SIMATIC CP 4163-1
SIMATIC NET
S7-4100 - Industrial Ethernet
SIMATIC CP 4163
-1
Operating Instructions
12/2022
C79000
-G8976-C588-01
Preface
Properties and functions
1
LEDs, connections, QR code
2
Installation, connection,
commissioning, removal
3
Configuration
4
Diagnostics and
maintenance
5
Technical specifications
6
Approvals
A
Dimension drawings
B
Bibliography
C

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C588-01
Ⓟ
11/2022 Subject to change
Copyright © Siemens AG 2022.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 3
Preface
Validity
This description contains information on the following product:
•CP 4163-1
Article number 6DL4163-1EX00-0XE0
Hardware product version 1
Firmware version V1.0
Communications processor for SIMATIC S7-4100
The CP has a PN/IE interface for connection of the SIMATIC S7-4100 to
PROFINET IO/Industrial Ethernet.
View of the CP 4163-1
①
Front flap
②
LEDs for status and error displays (Page 17)
③
LEDs of the Ethernet ports for connection status and activity (Page 17)
④
Print of MAC address
⑤
Ethernet interface: 2 x 8-pin RJ45 socket (Page 40)
⑥
QR code (Page 20)
Figure 1 Display of the CP 4163-1

Preface
SIMATIC CP 4163-1
4Operating Instructions, 12/2022, C79000-G8976-C588-01
Purpose of the manual
These operating instructions supplement the SIMATIC S7-4100 system manual.
With the information in the operating instructions and the system manual, you will be able to
commission the communication processor (CP).
Documentation and other literature
The documentation for this device consists of these operating instructions.
You will find more information on assembly, installation and commissioning here:
•SIMATIC S7-4100 system manual
•CPU 4168-H equipment manual
You will find information on configuring here:
•PUD Manager
The Plant and User Documentation Manager is the help portal of PCS neo.
As of SIMATIC PCS 7 9.1 and 9.0, the PUD Manager Help Viewer is available to view the
documentation offline. By adding documentation packages, you expand and update the
scope of your individual user documentation. You can find the documentation packages
on the following page:
Link: (https://support.industry.siemens.com/cs/de/en/view/109748882)
You can find an overview of further reading and references in the Appendix of this manual.
Required experience
Knowledge of the following areas is required to install, commission and operate the device:
•General electrical engineering
•Automation engineering
•Knowledge of the documentation:
/2/ (Page 49)
•Knowledge of engineering with SIMATIC PCS neo
Current manual edition on the Internet
You will also find the current version of this manual on the Internet pages of Siemens
Industry Online Support:
Link: (https://support.industry.siemens.com/cs/ww/en/ps/15334/man)

Preface
SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 5
Abbreviations and terminology
Term
Synonyms
Notices
CP
Communications processor
The term "CP" is used in this document in place of the full product
name SIMATIC CP 4163-1.
If not otherwise specified, applies to the module and to the module
function.
CPU
Central processing unit
If not otherwise specified, applies to the module and to the module
function.
PCS neo
For the SIMATIC PCS neo process control system
PN/IE interface PROFINET interface;
Ethernet interface Interface for the connection to PROFINET/Ethernet.
•Mostly referred to as PROFINET interface in the user interface.
•PROFINET interface:
With exclusive reference to the PROFINET IO system in this
documentation.
•Ethernet interface:
–Mostly referred to as PROFINET interface in the user interface.
–With exclusive reference to Ethernet (Industrial Ethernet or
LAN) in this documentation.
Module
Module, Device, Product
Generally applies to the CP described here.
If another hardware component of the rack is described in the
respective context, it applies to it.
ES
Engineering station
PC station, with installed configuration software (e.g. for configuring
the controller and the associated distributed I/O).
Working with the PDF reader
•Cross references
In this manual, there are often cross-references to other sections. To be able to return to
the initial page after jumping to a cross-reference, some PDF readers support the
command <Alt>+<Left cursor key>.
•Search
To show all places where a term was found in a list, some PDF readers support the
command <Ctrl>+<Shift>+<F>.
License conditions
Note
Open source software
The product contains open source software. Read the license conditions for open source
software carefully before using the product.
You will find license conditions in the following document on the supplied data medium:
•OSS_CP4163-1_99.pdf

Preface
SIMATIC CP 4163-1
6Operating Instructions, 12/2022, C79000-G8976-C588-01
Firmware
The firmware is signed and encrypted. This ensures that only firmware created by Siemens
can be downloaded to the device.
Note on firmware/software support
Check regularly for new firmware/software versions or security updates and apply them. After
the release of a new version, previous versions are no longer supported and are not
maintained.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. firewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customer’s exposure to
cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/industrialsecurity.
Observe the PCS neo security concept, see:
Link: (https://support.industry.siemens.com/cs/ww/en/view/109802560)
Device defective
If a fault develops, please send the device to your Siemens representative for repair. Repairs
on-site are not possible.
Decommissioning
Shut down the device properly to prevent unauthorized persons from accessing confidential
data in the device memory.
To do this, restore the factory settings on the device.

Preface
SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 7
Recycling and disposal
The product is low in pollutants, can be recycled and meets the requirements of the WEEE
directive 2012/19/EU "Waste Electrical and Electronic Equipment".
Do not dispose of the product at public disposal sites. For environmentally friendly recycling
and the disposal of your old device contact a certified disposal company for electronic scrap
or your Siemens contact.
Keep to the local regulations.
You will find information on returning the product on the Internet pages of Siemens Industry
Online Support:
Link: (https://support.industry.siemens.com/cs/ww/en/view/109479891)
SIMATIC NET glossary
The SIMATIC NET glossary describes terms that may be used in this document.
You will find the SIMATIC NET glossary in the Siemens Industry Online Support at the
following address:
Link: (https://support.industry.siemens.com/cs/ww/en/view/50305045)
Training, Service & Support
You will find information on training, service and support in the multilanguage document
"DC_support_99.pdf" on the Internet pages of Siemens Industry Online Support:
Link: (https://support.industry.siemens.com/cs/ww/en/view/38652101)

Preface
SIMATIC CP 4163-1
8Operating Instructions, 12/2022, C79000-G8976-C588-01

SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 9
Table of contents
Preface ................................................................................................................................................... 3
1 Properties and functions...................................................................................................................... 11
1.1 Application ........................................................................................................................ 11
1.2 Communication services .................................................................................................... 11
1.3 Further services and characteristics .................................................................................... 12
1.4 Configuration limits and performance data......................................................................... 13
1.4.1 Rack components............................................................................................................... 13
1.4.2 PROFINET IO characteristic data.......................................................................................... 13
1.4.3 Characteristic data Open User Communication ................................................................... 14
1.5 Requirements for use......................................................................................................... 15
1.5.1 Hardware requirements - CPUs........................................................................................... 15
1.5.2 Software requirements - Configuration............................................................................... 15
2 LEDs, connections, QR code................................................................................................................. 17
2.1 LEDs .................................................................................................................................. 17
2.2 PN/IE interface ................................................................................................................... 19
2.3 Connections on the slot and module .................................................................................. 20
2.4 QR code............................................................................................................................. 20
3 Installation, connection, commissioning, removal ............................................................................. 23
3.1 Important notes on using the device .................................................................................. 23
3.1.1 Notes on use in hazardous areas ........................................................................................ 23
3.1.2 Notes on use in hazardous areas according to ATEX / UKEX / IECEx / CCC-Ex ........................ 24
3.1.3 Notes on use in hazardous areas according to UL HazLoc and FM........................................ 25
3.2 Installation, removal and repairs in hazardous areas ........................................................... 26
3.3 Installing and connecting................................................................................................... 27
3.3.1 Connection: Slots and modules .......................................................................................... 28
3.4 Commissioning.................................................................................................................. 29
3.5 Disassembly....................................................................................................................... 30
4 Configuration....................................................................................................................................... 31
4.1 Security recommendations................................................................................................. 31
4.2 CP in the configuration....................................................................................................... 33
4.3 Creating and configuring a CP ............................................................................................ 34
5 Diagnostics and maintenance ............................................................................................................. 35
5.1 Diagnostics........................................................................................................................ 35
5.1.1 Diagnostics options............................................................................................................ 35
5.1.2 Diagnostics with SNMP....................................................................................................... 35

Table of contents
SIMATIC CP 4163-1
10 Operating Instructions, 12/2022, C79000-G8976-C588-01
5.2 Maintenance ..................................................................................................................... 37
5.2.1 Update firmware................................................................................................................ 37
5.2.2 Replacing a module without a programming device ........................................................... 38
5.2.3 Resetting to factory settings............................................................................................... 38
6 Technical specifications....................................................................................................................... 39
6.1 Technical specifications of the CP 4163-1........................................................................... 39
6.2 Assignment of the PN/IE interfaces..................................................................................... 40
6.3 Permitted cable lengths - Ethernet ..................................................................................... 40
A Approvals............................................................................................................................................. 41
B Dimension drawings............................................................................................................................ 47
C Bibliography ........................................................................................................................................ 49
Index.................................................................................................................................................... 51

SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 11
Properties and functions
1
1.1 Application
Automation system
The CP 4163-1 communications processor is intended for operation in the SIMATIC S7-4100
system.
The CP enables an additional connection of the SIMATIC S7-4100 to Industrial Ethernet and
PROFINET.
The CP has the following interface:
•PROFINET-capable Ethernet interface
The PROFINET/Industrial Ethernet interface (PN/IE interface) is designed as 2-port switch.
The 2-port switch allows the integration of the CP in a bus or a ring with media
redundancy.
1.2 Communication services
The CP supports the following communication services:
•PROFINET IO controller
PROFINET IO allows access to PROFINET IO devices.
•S7 communication with the following functions:
–Operator monitoring and control functions
–Data exchange over S7 connections
•TCP/IP / UDP
Communication is handled by the program blocks of the Open User Communication (T
blocks).
The following types of communication are available:
–ISO-on-TCP
–TCP native
–UDP
You can find information on configuring communication with systems that were not
configured with PCS neo in the online help for engineering.

Properties and functions
1.3 Further services and characteristics
SIMATIC CP 4163-1
12 Operating Instructions, 12/2022, C79000-G8976-C588-01
1.3 Further services and characteristics
•Media redundancy
Within an Ethernet network with a ring topology, the CP supports the media redundancy
protocol (MRP). You can assign the role of media redundancy manager and client to the
CP.
•Time-of-day synchronization over Industrial Ethernet using the following
configurable modes (alternative):
–SIMATIC mode
The CP receives MMS time-of-day messages and forwards these to the CPU or sends
them to a lower-level network as (time) master time frames.
–NTP (Network Time Protocol)
The CP sends timeofday queries at regular intervals to an NTP server and forwards the
time to the CPU.
Note
The time master in the rack is the CPU
Note the following fundamental behavior of the SIMATIC S7
-4100:
The CPU always synchronizes all modules in the rack.
•SNMP
The CP supports data queries using SNMP (Simple Network Management Protocol) in
version V1. For the supported MIBs, refer to the section Diagnostics with SNMP (Page 35).
•IP configuration
For the interface, you can configure how and by which method the CP is assigned the IP
address, the subnet mask and the address of a gateway.
•Diagnostic buffer
Diagnostic events of the CP are shown in the "Diagnostic view" of the engineering and
entered in the diagnostic buffer of the CPU.
•Detection of double IP addressing in the network
If duplicate addressing occurs in the network after a module replacement, the CPU detects
this.
Reaction of the CP when double addressing is detected: The red LED (ERROR) flashes and
an event is entered in the diagnostic buffer of the CPU.

Properties and functions
1.4 Configuration limits and performance data
SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 13
1.4 Configuration limits and performance data
1.4.1 Rack components
Use of multiple CPs
By operating several CPs, you can increase the configuration limits listed below for the station
as a whole.
The CPU does, however, have set limits for the entire configuration. Observe the information
in the documentation of the CPU, see /3/ (Page 49).
CP quantity
The following limits apply to the number of CPs in a station:
•Installation in the bus module
The number of CPs is dependent on the power supply:
–1 power supply module plugged
A maximum of five CPs can be plugged.
–2 power supply modules plugged (redundant power supply)
A maximum of four CPs can be plugged.
•Installation with U-connector
A maximum of five CPs can be plugged.
You can find more detailed information on the maximum number of modules and the
maximum configuration in the SIMATIC S7-4100 system manual; see /2/ (Page 49).
1.4.2 PROFINET IO characteristic data
Configuration limits of the CP as IO controller
The CP supports the following maximum configuration as a PROFINET IO controller:
Characteristic
Explanation / values
Number of operable PROFINET IO devices
256
Size of the input area over all PROFINET IO devices
Max. 8192 bytes
Size of the output area over all PROFINET IO devices
Max. 8192 bytes
Size of the IO data area per submodule of a module in an IO
device •Inputs: 256 bytes
•Outputs: 256 bytes
Size of the consistency area for a submodule
256 bytes
Number of submodules to be supported as CP for PN IO
controller
Max. 8192

Properties and functions
1.4 Configuration limits and performance data
SIMATIC CP 4163-1
14 Operating Instructions, 12/2022, C79000-G8976-C588-01
1.4.3 Characteristic data Open User Communication
Open User Communication (OUC) provides access to communication over TCP, ISO-on-TCP
and UDP connections.
Characteristic
Explanation / values
Number of connections
•Max. number of connections via T blocks:
(ISO-on-TCP + TCP + UDP) ≤63
of which:
–TCP connections: 0 ... 63 1)
–ISO-on-TCP connections: 0 ... 63
–UDP connections: 0 ... 63
Notes:
•1) Avoid overload at receiving end
The flow control on TCP connections cannot control permanent
overload of the recipient. You should therefore make sure that the
processing capabilities of a receiving CP are not permanently exceeded
by the sender (approximately 150 200 messages per second).
Maximum data length for program blocks Program blocks allow the transfer of user data in the following lengths:
•ISO-on-TCP, TCP: 1 to 32 kbytes
•UDP: 1 to 1472 bytes
LAN interface max. data field length generated
by CP per protocol data unit (TPDU = transport
protocol data unit)
•For sending and receiving
–ISO-on-TCP, TCP: 1452 bytes / TPDU
Restrictions for UDP
•Restrictions UDP broadcast / multicast
To avoid overloading the CP due to high broadcast / multicast frame traffic, the receipt of
UDP broadcast / multicast on the CP is limited.
•UDP frame buffering
Length of the frame buffer: At least 7360 bytes
Following a buffer overflow, newly arriving frames that are not fetched by the user
program are discarded.

Properties and functions
1.5 Requirements for use
SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 15
1.5 Requirements for use
1.5.1 Hardware requirements - CPUs
Only the following CPU that can be configured in PCS neo can be used as local CPU of the
communication module:
•CPU 4168-H
as of firmware version V4.0
Note
Keep the firmware version
of the communications modules up to date
Check regularly for security updates of the firmware and use them.
Information regarding product news and new firmware versions is available at the following
address:
Link: (https://support.industry.siemens.com/cs/ww/en/ps/15334/dl)
1.5.2 Software requirements - Configuration
Software for configuration and online functions
To configure and use the CP's full scope of functions, the following configuration tool is
required:
PCS neo version
Function of the CP
PCS neo V4.0 The full functionality of the CP can be configured with the
functions of the firmware version according to Preface
(Page 3). You can find more detailed information in the
"Released modules" documentation of PCS neo.

Properties and functions
1.5 Requirements for use
SIMATIC CP 4163-1
16 Operating Instructions, 12/2022, C79000-G8976-C588-01

SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 17
LEDs, connections, QR code
2
2.1 LEDs
①
Status displays of the CP (always visible)
②
LEDs (under the front panel of the CP)
Meaning of the LED displays
CP 4163-1 has the following three LEDs to display the current operating status and the
diagnostics status:
•Green: RUN
•Red: ERROR
•Yellow: MAINTENANCE

LEDs, connections, QR code
2.1 LEDs
SIMATIC CP 4163-1
18 Operating Instructions, 12/2022, C79000-G8976-C588-01
Table 2- 1 Meaning of the LED symbols
LED pattern
Meaning
LED is off.
LED lights up
LED flashes
LED flickers.
-
LED state is irrelevant.
Table 2- 2 Meaning of the LED displays
LED (green)
LED (red)
LED (yellow)
Meaning
RUN
ERROR
MAINTENANCE
•No supply voltage on the CP or
supply voltage too low
•CP was reset to factory settings
LED test during startup
CP startup
CP waiting for connection to CPU
•CP in RUN mode
•No fault
•A diagnostic event is present
•CP has started with retentive
configuration and waits for
connection to the CPU
Maintenance is demanded
Maintenance demanded and a
diagnostic event is present
•Module fault (LEDs flash
synchronously)
•Display during "Find device"
action (flash test):
All LEDs of the CP flash for 3
seconds.
Meaning of the LED displays of the PN/IE ports X1 P1 R / X1 P2 R
To signal whether a connection exists and data is being transferred each port has a two-color
LED (green/yellow):
•X1 P1 R LINK/ACT
•X1 P2 R LINK/ACT

LEDs, connections, QR code
2.2 PN/IE interface
SIMATIC CP 4163-1
Operating Instructions, 12/2022, C79000-G8976-C588-01 19
The following table shows the meaning of the various color combinations of the LEDs X1 P1 R
and X1 P2 R.
Table 2- 3 Meaning of the LEDs
LED (green)
LED (yellow)
Meaning
•No connection to the network
•No connection between port of the CP and the
communication partner. Currently no data is being
received/sent via the port.
The "node flash test" is being performed.
•Connection to the network is established
•Connection between port of the CP and a
communication partner is established.
Data is being sent or received via the port.
2.2 PN/IE interface
PN/IE interface
The CP is intended for operation in the SIMATIC S7-4100.
The CP has a PN/IE interface in accordance with 100BASE-TX, IEEE 802.3 with autocrossing,
autonegotiation and autosensing. This allows the station to be connected to Industrial
Ethernet.
The PN/IE interface is configured as 2-port switch. The 2-port switch allows the integration of
the CP into a bus or a ring with media redundancy.
Each port is set permanently to 100 Mb full duplex mode. Each port can be disabled
individually in the configuration.
Each port of the switch comes with an LED for simple diagnostics. For the meaning of the
LEDs, see section LEDs (Page 17).
You can find more information on the function of the PN/IE interface in the following
documentation: /2/ (Page 49)
You can find more information on the configuration limits of the PN/IE interface in the
following documentation: /3/ (Page 49)

LEDs, connections, QR code
2.3 Connections on the slot and module
SIMATIC CP 4163-1
20 Operating Instructions, 12/2022, C79000-G8976-C588-01
MAC addresses
The CP is supplied with three default MAC addresses with the following assignment:
•PN/IE interface:
The MAC address of the PROFINET interface is printed on the housing
(visible in the engineering at "Accessible devices in the subnet")
•One MAC address for each of the two ports of the PN/IE interface
The MAC addresses of the ports are used in PROFINET IO operation for detecting and
evaluating neighbor and topology relationships (LLDP).
2.3 Connections on the slot and module
Connections on the slot and module
You can find an overview of the connections on the slot and module in the appendix to the
following documentation: /2/ (Page 49)
2.4 QR code
