Siemens Hicom 300E User manual

s
Convenience
mobile unit 2000C
for Hicom 300E
Hicom cordless E
Operating
instructions

2

3
Contents
Safety notes 6
Notes on mobile unit use........................................................................6
Notes on battery use ..............................................................................6
Meaning of symbols: ..............................................................................6
General 7
Operating elements, unit parts ...............................................................7
Explanation of display, display keys.......................................................8
Hicom cordless E ...................................................................................9
Features .................................................................................................9
Environmental conditions.....................................................................10
General notes on operation..................................................................10
Radio range.......................................................................................... 11
Leaving the radio network ....................................................................11
Fitting the attachment clip.................................................................... 11
Cleaning your mobile unit ....................................................................12
Lending/disposing ................................................................................12
User guidance, selecting functions.......................................................12
Putting into service 13
Inserting batteries in the mobile unit ....................................................13
Charging the batteries ..........................................................................14
Logging mobile units onto a telephone system ....................................15
Activating/deactivating mobile units.....................................................15
Activating/deactivating keypad protection............................................15
Telephone functions 16
Internal dialling.....................................................................................16
Dialling the Switchboard.......................................................................16
External dialling ...................................................................................17
Answering calls ....................................................................................18
Call Pickup ...........................................................................................19

4
Contents
Second Call Waiting.............................................................................20
Timed Reminder ..................................................................................21
Number redial - last 5 numbers............................................................22
System Abbreviated Dialling................................................................22
Night service ........................................................................................23
Switching functions 24
Automatic callback ...............................................................................24
Transfer................................................................................................24
Consultation during a call.....................................................................25
Toggle - switching between 2 users......................................................25
Conference...........................................................................................26
Call forwarding .....................................................................................28
Service menu .......................................................................................30
Telephone book 31
Saving numbers ...................................................................................31
Entering letters/characters and digits ...................................................32
Dialling a number from the telephone book .........................................33
Storing numbers from redial.................................................................33
Deleting / Editing an entry....................................................................34
Deleting the telephone book ................................................................35
PIN Features 36
Electronic Telephone Lock ...................................................................36
Mobile Class of Service .......................................................................37
Saving/modifying the mobile unit PIN..................................................38
Settings 39
Overview - settings ..............................................................................39
Setting the language ............................................................................40
Settings - handset, tone ringing... ........................................................40
Setting the station ................................................................................42

5
Contents
Tones - keys, battery, range... ..............................................................43
Overview - Tones .................................................................................44
Appendix 45
Fault clearance.....................................................................................45
Add-ons ................................................................................................46

6
Safety notes
Notes on mobile unit use
lDo not use mobile units in damp environments (bathroom/shower). The
units are not splash proof.
lDo not use the mobile unit in environments where there is danger of
explosion.
lMake sure that the telephone is at least one meter away from any
medical equipment.
lThe mobile unit is not suitable for people with hearing aids since the
radio signals interfere with hearing aids, producing a very unpleasant
humming sound if the volume is turned up high enough.
Recommendation: Gigaset 2000C headset,
see page 46.
Notes on battery use
lOnly use approved nickel-cadmium batteries (NiCad batteries), see
page 13.
lNever use other batteries or normal (non-rechargeable) batteries.These
batteries can cause short-circuit and may be subject to damage
(dangerous). Read the labels in the mobile unit and charging shell
battery compartments.
Meaning of symbols:
lWarning! Please read safety note
in the instructions.
lUse rechargeable batteries only
and observe polarity.
lAvoid contact with water and fire.
lDo not use non-Siemens charging devices. This could damage the
batteries.
lSuitable add-on charging shells are available from Siemens.

7
General
Operating elements, unit parts
1
2
3 11 13
4
5
6
7
12
8
9
10
Front Rear
1 Receiver inset 8 Recall key
2 Display (illuminated) 9 Microphone
3 Display keys 10 On/Off/Protect key
4 Menu key 11 Ringer loudspeaker
5 End call key 12 Battery compartment/lid
6 Talk key 13 Attachment clip
7 Alphanumeric keypad
Figure 1: Operating elements, unit parts

8
General
Explanation of display, display keys
The mobile unit features a 4-line display with 16 characters per line. Depend-
ing on the situation, the display shows:
ldigits, e.g. dialled numbers
ltext, e.g. the current station (system) or call options
lsymbols, e.g. ringing or battery symbol
land in the last line the current functions of the two display keys
Note:
The display texts are displayed in German (default setting), English,
French, Italian, Spanish or Dutch.
Setting the language, see page 40.
Display key functions
dCalls up the directory
SVC
Calls up T-Net services
INT
Sets up internal connections
zRedials number
{Cancels procedures
WCalls up supplementary menu
YZ Selects menu item or entry
<<< >>>
Moves to left or right
XDeletes characters
OK
Confirms actions

9
General
Hicom cordless E
The Hicom® cordless E DECT* telephone system comprises
lthe radio switching module for the Hicom 300E system
lbase stations (transmitter/receiver)
l2000C or 2000S mobile units (cordless telephones)
land the Gigaset 2000L charging shell (optional)
Features
Each mobile unit can log on to and be used by up to 4 DECT systems, e.g.
Hicom cordless E and Gigaset** 2000. This allows you to employ all the
features of the system in question. The features offered by Hicom cordless E
2000C include:
lmobile unit with 4-line, illuminated display, e.g. for displaying
– the dialled call number,
– the current applicable functions,
– the operating status and settings.
lStatus-dependent functions
lNumber redial for the last five numbers dialled
lTelephone book in the mobile unit for 100 entries
lInternal and external calls in the entire Hicom cordless E radio network
lRoaming (the user can roam throughout the entire radio network and
still receive all internal and external calls under one call number)
lAutomatic call transfer from base station to base station (handover)
lEnhanced user guidance with displays in German, English, French,
Italian, Spanish or Dutch (can be set)
lAutomatic callback for internal calls
lCall transfer to internal users
lConsultation during a call
lUse of all important Hicom functions that do not require a system-
specific telephone
lProtection against inadvertent key activation
lLong-lasting batteries:(NiCd 600ma, NiMH 1100ma, NiMH 1300ma)
– between 70 and 130 hours in stand-by mode
– between 7 and 13 hours when phone is in use

10
General
Environmental conditions
lPlease read the safety notes on page 6.
lMake sure that the mobile unit is at least one meter away from medical
equipment, fire alarm equipment and other radio equipment (e.g. radio
telephones or radio pagers), otherwise its performance may be im-
paired, e.g. by interference.
lThe mobile unit and charging shell should not be placed near other
electronic devices, such as Hi-fi, office or microwave devices, as this
may adversely affect operation of your telephone and/or the electronic
equipment.
lDo not expose the mobile unit or charging shell to direct sunlight or
other sources of heat.
lUse the mobile unit at temperatures between 0°C and +45°C.
lDo not expose the mobile unit to damp environments.
lAvoid using the mobile unit and charging shell in rooms where there is
a lot of dust.
General notes on operation
lWhen operating the mobile unit a basic distinction is made between
– telephone/switching functions, e.g. when a call is in progress
and
– local functions, display when mobile unit is on.
lAn incoming call cancels the local functions.
lLocal functions can be cancelled before saving with the function key
.or the end call key.
lLocal functions can also be performed in the charging shell.
lDisplay texts from the system are shown without muted vowels and
special characters.
lThe display of call charges at the mobile unit depends on the Hicom
setting.
lYour telephone book entries, all settings and your PIN are not lost,
even if you remove the batteries.
lThe mobile unit can be used as a second executive telephone with
limited functions.

11
General
lThe device offers a high level of privacy. No protection can be guaran-
teed against illegal bugging using other radio receivers.
Radio range
lDepending on the environment, the range in the open is up to 300 m.
lIn buildings the range extends to up to 50 m (depending on the room
and building layout and construction).
lIf you leave the system’s base station radio range during a call, you will
hear the range tone. The quality of the voice connection drops, espe-
cially if you move. For a better voice connection, move back into the
base station range.
lThe radio connection is lost if you exceed the range. This is identified
by the display Search station .
lPlease consult your system administrator in the case of on-going range
problems.
Leaving the radio network
lIntegrated power saving function: if you leave the base station radio
range when the mobile unit is switched on, the interval between
synchronisation attempts gradually increases – this increases the
battery life in stand-by mode.
lTo ensure that the mobile unit can be used as soon as you return to the
radio network, you should immediately log it on again:
lPress the On/Off key until the display is blank, press the On/Off key
again when the mobile unit is on.
lIf you intend to leave the radio network and take your mobile unit with
you, we recommend that you turn the mobile unit off in order to save
the batteries.
Fitting the attachment clip
An attachment clip is supplied with your mobile unit to facilitate portability.
To use this clip, simply attach it to the rear of the mobile unit.
Slot the protrusions on the attachment clip into the holes on the sides of the
mobile unit (at display level).

12
General
Cleaning your mobile unit
Tocleanthe mobile unitandthechargingshell,simplywipe them withadamp
or antistatic cloth. Never use a dry cloth (since this can generate electrostatic
charges and discharges) or abrasive cleaning agents.
Lending/disposing
lIf you lend your mobile unit to someone else, please make sure you
include the operating instructions with it.
lPlease dispose of defective batteries, mobile units and charging shells
in accordance with legal requirements.
User guidance, selecting functions
The user-friendly display system guides the user quickly and effectively
through the entire range of features available with this telephone system.
For information on setting the language to German, English, French, Italian,
Spanish or Dutch, see page 40.
Differentfunctionscanbeselecteddependingonthestatusofthemobileunit.
Only functions applicable to the relevant status are displayed.

13
Putting into service
Inserting batteries in the mobile unit
lRead the safety notes on page 6 first!
lHold the mobile unit with the dialling keypad facing downwards. A
battery compartment for 2 batteries is located in the lower part of the
mobile unit.
lTo open the battery compartment, slide the lid upwards in the direction
of the arrow (see Figure 2).
lInsert the two batteries supplied in the battery compartment as shown
in Figure 2.
Ensure that the batteries are inserted correctly (polarity illustrated on
the label in the battery compartment).
The battery compartment cannot be closed if batteries are inserted
incorrectly.
lSlide the lid of the battery compartment downwards into the grooves on
the mobile unit (see Figure 2) until the compartment is closed.
Figure 2: Rear of mobile unit, battery compartment open

14
Putting into service
Charging the batteries
Batteries supplied are not charged.
Note:
lNew batteries should be initially charged for a minimum period of 16
hours without interruption – irrespective of any messages on the
display.
lIn order to maintain max. battery storage capacity for as long as
possible, the mobile unit should only ever be inserted in the charging
shell when the batteries are empty.
lThe batteries warm up during charging.
lOnly the following spare batteries are permitted:
Panasonic P-60 AA, Philips R6 NC-P, Saft RC6, UCAR RC6, DAIMON
ACCU 1000, Varta 751RS, Sanyo N-3UN and N-3UC.
lInsert the mobile unit in the Gigaset 2000L charging shell to charge the
batteries. The mobile unit can be inserted with the display facing
upwardsor downwards.
The left LED Bon the charging shell lights up while the batteries
are charging.
Charging times:
– Batteries in the mobile unit: 4 - 5 hours
– Replacement batteries in the reserve compartment of the
charging shell: 20 - 24 hours
Battery life:
These times are only achieved after several charging and discharging
cycles.
– between 70 and 130 hours in stand-by mode
– between 7 and 13 hours when phone is in use.
UDisplay at 100% V Display at 66%
eDisplay at 33% =Display when batteries are
almost flat

15
Putting into service
Logging mobile units onto a telephone system
Your phone should be logged on and ready to use. If this is not the case then
contact your System Administrator.
Note:
lIn the case of Hicom cordless E, the mobile units are not logged on to
stations (base stations), but rather to the Hicom 300E telephone
system. In this case, Station always means system.
Activating/deactivating mobile units
Activating the mobile unit:
hPresstheOn/Offkey-acknowledgementtoneisheard.
Deactivating the mobile unit:
hPresstheOn/Offkeyuntilthedisplayisclear–youhear
the acknowledgement tone.
Activating/deactivating keypad protection
This allows you to protect your mobile unit against inadvertent key activation,
e.g. when carrying it in your bag. Call are signalled even if keypad protection
is on and can be answered as in the same way as when the telephone is
switched on.
Prerequisite: mobile unit is activated.
Activating keypad protection:
hPress the On/Off key for less than 1 second.
Keyboard Display when keypad protection is on.
protected
Deactivating keypad protection:
hPress the On/Off key for less than 1 second.

16
Telephone functions
Internal dialling
oDial an internal number
Also see Note:
cPress the “Green” talk key.
Call Conductthecall–thenumberandthenameoftheuser
are displayed.
You can now scroll through the functions offered with
the
>
display key and if necessary, execute a function.
Ending a call:
aPress the “Red” end call key or place the mobile unit in
the charging shell.
Note:
lYou can cancel the dialling operation by pressing
DIAL AGAIN
.
lThe dialled number is automatically stored for number redial, see page
22.
lIf the called party is busy or does not answer, you can store an auto-
matic callback request by pressing
CALLBACK
, also see page 24.
Dialling the Switchboard
e.g. 9Enter the "Switchboard code", e.g. "9"
cPress the “Green” talk key.
Ending a call:
aPress the “Red” end call key or place the mobile unit in
the charging shell.

17
Telephone functions
External dialling
External code
e.g. 0Enter the "External code", e.g. "0"
oDial the external number – the digits entered are
zoomed at the beginning.
Also see Note:
cPress the “Green” talk key.
Call Conduct the call.
You can now scroll through the functions offered with
the
>
display key and if necessary, execute a function.
Ending a call:
aPress the “Red” end call key or place the mobile unit in
the charging shell – the call charges are displayed
depending on the system settings.
Note:
lYou can cancel the dialling operation by pressing
DIAL AGAIN
.
lDigit size is reduced in the case of longer numbers.
lInternal calls only can be conducted if No access rights is displayed.
lThe dialled number automatically stored for number redial.

18
Telephone functions
Answering calls
The mobile unit’s ringing tone is audible. Depending on the user (internal/
external), the number and the name of the caller is displayed.
lThe mobile unit is in the charging shell:
Simplyremove themobile unit fromthe charging shell.
or
lThe mobile unit is not in the charging shell:
cPress the “Green” talk key.
Call Conduct the call.
You can now scroll through the functions offered with
the display key and if necessary, execute a function.
Ending a call:
aPress the “Red” end call key or place the mobile unit in
the charging shell.

19
Telephone functions
Call Pickup
The Call Pickup feature allows you to answer any ringing extension in your
pickup group from your telephone.
Activate Call Pickup
An extension within your pickup group is ringing
a ping ring will alert you to an incoming call
Display shows Source of call and Destination of
call
oDial ∗∗
∗∗
∗33
cPress the “Green” talk key.
You have now answered the call

20
Telephone functions
Second Call Waiting
Thisfeatureallowsasecondcalltocamponyourextensionwhenyouarebusy
on a call.
The caller will receive ringing tone instead of busy tone.
Activate Second Call Waiting
üpress the INT Key
>
Scroll to
SWITCHES
.
SWITCHES
Press the display key.
SECOND CALL
Press the display key.
Display shows Camp-on is off
ACTIVATE
Press the display key.
Display shows Second call activated
Deactivate Second Call Waiting
üpress the INT Key
>
Scroll to
SWITCHES
.
SWITCHES
Press the display key.
SECOND CALL
Press the display key.
Display shows Camp-on is on
DEACTIVATE
Press the display key.
Display shows Second call deactivated
