Sicce SyncraSDC 6.0 User manual

7.0
9.0
6.0
INSTRUCTION MANUAL
EN · IT · DE · FR · ES · NL · PT · RU

SYNCRA SDC · 6.0 · 7.0 · 9.0
•Check the distance between the device and the wireless router (Wi-Fi network). A long
distance may weaken the signal strength and take a long time to record the device, in worst
scenario the installation may fail.
•To check the Wi-Fi connection, make sure that the Wi-Fi icon is on
•The device only supports 2.4 GHz Wi-Fi networks. To check the frequency of your network,
you need to contact your internet service provider or refer to your wireless router manual.
•SICCE Srl is not responsible for any problems relating to the network connection or for
failures, malfunctions or errors caused by the network connection.
•In case connecting the device to the Wi-Fi network does not succeed, it is possible that the
device is too far from the router. Buy a repeater (range extender) to increase the intensity of
the Wi-Fi signal.
•The Wi-Fi connection may not occur or be interrupted due to the environment of the home
network.
•The network connection may not work properly depending on the Internet service provider.
•The surrounding wireless environment may slow down the wireless network service.
•The device cannot be registered due to problems with wireless signal transmission.Disconnect
the device and wait for about a minute before trying again.
•If the firewall on the wireless router is active, disable it or add an exception.
•The name of the wireless network (SSID) should be a combination of English letters and
numbers. (do not use special characters).
•The smartphone user interface (IU) may vary depending on the operating system (OS), the
manufacturer or following updates to the App CONTRALL or the operating system itself.
•If the router security protocol is set to WEP, it may not be possible to set up the network.
Change the protocol (WPA2 is the recommended one) and register again the product.
CHECK LIST BEFORE USING CONTRALL APP
INSTRUCTION MANUAL

SYNCRA SDC · 6.0 · 7.0 · 9.0
SEAL AND SIGNATURE OF RESALE DEALER
TIMBRO E FIRMA DEL RIVENDITORE
STEMPEL UND UNTERSCHRIFT DES VERKAUFERS
CACHET ET SIGNATURE DU REVENDEUR
SELLO Y FIRMA DEL REVENDEDOR
STEMPEL EN HANDTEKENING VAN DE DEALER
CARIMBO E ASSINATURA DO REVENDEDOR
ПЕЧАТЬ И ПОДПИСЬ ДИЛЕРА
DATE OF PURCHASE
DATA DI VENDITA
VERKAUFSDATUM
DATE DE VENTE
FECHA DE VENTA
DATUM VAN AANKOOP
DATA DE VENDA
ДАТА ПРОДАЖИ
____ / ____ / ____
day month year
WARRANTY
WARRANTY
GARANZIA
GARANTIE
GARANTIA
GARANTIED
GARANTIA
GARANTI
ГАРАНТИЯ
INSTRUCTION MANUAL

SYNCRA SDC · 6.0 · 7.0 · 9.0
ITALIANO
DEUTSCH
FRANÇAIS
ESPAÑOL
NEDERLANDS
PORTUGUÊS
РУССКИЙ
ENGLISH
INSTRUCTION MANUAL

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0
INDEX
SAFETY INSTRUCTIONS
COMPONENTS
SPARE PARTS
PUMP INSTALLATION: USE AND REGULATION
IN LINE APPLICATIONS
CONTROLLER USE AND PUMPS REGULATION
WI-FI SET UP
MAINTENANCE
SPECIAL MAINTENANCE AND REPLACING GROUP ROTOR
KEY FEATURES
LOSS OF WI-FI CONNECTION AND CONTROLLER RESET
CONTROLL APP AND ALERTS SYSTEM
CONTRALL APP INFOS
VOICE COMMANDS
ONLINE HELP
INSTRUCTIONS FOR THE CORRECT DISCHARGE OF THE PRODUCT ACCORDING TO EU DIRECTIVE 2002/96/EC
WARRANTY
DEEP Cleaning & TIPS FOR A LONGER LASTING

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
KEY FEATURES
Dear Customer, thank you for choosing the new pump SYNCRA SDC. By purchasing this new generation of SYNCRA Silent pumps you will benefit from a high-
tech and cutting-edge product. The pumps are speed control and can be set up with the use of the controller included. Furthermore by using your domestic
Wi-Fi network you can download the new SICCE App: CONTRALL and manage the pump with your smarthphone ( Android system or iOS). The SYNCRA SDC
pumps offer a guarantee of a complete and efficient managment, without limits of time and space. Directly from your smartphone, wherever you are, you can
control and monitor your system in a simple and immediate way. SYNCRA SDC and CONTRALL App: our future is energy saving and environmental protection.

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
SYNCRA SDC is made in conformity with the national and international safety standard
regulation.
1) Always isolate the pump from the mains electricity before installing or carrying out any
maintenance. Power to the pump must be supplied through a Residual Current Device (RCD)
with a rated residual operating current not exceeding 30mA.
2) The pump can work submerged or inline out of water. (impeller must always run wet)
3) Before connecting the pump to the electricity supply, check there is no damage to the cord
or plug.
4) The pump has a type Z cable link. The cable and the plug cannot be substituted or repaired;
in case of damage to the cable, the entire pump must be replaced.
5) ATTENTION: do not operate any Appliance if it has a damaged cord or plug, if it is
malfunctioning, or if it has been dropped or damaged in any way.
6) The pump must not work without water to avoid damages to the motor.
7) The pump can be used in liquids or in environment with a temperature not higher than 35
°C / 95 °F.
8) Do not use the pump for uses different to those for which it has been projected as, i.e. in
bathroom or similar Applications.
9) Avoid using the pump with corrosive and abrasive liquids.
10) This pump requires adult supervision.
11) To avoid that accidental drips wet the plug or the socket, make a loop with the cord under
the socket level (Pic. A).
12) To prevent any damage , avoid to take the pump by the cord during the installation or
maintenance.
13) The pump can be used only in the above mentioned Applications and it is only for internal
use, when the cable’s lenght is shorter than 10mt or 10”.
14) If the pump or the filter is supplied with a cable 10 meters long, or more than 6 feet long
for the American type (USA), these Appliances are intended for outdoor use as required by
international standards.
A
OUTDOOR USE
(10 m · 20 ft cable)
SAFETY INSTRUCTIONS

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
COMPONENTS
SYNCRA SDC pumps are designed favoring the almost total dismantling of their components, to
facilitate proper use and maintenance and ensure a long life. Below is the list of the individual
parts and spare parts (Pic.B):
1. Motor body completely submersible and insulated by epoxy resin;
2. Rotor Kit with Impeller and bottom bearing
3. Bottom Bearing ( Hook - accessory)
4. O-Ring
5. Anti-vibration Rubber Feet
6. Turning Pre-Chamber
7. Pre-filter Grid
8. Threaded Hose fittings
9. Remote control Controller with “T” cable
10. AC-DC power adaptor with LED light
11. Connector cable “T”
TECHNICAL DATA 6.0 (24 V) 7.0 (24 V) 9.0 (24 V)
Switching
power supply
INPUT:
100-240V
50/60Hz
OUTPUT:
24V DC
Q min - max 2000 - 5500 l/h 3000 - 7000 l/h 4000 - 9000 l/h
530 - 1450 US gph 800 - 1900 US gph 1000 - 2500 US gph
H min - max 1,0 - 3,5 m 2,0 - 5,0 m 2,6 - 7,0 m
3.5 - 11.5 ft 6.5 - 16.5 ft 8.5 - 23.0 ft
Watt min - max 10 - 40 W 20 - 65 W 30 - 95 W
Cable length 3,0 m +
10.0 ft +
1
2
3
4
5
6
7
8
8
External diameter 25mm
(1”) for flexible pipeinternal
diameter 25mm (1”)
External diameter 32mm (1” ¼)
for flexible pipe internal diameter
32mm (1” ¼)
Male threaded 1” GAS
Female threaded ring 1” ³⁄8GAS
Inlet grid with female
threaded 1” ³⁄8GAS
Male threaded 1” ³⁄8GAS
Male threaded 1” ³⁄8GAS
Female connector 1” GAS
Rigid pipe connector. External
diameter 25/26,5mm (1”)
Rigid pipe connector. External
diameter 32/33,5mm (1” ¼)
9
10
11
B

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
SPARE PARTS 6.0 7.0 9.0
Rotor + ceramic shaft + O-ring ASGR0222 SGR0218 SGR0217
Bottom bearing + hook BSVE0054 SVE0052
Hook B1SPL0024
O-ring for prechamber and rotor CSVE0055 SVE0053
Prechamber with closing ring DSPL0097 SPL0095
Anti-vibration silicon feet ESVE0033 (4 pcs.)
Hose fittings for rigid and flexible pipes FSTR0029
Protective grid GSPL0094
Controller HSKT0207
AC/DC power adaptor (EU) ISKT0216 SKT0208
AC/DC power adaptor (US) JSKT0217 SKT0209
AC/DC power adaptor (UK) KSKT0218 SKT0210
AC/DC power adaptor (AU) LSKT0219 SKT0211
B1
B
C
E
D
GF
F
H
I
J
K
L
A
SPARE PARTS
B

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
SYNCRA SDC can be remotely set up by using the controller or by
downloading the new SICCE CONTRALL App.( iOS-Android)
For the physical installation of the pump it is necessary to proceed
as follows:
- Unwind the power cord of the pump in an area where it will not be
damaged in any way.
- Join the connector of the pump’s cable to the special T joint of the
controller’s cable. On the other side of the “T” join the power supply
connector. Connect first the power supply cord to the transformer
and then to the power outlet. The transformer is universal and works
with all voltages and frequencies.
The pump is now powered but not active.
The controller must be positioned away from spray and moisture and
where it can not accidentally fall into the water.
The Controller can be attached to the wall or aquarium cabinet using
the included bioadhesive or screws.
- Connect the fitting to the pump’ s outlet to which you can then
connect the flexible or rigid pipe of the Appropriate diameter.
- Place the pump in an easily accessible area for the maintenance
operations.
- If the pump is used submersed and not in line, it must be always
fully submersed. (Pic. 1)
1
PUMP INSTALLATION:
USE AND REGULATION

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
It is recommended to place the pump in spaces where there is
a proper ventilation and the pump is not directly exposed to heat
sources.
Place the pump so as to prevent too long idraulic pipings, which
would reduce its performance.
Do not position the pump above the water level (Pic.2) because it
is not self-priming and the risk of the pump to run dry. The risk of
invisible air bubbles creating a vacuum area is very high. Damages
which are caused by the pump running dry are excluded from
warranty.
To maximize the pump’s efficiency, choose a straight inlet tube
without elbows. (Pic.3)
We suggest an Inlet and outlet tubes with diameter equal or bigger
than the diameter of the threaded pipe included. (Pic.4)
Do not use the pump leaving the outlet totally closed. A minimum
water flow is necessary to keep the inner motor cool without running
dry (Pic.5)
IN LINE
2 3
4 5
IN LINE APPLICATIONS

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
For the periodic maintenance of the pump, unplug the pump from the
electric socket and then remove the pump from water.
1) Lift the plastic ring of the pump’s volute pulling the tab outwards
(Pic.6)
2) Remove the ring (Pic.7)
3) Remove the volute of the pump by turning and simultaneously
pulling forward (in the case of fouling this may take more pressure).
4) Pull out the complete rotor set (Pic.8)
5) Rinse each part with water, using a soft brush to remove the
deposit.
6) Then assemble everything in the inverse order.
6 7
8
O-RING 2
O-RING 1
MAINTENANCE

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
7) Put the ring in place with the biggest teeth facing the pump and
close it by pressing on the tab until you hear a “click”. (Pic.9)
Any damage to the o-rings, even small, can seriously endanger the
pump performance. In this case, it is best to replace them.
IMPORTANT: The build-in circuit board of the pump has been
programmed to provide 3 levels of protection:
Protection against rotor’s blockage: In case of malfunction which
causes the lock of the rotor (due to excessive dirt or other) or of
operating without water, the pump, will initiate 10 startup attempts
to turn the pump on correctly. If after 10 attempts this does not
happen, the pump will stop automatically and remain in standby. The
controller will remain powered, but the engine will shut down. In this
case to restart the pump you need to disconnect the plug for about
30 seconds and re-insert it into the power socket.
Dry running protection: motor’s protection in case of functioning
without water. The pump stops when it works without water, or if
there is a locked rotor. When the pump is taken out from the water,
the motor stops.
- Thermal protection: when the buil-in electronic board detects a
temperature increase outside the working parameters of the pump,
it turn the pump off to avoid damage to components or to the motor.
ATTENTION: do not underestimate the power of the magnet. If you
slightly loose the grip and the axis hits the rear bearing, the risk to
damage the bearing is very high. A damage axis and bearing causes
high reparation costs.
ROTATING PRECHAMBER
9
BIG TEETH
BEHIND
CLICK

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
Follow this instruction for an accurate rotor kit cleaning or replacing
Repeat the opening actions as indicate in Maintenance’ section,
steps 1,2,3,4.
To easily remove the bottom bearing, we suggest to leave the pump
submersed with water and Pump Clean for a while to make soften
debris or limestone.
- Insert the hook ( accessory) inside the tube of the pump. (Pic 10)
- Hook the bearing and pull it out
-Clean the bearing under running water (never use soap or detergent
of any kind because they pollute the aquarium water: we recommend
using a vinegar and water solution) possibly using a soft brush to
remove scale deposits. If it is heavily worn we suggest to replaces it
with a new one.
-Re-insert the bearing sleeve in the pump ( Pic.10) after wetting and
push it all the way.
10
1
2
RIGHT SIDE
SPECIAL MAINTENANCE AND REPLACING GROUP ROTOR

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
By connecting the power supply to the controller, all the LEDs light
up once. After about 20 seconds the Wi-Fi symbol will start to flash
slowly to indicate that it is ready and awaiting the set-up. After the
configuration, once connected to the Wi-Fi network, the led will make
5 rapid flashes every 5 seconds. If the controller has already been
set-up, once powered, the Wi-Fi automatically reconnects to the
network and reloads the programs set in the CONTRALL App.
To activate the pump, keep the right key (+) pressed for 3 seconds.
The pump starts at 50% of the operating range. Pressing the keys
(+) and ( -) it is possible to increase or decrease the pump flow.
Consequently, the luminous intensity of the 5 LEDs will vary. The
pump symbol will light up in the color set via the CONTRALL App.
The Wi-Fi symbol will flash blue slowly while waiting to be connected
to the Wi-Fi network via the CONTRALL App. If the pump is managed
via CONTRALL, it will not be possible to modify its operation using the
controller. It will only be possible to switch it off by keeping the right
key (+) pressed for 3 seconds.
The Controller supplied can only regulate the flow. It can only be
powered with the included transformer and manages only the
supplied pump. Any other use could irreparably damage the device
and void the warranty.
SPEED LED
NEW SDC SMART CONTROLLER
CUSTOM COLOR
PUMP’S ID
WI-FI
SPEED DOWN
SPEED UP /
ON - OFF
CONTROLLER USE AND PUMPS REGULATION

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
CONTRALL App Free download
Select MY DEVICES and tab on +
Choose these SYNCRA SDC
Read the text and then Confirm PROCEED.
Next: select the WIFI network you wish to link the pump and the WIFI psw.
Give a name to your pump and confirm with DONE.
It may take few seconds before the connection is active
Faster Set-Up with New configuration system
WI-FI SET UP

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
Voice commands can be activated via Siri - Google assistant - Alexa
- POWER ON
- SHUTDOWN
- TEMPERATURE CONTROL
- READING OF THE ALERT IN CASE IT IS ACTIVATED
- PRESET CHANGE OF FLOW AND PUMP POWER - (REDUCE 10% / INCREASE 10%)
COMPATIBLE WITH:
- Apple Watch (iOS)
- Smartwatch (Android)
VOICE COMMANDS
In case Wi-Fi connection is lost, the pump will continue working and the user will receive a notification via email if this warning has been activated in the App
CONTRALL.The connection will be restored automatically as soon as the wireless network is available again.
WIFI AND CONTROLLER RESET
Remove power from the controller.Press and hold down the “+” and “-” buttons at the same time and re-power the controller. Keep them pressed until the
Wi-FiI LED flashes quickly. Release the buttons. After about 20 seconds the Wi-Fi symbol will start blinking slowly to indicate that it is ready and waiting for
configuration.
LOSS OF WI-FI CONNECTION AND CONTROLLER RESET

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
Notifications in real-time with a complete alert system can be activated in CONTRALL App profile session. Alerts in real time will be sent in case of:
- Aquarium temperature outside of the custom set range
- Blocked Rotor protection
- Dry running protection
- Loss of Wi-Fi signal
CONTROLL APP AND ALERTS SYSTEM
Periodic updates of the App are recommended in order to take advantage of any improvements to the service and the Application itself.
INITIAL SCREEN
MY DEVICES: these are the single devices registered and manageable individually
MY SMART SYSTEMS: it is possible to group together a series of individual devices, for example 2 XSTREAM SDC pumps, a SYNCRA SDC pump and a pump
for skimmer PSK SDC and create a system to which to assign a distinctive name. In case you want to manage multiple aquariums, this function allows you to
control them more immediately and efficiently. It will be possible to switch off and switch on all devices by pressing a single button and schedule FEED TIME.
NOTIFICATIONS: in this session the received notifications will be automatically recorded.
PROFILE: within this session it is recommended to activate the NOTIFICATIONS, to adapt the units of measurement to the country system, to give consent to
the newsletter to receive updates and communications, to select the desired language.
CONTRALL APP INFOS

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
It’s important to keep your SICCE Pump in prime operating condition
to ensure long-life and efficient operation. Over time, natural mineral
deposits will form in the filter surface and rotor, and if untreated, may
cause undesirable operation or even failure. SICCE PUMP CLEAN is
a super-concentrated, yet completely safe solution to remove these
deposits and keep your filter in tip-top shape.
DEEP CLEANING
& TIPS FOR LONGER LASTING
USE SICCE PUMP CLEAN
TIPS
In case, after a first installation, the pump will not be used for over
one week, we recommend to take the rotor assembly out of the pump,
cleaning it thoroughly and store pump and rotor separately.
The limestone deposits and the natural wear-out of the components
might cause a raise of the pump’s noise. However, they do not affect
the good functioning of the pump. In this case, we recommend you
to replace the impeller.

INSTRUCTION MANUAL · ENSYNCRA SDC · 6.0 · 7.0 · 9.0 INDEX
Watch our tutorial videos on THE SICCE YOU TUBE official channel
www.youtube.com/SICCEspa
When used or broken, the product does not have to be discharged with the other waste. It can be delivered to the specific electric waste collection centers
or to dealers who give this service. Discharge separately an electric tool avoid negative consequences for the environment and for the Health and allows to
regenerate the materials so to have a great saving of energy and resources.
ONLINE HELP
INSTRUCTIONS FOR THE CORRECT DISCHARGE OF THE
PRODUCT ACCORDING TO EU DIRECTIVE 2002/96/EC
