Series SX602
Alphanumeric large size displays
with Profinet IO RT interface
Operating instructions
Pos: 3/ Siebert/Seitenum bruch @ 0\mod_13141945 53878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 2/36
Pos: 4/ Siebert/Bedie nungsanleitungen/ Gerätebeschreib ung Grossanzeigen all eS erien/Kontakt @ 1 \mod_1339668 951540_48.docx @ 43 23@ 1 @ 1
1 Contact
www.siebert-group.com
GERMANY
Siebert Industrieelektronik GmbH
Siebertstrasse, D-66571 Eppelborn
P.O. Box 11 30, D-66565 Eppelborn
Phone [phone], Fax [phone]
email: [e-mail]
AUSTRIA
Siebert Österreich GmbH
Mooslackengasse 17. A-1190 Wien
Phone [phone], Fax [phone]
email: [e-mail]
FRANCE
Siebert France Sarl
4 rue de l’Abbé Louis Verdet, F-57200 Sarreguemines
P.O. Box 90 334, F-57203 Sarreguemines Cédex
Phone [phone], Fax [phone]
email: [e-mail]
ITALY
Siebert Italia Srl
Via Galileo Galilei 2A, I-39100 Bolzano (BZ)
Phone [phone] Fax [phone]
email [e-mail]
THE NETHERLANDS
Siebert Nederland B.V.
Jadedreef 26, NL-7828 BH Emmen
Phone [phone], Fax [phone]
email: [e-mail]
SWITZERALND
Siebert AG
Bützbergstrasse 2, P.O. Box 91, CH-4912 Aarwangen
Phone [phone], Fax [phone]
email: [e-mail]
Pos: 5/ Siebert/Seitenum bruch @ 0\mod_13141945 53878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 3/36
Pos: 6/ Siebert/Bedienungs anleitungen/Gerät ebeschreibung Grossanz eigen alleS erien/Rechtlicher Hin weis@ 1 \mod_133966887 8995_48.docx @ 4317 @ 1 @ 1
2 Legal note
© Siebert Industrieelektronik GmbH
This operation manual has been prepared with the utmost care. However, we do not accept any
liability for possible errors. We always appreciate your suggestions for improvement, corrections,
comments and proposals. Please contact us: [e-mail]
Siebert®, LRD®and XC-Board®are registered trademarks of Siebert Industrieelektronik GmbH. All
other product names mentioned herein may be trademarks or registered trademarks of their respective
owners.
We reserve the right to make alterations to the technical data and delivery options without notice. - All
rights reserved, including the rights of translation. No part of this document may in any form or by any
means (print, photocopy, microfilm or any other process) be reproduced or by using electronic
systems be processed, copied or distributed without our written permission.
Pos: 7/ Siebert/Seitenum bruch @ 0\mod_13141945 53878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 4/36
Pos: 8/ Siebert/Bedienungs anleitungen/Modul Inh altsverzeichnis @ 1\mod_1 352981287156_48. docx@ 51 55@ @ 1
Table of contents
1Contact 2
2Legal note 3
3Safety precautions 7
Important information .........................................................................................................................................7
Safety .................................................................................................................................................................7
Intended use.......................................................................................................................................................7
Mounting and installation....................................................................................................................................7
Grounding...........................................................................................................................................................8
EMC measures...................................................................................................................................................8
Disposal..............................................................................................................................................................8
4Unit description 9
Model designation ..............................................................................................................................................9
Unit construction.................................................................................................................................................9
Principle circuit diagram ...................................................................................................................................10
Central Processing Unit....................................................................................................................................11
Profinet-IO interface .........................................................................................................................................11
Serial Interface .................................................................................................................................................11
Function inputs.................................................................................................................................................12
Menu display ....................................................................................................................................................12
Status indicators...............................................................................................................................................12
Battery..............................................................................................................................................................13
Power supply....................................................................................................................................................13
5Character display 14
LED matrix........................................................................................................................................................14
Character sets..................................................................................................................................................14
Proportional lettering ........................................................................................................................................14
LED color..........................................................................................................................................................14
6Configuration 15
MAC address....................................................................................................................................................15
GSDML data file...............................................................................................................................................15
Configuration....................................................................................................................................................15
7Text types 16
8Operating mode 'Quick call of static texts' 17
Operating mode................................................................................................................................................17
Input-/Output data bytes...................................................................................................................................17
Configuration inside IO controller.....................................................................................................................17
Data format.......................................................................................................................................................17

BAL SX602 PFN RT 5/36
9Operating mode 'Dynamic and static texts' 18
Operating mode................................................................................................................................................18
Output data bytes.............................................................................................................................................18
Configuration inside IO controller.....................................................................................................................18
Example of configuration..................................................................................................................................18
Data transmission.............................................................................................................................................18
Block diagram of the handshake method.........................................................................................................18
Data segmentation ...........................................................................................................................................19
Functional building block..................................................................................................................................19
Text types.........................................................................................................................................................19
Commands.......................................................................................................................................................19
Table of commands..........................................................................................................................................19
Display dynamic text ........................................................................................................................................21
Static texts........................................................................................................................................................21
Inserting variables ............................................................................................................................................21
Deleting text......................................................................................................................................................21
Flashing............................................................................................................................................................21
Marquee text.....................................................................................................................................................22
Forced line break..............................................................................................................................................22
Character set....................................................................................................................................................22
LED color..........................................................................................................................................................22
Inserting time/date............................................................................................................................................22
Bar graph..........................................................................................................................................................22
Character $.......................................................................................................................................................22
Brightness.........................................................................................................................................................23
Brightness.........................................................................................................................................................23
Reset................................................................................................................................................................23
Setting time/date...............................................................................................................................................23
Reading out time/date ......................................................................................................................................23
Paging ..............................................................................................................................................................23
Initial text ..........................................................................................................................................................23
10 Parameterization 24
Menu.................................................................................................................................................................24
Menu operation.................................................................................................................................................24
Menu table........................................................................................................................................................24
Operation mode................................................................................................................................................25
Output data bytes.............................................................................................................................................25
Time-out ...........................................................................................................................................................26
Initial text ..........................................................................................................................................................26

BAL SX602 PFN RT 6/36
Paging ..............................................................................................................................................................26
Character set....................................................................................................................................................26
Language..........................................................................................................................................................26
Display test.......................................................................................................................................................26
Set time/date ....................................................................................................................................................26
11 Status messages 27
Fault messages................................................................................................................................................27
12 Character table 28
13 Technical data 29
Unit properties..................................................................................................................................................29
Housing colors..................................................................................................................................................29
Front frame.......................................................................................................................................................29
Ambient conditions...........................................................................................................................................30
Max. power consumption .................................................................................................................................30
Screw-type terminals........................................................................................................................................30
Fixed text memory............................................................................................................................................30
Marquee ...........................................................................................................................................................30
Real-time clock.................................................................................................................................................30
Dimensions and weights ..................................................................................................................................31
=== Ende der List ef ürT extmar keI nhalt1 ===
Pos: 10 /Siebert/Seitenu mbruch@ 0 \mod_1314194 553878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 7/36
Pos: 11 /Siebert/Bedi enungsanleitunge n/Gerätebeschrei bungGr ossanzeige n alle Serien/Sicherheits hinweise Grossanzeig en SX502 Busf ehler @ 1\mod_13 85723478553_48.doc x @ 7030 @ 1222222 2@ 1
3 Safety precautions
Bus errors may result in personal injury or material damage. Therefore it must be noted that
the reset of the display with command $0 and activation of the menu may cause a bus error.
Important information
Read these operating instructions before starting the unit. They provide you with important information
on the use, safety and maintenance of the units. This helps you to protect yourself and prevent
damage to the unit.
Information intended to help you to avoid death, bodily harm or considerable damage to
property is highlighted by the warning triangle shown here; it is imperative that this
information be properly heeded.
The operating instructions are intended for trained professional electricians familiar with the safety
standards of electrical technology and industrial electronics.
Store these operating instructions in an appropriate place.
The manufacturer is not liable if the information in these operating instructions is not complied with.
Safety
Components inside the units are energized with electricity during operation. For this reason,
mounting and maintenance work may only be performed by professionally-trained personnel
while observing the corresponding safety regulations.
The repair and replacement of components and modules may only be carried out by the manufacturer
for safety reasons and due to the required compliance with the documented unit properties.
The units do not have a power switch. They are operative as soon as the operating voltage is applied.
Intended use
The units are intended for use in industrial environments. They may only be operated within the limit
values stipulated by the technical data.
When configuring, installing, maintaining and testing the units, the safety and accident-prevention
regulations relevant to use in each individual case must be complied with.
Trouble-free, safe operation of the units requires proper transport, storage, installation, mounting and
careful operation and maintenance of the units.
Mounting and installation
The attachment options for the units were conceived in such a way as to ensure safe, reliable
mounting.
The user must ensure that the attachment hardware, the unit carrier and the anchoring at the
unit carrier are sufficient to securely support the unit under the given surrounding conditions.
The units are to be mounted in such a way that they can be opened up while mounted. Sufficient
space for the cables must be available in the unit near the cable entries.
Sufficient space is to be kept clear around the units to ensure air circulation and to prevent the build-
up of heat resulting from use. The relevant information must be heeded in the case of units ventilated
by other means.
When the housing fasteners are opened, the front frame of the housing hinges out upward or
downward (depending on the unit version) automatically.

BAL SX602 PFN RT 8/36
Grounding
All devices are equipped with a metal housing. They comply with safety class I and require a
protective earth connection. The connecting cable for the operating voltage must contain a protective
earth wire of a sufficient cross section (DIN VDE 0106 part 1, DIN VDE 0411 part 1).
EMC measures
The devices comply with the current EU Directive (EMC Directive) and provide the required
interference immunity. Observe the following when connecting the operating voltage and data cables:
Use shielded data cables.
The data and operating voltage cables must be laid separately. They may not be laid together with
heavy-current cables or other interference-producing cables.
The cable thickness must be properly assessed (DIN VDE 0100 Part 540).
The cable lengths inside the units are to be kept as short as possible to prevent interference. This
applies especially to unshielded operating voltage cables. Shielded cables are also to be kept short
due to any interference which might be emitted by the shielding.
Neither excessively long cables nor cable loops may be placed inside the units.
The connection of the cable shielding to the functional ground (PE) must be as short and low-
impedance as possible. It should be made directly to the mounting plate over a large area with a
conductive clip:
①mounting plate
②conductive clamp
③data lines
④cable shielding
The cable shielding is to be connected at both cable ends. If equipotential bonding currents are
expected due to the cable arrangement, electrical isolation is to be performed on one side. In this
case, capacitive connection (approx. 0.1μF/600 V AC) of the shielding on the isolated side must occur.
Disposal
Units or unit parts which are no longer needed are to be disposed of in accordance with the
regulations in effect in your country.
Pos: 12 /Siebert/Seitenu mbruch@ 0 \mod_1314194 553878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 9/36
Pos: 13 /Siebert/Bedienu ngsanleitungen/Seri eSX 502/ SX 602/Gerätebeschrei bung/ÜBS Gerätebeschr eibung @ 0\mod_13172 99752517_48.doc x@ 2907 @ 1 @ 1
4 Unit description
Pos: 14 /Siebert/Bedienu ngsanleitungen/Seri eSX 502/ SX 602/Gerätebeschrei bung/Geltungsbereic h/SX602 Geltungsbereic hPFN RT @ 3\ mod_146590358 2173_48.docx @ 25860 @ 2 @ 1
Model designation
This manual applies to units with the following model designation (x = the 'x's in the model designation
indicate the size and design of the units see Chapter 14):
SX602-xxx/xx/xx-xxx/xx-YP
Pos: 15 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Gerätebeschreibu ng/Geräteaufbau/ SX602 Geräteaufba uP FNR T @ 3\mod_14 65903805669_48. docx @ 25867 @ 2 @ 1
Unit construction
The following figure shows model type SX602-10/10/xx-xxx/xx-xx as example for the other model
types. The front frame of the housing is locked with quick-action releases. When opening the unit the
front frame hinges downward.
The following figure shows the unit when open.
Central Processing Unit
Power supply unit
Connector plug for power supply
Matrix modules
Lower housing section
Housing front frame
Units with double-sided display show the same information on the front and on the rear side.
Pos: 16 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Gerätebeschreibu ng/Prinzipschaltbild/ Prinzipschaltbil d neu/Prinzipsc haltbild SX502 PFN RT, SX 602 PFNR T @ 2\mod_14 08012971720_ 48.docx @ 9128 @ 2 @ 1

BAL SX602 PFN RT 10/36
Principle circuit diagram
①Central Processing Unit
②Power supply unit
③Power supply
④Display
ⒷBattery
ⒹSub D connector –serial interface
ⒻFunction input
ⓁStatus indicato

BAL SX602 PFN RT 11/36
Pos: 17 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX60 2/Gerätebeschrei bung/Steuerrechner/ Steuerrechner a ktuell/Steuerrechn erS X502 ETH/IP, MDB TCP, PFN RT, SX602 PFN RT @ 2\mod_14083 53413797_48.doc x @ 9448 @ 2 @ 1
Central Processing Unit
The following figure shows the Central Processing Unit, located in the lower part of the housing.
ⒷBattery
ⒹSub D connector –Serial interface
ⒻFunction input
ⓁStatus indicators
ⓂMenu display
ⓉMenu button
ⓋPower supply
Pos: 18 /Siebert/Bedie nungsanleitungen/Seri eS X502/ S X602/Gerätebesc hreibung/Schnittst ellen/Profinet/Profi net-IO-Schnittst elle S302/SX302 PFN IRT , SX502 PFN RT, SX6 02PFN RT @ 3\mod_14 43085005617_48. docx @ 19565 @ 2 @ 1
Profinet-IO interface
The Profinet-IO interface is located on the RJ45 socket of the Profinet-IO coupling.
The units have an Ethernet switch with 2 ports. Connection can be made via Port1 or Port2.
The GSDML data file is included on disk in delivery.
Pos: 19 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Gerätebeschreibu ng/Schnittstelle n/Seriell/Serielle Sc hnittstelle SX502 ETH/I P, IBSPDGWY,MDBTC P,MDBTCPG WY,DVN,PFB,PFN RT, S X602 PFN RT @ 2\ mod_1408019069 537_48.docx @ 921 1 @ 2@ 1
Serial Interface
The interface RS232 is determined for programming the device using a PC, for example for loading
static texts in the text memory and for installing character sets by means of the PC tools
'DisplayManager' and 'FontManager' provided on data carrier.
The interface RS232 is located, on the sub D connector of the control computer. It has the following
assignment:
Pin
1
2
3
4
5
6
7
8
9
Signal
–
RxD
TxD
–
COM
–
RTS
CTS
–
The PC connection is established using a standard null-modem cable.
The parameters of the interface are as follows: 9600 bauds, 8 data bits, no parity, 1 stop bit, RTS/CTS
handshake, CR/LF protocol, no addressing.
Pos: 20 /Siebert/Bedi enungsanleitunge n/Serie S302/SX30 2SX 502 SX602 Überei nstimmungen/Gerät ebeschreibung Gros sanzeigen Überei nstimmung versc h.S erien/Geräteb eschreibung S302/S X302S X502 SX602/Fu nktionseingänge/F unktionseingäng e S302/SX302 PFN IRT , SX502 PFN RT, SX60 2 PFNR T Einleitungssatz @ 2\mod_1 395322132214_4 8.docx @ 7789 @ 2 @ 1

BAL SX602 PFN RT 12/36
Function inputs
The function inputs are located on the screw-type terminal strip of the control computer. They allow
reduction in brightness and flashing of the display, independently of commands via the PROFINET IO
interface (see Chapter 9).
Pos: 21 /Siebert/Bedi enungsanleitunge n/Serie S302/SX30 2SX 502 SX602 Überei nstimmungen/Gerät ebeschreibung Gros sanzeigen Überei nstimmung versc h.S erien/Geräteb eschreibung S302/S X302S X502 SX602/Fu nktionseingänge/F unktionseing.S 302ANA,CAN,DVN, ETH,IBS,MDB,MD BTCP,NTP ,PFN,PFNIRT, SER,TMR,WTH, WTS,SX502/SX3 02/SX602 su @ 2\m od_1395322124370 _48.docx @ 7771 @ @ 1
The function inputs are designed for the following signal voltages:
Signal voltage: L = -3.5...+5 V (open input = L)
H = +18...30 V (active H), M = reference potential
Pos: 22 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Gerätebeschreibu ng/Menüanzeige/M enüanzeige neu/SX 602M enüanzeige PFN RT @ 3\mod_1 465905792966_4 8.docx @ 25916 @ 2 @ 1
Menu display
The parameterization of the units is carried out in a menu of the menu display:
In normal operation, the following status messages can appear in the menu display:
 The display is waiting for new data
  Data are received at the interface
 The unit detects a telegram ending
In the operation mode 'Quick call of static texts' the currently valid command is shown as hexadecimal
number.
During the start-up on Profinet the following status messages may appear on the menu display:
The display was not assigned with a name yet
The display was not assigned with an IP address yet
Display is ready for Profinet
In programming mode the following status messages can appear on the menu display:
 Static texts are loaded in the text memory
 Static texts are read out from the text memory
During the start-up or in case of error further messages, which are of internal nature, appear.
Pos: 23 /Siebert/Bedi enungsanleitunge n/Serie S302/SX30 2SX 502 SX602 Überei nstimmungen/Gerät ebeschreibung Gros sanzeigen Überei nstimmung versc h.S erien/Geräteb eschreibung S302/S X302S X502 SX602/Stat usanzeigen neu/Stat usanzeigen SX5 02PFN RT SX602 PFN R T@ 2 \mod_140801 8530096_48.docx @ 9 183 @ 2 @ 1
Status indicators
The status indicators (LEDs) of the control computer and the Profinet coupling have the following
meaning:
LEDs Ⓛsee fig. control computer:
DATA Data transmission in progress
ERR False command
PWR Internal meaning
LED NS: on the left, next to the RJ45 socket of port 1:
Off Offline No connection to the IO controller
Green Online (RUN) Connection to the IO controller
IO controller in RUN state
Green, flashing Online (STOP) Connection to the IO controller
IO controller in STOP state
LED MS: on the right, next to the RJ45 socket of port 2:
Off Not initialized No connection
Module in ˈSETUPˡor ˈNW INITˈstate
Green Normal operation Module has shifted from the ˈNW INITˈ state
Green, 1 flash Diagnostic events Diagnostic events present
Green, 1 Hz DCP Flash Used by engineering tools to identify the node on the
network

BAL SX602 PFN RT 13/36
Red Exception error Module in state ˈEXCEPTIONˈ
Red, 1 flash Configuration error Expected identification differs from real identification
Red 2 flashes IP address error IP address not set
Red, 3 flashes Station name error Station name not set
Red, 4 flashes Internal error Module has encountered a major internal error
Pos: 24 /Siebert/Bedie nungsanleitungen/ SerieS 302/SX302 SX502 SX6 02Üb ereinstimmungen /Gerätebeschreibung Gros sanzeigen Übereinsti mmung versch. Serien/Gerä tebeschrei bungS 302/SX302 SX502 SX6 02/Batterie/Batterie S302 DCF , SX502 DVN, ETH, ETH/IP,MD B,IBSPDG WY, MDBTCP,MD BTCPGWY, PFB, PFN IRT, s. u.@ 2\mod_1408356 423444_48.doc x@ 948 7@ 2 @ 1
Battery
The lithium battery (type CR2032) provides a power reserve for the real-time clock. It is located in a
battery holder and should be replaced after three years.
Pos: 25 /Siebert/Bedi enungsanleitunge n/Gerätebeschrei bung Grossanzeige n alle Serien/Betriebssp annung Grossanz eigen @ 0\mod_1 315494019425_4 8.docx @ 1864 @ 2 @ 1
Power supply
The screw-type terminals for the power supply are located on the power supply unit in the bottom
section of the housing. They have the following designations:
Devices for a power supply 115 V AC or 230 V AC L, N and PE
Devices for a power supply 24 V DC +, –and PE
Pos: 26 /Siebert/Seitenu mbruch@ 0 \mod_1314194 553878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 14/36
Pos: 27 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/Z eichendarstellung /ÜBSZ eichendarstellu ng @ 0\mod_1 317306112128 _48.docx@ 2977 @ 1 @ 1
5 Character display
Pos: 28 /Siebert/Bedienu ngsanleitungen/Seri eSX 502/ SX 602/Zeichendarstellu ng/SX602 LED-Matri x PFN RT @ 3\mod_1 465908413330_4 8.docx@ 2 5933 @ 2@ 1
LED matrix
The characters are displayed on an LED matrix.
Pos: 29 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/Z eichendarstellung/S X602 Zeichens ätze PFNR T @ 3\mod_ 1465908639121_ 48.docx @ 25947 @ 2 @ 1
Character sets
The character sets Acala 7 and Acala 7 extended are permanently installed in the devices.
Character set
Character display
Acala 7
AaBbCcDdEeFfGgHhIiJjKkLlMmNnOoPpQqRr
Acala 7 extended*
AaBbCcDdEeFfGgHhIi
Pos: 30 /Siebert/Bedienu ngsanleitungen/Seri eSX 502/ SX 602/Zeichendarstellu ng/SX602 Proportionalsc hrift PFN RT @ 3\ mod_14659086787 86_48.docx @ 25954 @ 2 @ 1
Proportional lettering
The character sets Acala 7 and Acala 7 extended display the characters in non-proportional lettering
(monospace font). The same number of pixels is available for the width of each character.
Character set Acala 7 P, which displays the characters in proportional lettering is pre-installed and is
included on data carrier. Each character uses the width it requires visually.
Pos: 31 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/Z eichendarstellung/S X602 LED-Farb e PFNRT @ 3\mod_1 465908712403_48.d ocx @ 25961 @ 2 @ 1
LED color
The unit versions SX602-xxx/xx/xR-xxx/xx-xx have a display with red LED color. The LED color cannot
be changed (monochrome display).
The unit versions SX602-xxx/xx/xM-xxx/xx-xx have a display whose LED color can be switched
between red, green and orange. This version is only available in 50 mm character height.
Pos: 32 /Siebert/Seitenu mbruch@ 0 \mod_1314194 553878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 15/36
Pos: 33 /Siebert/Bedienu ngsanleitungen/Seri eSX 502/ SX 602/Konfiguration/ÜB S Konfiguration @ 1\mod_136 3345330599_48.d ocx@ 583 5@ 1 @ 1
6 Configuration
Pos: 34 /Siebert/Bedi enungsanleitunge n/Serie S302/SX30 2SX 502 SX602 Überei nstimmungen/Konfig uration Grossanzeige nÜ breinstimm ung versch. Serie n/MAC-Adresse/M AC-Adresse S302/ SX302 PFN,PFN IRT,SX 502 PFN IRT,PFN RT,S X602 PFN RT @ 2\m od_14083618455 61_48.docx @ 957 1@ 2 @ 1
MAC address
MAC address
The MAC address of the unit is to be found on the Profinet IO coupling of the control computer (see
label). It is needed for commissioning and should be written down before the unit is mounted on an
inaccessible location.
Pos: 35 /Siebert/Bedi enungsanleitunge n/Serie S302/SX30 2SX 502 SX602 Überei nstimmungen/Konfig uration Grossanzeige nÜ breinstimm ung versch. Serien/G SDML-Datei/SX 502 SX602 GSDML-D ateiP FN RT @ 2\mod_ 1408355544594_48. docx @ 9461 @ 2 @ 1
GSDML data file
After importing the GSDML data file (data carrier included in delivery) into the Engineering-Tool the
unit is shown in hardware-catalog under 'PROFINET IO / Further Field Units / General / Siebert
SX502/SX602/SX702'.
Pos: 36 /Siebert/Bedi enungsanleitunge n/Serie S302/SX30 2S X502 SX602 Überei nstimmungen/K onfiguration Grossanzeig enÜ breinstimm ung versch. Serien/Ko nfiguration/SX502 K onfiguration ETH/I P,MDBTCP,PFN RT, SX602 PFN RT @ 2\ mod_1408355641 812_48.docx @ 947 4@ 2 @ 1
Configuration
The configuration is dependent on the operating mode selected in menu item 1 (see Chapter 11).
Pos: 37 /Siebert/Seitenu mbruch@ 0 \mod_1314194 553878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 16/36
Pos: 38 /Siebert/Bedienu ngsanleitungen/Seri eSX 502/ SX 602/Textarten/ÜBS Te xtarten@ 0\ mod_132273248 0112_48.docx @ 3668 @ 1 @ 1
7 Text types
Pos: 39 /Siebert/Bedi enungsanleitunge n/Serie S302/SX30 2SX 502 SX602 Überei nstimmungen/Textart en/SX502 Textart enE TH/IP,MDBTCP ,PFB,PFN IRT,PFN R T SX602 PFN RT @ 0\ mod_1322732081 577_48.docx @ 3663 @ @ 1
The units can display dynamic and static texts.
Dynamic texts can be changed while the unit is running. They are generated from within the process
and have modifiable contents.
Static texts cannot be changed while the unit is running. They are compiled using the PC tool 'Display
Manager' included on data carrier and are loaded in the text memory. After that, they can be opened
via their text number.
Pos: 40 /Siebert/Seitenu mbruch@ 0 \mod_1314194 553878_0.docx @ 150 @ @ 1

BAL SX602 PFN RT 17/36
Pos: 41 /Siebert/Bedie nungsanleitungen/Seri eS X502/ S X602/Betriebsart en/Betriebsart 'Schnella ufrufs tatischer Texte'/ÜBS B etriebsart 'Schnellaufruf st atischer Texte' @ 0\mod_13 22734463357_48.d ocx @ 3685@ 1 @ 1
8 Operating mode 'Quick call of static texts'
Pos: 42 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX60 2/Betriebsarten/Be triebsart 'Schnellaufr ufs tatischer Texte'/Ei nleitungsatz/Einl eitungssatz SX50 2ETH /IP,MDB,MDBTCP, PFB,PFN IRT ,PFN RT SX602 PFN RT @ 2\m od_140802436 1302_48.docx @ 9390 @ @ 1
If the units are used exclusively for the display of static texts (e.g. static fault message texts) and if no
variables must be shown in the texts, the static texts can be called up directly.
Pos: 43 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Schnellaufr ufs tatischer Texte'/Betri ebsart/Betrie bsart SX502 ETH/IO,MD BTCP,PFN IRT,PFN R T SX602 PFN RT @ 2\ mod_1408024285 006_48.docx @ 93 63@ 2 @ 1
Operating mode
In menu item 1 the setting  is to select (see Chapter 11).
Pos: 44 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX60 2/Betriebsarten/Be triebsart 'Schnellaufr ufs tatischer Texte'/Ei n-/Ausgangsdate nbytes/Ein-/A usgangsdatenbytes ETH/ IP,PFN RT SX602 PFN R T@ 2\mod_1408 024333166_4 8.docx@ 9383 @ 2 @ 1
Input-/Output data bytes
The number of output data bytes is fixed on two.
Pos: 45 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Schnellaufr ufs tatischer Texte'/Ko nfiguration im IO-C ontroller/Konfigurati oni mI O-Controller SX502 PFN R, SX602 PFN RT @ 2\ mod_140802 4404776_48.docx @ 9 403 @ 2 @ 1
Configuration inside IO controller
The module "002 Bytes OUT static text call" from file 'RT Input/Output' in the hardware catalog has to
be plugged into slot 1 of the IO device. Other configurations are not allowed.
Pos: 46 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX60 2/Betriebsarten/Be triebsart 'Schnellaufr ufs tatischer Texte'/D atenformat/Datenfor mat SX502 ETH/IP,MD B,MDB TCP,PF B,PFN IRT,PFN RT SX602 PFN RT @ 2\mo d_140802429859 5_48.docx @ 9370 @ 2 @ 1
Data format
To call a static text 2 bytes are sent to the display which receive the text number as 12-bit integer
value and four formatting bits (brightness, blinking, blanking, display test).
Byte 0 (MSB)
Byte 1 (LSB)
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
:
:
:
:
:
:
:
:
211
210
29
28
27
26
25
24
23
22
21
20
:
:
:
:
:
:
:
:
–––––––––––––––––––– Fixed text number 0…4095–––––––––––––––––––
:
:
:
:
:
:
:
0
Normal brightness
:
:
:
1
Reduced brightness
:
:
:
:
:
0
BFlashing off
:
:
1
BFlashing on
:
:
:
0
Blanking off
:
1
Blanking on (priority over flashing)
:
0
Display test off
1
Display test on (priority over flashing and blanking)
Pos: 47 /Siebert/Seit enumbruch @ 0\mod _1314194553878_0. docx @ 150 @ @ 1

BAL SX602 PFN RT 18/36
Pos: 48 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Dynamische u ndst atische Texte'/ÜB S Betriebsart 'Dyn amische und statische T exte' @ 0\mod_132 2735418254_48.d ocx @ 3711 @ 1 @ 1
9 Operating mode 'Dynamic and static texts'
Pos: 49 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Dynamische u ndst atische Texte'/B etriebsart/Betrie bsart ESX502 TH/IP, PFN IRT, PFN RT SX602 PFN RT @ 2 \mod_1398 435204415_48.doc x@ 8 089 @ 2 @ 1
Operating mode
In menu item 01 the setting  is to select (see Chapter 11).
Pos: 50 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Dynamische u ndst atische Texte'/A usgangsdatenb ytes/Ausgangsdat enbytes SX502 ETH/ IP,PFN RT SX602 PFN RT @ 2 \mod_1398435 131644_48.docx @ 8 082 @ 2 @ 1
Output data bytes
In menu item 02 the number of output data bytes (8, 16, 32, 64) is set (see Chapter 11). The number
of input data bytes is 1.
Pos: 51 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Be triebsart 'Dynamische u ndst atische Texte'/K onfiguration im IO-Co ntroller/Konfigur ation im IO-Controll erS X502 PFN RT, SX602 PFN RT @ 2\mod_139 8427186123_48.doc x@ 7952 @ 2 @ 1
Configuration inside IO controller
The module "001 Byte IN HANDSHAKE" from file 'RT INPUT/OUTPUT' in the hardware catalog has to
be plugged into slot 1 of the device. A module with the same number of bytes as set in menu point 2,
has to be plugged into slot 2 from file “RT INPUT/OUTPUT”(see Chapter 11). Other configurations are
not allowed.
Pos: 52 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Dynamische u ndst atische Texte'/K onfigurationsbeis piel/Konfiguratio nsbeispiel SX502 PFN RT, SX602 PFN RT @ 2\ mod_1398427327 589_48.docx @ 7965 @ 2 @ 1
Example of configuration
The display is to be controlled with 8 bytes of output data. The configuration of the IO device is as
follows:
Slot 1 001 byte IN handshake
Slot 2 008 bytes OUT handshake and dynamic text
The following settings have to be made in the menu:


Pos: 53 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Dynamische u ndst atische Texte'/Da tenübertragung/D atenübertragu ngS X502 PFN IRT, PFN RT SX 602 PFN RT @ 2\mod _1398428107920 _48.docx @ 7985 @ 2 @ 1
Data transmission
Due to the system the data transfer within the Profinet IO is cyclically. The data in the input and output
range of the IO controller are exchanged cyclically between IO controller and IO device This is why
data modified by the handshake method must be marked as 'new'. The new data are applied once,
whereas their cyclic repetition is ignored.
Pos: 55 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/ Betriebsart 'Dynamisch e und statische Te xte'/Flussdiagram m/Flussdiagramm SX5 02ETH/ IP,PFN IRT,PFN RT S X602 PFN RT @ 2\m od_13984287066 17_48.docx @ 8011 @ 2@ 1
Block diagram of the handshake method
After switching to the DATA EXCHANGE status (display parameterized and recognized as Profinet IO
device), the display sets the RxHS bit to the initial value 0. When switching to the DATA EXCHANGE
status, the IO-Controller must likewise set the TxHS bit to 0.
TxHS-Bit:=0 New data
to display?
RxHS-Bit
==
TxHS-Bit?
Toggle
TxHS-Bit
Build new
data block
Write data block (TxHS-
Byte and data) consistently
to output bytes (special
PLC function)
No
Entry of
state DATA-
EXCHANGE
No
The display is ready to receive as soon as the RxHS bit has the same value as the TxHS bit sent last.
Now new data can be transmitted from the IO controller to the display. The controller signals new data
by inverting (toggling) the TxHS bit. The new data and the modified TxHS byte must be written
consistently to the output data area by means of special master functions. After a short processing
time, the display signals again readiness to receive by setting the RxHS bit equal to the TxHS bit
received last.
Pos: 56 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/di v.Ka pitel: A nsteuerung, Betrie bsart dynamisch eT exte, Betriebsart dynamische und statisch eT ext/Datensegm entierung SX502 DVN ,ETH/IP,IBSPDG WY,MDBTCP,PF B,PFN IRT,PFN RT SX6 02PF N RT @ 0\mod_1 319726312065_48.d ocx @ 3530 @ 2 @ 1

BAL SX602 PFN RT 19/36
Data segmentation
Due to the system the number of output bytes is limited. This may require the allocation of a data
telegram into multiple segments.
Each segment contains, according to the handshake as described before, a transmission handshake
byte (TxHS byte) and can at a maximum contain as many bytes as configured in the output data area.
The segments are sent to the display successively in compliance with the handshake. Upon receipt of
a telegram ending the display analyzes the data.
Attention! If less data is sent to the display as configured in the output data area surplus
output data bytes have to be filled with 00hh regardless of whether or not data is
segmented. Data bytes with content 00hare ignored by the display.
Pos: 57 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Dynamische u ndst atische Texte'/Fu nktionsbaust ein/Funktionsbaust ein SX502 PFN RT, SX60 2P FNR T @ 2\mod_1398 429157645_48.d ocx @ 8024 @ 2 @ 1
Functional building block
An example program for Siemens S7-3xx for activating one or more displays, including a functional
building block for implementing a handshake method, are included in delivery on data carrier.
Pos: 58 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX60 2/Betriebsarten/Be triebsart 'Dynamisch e und statische Te xte'/Textarten/Textart enS X502PFN RT SX602 PFN RT @ 2\mod_1 398429323744_4 8.docx @ 8037 @ 2 @ 1
Text types
The units can display dynamic and static texts.
Dynamic texts can be changed while the unit is running. They are generated from within the process
and are sent to the display via the PROFINET interface.
Static texts cannot be changed while the unit is running. They are compiled using the PC tool 'Display
Manager' included on data carrier and are loaded in the text memory. After that, they can be opened
via their text number.
Pos: 59 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Betr iebsart 'Dynamische u ndst atische Texte'/B efehle/Befehle SX5 02 ETH/IP,MDBTCP ,PFN IRT,PFN RT SX 602 PFN RT @ 2\mod_ 1398429448741_ 48.docx @ 8056 @ 2 @ 1
Commands
The data are evaluated according to the command table shown below. In the following description, the
numbers in [ ] refer to the corresponding lines in the command table.
Some of the following commands require a telegram ending (). This ending can be inserted by
means of a single CR (0Dh) or LF (0Ah) or character or a CR/LF character combination.
In lines [1] and [3] cc... stands for a character chain of any desired content.
Pos: 60 /Siebert/Bedi enungsanleitunge n/Serie SX502 / SX602/ Betriebsarten/Be triebsart 'Dynamische u ndst atische Texte'/B efehlstabelle/SX 602 Befehlstabelle PFN RT @ 3\mod_146 5983664032_48.d ocx @ 25998 @ 2 @ 1
Table of commands
Commands for text manipulations
Display dynamic text
cc...
Send any desired characters
[1]
Display static text
$Tn
Calling up fixed text (n = text number, one to four digits)
[2]
Insert variables
$VEcc...
Entering variables from the current insertion position
[3]
$VPn
Selecting insertion position of variables (n = wildcard number for the
variable, 0...255)
[4]
Delete text
$E
Delete text in the display
[5]
Commands for text formatting
Line break
$C
Forced line break
[6]
Flashing
$F1
Flashing of following characters on
[7]
$F0
Flashing of following characters off
[8]

BAL SX602 PFN RT 20/36
Marquee text
$Y
Marquee text from current position until end of text or $C
[9]
Charcter set
$M1
Acala 7
[10]
$M2
Acala 7 extended
[11]
$M3
Do not use
[12]
$M4
Do not use
[13]
$M5
Acala 7 P / user-defined character set 7 pixel
[14]
$M6
Do not use
[15]
$M7
Do not use
[15a]
$M8
Do not use
[15b]
$M9
Do not use
[15c]
LED color
$A0
Red
[16]
$A1
Green
[17]
$A2
Orange
[18]
Place holders for variables
$VS
Inserting place holders for variables
[19]
Inserting time
$HA
Current time (HH:MM:SS)
[20]
$HH
Hour of current time (HH)
[21]
$HM
Minute of current time (MM)
[22]
$HS
Second of current time (SS)
[23]
Inserting date
$DA
Current date, four-digit year (TT.MM.JJJJ)
[24]
$DB
Current date, two-digit year (TT.MM.JJ)
[25]
$DD
Current day (TT)
[26]
$DM
Current month (MM)
[27]
$DY
Current year, four-digit (JJJJ)
[28]
$DZ
Current year, two-digit (JJ)
[29]
$DW
Weekday in selected dialog language
[30]
Bar graph
$Gnnnn
Bar graph display (nnn = number of columns,
always enter in four numeric digits, e.g. $G0040)
[31]
Character $
Display of the character '$' in the text
[32]
Commands for display options
Flashing
$F1
Flashing of the whole display on
[33]
$F0
Flashing of the whole display off
[34]
Brightness
$B0
Normal brightness
[35]
$B1
Reduced brightness
[36]
Reset
$0
Restart of the display
[37]
Commands for time and date
Set time/date
$SHhhmmss
Set time
[38]
$SDddmmyy
Set date
[39]
Reading out time/date
$RH
Read out time via serial interface
[41]
