Siemens SIMATIC IPC MD-34A User manual

© Siemens AG 2023. All rights reserved
A5E52413713-AA, 05/2023 1
SIMATIC IPC MD-34A Desk Docking
Product Information
Package Content
•Desk docking × 1
Design of product
Device in desk docking
Front view
Top view
Back view
Side view
①Docking connector
②
Power port for a 19 V DC power supply
③2 × USB 2.0 port
④1 × RJ45 E1hernet connection for 10/100 Mbps
⑤
VGA connection
⑥COM port for RS232 connection

SIMATIC IPC MD-34A Desk Docking
2A5E52413713-AA, 05/2023
Using the desk docking
Inserting the IPC
Hold the sides of the IPC with two hands and align the bottom of the IPC into the docking connector of desk docking.
Note
Make sure the IPC is aligned with the desk docking. Reposition the IPC if it moves around.
Removing the IPC
Lift the tablet straight up from the desk docking to remove the IPC.
Powering on the desk docking
Note
Use the original power adapter of the IPC. The desk docking does not provide a separate power adapter.
Connect the power adapter of the IPC to the power port of desk docking directly. The desk docking's input/output expansion
functions will only work if power supply is connected.
Display mode
Note
The display settings are automatically saved for future use.
Display Mode
Description
Extend Mode (Default)
This mode is recommended when operating tablet with keyboard or mouse device.
Mirror Mode
This mode is recommended when operating the tablet with touch screen.
SIMATIC IPC MD-34A Desk Docking
A5E52413713
-AA, 05/2023
