SICK TiM31x User manual

8018590/YK97/2015-04-27 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com TIM31X/TIM32X | SICK 1
TiM31x
TiM32x
Intended use
The laser scanner TiM31x/TiM32x (referred to as the TiM
below) is an intelligent sensor for invisibly detecting objects
in areas (elds) to be monitored. It is designed for mobile
or stationary interior use in stand-alone operation, with a
scanning range of up to 4 m. The combined triggering of the
four switching inputs activates one of the 16 eld sets as an
evaluation case for performing eld monitoring.
With the TiM31x, each congurable eld set offers three
origin-oriented, partially overlapping elds of uniform shape,
but different sizes. Field sets with xed or freely denable
shapes are available.
With the TiM32x each eld set provides three congurable
elds.
The TiM signals detected eld infringements in relation to the
three elds through a combination of three switching outputs.
The TiM is available in both a PNP and an NPN variant. The
NPN variant is identied by S02 in the type code on the type
label.
The purpose of this instruction manual is to allow you to put
the TiM into operation quickly and easily using precongured
eld sets and to obtain the rst detection results.
Further information on the mechanical and electrical
installa-tion is available in the &Technical Information
(no. 8014318).
This document can be accessed on the TiM product website
(www.mysick.com/en/tim3xx).
The TiM is certied to IEC/EN/UL/CSA 61010-1:2007. These
operating instructions may contain passages of text in a
foreign language.
Safety information
• Read these instructions before commissioning the TiM
in order to familiarize yourself with the device and its
functions.
• Mounting and electrical installation are to be performed
only by qualied technicians.
• Electrical connections between the TiM and other devices
may only be made when there is no power to the system.
Otherwise, the devices may be damaged.
• Select and design conductor cross sections of the supply
cable from the customer's power system in accordance
with the applicable standards. If the supply voltage for the
TiM is not fed via the optional CDB730-001 connection
module, protect the TiM with an external 0.8 A delay-action
fuse at the start of the supply cable.
• All circuits connected to the TiM must be designed SELV
or PELV circuits. (SELV = Safety Extra Low Voltage, PELV =
Protective Extra Low Voltage).
• Use the device only under permitted environmental condi-
tions (e.g. temperature, grounding potential,
see "Technical specications Page 5").
• Protect the TiM against moisture and dust when the cover
to the USB socket is open. To comply with the IP 65 enclo-
sure rating during operation, the black rubber plate must
be ush-mounted on the housing.
• Opening the screws of the TiM housing will invalidate any
warranty claims against SICK AG.
• The TiM does not constitute personal protection
equipment in accordance with the respective applicable
safety standards for machines.
Commissioning and conguration
Step 1: Electrical installation
1. Connect the 15-pin D-sub-HD connecting cable plug
with the corresponding socket of the connection modul
CDB730-001.
– or –
Connect the 12-pin M12 connecting cable plug to a
customer-side connection box. To do this, make a connec-
tion box with a 12-pin M12 socket. The box serves as the
connection module for feeding the supply voltage, and for
the signal routing of the switching inputs and outputs (
see "Electrical Installation" chapter in the &Technical
Information (no. 8014318)).
2. Connect the TiM's Micro USB socket (behind the black rub-
ber plate on the side) to a free USB socket (type A) on the
PC using a suitable shielded high-speed USB cable (e.g.
no. 6036106, 2 m). Do not extend the cable!
3. Supply power to the TiM.
Using the power supply unit it must be ensured that
the supply voltage does not drop below 8 V for longer
than 2 ms and never rises above 30 V.
Following successful initialization, the green LED lights up
"
▸" (device ready for operation).
Do not supply the switching inputs with current yet.
Connection module
CDB730-001
12
DC 9 ... 28
V
GND
...
... SOPASSOPAS
“Power/I/O”
“USB 2.0”
Configuration
Field monitoring
Diagnosis
TiM
USBUSB
OUT 1 OUT 2 OUT 3 OUT 4
Electrical block diagram for commissioning the TiM with a 15-pin D-Sub-
HD cable plug.
SOPASSOPAS
“Power/I/O”
“USB 2.0”
Configuration
Field monitoring
Diagnosis
TiM
Connection
box
USBUSB
DC 9 ... 28 V
...
IN 1 IN 4
OUT 1 OUT 3
customer-
provided
OUT 2
delay-
action
fuse
0,8A/T
Electrical block diagram for commissioning the TiM with a 12-pin M12
cable plug.
TiMxS02
IN
9 ... 28 V
SOPASSOPAS
„Power/I/O“
„USB 2.0“
USBUSB
DC 9 ... 28 V
...
IN 1 IN 4
OUT 1 OUT 3
OUT 2
delay-
action
fuse
0,8A/T
Configuration
Field monitoring
Diagnosis
customer-
provided
Connection
box
Electrical block diagram for commissioning the NPN variant with a 12-
pin M12 cable plug.
Step 2: Mounting and alignment
NOTE
During installation make sure there is no reective surface
behind the reference targetsee "Device overview Page
4", point â.
1. Optional: mount the TiM to separately ordered mounting
accessories (mounting kit 2), see "Mounting" Chapter in
the &Technical Information (no. 8014318).
2. Otherwise, mount the two straight plates from the
enclosed mounting kit 1 on the TiM using two M3 screws.
Use the two blind-hole threads either on the underside or
back of the housing (see "Device overview Page 4").
If the straight plates are not used, screw the screws
provided by the customer max. 2.8 mm into the thread.
3. Mount the TiM on a prepared bracket.
The device should be as free from vibration as possible
during operation.
4. Align the 90° axis of the TiM's scanning angle with the
center of the area to be monitored. The marking on the
lid of the optical hood serves as a bearing alignment aid
(see "Device overview Page 4").
0
Scanning range in m (feet)
4
(13.12)
4
(13.12)
6
(19.69)
6
(19.69)
2
(6.56)
2
(6.56)
Scanning range in m (feet)
2
(6.56)
4
(13.12)
2
(6.56)
4
(13.12)
6
(9.69)
6
(19.69)
0
Scanning range max. 4 m (13.12 feet)
Scanning range for objects up to
10 % remission 2 m (6.56 feet)
270°
90°
180°
0°
‒45°
225°
Range diagram for TiM
a. Conguration without PC
Here, the TiM provides two options:
• Using one of 16 default eld sets, each with 3 predened
elds having the same eld shape, but different sizes
• Teach-in of the surrounding contour to automatically
generate the outer eld with any shape, including more
complex shapes, and to deduce the two inner elds.
The eld sets are organized by groups into segmented eld
shapes. The shapes can be modied, with the default being a
rectangle. In the factory setting, the 3 origin-oriented elds of
Detecting Laser Scanner
Short Range
OPERATING INSTRUCTIONS
en

TIM31X/TIM32X | SICK 8018590/YK97/2015-04-27 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com2
a set overlap to some extent and form a triple.Dimensions of
the respective eld 1 and its shape in the factory settings, as
well as the required wiring of the switching inputs for eld set
selection see "Field set factory settings - switching inputs
Page 5".
Structure of the elds of a eld set and possible eld
shapes (TiM31x)
Semi-circle
Segmented,
free shape type
Rectangle
Field 1
Field 2
Field 3
0°180°
90°
The limits of the outer eld 3 and the middle eld 2 relate
to the limits of the inner eld 1. The relationship between
the limits is xed as a percentage for the eld sets 1 to 4;
the limits of eld 2 and eld 3 can be adjusted freely for the
eld sets 5 to 16 if needed, using the SOPAS conguration
software. The following rules apply: Field 1 may not be larger
than eld 2, and eld 2 may not be larger than eld 3; neither
may elds be congruent.
Structure of the elds of a eld set and possible eld
shapes (TiM32x)
Segmented,
free shape type
Rectangle
Field 1
Field 2
Field 3
0°180°
90°
Preparing for teach-in
In general, the function button and both LEDs on the device
are used for teach-in.
• Remove all objects that will not permanently be in the eld
of view in monitoring mode later on.
• Distance yourself sufciently from the TiM during the
advance warning phase of the teach-in, so that you are not
detected as part of the eld contour.
Teaching-in the eld contour
The TiM uses eld set 1 (segmented, initial shape: rectangle)
to adjust the eld shape and size to the surrounding contour
that was detected. The switching inputs may not be supplied
with current during this process.
The TiM forms the outer eld 3 from the surrounding contour
with a negative offset of 100 mm, and deduces
the limits of the two inner elds from this, so that eld
2 = eld 1 plus 25% and eld 3 = eld 1 plus 52%.
• The eld shape to be formed can be dened by pacing out
the limits during the teach-in phase. Do not wear black
clothing during this process!
>Start the eld contour teach-in.
3 seconds = flashes slowly
The behavior of the two LEDs indicates the progress of the
eld contour teach-in:
LED a
(red) LED b (green)
Status
–
Field contour teach-in – Start
LED ashes slowly (0.5 Hz)
Field contour teach-in – Advance warning phase
LED ashes increasingly rapidly within 15 s
OOField contour teach-in – Teach-in phase
60 seconds
–Field contour teach-in – Completion of advance
warning phase
LED ashes increasingly rapidly within 15 s
–OAutomatic return to monitoring mode
All elds free
OOMonitoring mode
In the event of eld infringement
O = illuminated;  = ashes
The TiM stores the new eld set 1 permanently.
b. Conguration with PC
The SOPAS conguration software is used by default to adjust
the 3 elds of a eld set and other TiM parameters to the ap-
plication and to perform diagnostics in the event of an error.
If the eld shape of the eld set 1 has been taught in without
a PC using the function button, SOPAS is generally used to
continue the conguration.
This includes setting the eld shapes/sizes and any other
non-teachable eld sets based on the default setting, the
response time of the elds, the blanking size, and the holding
time of the assigned switching outputs OUT 1 ... OUT 3.
The blanking size is the cross-section of the object after
which an object not previously in the viewing area of the TiM
leads to a eld infringement. Like the response time and the
holding time, the blanking size applies to all eld sets and
their elds.
Installing and launching the SOPAS conguration software
1. Download and install on the PC the software from the web-
site "www.mysick.com/en/SOPAS_ET", SOPAS ET software
type. In this case, select the "Complete" option as selected
by the installation wizard. Administrator rights may be
required on the PC to install the software.
2. Start the "Single Device" program option after completing
the installation.
Path: Start > Programs > SICK > SOPAS Engineering
Tool > SOPAS (Single Device).
SOPAS will automatically install the necessary USB driver
the rst time it detects a connected TiM. It may then be
necessary to restart the PC.
3. Establish a connection between SOPAS and TiM via the
automatically opened assistant. Select the TiM from the
list of available devices.
SOPAS program window (single device)
Field monitor display window
• In the Field monitor window, SOPAS displays the eld
contour (scan line) currently seen by the device through
ambient reection in blue. If the 4 switching inputs are
not supplied with current, SOPAS also displays the three
evaluation elds (segmented rectangles) for the eld set
1 according to the TiM's default setting, or the eld shape
generated using the teach-in function along with its dimen-
sions, the status of the switching inputs/outputs, and the
position of the mouse pointer.
• SOPAS displays the elds as green if no eld infringement
is present. If objects of a certain size and duration
(see "Default settings TiM Page 3") are
located in the part of the visual range that is covered by
elds, the TiM will recognize this as a eld infringement.
SOPAS displays this separately in yellow for the individual
elds.
>Try changing the orientation of the TiM in the room and ob-
serve the effects this has on detection in the eld monitor.
Click the reset button to cause SOPAS to reset the
switching output counters.
Continuing conguration (TiM31x)
Field editor display window

8018590/YK97/2015-04-27 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com TIM31X/TIM32X | SICK 3
accordingly using the switching inputs.
The blanking size is the cross-section of the object after
which an object not previously in the viewing area of the TiM
leads to a eld infringement.
Completing the conguration
>Permanently save the entire conguration:
Parameter set in: TiM click the button
Conguration le on the PC: click the button.
Default settings TiM
Parameter Value
Blanking size Cross-section 200 mm
Response time of the elds 335 ms (5 scans)
Holding time of the switching outputs 335 ms (5 scans)
Conguring the TiM
Shifting eld positions
1. Click the button.
2. Click on the green marking rectangle of the desired eld
position in the outer eld.
The color of the marking rectangle changes to blue.
3. Re-click the rectangle and drag it to the desired position,
then release the pushbutton. SOPAS controls the available
positioning area during shifting.
Inserting additional eld positions
1. Click the button.
2. Click on the desired position on the limits of the outer eld.
SOPAS inserts a new, green marking rectangle.
This can now also be shifted as already described.
Deleting eld positions
1. Click the button.
2. Click on the green marking rectangle of the eld position to
be deleted in the outer eld.
The color of the marking rectangle changes to red.
3. Re-click the marking rectangle.
SOPAS removes the marking rectangle and instead con-
nects the two nearest marking rectangles with a new line.
Rotating the eld pair around the central axis along with
the TiM
>In order to align the position of the eld pair in SOPAS to
the conditions on site from the user's perspective, enter
and conrm the desired angle of rotation in the 0.0° input
eld (negative sign "–" means turn right).
Some other useful functions
• button: Display the elds in the polar coordinate
system
• button: Change the view of the TiM/ elds from above
(TiM: black) to the view from below
(TiM: blue)
• or button: Switch off the display the full measur-
ing line or display a dotted measuring line.
Response time, blanking size and holding time
>Adjust the response time of the elds, the blanking size
of objects, and the holding time of the OUT 1 and OUT 2
switching outputs under settings on the right side of the
program window. All three values are valid for both elds
and switching outputs.
When selecting the response time, note that the TiM's
internal reaction time must also be added.
>To test the effects of the changed settings, click on the
Field evaluation monitor tab at the top.
If the changed elds have been transferred to the TiM as
described, SOPAS will also display these in the monitor,
displaying the infringed elds in yellow. If you wish to
observe another eld set, it must rst be activated
accordingly using the switching inputs. If you wish to
observe another eld set, it must rst be activated
1. To optimize the monitored elds of the eld sets used by
the TiM manually, click the Field editor tab at the top of
the program window.
2. Select the eld set 1, for example, under Field name on the
right of the window.
3. Adjust the settings for other functions such as response
times of the elds, blanking size and holding (duration)
time output under settings on the right of the program
window. When selecting the response time, note that the
tim also has its own internal response time.
4. To check the effects of the settings applied, click the Field
monitor tab at the top.
SOPAS displays the infringed elds in yellow in the eld
monitor for the eld set 1. If you wish to observe another
eld set, this must rst be activated accordingly using the
switching inputs.
Continuing the conguration (TiM32x)
Field editor display window
The user can change parameters in the right part of the
program window under settings & device status. SOPAS
immediately transfers these changes to the TiM32x
(default setting).
However, evaluation elds that have been changed in size
and shape must always be manually transferred to the
TiM32x using the button. All changed parameters are
only temporarily stored in the device for the time being and
are not stored in the computer at all.
In order to optimize the dimensions of the monitoring elds:
1. Click the evaluation Fields tab at the top of the program
window.
2. Under Field selection on the right side of the window,
select, for example, eld set 1.
3. Select the eld to be congured.
>You can optionally perform the following actions:

8018590/YK97/2015-04-27 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com TIM31X/TIM32X 4
Device description
Device overview
79 (3.11)
55.8 (2.19)
60 (2.36)
8 (0.31)
27.3 (1.08)
4.4 (0.17)
(0.76)
19.4*)
4
5
3
7
6
76.3 (3.0)*)
Ø 4.3
*)
(0.16)
68.8 (2.71)*)
51 (20)
68.8 (2.71)*)
38.3 (1.50)
Ø 4.3 (0.17)
*)
2
1
225°‒45°
180°0°
90°
á
à
19.4
(0.76)
51 (2.00)
0.5*)
98
ß
22
All measures of length in mm (inch)
*) measures including straight plates
60 (2.36)
(0.02)
Mounting kit 1
2 x
30° â
12 x straight plates with M3 x 4 mm screw (included in delivery)
2M3 threaded mounting hole, 2.8 mm deep (blind hole thread)
3Optical hood
4Receiving range (light inlet)
5Transmission range (light emission)
6 Red and green LED (status displays)
7Function button for teach-in
8 Connecting cable outlet 0.9 m with 15-pin D-Sub HD plug or
connecting cable 0.8 m with 12-pin M12-plug
('Power/Switching inputs/outputs' connection).
9 Micro USB socket, behind the black rubber plate
('Aux interface' connection for conguration with PC)
ßMarking for the position of the light emission level
à Bearing marking to support alignment (90° axis)
á 270° aperture angle (visual range)
â Area in which no reective surfaces are allowed for mounted
devices
Status indicators, functions
Status displays
LED a
(red) LED b (green)
Status
–ODevice ready/monitoring mode
OOField infringement
–Teach-in – Start
OOTeach-in – End of advance warning phase
60-second teach-in phase
–Teach-in – End of teach-in phase
–Error
– – Device without supply voltage
O = illuminated;  = ashes
aCAUTION
Laser radiation!
CLASS 1 LASER PRODUCT
The TiM corresponds to laser class 1 (eye-safe).
The laser beam is not visible to the human eye.
CAUTION – the use of controls, or adjustments or perfor-
mance of procedures other than those specied herein may
result in hazardous radiation exposure.
>Do not open the housing (opening the housing will not
switch off the laser).
>Pay attention to the laser safety regulations as per IEC 60
825-1 (latest version).
aMISE EN GARDE
Rayonnement laser !
APPAREIL À LASER DE CLASSE 1
Le TiM est conforme à la classe laser 1 (sécurité des yeux).
Le rayon laser n’est pas visible pour l’oeil humain.
PRUDENCE – tout usage de commandes, réglages ou toute
application de procédures autres que ceux décrits dans ce
document peut entraîner une exposition dangereuse au
rayonnement.
Attention – L’utilisation des commandes ou réglages ou
l’exécution des procédures autres que celles spéciées dans
les présentes exigences peuvent être la cause d’une exposi-
tion à un rayonnement dangereux.
>Ne pas ouvrir le boîtier. (La diode laser n’est pas désac-
tivée en cas d’ouverture du boîtier)
>Se conformer aux dernières consignes de protection en
date contre le rayonnement laser (IEC 60825-1).
Additional information see "Technical specications Page 5".

TIM31X/TIM32X | SICK 8018590/YK97/2015-04-27 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com5
Technical specications
Model Name TiM310-1030000 (part no. 1052627)
TiM310-1130000 (part no. 1056550)
TIM310-0130000S02 (part no. 1069932)
TIM310-1030000S02 (part no. 1062221)
TIM310-1130000S02 (part no. 1067917)
TiM320-1031000 (part no. 1063467)
TiM320-1131000 (part no. 1062219)
TiM320-0131000S02 (part no. 1069933)
TiM320-1131000S02 (part no. 1067919)
Scanning range Radial, aperture angle 270°
Scanning fre-
quency
15 Hz (15 scans/s)
Response time Typical 134 ms (2 scans)
Scanning range 0.05 m ... 4 m; typically 2 m at 10 % remission
Remission Typical 4 % ... > 1,000 % (reector)
Physical minimum
object size
(cross-section)
170 mm for a scanning range of 4 m,
85 mm for a scanning range of 2 m and 10 %
remission
Measuring error Statistical (1 s): 30 mm
Systematic: ± 40 mm
Temperature drift 0.5 mm/K
Ambient light
immunity
15,000 lx
Light source Laser diode, infrared (λ = 850 nm)
Device laser class Laser class 1 according to EN 60825-1:
2007-101), eye-safe
Field evaluation 1 evaluation case with 1 eld set (3 elds).
Signaling of eld infringements via a
combination of 3 switching outputs.
Number of eld
sets
TiM31x: 16 with 3 congurable elds each
TiM32x: 16 with 3 exible congurable elds
each
Aux interface USB 2.0, for conguration
Switching inputs PNP: 4 x IN (Ue = max. 28 V, Ie = max. 5 mA),
opto-decoupled, debouncing time approx.
10 ms
NPN: Common reference potential 9 ... 28 V
Switching outputs 4 x OUT (each Ia ≤ 100 mA), not galvanically
isolated from the supply voltage, short-circuit
protected/temperature protected
Congurable for OUT 1 .... OUT 3:
Response time (134 ms ... 30 s)
Holding time (0 ms ... 10 s)2)
Electrical
connections
1 x 0.9 m cable (+10 %) with 15-pin D-Sub-HD
plug
1 x 0.8 m cable (+10 %) with 12-pin M12 plug
1 x micro USB socket, type B (covered)
Function key Teach-in (eld set 1 eld contour)
Optical indicators 2 x LED
Supply voltage DC 9 ... 28 V, SELV and PELV according to
IEC 60364-4-41: 2005-12
Power
consumption
3 W (for unloaded switching outputs)
15 W (with four loaded switching outputs)
Housing Lower part: Die-cast aluminum
Optics hood: Polycarbonate with scratch-proof
coating
Weight Approx. 150 g without cables
Electrical safety According to EN 60950-1:2011-01
Protection class III according to EN 61140: 2006-08
IEC 61010-1:2011-07
Enclosure rating IP 65 (EN 60529: 1991-10/A2: 2000-02)
Assignment of infringed elds - switching outputs
Fields of a eld set Switching outputs
OUT 1 OUT 2 OUT 3
Fields 1, 2, and 3 infringed Active Active Active
Fields 2 and 3 infringed Deacti-
vated Active Active
Field 3 infringed Deacti-
vated
Deacti-
vated
Active
All elds free Deacti-
vated
Deacti-
vated
Deacti-
vated
Field 1: inner, eld 2: center, eld 3: outer
Active: in working position; deactivated: in resting position
Output level
• PNP: The level of the switching outputs OUT 1 ... OUT 3 is
active low (in resting position: high, in working position: low
(eld infringed)).
• NPN: The level of the switching outputs OUT 1 ... OUT 3 is
active high (in resting position: low, in working position:
high (eld infringed)).
All elds of a eld set are also deemed to be infringed during
switching on, booting, in the event of an error, and when the
device is switched off.
The OUT 4 switching output works with the following levels:
Function Level PNP Level NPN
Device Ready High Low
Index signal (15 Hz), corresponds to
measurement at 90° Low-Peaks High-Peaks
Errors Low High
Model Name TiM310-1030000 (part no. 1052627)
TiM310-1130000 (part no. 1056550)
TIM310-0130000S02 (part no. 1069932)
TIM310-1030000S02 (part no. 1062221)
TIM310-1130000S02 (part no. 1067917)
TiM320-1031000 (part no. 1063467)
TiM320-1131000 (part no. 1062219)
TiM320-0131000S02 (part no. 1069933)
TiM320-1131000S02 (part no. 1067919)
EMC Radiated emission: Residential area according
to EN 61000-6-3: 2007-01
Electromagnetic immunity: Industrial
environment according to
EN 61000-6-2: 2005-08
Vibration
resistance
According to EN 60068-2-6: 2008-02
Shock resistance According to EN 60068-2-27: 2009-05
Ambient
temperature
Operation: –10 ... +50 °C
Storage: –30 ... +70 °C
Temperature
change
According to EN 60068-2-14: 2009-07
Damp heat According to EN 60068-2-30: 2005-12
Air humidity < 80%
Installation height < 5,000 m above sea level
Ambient condi-
tions
According to EN 61010-1:2011-07, contamina-
tion level 3 outside housing
1) Complies with 21 CFR 1040.10:2007-04 except for the tolerance according to
Laser Notice No. 50 of June 2007
2) The TiM has an internal, system-related time delay of 67 ms.
For further technical specications, see the Online data sheet
on the product website (www.mysick.com/en/tim3xx)
aWARNING
Risk of potential equalization currents
The TiM is designed to be operated in a system with proper
grounding of all connected devices and mounting surfaces
to the same ground potential. If this condition is not met,
potential equalization currents may through along the cable
shields, causing the following hazards:
• Dangerous contact voltage on the metal housing
• Malfunction or destruction of the TiM
• Heating of the cables with possible spontaneous
combustion.
>See the "Electrical Installation" chapter in the &Technical
Information (no. 8014318) on the product website (www.
mysick.com/en/tim3xx) for measures for eliminating
hazards.
Field set factory settings - switching inputs
Field
set Switching inputs Field shape Default size of eld 1
IN 1 IN 2 IN 3 IN 4
10000Rectangle1) 2), segmented
L: 1 m, W: 2 m
2 1 000Rectangle1) 2), segmented
L: 1.25 m, W: 2 m
3010 0 Rectangle1) 2), segmented
L: 1.5 m, W: 2 m
4 110 0 Rectangle1) 2), segmented
L: 1.75 m, W: 2 m
5 0010
TiM31x: Semi-circle 3),
radius: 0.75 m
TiM32x: Rectangle1), seg-
mented L: 1 m, W: 2 m
6 1 0
10 TiM31x: Semi-circle 3),
radius: 1 m
TiM32x: Rectangle1), seg-
mented L: 1.25 m, W: 2 m
7 0 1
10 TiM31x: Semi-circle 3),
radius: 1.5 m
TiM32x: Rectangle1), seg-
mented L: 1.5 m, W: 2 m
8 1 1 1
0 TiM31x: Semi-circle 3),
radius: 2 m
TiM32x: Rectangle1), seg-
mented L: 1.75 m, W: 2 m
90001Rectangle1) 4), segmented
L: 1 m, W: 2 m
10 1001Rectangle1) 4), segmented
L: 1.25 m, W: 2 m
11 0101Rectangle1) 4), segmented
L: 1.5 m, W: 2 m
12 1 1 01Rectangle1) 4), segmented
L: 1.75 m, W: 2 m
13 001 1 Rectangle1) 4), segmented
L: 1 m, W: 2 m
14 1 01 1 Rectangle1) 4), segmented
L: 1.25 m, W: 2 m
15 0 111Rectangle1) 4), segmented
L: 1.5 m, W: 2 m
16 1 1 1 1 Rectangle1) 4), segmented
L: 1.75 m, W: 2 m
L = length, W = width
1) Default setting, starting shape can be modied as required
2) TiM31x: Field 2 limits = eld 1 limits plus 25 %, relationship cannot be changed
Field 3 limits = eld 1 limits plus 52 %, relationship cannot be changed
3) TiM31x: Default settings:
Field 2 limits = eld 1 limits plus 25 %, limits can be adjusted freely
Field 3 limits = eld 1 limits plus 52 %, limits can be adjusted freely
4) TiM32x: Default setting, starting shape can be modied as required
Input level
• PNP: Low (in resting position): ≤ 2 V, high (in working
position): ≥ 8 V
• NPN: Active low (in working position): ≤ (IN 9...28 V) – 8 V,
inactive high (in resting position) > (IN 9...28 V) – 2 V

8018590/YK97/2015-04-27 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com TIM31X/TIM32X | SICK 6
8018590/YK97/2015-04-27 ∙ 8M_SH ∙ Printed in Germany (2015-04) ∙ All rights reserved ∙ Subject to change without notice
aATTENTION
Risques liés à des courants d’équipotentialité
Le TiM a été conçu pour être utilisé dans une installation
prévoyant une mise à la terre correcte de tous les appareils
et surfaces de montage raccordés sur un même potentiel
de sol. Si cette condition n’est pas remplie, des courants
d’équipotentialité risquent dans certaines conditions de
passer par les blindages des câbles et d’exposer aux risques
suivants :
• tension de contact dangereuse sur le boitier en métal,
• comportement incorrect ou destruction du TiM.
• chauffe des câbles jusqu’à leur inammation spontanée.
>Pour des mesures de prévention de tels risques, voir le
chapitre « Installation électrique » de &l’Information tech-
nique (no. 8014318) ou sur la page produit sur internet
(www.mysick.com/en/tim3xx).
Connection plug pin positions
6110
5
11 15
“Power/switching inputs/outputs” connection
15-pin D-Sub HD plug on the cable
IN 4 (switching input)
IN 3 (switching input)
IN 1 (switching input)
IN 2 (switching input)
DC 9 ... 28 V
n.c.
n.c.
n.c.
GND
n.c.
OUT 1 (switching output)
OUT 2 (switching output)
7
6
OUT 4 (switching output)
OUT 3 (switching output)
INGND
4
3
2
1
5
8
9
10
11
12
13
14
15
Connection plug pin position TiM with 15-pin D-Sub-HD cable plug
“Power/switching inputs/outputs” connection
12-pin M12 plug on the cable
IN 4 (switching input)
IN 3 (switching input)
IN 1 (switching input)
IN 2 (switching input)
DC 9 ... 28 V
GND
n.c.
OUT 1 (switching output)
OUT 2 (switching output)
7
6
OUT 4 (switching output)
OUT 3 (switching output)
4
3
2
1
5
8
9
10
11
12
4
10
1112
8
6
7
9
1
5
3
2
PNP: INGND
NPN: IN 9 ... 28 V (Reference potential for
switching inputs)
Connection plug pin position TiM with 12-pin M12 cable plug
Scope of delivery
• TiM including mounting kit 1 (two straight plates, 2 M3 x
4 mm screws)
• Printed operating instructions in German and English, in
other languages, as necessary.
• Other optional accessories (if these have been ordered)
Maintenance and care
The TiM does not contain any components that require
maintenance. Nor is any maintenance necessary to ensure
compliance with laser protection class 1.
>If it is dirty, carefully clean the infrared light-permeable,
black optical hood to ensure optimal detection perfor-
mance. Use a soft, damp cloth and a mild cleaning agent.
Transport and storage
The TiM must be transported and stored in its original pa-
ckaging with the USB protective cap plugged in. Do not store
outdoors. To ensure that any residual moisture present can
escape. Do not expose to aggressive media (e. g., solvents).
Storage conditions: dry, dust-free, no direct sunlight, as little
vibration as possible, storage temperature –40°C to +75°C,
relative air humidity max. 90% (non-condensing).
Repair
Repair work on TiM may only be performed by qualied and
authorized service personnel from SICK AG.
Removal and disposal
Any TiM which can no longer be used at the end of the
product life cycle must be disposed of in an environmentally
friendly manner in accordance with the respective applicable
country-specic waste disposal regulations.
The TiM is electronic waste and must under no circumstances
be disposed of with general waste!
Sources for obtaining additional information
Additional information about the TiM and its optional
accessories can be found in the following places:
TiM product website
(www.mysick.com/en/tim3xx)
• Technical Information (supplementary information on
mounting and electrical installation, an overview list, and
license texts for open-source software) in German (no.
8014317) and English (no. 8014318).
• These operating instructions in German (no. 8015530),
English (no. 8015531), and in other languages if required
• SOPAS conguration software with online help
• Ordering information in the detection and ranging solu-
tions product catalog
• TiM product information
• Detailed technical specications (online data sheet)
• Dimensional drawing and 3D CAD dimension models in
various electronic formats
• EC declaration of conformity
• SOPAS conguration software updates
Support is also available from your sales partner: www.sick.
com/worldwide.
Copyright notices for open-source programs
SICK uses open source software in its TiM sensors. This
software is licensed by the rights holders using the following
licenses among others: the free licenses GNU General Public
License (GPL Version2, GPL Version3) and GNU Lesser Gen-
eral Public License (LGPL), the MIT license, zLib license, and
the licenses derived from the BSD license.
This Program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied war-
ranty for merchantability or tness for a particular purpose.
See the GNU General Public License for more details.
View the complete license texts here: www.sick.com/licen-
setexts.
A printed copy of the license texts is also available on request.
