SIEMENS APOGEE TECHNOLOGY OPTION 1
A System Overview........................................................................................... 1
Protocol ........................................................................................................................1
Product Features ...........................................................................................................1
Size Notation – Part Numbers........................................................................................1
Installation ....................................................................................................... 2
Apogee P1 FLN Communication Module (HVAC10) .......................................................2
•PLC/SCADA Supervisor (4-wire only)...........................................................2
•Cable Specification.....................................................................................2
•Cable Routing ............................................................................................2
•Earthing/Grounding ...................................................................................2
•User Connections to the Main Serial Port (P1)..............................................3
•DIL Switch (SW1) Settings............................................................................3
•Terminators................................................................................................3
•Terminal Block (TB1) Connections...............................................................4
Fitting and Connecting to the Technology Box ................................................................4
Wiring Diagrams ..........................................................................................................5
Initial Check for Connection ..........................................................................................7
Understanding the LED Indications ................................................................................7
Initial Set-up for Apogee P1 ............................................................................ 9
Configuring the Drive....................................................................................................9
Troubleshooting ............................................................................................. 11
Point Database for Siemens Apogee P1 .......................................................................12
Point Database Cross Reference ..................................................................................14

1
Siemens Apogee P1 Communications Interface
SIEMENS APOGEE TECHNOLOGY OPTION
A System Overview
The Apogee P1 Technology Option provides a serial data port, allowing VSDs (variable speed
drives) to be linked to form a network. Using a PLC/SCADA or other intelligent device, this
network can be continuously controlled to provide supervision and monitoring for each VSD in
the system.
With each unit under local
control, the central
supervisor performs only
periodic setpoint updating,
control sequencing and data
collection.
In the system, the
PLC/SCADA supervisor
acts as the Master, and the
VSD as the Slave.
The network of VSDs can
be set-up using each unit’s
MMI/Operator Station.
Protocol
This card communicates using the Siemens Apogee P1 protocol. Any connections made to it
most comply with this protocol. Every effort has been made to maintain compatibility with
devices using this protocol.
Product Features
•Suitable for use with:
HVAC10 Drive Products software version 4.6 onwards
•Connection using 2 or 4-wire shielded twisted pair (RS485)
•Configured using Function Block inputs
•Protocol tag access for defined P1 parameters
Size Notation – Part Numbers
Size 1 HVAC10 drives use the 6053/APOG Apogee Technology Box.
All Size 2 and 3 HVAC10 drives use the 6055/APOG Apogee Technology Box.
Advantages with this type of control system
1. Multi-wire analog transmission from a central programmable
controller is replaced by a bussed digital system using serial
data transmission over differential twisted-pair wires.
2. Digital transmission is fundamentally less noise-prone than
analog methods, and the accuracy of the transmitted data is
unaffected by the transmission medium. The use of intelligent
devices at either end of the data link allows error checking to
be used. This virtually eliminates the effects of electrical noise
on data integrity. It is therefore possible to issue setpoints to
drives with much higher accuracy using this method.
3. The communication standard used allows up to 32 drives to be
connected to a single link which can be driven from a
computer serial port.
4. The chosen standard and protocol are compatible with other
Eurotherm Group products. Temperature controls, process
controls, data loggers and drives can communicate easily with
a common supervisory system.

2
Siemens Apogee P1 Communications Interface
Installation
WARNING!
Before installing, ensure that the drive and all wiring is electrically isolated and
cannot be made “live” unintentionally by other personnel.
Wait 5 minutes after disconnecting power before working on any part of the
system or removing the covers from the Drive.
Apogee P1 FLN Communication Module (HVAC10)
You can create a network of drives by linking a Master (PLC or Apogee controller) to one or
more HVAC10 drives fitted with this module.
Plug this Communication Module on to the front of the HVAC10 drive by removing its terminal
cover and fitting the product to the right-most Technology Box position.
Wiring is very simple - all connections are SELV (Safe Extra Low Voltage).
It is possible to establish serial communications without adhering to the following
recommendations, however, the recommendations will promote greater reliability.
PLC/SCADA Supervisor (4-wire only)
If possible, avoid using a PLC/SCADA supervisor which take its transmitter to a high impedance
state (tri-state) when idling. If it is unavoidable, then it is essential to use properly screened
cable.
Cable Specification
Use cable which has two twisted pairs,
with each pair individually screened as
shown. The characteristic impedance
should be in the range 100 to 165 Ohms.
Recommended Cable Specification
Recommended Cable SpecificationRecommended Cable Specification
Recommended Cable Specification
Characteristic Impedance 100-165Ωat 3-20MHz
Cable Capacitance <30pF/m
Core Diameter 0.34mm² (22 AWG)
Cable Type Twisted pair cable
Resistance <110Ω/km
Shielding Copper braid, or braid & foil
Note: One example: Belden B3079A cable meets the above specification.
Cable Routing
Daisy chain one drive to the next. The supervisor should be at one end of the run. Avoid spurs.
Earthing/Grounding
Connect the screens of both pairs of wires to ground at the supervisor. If possible, connect the
supervisor’s transmitter/receiver 0V reference to earth. Connect all screens as shown in the
following diagrams.
screen
insulation outer sheath
conductors
twisted pair

3
Siemens Apogee P1 Communications Interface
User Connections to the Main Serial Port (P1)
The serial port on the Option allows the following Apogee P1 links to be made.
RS485
RS485RS485
RS485
Electrical Connections 4-wire
differential
2-wire
differential
Number of transmitters and transceivers
allowed per differential pair of wires
32 drivers
32 receivers
32 transceivers
Maximum cable length 4000ft/1200 metres
Technology Box
6053 6055
Technology Box
123456
TB1
Terminal Block
1
2
1
2
PLG1
BI SYNCH
1
Switch SW1
Figure 1 Option showing Terminal Block TB1 and DIL Switch SW1
DIL Switch (SW1) Settings
Set this switch to select 2-wire or 4-wire operation, and to switch in a terminator for the last
drive in the system.
Switch
SwitchSwitch
Switch Status
StatusStatus
Status Description
DescriptionDescription
Description
1OFF
ON
4-wire (default)
2-wire
2OFF
ON
Terminator out (default)
Terminator in
Terminators
•The unit logically furthest from the supervisor must have switch 2 set to ON.
•All other units in the system must have switch 2 set to OFF.
The supervisor’s receiver input should also have a terminating resistor, chosen to match the
characteristic impedance of the cable, typically 100 to 165 Ohms.
1
2
ON
OFF
Switch SW1

4
Siemens Apogee P1 Communications Interface
Terminal Block (TB1) Connections
Terminal No.
Terminal No.Terminal No.
Terminal No. 2-Wire Designation
2-Wire Designation2-Wire Designation
2-Wire Designation 4-Wire Designation
4-Wire Designation4-Wire Designation
4-Wire Designation
1notused TXB
2notused TXA
30V 0V
4 Cable Screen (except B versions) Cable Screen (except B versions)
5 RXB/TXB RXB
6 RXA/TXA RXA
Fitting and Connecting to the Technology Box
Figure 2 Plug-in Technology Boxes
WARNING!
Ensure that all wiring is isolated.
IMPORTANT: Remember to set the switch positions on the DIL switch, SW1.
The Technology Option plugs into the right-hand position on the front of the drive, or in place of
the Operator Station/blank cover (SIZE 1 only).
It can be used with the Operator Station fitted, but for the HVAC10 SIZE 1 unit you must mount
the Operator Station remotely using the Panel Mounting Kit with connecting lead (6052). The
connecting lead enters the HVAC10 drive through the gland plate.
•Remove the terminal cover and screws.
•On the HVAC10 unit, plug the ribbon cable into the back of the Technology Box and into the
socket on the drive.
•Click the Technology Box into place in the recess on the front of the drive. If provided,
secure in position by tightening the captive screw on the bottom right hand corner of the
Option. On the SIZE 1 unit it will protrude slightly above the standard plastic enclosure.
•Make all user wiring connections. Refer to the Wiring Diagrams.
•Re-fit the terminal cover securely with the screws.
Technology
Box
Captive Screw
HVAC10 Size 2 & 3
6055
Technolog
y
Box
HVAC10 Size 1
screen connections
6053

5
Siemens Apogee P1 Communications Interface
Wiring Diagrams
0V
DRIVE
(slave)
PLC/SCADA
(master)
123456
BA0V SCR BA
123456
BA0V SCR BA
AB
GND
DRIVE
(slave)
last inverter in chain
ONOFF
1
2
1
2
ONOFF
1
2
1
2
Figure 3 2-Wire Wiring Diagram for the HVAC10 Size 2 & 3 Drive
RXA RXB
RECEIVE
0V 0V
DRIVE
(slave)
PLC/SCADA
(master)
123456
TXB TXA 0V SCR RXB RXA
TRANSMIT RECEIVE
123456
TXB TXA 0V SCR RXB RXA
TRANSMIT
TRANSMIT
TXA TXB
RECEIVE
GND GND
DRIVE
(slave)
last inverter in chain
ONOFF
1
2
1
2
ONOFF
1
2
1
2
Figure 4 4-Wire Wiring Diagram for the HVAC10 Size 2 & 3 Drive

6
Siemens Apogee P1 Communications Interface
0V
DRIVE
(slave)
PLC/SCADA
(master)
123456
BA0V SCR BA
123456
BA0V SCR BA
AB
GND
DRIVE
(slave)
last inverter in chain
ONOFF
1
2
1
2
ONOFF
1
2
1
2
Figure 5 2-Wire Wiring Diagram for the HVAC10 Size 1 Drive
RXA RXB
RECEIVE
0V 0V
DRIVE
(slave)
PLC/SCADA
(master)
123456
TXB TXA 0V SCR RXB RXA
TRANSMIT RECEIVE
123456
TXB TXA 0V SCR RXB RXA
TRANSMIT
TRANSMIT
TXA TXB
RECEIVE
GND GND
DRIVE
(slave)
last inverter in chain
ONOFF
1
2
1
2
ONOFF
1
2
1
2
Figure 6 4-Wire Wiring Diagram for the HVAC10 Size 1 Drive

7
Siemens Apogee P1 Communications Interface
Initial Check for Connection
With the correct connections to the active
PLC/SCADA supervisor, the MODULE
LED will be ON continuously and the
NETWORK LED will indicate the IDLE state
with a flash.
Understanding the LED Indications
Figure 7 Technology Option LEDs
HINT:
The general rule for LED indications is
“ON IS GOOD, OFF IS BAD”
Health and Run LEDs
HVAC10 Size 1 (6053) Technology Box
These LEDs reproduce the indications of the LEDs on the HVAC10 drive that are hidden when
the Technology Box is fitted.
HVAC10 Size 2 & 3 (6055) Technology Box
The board does not have its own Health or Run LEDs. The LEDs are either on the Operator
Station or blank cover.
Module LED
This indicates the set-up state of the Technology Box. The states indicated are those produced by
the FAULT parameter of the TEC OPTION function block.
Module LED Indication
Module LED IndicationModule LED Indication
Module LED Indication FAULT Parameter Indication
FAULT Parameter IndicationFAULT Parameter Indication
FAULT Parameter Indication Description
DescriptionDescription
Description
OFF SELF TEST Initialising
SHORT FLASH HARDWARE Hardware fault
FLASH TYPE MISMATCH Wrong type or disabled
LONG FLASH PARAMETER Set-up fault, parameter
values out-of-range
ON NONE Valid set-up, ready for
external communications
ON MODULE LED
FLASH NETWORK LED
HEALTH
NETWORK
MODULE
RUN
6053 Technology Box
HVAC10 Size 1 HVAC10 Size 2 & 3
TB1
SW1
6055 Technology Box
NETWORK
MODULE
PLG1

8
Siemens Apogee P1 Communications Interface
Network LED
This indicates the state of the connected network.
Network LED Indication
Network LED IndicationNetwork LED Indication
Network LED Indication Description
DescriptionDescription
Description
OFF NOT READY/DISABLED: Initialising.
FLASH IDLE: No data is being received from Network Control
Module.
LONG FLASH SOFT TIMEOUT: Drive not addressed in the last 10 seconds.
ON OK: Device has been addressed.
Note: The NETWORK LED can only be in the ON state when the MODULE LED is ON
continuously, indicating that the Option is ready for external communications.

9
Siemens Apogee P1 Communications Interface
Initial Set-up for Apogee P1
Configuring the Drive
Using the Operator Station (MMI) or other suitable PC programming tool, the TEC OPTION
function block requires configuring before the Apogee P1 option can be used.
The parameter names/functions in the TEC OPTION function block are inter-dependant and will
change with different parameter values and the various Technology Options that can be fitted.
The top function block diagram shows the ConfigEd Lite parameter names, which are also
displayed on the MMI if no Technology Option is fitted or an incorrect TYPE is selected for the
fitted Technology Option.
ConfigEd Lite is Eurotherm Drives’ Windows-based block programming software.
When the TYPE parameter is set to display RS485, the function block parameters take on new
identities, as shown in the lower Function Block diagram.
Selecting Siemens Apogee P1
(Select Advanced view level on the Operator Station and view the TEC OPTION function block).
•Select RS485 in the TYPE parameter
•Select P1 FLN in the PROTOCOL parameter
•Select the node ADDRESS (0 to 31)
•Select the BAUD RATE (default is 4800)
•Check the FAULT parameter for error messages and rectify if necessary
When setting values for parameters from ConfigEd Lite (or other suitable PC programming tool)
you are able to select any value in the parameter’s range, i.e. -32768 to 32767. If the value is
incorrect, i.e. it doesn’t correspond to a value that can be set using the MMI, then the FAULT
output parameter will be set to PARAMETER.
MMI Parameter Descriptions for Apogee P1
TYPE Range: Enumerated - see below
Selects the type of Technology Option. The TYPE parameter is automatically set when defaults
are loaded if a Technology Option is present.
Enumerated Value : Type
0 : NONE
1 : RS485
2 : PROFIBUS DP
3 : LINK
4 : DEVICENET
5 : CANOPEN
6 : LONWORKS
7 : CONTROLNET
8 : MODBUS PLUS
9 : ETHERNET
PROTOCOL Range: Enumerated - see below
Selects the protocol to be used.
Enumerated Value : Protocol
0 : EI ASCII
1 : EI BINARY
2 : MODBUS RTU
3 : P1 FLN
4 : METASYS N2
MMI Menu Map
Non-specific MMI view
1 SETUP
2 COMMUNICATIONS
3 TEC OPTION
TYPE
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
FAULT
VERSION
OUTPUT 1
OUTPUT 2
MMI Menu Map
MMI view
1 SETUP
2 COMMUNICATIONS
3 TEC OPTION
TYPE
PROTOCOL
ADDRESS
BAUD RATE
UNUSED 1
UNUSED 2
FAULT
VERSION
NETWORK STATE
NIGHT

10
Siemens Apogee P1 Communications Interface
ADDRESS Range: 0 to 31
Selects the Node address of this drive.
BAUD RATE Range: Enumerated - see below
Selects the Baud Rate.
Enumerated Value : Baud Rate
0 : 4800 (default)
1 : 9600
UNUSED 1
Parameter not used for this protocol.
UNUSED 2
Parameter not used for this protocol.
FAULT Range: Enumerated - see below
The fault state of the Technology Option.
Enumerated Value : Fault
0 : NONE no faults
1 : PARAMETER parameter out-of-range
2 : TYPE MISMATCH TYPE parameter not set to RS485
3 : SELF TEST hardware fault - internal
4 : HARDWARE hardware fault - external
5 : MISSING no option fitted
Also refer to Module LED, page 7.
VERSION Range: 0x0000 to 0xFFFF
The version of the Technology Option card. If no option is fitted then the version is reset to zero.
NETWORK STATE Range: Enumerated - see below
Shows the current Network State of the Technology Option card.
Enumerated Value : Network State
0 : OK network comms to this device
1 : SOFT TIMEOUT no comms addressed to this device
during last 10 seconds.
2 : ACTIVITY activity on the Serial Port but not to the device
3 : IDLE no comms on Serial Port
4 : NOT READY device not yet initialised for communication
5 : DISABLED Serial communication has been disabled (default)
Also refer to Network LED, page 8.
NIGHT Range: FALSE/TRUE
Shows the Night occupancy set by the FLN P1 network.

11
Siemens Apogee P1 Communications Interface
Troubleshooting
LED Indications Cause/Symptom Remedy
NETWORK MODULE
(OFF)
No power at the drive. Check and apply power to the drive.
Technology Box/Option not installed
correctly.
Check connections between Technology
Box/Option and drive. On the HVAC10 Size 1,
check the ribbon cable.
Hardware fault.
HVAC10 Size 1 WARNING:
Remove the terminal cover and the
Technology Box whilst connected to
see the drive’s HEALTH and RUN
LEDs.
BEWARE OF ELECTRIC SHOCK.
If HEALTH and RUN LEDS are OFF, replace the
drive, else replace the Technology Box/Option.
The self-test has failed. Replace the Technology Box/Option.
Incorrect Technology Box/Option
fitted or selected.
Fit the correct Technology Box/Option or select the
matching value for the TYPE parameter in the TEC
OPTION function block. (TYPE = RS485).
Set-up fault. A TEC OPTION
parameter is out-of-range.
Select the correct value for the parameter in the
TEC OPTION function block.
NOT READY/DISABLED:
Initialising.
If this condition persists for longer than 10 seconds
check wiring to RXA and RXB terminals. It may be
transposed.
IDLE:
No data is being received from
Network Control Module.
Enable the PLC/SCADA application program.
Check that switch SW1:1 is ON, i.e. selected for 2-
wire operation.
Check power for all equipment on the network,
e.g. RS232 to RS485 converter or repeater.
SOFT TIMEOUT:
Drive not addressed in the last 10
seconds.
Check the PLC/SCADA program is running.
OK

12
Siemens Apogee P1 Communications Interface
Point Database for Siemens Apogee P1
Point
Number
Point
Type
Subpoint Name Factory Default
(SI Units)
Engr. Units
(SI Units)
Slope
(SI Units)
Intercept
(SI Units)
On Text Off Text
1 LAO CTRL ADDRESS 1 – 1 0 – –
2 LAO ED_HVAC10 Error! Reference –10––
3 LAI Freq Output 0 Hz 0.1 0 – –
4 LAI Freq Demand 0 Hz 0.1 0 – –
5 LAI Speed 0 RPM 0.1 0 – –
6 LAI Current 0 A 0.1 -1638.3 – –
7 LAI Torque 0 PCT 0.1 -1638.3 – –
8 LAI Power 0 Kw 0.1 0 – –
10 LAI Drive KWH 0 KWh 0.1 0 – –
12 LAI Runtime 0 Hrs 1 0 – –
13 LAI DC Bus Volts 0 Volts 1 0 – –
14 LAI Output Volts 0 Volts 1 0 – –
20 LAO OVRD Time – – – – –
21 LDI Direction FWD – 1 0 REV FWD
22 LDO Direction SP FWD – 1 0 REV FWD
23 LDI RUN STOP – 1 0 RUN STOP
24 LDO RUN SP STOP – 1 0 RUN STOP
25 LAO Stop Mode 0 – 1 0 – –
27 LDO Coast Stop FALSE – 1 0 TRUE FALSE
28 LDO Fast Stop FALSE – 1 0 TRUE FALSE
29 LDO Day.Night DAY – 1 0 – –
30 LAO Curr Limit 150.0 PCT 0.1 0 – –
31 LAO Accel Time 1 10.0 SECS 0.1 0 – –
32 LAO Decel Time 1 10.0 SECS 0.1 0 – –
33 LAO Stop Decel T 10.0 SECS 0.1 0 – –
34 LAO Fast Decel T 0.1 SECS 0.1 0 – –
35 LDO Run Enable ENABLE – 1 0 ENABLE DISABL
37 LAO Reference SP 0 PCT 0.1 -1683.3 – –
40 LDI O/P Relay 1 OFF – 1 0 ON OFF
41 LDI O/P Relay 1 OFF – 1 0 ON OFF
42 LDI O/P Relay 3 OFF – 1 0 ON OFF
44 LDO Flycatch EN FALSE – 1 0 TRUE FALSE
45 LDI Flycatching FALSE – 1 0 TRUE FALSE
a. Points not listed are not used in this application.
b. A single value in a column means that the value is the same in English units and in SI units.
c. Point numbers that appear in brackets { } may be unbundled at the field panel.
continued on next page…

13
Siemens Apogee P1 Communications Interface
Point Database for Siemens Apogee P1 cont.
50 LAO Analog 1 Out 0 PCT 0.01 -163.83 – –
51 LAO Analog 2 Out 0 PCT 0.01 -163.83 – –
52 LAO Analog 3 Out 0 PCT 0.01 -163.83 – –
53 LAI Analog In 1 0 PCT 0.01 -163.83 – –
54 LAI Analog In 2 0 PCT 0.01 -163.83 – –
55 LAI Analog In 3 0 PCT 0.01 -163.83 – –
56 LAI Analog In 4 0 PCT 0.01 -163.83 – –
60 LAO S/W Speed SP 0 PCT 0.1 0 – –
61 LDO S/W Spd Sel HW – 1 0 SW HW
63 LAO PID Ref 0 PCT 0.1 0 – –
64 LAI PID Feedback 0 PCT 0.1 0 – –
65 LAI PID output 0 PCT 0.1 0 – –
67 LAO Preset Spd 1 0 PCT 0.1 0 – –
68 LAO Preset Spd 2 0 PCT 0.1 0 – –
69 LAO Preset Spd 3 0 PCT 0.1 0 – –
75 LDO Preset Sel MAIN – 1 0 PRESET MAIN
77 LDI Purge NORMAL – 1 0 PURGE NORMAL
79 LDI Tripped FALSE – 1 0 TRUE FALSE
80 LDO Reset Fault OK – 1 0 RESET OK
81 LAO Net Timeout 0 SECS 0.1 0 – –
82 LDI Auto Mode AUTO – 1 0 AUTO MANUAL
85 LAO Skip Freq 1 0 Hz 0.1 0 – –
86 LAO Band 1 0 Hz 0.1 0 – –
87 LAO Skip Freq 2 0 Hz 0.1 0 – –
88 LAO Band 2 0 Hz 0.1 0 – –
89 LAO Skip Freq 3 0 Hz 0.1 0 – –
90 LAO Band 3 0 Hz 0.1 0 – –
91 LAO Skip Freq 4 0 Hz 0.1 0 – –
92 LAO Band 4 0 Hz 0.1 0 – –
94 LDO AR Enable FALSE – 1 0 TRUE FALSE
95 LAO AR attempts 5 – 0.1 0 – –
96 LAO AR Delay 10.0 Sec 0.1 0 – –
99 LAI Error Status 0 – 1 0 – –
a. Points not listed are not used in this application.
b. A single value in a column means that the value is the same in English units and in SI units.
c. Point numbers that appear in brackets { } may be unbundled at the field panel.

14
Siemens Apogee P1 Communications Interface
Point Database Cross Reference
Point Number Subpoint Name Parameter
1 CTRL ADDRESS Setup/Communications/Tec Option/Address
2 ED_HVAC10 ---
3 Freq Output Setup/Motor Control/Pattern Gen/Drive Frequency
4 Freq Demand Setup/Seq & Ref/Reference/Speed Demand
5 Speed Setup/Motor Control/Feedbacks/Speed Feedback
6 Current Setup/Motor Control/Feedbacks/Motor Current
7 Torque Setup/Motor Control/Feedbacks/Torque Feedback
8 Power Setup/Motor Control/Motor Data/Power
10 Drive KWH ---
12 Runtime ---
13 DC Bus Volts Setup/Motor Control/Feedbacks/DC Link Volts
14 Output Volts Setup/Motor Control/Feedbacks/Terminal Volts
20 OVRD Time ---
21 Direction Setup/Seq & Ref/Reference/Reverse
22 Direction SP Setup/Inputs & Outputs/Dig In/Dig In 4/Invert
23 RUN Setup/Seq & Ref/Sequencing Logic/Running
24 RUN SP Setup/Seq & Ref/Sequencing Logic/Run Forward
25 Stop Mode Setup/Seq & Ref/Reference Stop/Run Stop Mode
27 Coast Stop Setup/Seq & Ref/Sequencing Logic/Not Coast Stop
28 Fast Stop Setup/Seq & Ref/Sequencing Logic/Not Fast Stop
29 Day.Night Setup/Communications/Tec Option/Night
30 Curr Limit Setup/Motor Control/Current Limit/Current Limit
31 Accel Time 1 Setup/Seq & Ref/Reference Ramp/Accel Time
32 Decel Time 1 Setup/Seq & Ref/Reference Ramp/Decel Time
33 Stop Decel T Setup/Seq & Ref/Reference Stop/Stop Time
34 Fast Decel T Setup/Seq & Ref/Reference Stop/Fast Stop Time
35 Run Enable Setup/Seq & Ref/Sequencing Logic/Drive Enable
37 Reference SP Setup/Seq & Ref/Reference/Speed Setpoint
40 O/P Relay 1 Setup/Inputs & Outputs/Dig Out/Dig Out 1/Value
41 O/P Relay 1 Setup/Inputs & Outputs/Dig Out/Dig Out 2/Value
42 O/P Relay 3 Setup/Inputs & Outputs/Dig Out/Dig Out 3/Value
44 Flycatch EN Setup/Motor Control/Flycatching/Enable
45 Flycatching Setup/Motor Control/Flycatching/Active
50 Analog 1 Out Setup/Inputs & Outputs/An Out/An Out 1/Value
51 Analog 2 Out Setup/Inputs & Outputs/An Out/An Out 2/Value
52 Analog 3 Out Setup/Inputs & Outputs/An Out/An Out 3/Value
continued on next page…

15
Siemens Apogee P1 Communications Interface
Point Database Cross Reference cont.
53 Analog In 1 Setup/Inputs & Outputs/An Input/An Input 1/Value
54 Analog In 2 Setup/Inputs & Outputs/An Input/An Input 2/Value
55 Analog In 3 Setup/Inputs & Outputs/An Input/An Input 3/Value
56 Analog In 4 Setup/Inputs & Outputs/An Input/An Input 4/Value
60 S/W Speed SP Setup/Misc/Value Func/Value Func 5/Input B
61 S/W Spd Sel Setup/Misc/Value Func/Value Func 5/Input C
63 PID Ref Setup/Setpoint Funcs/PID/Setpoint
64 PID Feedback Setup/Setpoint Funcs/PID/Feedback
65 PID output Setup/Setpoint Funcs/PID/PID Output
67 Preset Spd 1 Setup/Setpoint Funcs/Preset/Preset 1/Input 2
68 Preset Spd 2 Setup/Setpoint Funcs/Preset/Preset 1/Input 1
69 Preset Spd 3 Setup/Setpoint Funcs/Preset/Preset 1/Input 3
75 Preset Sel Setup/Setpoint Funcs/Preset/Preset 1/Select Input
77 Purge Setup/Misc/Value Func/Value Func 3/Input C
79 Tripped Setup/Seq & Ref/Sequencing Logic/Tripped
80 Reset Fault Setup/Seq & Ref/Sequencing Logic/Remote Trip Reset
81 Net Timeout Setup/Seq & Ref/Comms Control/Comms Timeout
82 Auto Mode Setup/Seq & Ref/Local Control/Remote Seq
85 Skip Freq 1 Startup/Setpoint Funcs/Skip Frequencies/Freq 1
86 Band 1 Startup/Setpoint Funcs/Skip Frequencies/Band 1
87 Skip Freq 2 Startup/Setpoint Funcs/Skip Frequencies/Freq 2
88 Band 2 Startup/Setpoint Funcs/Skip Frequencies/Band 2
89 Skip Freq 3 Startup/Setpoint Funcs/Skip Frequencies/Freq 3
90 Band 3 Startup/Setpoint Funcs/Skip Frequencies/Band 3
91 Skip Freq 4 Startup/Setpoint Funcs/Skip Frequencies/Freq 4
92 Band 4 Startup/Setpoint Funcs/Skip Frequencies/Band 4
94 AR Enable Setup/Seq & Ref/Auto Restart/Enable
95 AR attempts Setup/Seq & Ref/Auto Restart/Attempts
96 AR Delay Setup/Seq & Ref/Auto Restart/Attempt Delay 1
99 Error Status ---

ISS. MODIFICATION ECN No. DATE DRAWN CHK'D
1 First release of HA470909. 16656 16/04/03 CM DL
FIRST USED ON MODIFICATION RECORD
Siemens Apogee P1 Communications
Interface
EUROTHERM DRIVES
DRAWING NUMBER
ZZ470909
SHT. 1
OF 1
