Siemens CENTRA Life User manual

CENTRATM Life
User Guide
Behind-the-Ear System
s

2
Congratulations !
As the owner of a new hearing system, you may once again
enjoy the sounds of your environment, and conversation
with your family and friends.
These instructions as well as guidance from your hearing
instrument specialist will help you understand how your new
hearing system works. In this guide, you’ll find instructions
about insertion, removal and use of your CENTRA LifeTM hea-
ring system. There are also tips and information on proper
handling, cleaning, care and changing of the batteries. In
addition, a troubleshooting section is offered for your refe-
rence.
Your hearing improvement with a hearing system depends
on the fit of the hearing instruments, the type and degree
of hearing loss, and proper diagnostic testing. Of course, a
hearing system cannot restore normal hearing, and not
everyone will benefit equally.
More than 80 percent of individuals with a hearing loss have
a hearing loss in both ears. Studies show that even when a
hearing loss is worse in one ear, most people with a hearing
loss in both ears will benefit from wearing two instruments.
Remember, a hearing system consists of finely-tuned devices
that have been specially designed and expertly adjusted for
your individual needs. Proper care and handling will ensure
the best possible performance of your CENTRA Life hearing
system.

3
Contents
Page
Your CENTRATM Life BTE (behind-the-ear) hearing system 4
Battery insertion and removal 5
Inserting and removing your CENTRA Life 8
Turning your CENTRA Life on and off 9
e2e wirelessTM 10
Using the directional microphone 12
Maintenance and care 13
Important notes 14
Troubleshooting tips 15

g
h
j
k
a
s
g
d
h
j
k
4
Your CENTRA Life BTE*
hearing system
Note:
• Always wear the LifeTube with the LifeTip.
• Make sure that the LifeTip is completely attached
to the LifeTip Adapter.
• Change the LifeTube or LifeTip when they are cracked.
• Put the LifeTube with the LifeTip carefully and not too
deep into the ear.
• Use the LifeTube and LifeTip only in the way described
in this user guide.
*) BTE – behind-the-ear
Features
1. LifeTube
2. LifeTip
3. LifeTip Adapter
4. Earhook (optional)
5. Microphone openings
6. Cover for programming
socket
7. Battery compartment
8. Color-coded typeplate
red = right instrument
blue = left instrument
CENTRA Life
f
Optional: CENTRA Life
Standard earhook

5
Battery insertion and removal
Handling the battery
Remove the tab on you battery
only when you are ready to use it.
Inserting the battery
Open the battery compartment
with your fingernail as shown in
the illustration.
Swivel open the battery compart-
ment door, if not already open.
Place the proper size battery (Type
312) so that the "+” symbol on the
battery coincides with the "+” mar-
ked on the battery compartment.
Three useful tips:
• The positive (+) side of the battery is always the
smooth side. You can recognize the negative (-) side
by the colored ring.
• Always keep spare batteries with you
• If you feel you cannot change the battery by yourself,
ask someone to help you: a family member, friend or
your hearing instrument specialist.

6
Close the battery compartment by
gently pressing the bottom of the
door upward with your finger tip.
Do not force the door shut. If
it does not close easily, check to
see if the battery was inserted
properly. When the battery door
is completely closed, your hearing
instrument is ready for use.
Removing the battery
Normally the battery drops out
when the compartment is comple-
tely open. If the battery does not
come out, lightly tap the system or
push the battery out with a pencil
as shown.
Low battery indicator
Your hearing system may be programmed to inform you
when the battery should be replaced for best system perfor-
mance. You may hear an intermittent series of beeps and/or
experience low amplification power or volume. Change the
battery when either of these occurs.
When using a remote control
If you have an ePocket remote control, the battery
status can be checked using the "data read out” function.
(See the ePocket user guide for more information).

7
Caution:
Keep batteries and instruments away from the
reach of small children.
Batteries can be harmful if swallowed.
If swallowed consult a physician or a hospital
immediately.
Change the batteries when any of the following occur:
- volume becomes softer or weak
- you hear a battery signal beep
- you see empty battery status on the display of
your ePocket.
Do NOT throw used batteries into household trash.
Return them to your hearing instrument specialist for
environmentally correct disposal.
Power-on-delay
Your CENTRA Life hearing instrument may be equipped with
a “power-on-delay” feature. In this case the hearing system is
automatically turned on with a delay of 12 seconds, so that
you may insert the hearing instrument into your ear without
experiencing unpleasant feedback (whistling).

8
Inserting and removing
your CENTRA Life
Make sure that your hearing
instrument is turned off. Hold
the LifeTip Adapter or earmold
between your thumb and index
finger and insert it carefully into
your ear canal. You may find it
helpful to pull your ear slightly
upward or to the back. Gently
work the LifeTip Adapter with the
LifeTip or earmold into its proper
position by adjusting it until it is
firmly seated in your ear. Once
inserted, you should feel whether
the LifeTip Adapter with the
LifeTip or earmold is placed cor-
rectly. Next, place your hearing
instrument behind your ear and
turn it on.
Tip:
Practice inserting and removing
your hearing instrument correctly.
An easy way to practice is to sit
down at a table. Place a mirror in
front of you and prop your elbows
on the table so you can guide
your hands easily and safely. This
will help you stay relaxed and
comfortable while you practice.

9
Turning your CENTRA Life
on and off
To turn off
Press the battery compartment to
the rear down to the first stop to
turn the instrument OFF.
To turn on
Fully close the battery compart-
ment to turn the instrument ON.
Your CENTRA Life hearing system automatically turns on
when a battery is inserted and the compartment door is
closed completely.

10
e2e wirelessTM
Unique to your CENTRA Life hearing system is the e2e
(ear-to-ear) wireless technology. The wireless functionality...
... automatically adjusts both of your hearing instru-
ments simultaneously to different listening situations
if activated by software.
... allows use of accessories including the ePocket
(bi-directional remote control) function.
... provides synchronization of the settings in the system.
If you change the volume or program on one hearing
instrument, the other is automatically adapted.*
For further information on the ePocket, contact your hearing
instrument specialist or refer to the ePocket user guide. Your
hearing instrument specialist can activate or deactivate the
wireless functionality of your hearing system. The ePocket
can be activated or deactivated separately.
Note:
The performance of the e2e wireless could be affected by
electro-magnetic interference, such as a computer monitor or
halogen lamp systems controlled by a switching power supply.
Move away from the source of interference if you experience
difficulty.
* Change volume and program only with the ePocket.

11
Wireless remote control –
ePocket
(accessory)
The e2e wireless function of your
CENTRA hearing system supports
ePocket, the bi-directional remote
control from Siemens. With ePocket,
you can change the program and
volume of your hearing system
and read out the system settings.
For further information on ePocket,
contact your hearing instrument
specialist or refer to the ePocket
user guide.
ePocketTM accessory
for CENTRA hearing systems
Note:
In case the hearing aid is controlled by another person’s
remote control unit (RCU), please return RCU and hearing aid
to the service department for change of the transmission key.

12
Using the directional
microphone system
Your CENTRA Life hearing system has a directional microphone
system, which can be programmed to your individual needs.
It can be set to an automatic mode so the CENTRA hearing
system automatically adjusts the microphone system from
omni-directional to directional mode and back, depending
on the hearing situation.
For example:
A typical situation for the directional mode is a face-to-face
conversation in a noisy environment.
A typical situation for the omni-directional mode is when you
are in more quiet environments and want to hear the sounds
around you.
Your hearing instrument specialist will program the operation
of the directional microphone system to function either auto-
matically or in conjunction with the program button based on
your individual hearing requirements and preferences. If the
directional microphone system is not programmed to function
automatically, your hearing instrument specialist can instruct
you on its use.

13
Care tips:
• You should place your hearing
system in a "dry aid kit" with a
special moisture-attracting capsu-
le overnight. The drying capsule
draws damaging moisture out of
the system.
• Your hearing instrument specialist
can provide you with special care
sets and drying capsules to keep
your hearing system in good
condition.
Maintenance and care
Your new CENTRA Life hearing system is a highly sensitive
system. Proper care and handling will ensure the best possi-
ble performance.
Earwax may accumulate on your LifeTube, LifeTip or earmold.
If not cleaned regularly you can damage the hearing systems
or cause health problems. Therefore:
1. Caution: Do NOT put the hearing
system in water.
2. Occasionally bring your hearing
system to your hearing instrument
specialist to have the LifeTube or
the hearing tube changed or
cleaned and the system checked.
Always store your hea-
ring system in the case
provided.

14
Important notes
• Never expose your hearing system to extreme temperatures
or high humidity. Do not store it in direct sunlight. Do not
wear it when taking a shower or when using hairspray.
• As with all electrical, non gas-encapsulated systems, the
hearing system must not be operated in explosionendange-
red rooms.
•
Do not wear your hearing system during short-wave therapy-,
or if you work with medical treatments that use strong
magnetic or high-frequency fields, such as magnetic reso-
nance tomography, X-rays or microwave oven.
• Make sure to turn off the system when not in use.
This helps preserve your batteries.
• When not wearing your system for long periods of time,
remove the batteries. This prevents leakage, which can
some times occur in batteries. Replace batteries that have
a leakage immediately.
• This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
• Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
IC: 267AB-WL001

15
Troubleshooting tips
Your CENTRA Life hearing system is an extremely reliable device.
However, should a problem occur, this can usually be corrected
quickly. Use this trouble shouting guide to sort out simple
problems.
PROBLEM CAUSE POSSIBLE SOLUTION
System Weak or dead Replace with new
sound is weak battery battery
System clogged Clean earmold
Volume too low Turn up volume with the
ePocket*
System Improper seating in Try reinserting the instru-
whistles ear (only with stan- ment until it fits securely
dard earhook)
Volume too high Lower volume with the
ePocket*
Clogged with wax or Clean Life Tube or ear
excessive wax in mold or contact your
ears hearing instrument
specialist
Crack in Life Tube or Contact your hearing
earmold tubing instrument specialist
Sound is Volume too high Lower volume control*
distorted or
intermittent Weak battery Replace battery
*) Only possible with ePocket (remote control)

16
If you still encounter problems after trying these suggestions,
consult your hearing instrument specialist.
PROBLEM CAUSE POSSIBLE SOLUTION
System Battery compartment Gently close the battery
whistles is not completely compartment completely
closed
Weak battery Replace battery
Hearing System not Turn system on
system turned on
does not work
Battery compart- Gently close the battery
partment is not compartment completely
completely closed
Dead battery Replace with new battery
Battery polarity Make sure battery is
reversed inserted correctly
Power-on-delay is Wait and check after
active app. 15 seconds

17

18

19

Siemens
Audiologische Technik GmbH
Gebbertstraße 125
91058 Erlangen
Germany
www.hearing-siemens.com
Order-No.: A91100-M5100-1259-02-7600
Printed in Germany
0306.CG
1016 9405
Subject to change without prior notice.
0123
With the CE marking Siemens confirms compliance with the European Directive 93/42/EEC
concering medical devices.
Within the European Union, the marked equipment is covered by
"Directive 2002/96/EC of the European Parliament and of the Council
of 27 January 2003 on waste electrical and electronical equipment.
Amended by Directive 2003/108/EC" (WEEE).
