel®
X38 Express Chipset supports the latest Intel®
Extreme Tuning Utility, an integrated over-
clocking feature within the chipset providing fine
tuning.
PCI-Express Gen 2.0 with ATi CrossFire™ Technology
Experience the most hardcore gaming platform
featuring PCI-Express Gen 2.0, the latest
architecture providing twice the bandwidth of
current PCI-Express. Be amazed by the stunning
graphics performance and ultimate visual experience
presented by ATi CrossFire™ Technology.
OASIS Cooling Technology
The newly designed OASIS Cooling Technology delivers
a specially designed heat-sink covering the
North Bridge, South Bridge and
MOSFET modules effectively
dissipate heat without the
use for fans. Featuring all-new
heat pipe designs, Shuttle OASIS
allows users to enjoy longer component
lifetime through lower temperatures and
added system stability all in a silent operational environment.
Dynamic Over-clocking Technology
User friendly Dynamic Over-clocking feature
enabling an easy way to over-clock your system
to BIOS presets (3%, 5%, 7% and 10%). For
more advanced users wanting more options additional voltage
and frequency settings are available including the tuning of
FSB, NB core, SB core and PCI-E.
Advanced Security for Your Digital Information
Add a layer of security protection through the
integrated biometric fingerprint reader, you can
keep your digital identity and data more secure, no
more worries for memorizing multiple passwords for different
usage.
All Solid Capacitors Motherboard Design
All solid capacitors design is the new
trend for Shuttle's motherboard and
guaranteed to deliver maximum stability,
reliability and longer system lifetime for
the ultimate PC gaming and entertain-
ment experience.
80 PLUS® Certified Power Supply
The 80 PLUS® performance specification is a
standard which requires power supplies in
computers and servers to be 80% or greater
energy-efficient. This makes an 80 PLUS®
certified power supply at least 33% more efficient than current
power supplies.
FORM FACTOR
• Shuttle Form Factor 325(L)x210(W)x220(H)mm
• Shuttle “P2” chassis
PROCESSOR
• Intel® Core™ 2 Quad / Core™ 2 Duo /
Core™ 2 Duo E4000 Series / Dual-Core
E2000 series, Celeron 400 series Processor
• 800/1066/1333 MHz FSB
• LGA775 package
CHIPSET
• North Bridge Intel® X38
• South Bridge ICH9R
MEMORY
• 4 x DDR2 667/800 (OC to 1066MHz)
• Supports Dual channel 2GB per DIMM (Max 8GB)
AUDIO
• Realtek ALC888DD
• Supports Analog 7.1 channel output
• Supports Digital S/PDIF in/out
• Support Dolby Digital Live! and DTS
ETHERNET
• Marvell 88E8056 (PCI-E Interface)
• IEEE 802.3u 1000Base-T compliant
• 10Mb/s, 100Mb/s and 1000Mb/s operation
• Supports Wake-On-LAN
STORGE INTERFACE
• 1* UltraDMA 100 IDE channel connector
• 4* On board SATA 3.0Gb/s connectors
• 2* eSATA connectors in back panel
• 1* Floppy connector
• NCQ support
POWER
• 400W ATX Power supply
• Input 100 - 240V AC
• 80 PLUS certified
• Power Plug region specific
OVERCLOCKING
• CPU Frequency, CPU Voltage,
RAM Frequency ,RAM Voltage
• Dynamic Over-clocking
• PCI-E Frequency, Voltage
EXPANSION BAY
• 3* 3.5” bay
• 1* 5.25” bay
FRONT PANEL
• 2* USB 2.0 ports
• 1* mini IEEE1394
• 1* Mic in
• 1* Earphone out
• 1* Power-on button
• 1* Reset button
• 1* Power indicator - blue
• 1* HDD indicator - orange
• 1* Speed Link button
• 1* Fingerprint Recognition
BACK PANEL
• 2* PCI Express x16 slot
• 6* USB 2.0 ports
• 1* RJ45 Gigabit Ethernet port
• 1* Audio Line in connector
• 1* Audio Front out connector
• 1* Audio Rear surround connector
• 1* Audio Side surround connector
• 1* Audio Center/Bass connector
• 1* SPDIF In / Out port
• 1* Coaxial Out port
• 2* e-SATA connectors
• 1* IEEE 1394 port
• 1* Clear CMOS button
• 1* Wireless Antenna fixture
ACCESSORIES
• XPC Multilanguage Quick User Guide
• XPC CD Driver (XP/Vista 32bit, Fingerprint
recognition))
• 1* Bonus CD(PC-cillin 2007,Adobe Reader 8.1)
• 1* Power cord
• 1* IDE cable (pre-install)
• 2* SATA cables (pre-install)
• 1* Floppy cable
• Screws
• Heat sink Compound
