Siemens RUGGEDCOM RMC30 User manual

Technical Guidance Notes
The copyright and other intellectual property rights in this document, and in any model or article produced from it (and including
any registered or unregistered design rights) are the property of Siemens Protection Devices Limited. No part of this document
shall be reproduced or modified or stored in another form, in any data retrieval system, without the permission of Siemens
Protection Devices Limited, nor shall any model or article be reproduced from this document unless Siemens Protection Devices
Limited consent.
While the information and guidance given in this document is believed to be correct, no liability shall be accepted for any loss or
damage caused by any error or omission, whether such error or omission is the result of negligence or any other cause. Any
and all such liability is disclaimed.
©2007 Siemens Protection Devices Limited P issue 2007/12
DOCUMENTATION
All referenced documents can be provided on request to Siemens Protection Devices Ltd. Tel No. +44
(0)191 401 5555. They can also be found on our website at www.reyrolle-protection.com.
Technical Guidance Notes
Ethernet Interface
Ruggedcom RMC30

Technical Guidance Notes
Page 2 of 29 ©2007 Siemens Protection Devices Limited
DOCUMENT RELEASE HISTORY
This document is issue 2007/12. The list of revisions up to and including this issue is:
2007/12 First issue for Review

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 3 of 29
CONTENTS
Documentation .......................................................................................................................................1
Document Release History....................................................................................................................2
Contents..................................................................................................................................................3
Section 1: Introduction ..........................................................................................................................5
Section 2: Physical Connection............................................................................................................6
2.1 Relay Communication ports......................................................................................................6
2.1.1 RS485 Interface ...........................................................................................................6
2.2 RMC30 ......................................................................................................................................6
2.2.1 RS485 Interface ...........................................................................................................6
2.2.2 RS232 Interface ...........................................................................................................7
2.2.3 Ethernet Interface.........................................................................................................7
2.2.4 Power Supply ...............................................................................................................8
Section 3: Configuration of RMC30 Device .........................................................................................9
3.1 Configure RMC30 IP Address...................................................................................................9
3.2 Configure RMC30 MODBUS Parameters...............................................................................13
3.3 Configure RMC30 DNP3 Parameters.....................................................................................22
3.4 Configure RMC30 Tunnel Parameters ...................................................................................26
Section 4: Definitions...........................................................................................................................27
4.1 Introduction .............................................................................................................................27
Section 5: Glossary..............................................................................................................................28
Section 6: Appendix.............................................................................................................................29

Technical Guidance Notes
Page 4 of 29 ©2007 Siemens Protection Devices Limited
List of Figures
Figure 1 – Relay of COM1 Port Settings ..................................................................................................6
Figure 2 – RMC30 Phoenix Serial Connector, RS485 2 wire connection................................................7
Figure 3 – RMC30 RS232 connection......................................................................................................7
Figure 4 – RMC30 Bottom View Showing Power Supply Connection .....................................................8
Figure 5 – RMC30 Confirm Screen ..........................................................................................................9
Figure 6 – RMC30 Boot Screen .............................................................................................................10
Figure 7 – RMC30 Login Screen............................................................................................................10
Figure 8 – RMC30 Example Login Screen.............................................................................................10
Figure 9 – RMC30 Main Menu ...............................................................................................................11
Figure 10 – RMC30 Administration Menu ..............................................................................................11
Figure 11 – RMC30 IP Interfaces Menu.................................................................................................12
Figure 12 – RMC30 IP Apply Address Changed....................................................................................12
Figure 13 – RMC30 IP Address Changed..............................................................................................13
Figure 14 – RMC30 Admin Logout Screen ............................................................................................13
Figure 15 – RMC30 Browser Interface – Initial Page.............................................................................14
Figure 16 – RMC30 Browser Interface – Main Menu.............................................................................15
Figure 17 – RMC30 Browser Interface – Serial Protocols Menu ...........................................................16
Figure 18 – RMC30 Browser Interface – Serial Ports Configuration Page ............................................17
Figure 19 – RMC30 Browser Interface – Serial Port 1 Configuration Page...........................................18
Figure 20 – RMC30 Browser Interface – Empty Device Address Table Page.......................................19
Figure 21 – RMC30 Browser Interface – Device Address Editor Page .................................................20
Figure 22 – RMC30 Browser Interface –Populated Device Address Table Page..................................21
Figure 23 – RMC30 RMC30 Browser Interface –Logged Out Page ......................................................22
Figure 24 – RMC30 Browser Interface – Serial Port for DNP3..............................................................23
Figure 25 – RMC30 Browser Interface – PC DNP3 Device Entry..........................................................24
Figure 26 – RMC30 Browser Interface – IED DNP3 Device Entry.........................................................25
Figure 27 – RMC30 Browser Interface – IED DNP3 Device Entry.........................................................26
Figure 28 – RMC30 Browser Interface – Serial Port for Raw Socket ....................................................26
Figure 29 – Rear Terminals for E8 case (5CT/4VT) ..............................................................................29

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 5 of 29
Section 1: Introduction
This note describes the connection of the RUGGEDCOM RMC30 external Ethernet interface to the
RS485 port of Reyrolle Relays.
The new generation of Reyrolle relays support the DNP3 communications standard, in addition to
MODBUS and IEC60870-5-103 provided previously. Each communications port allows the user to
select a protocol, independent of the other ports, via a setting accessed through the Relay’s fascia. In
a communications system the Relay will be the slave device. There is a requirement for Ethernet
access to these relays and the RMC30 device provides a solution to accomplish this requirement.
The RMC30 can be configured as a dedicated MODBUS server, DNP3 SERVER, or a simple Ethernet
tunnel. Examples of all three methods are described below.
The information for the RMC30 was taken from [1] Rugged Operating System v3.2 User Guide, please
refer to that document for a more detailed description of configuration.

Technical Guidance Notes
Page 6 of 29 ©2007 Siemens Protection Devices Limited
Section 2: Physical Connection
2.1 RELAY COMMUNICATION PORTS
2.1.1 RS485 Interface
The RS485 communication port (COM1) is located on the rear of the relay and can be connected
using a suitable RS485 120 ohm screened twisted pair cable. On the RM platform it uses terminals
14(A), 16(SCREEN), 18(B) and 20(TERM) of the PSU terminal block.
The RS485 electrical connection can be used in a single or multi-drop configuration. The RS485
master must support and use the Auto Device Enable (ADE) feature. The last device in the connection
must be terminated correctly in accordance with the master device driving the connection. The relays
are fitted with an internal terminating resistor which can be connected between A and B by fitting an
external wire loop between terminals B and TERM on the power supply module. A full diagram of the
rear terminal blocks is shown in the Appendix, Figure 29 – Rear Terminals for E8 case (5CT/4VT).
The maximum number of relays that can be connected to the bus is 64.
Access to the communication settings is only available from the relay front fascia via the
COMMUNICATIONS MENU. The following settings must be configured via the relay fascia when
using the RS485 interface.
Setting name Range Default Setting Notes
Station Address 0 … 254 0 1-254
An address between 1 and 254
must be given to identify the
relay. Each relay must have a
unique address.
COM1-RS485 Protocol OFF, IEC60870-5-103,
MODBUS-RTU, DNP3
IEC60870-5-
103 As Required
Sets the protocol used to
communicate on the RS485
connection.
COM1-RS485 Baud Rate 75 110 150 300 600 1200
2400 4800 9600 19200
38400
19200 As Required
The baud rate set on all of the
relays connected to the same
RS485 bus must be the same
as the one set on the master
device.
COM1-RS485 Parity NONE, ODD, EVEN EVEN As Required
The parity set on all of the
relays connected to the same
RS485 bus must be the same
and in accordance with the
master device.
Figure 1 – Relay of COM1 Port Settings
2.2 RMC30
2.2.1 RS485 Interface
Connect the Serial Port terminals to the Relay. For an RS485 2 wire connection connect the –Rx
terminal of the Phoenix connector to A on the Relay, and the +Rx terminal to B.

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 7 of 29
Figure 2 – RMC30 Phoenix Serial Connector, RS485 2 wire connection
2.2.2 RS232 Interface
If required you can connect the RS232 port of the RMC30 to a PC, for example, if you cannot
configure the device via the Ethernet connection, as shown below.
Figure 3 – RMC30 RS232 connection
2.2.3 Ethernet Interface
Connect the RMS30 to the network using a standard RJ45 Ethernet cable.

Technical Guidance Notes
Page 8 of 29 ©2007 Siemens Protection Devices Limited
2.2.4 Power Supply
Connect a suitable PSU to the RMC30.
Figure 4 – RMC30 Bottom View Showing Power Supply Connection

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 9 of 29
Section 3: Configuration of RMC30 Device
3.1 CONFIGURE RMC30 IP ADDRESS
You can change all the parameters via a Web Browser; however, to do this you must use the IP
address of the RMC30 device. If the default address (192.168.0.1) is not suitable for your network you
must change it using a Terminal program, e.g. HyperTerminal or TeraTerm. To do this you should
connect the RS232 port of the RMC30 to a PC.
Power down the RMS30 and then temporarily disconnect the Ethernet cable and RS485 connection.
Start a terminal program connected to the PC serial port with parameters Baud Rate 57600, No Parity,
8 bit data and VT100 emulation. While holding down CTRL+Z on the PC keyboard power up the
RMC30. After a short while you will be presented with a screen as follows.
Figure 5 – RMC30 Confirm Screen
Type yes to continue

Technical Guidance Notes
Page 10 of 29 ©2007 Siemens Protection Devices Limited
Figure 6 – RMC30 Boot Screen
Press a key to continue
Figure 7 – RMC30 Login Screen
Enter admin for both the user name and password, press return after each.
Figure 8 – RMC30 Example Login Screen
The main menu screen is displayed. Use the arrow keys (←↑↓→) to navigate menus, Enter to enter a
menu and Escape to leave it and return to the previous level.

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 11 of 29
Figure 9 – RMC30 Main Menu
Press return to open the Administration menu.
Figure 10 – RMC30 Administration Menu
Press return to open the Configure IP Interfaces menu.

Technical Guidance Notes
Page 12 of 29 ©2007 Siemens Protection Devices Limited
Figure 11 – RMC30 IP Interfaces Menu
Select the IP Address setting and press Enter to edit it. Type a suitable IP address for the network.
Figure 12 – RMC30 IP Apply Address Changed
For the purposes of this test the IP address used is 169.254.199.24. Press the return key to accept the
new address, and then CTRL+A to apply it.

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 13 of 29
Figure 13 – RMC30 IP Address Changed
Press CTRL+X to exit the logout.
Figure 14 – RMC30 Admin Logout Screen
Reboot the RMC30
3.2 CONFIGURE RMC30 MODBUS PARAMETERS
To configure parameters, start up a web browser and attach to the IP address set in section 3.1, in this
example 169.254.199.24. You will be presented with the initial page as shown below.

Technical Guidance Notes
Page 14 of 29 ©2007 Siemens Protection Devices Limited
Figure 15 – RMC30 Browser Interface – Initial Page
First, login to the device, again using “admin” as both the User Name and Password. After logging in
you will be presented with the main menu page.

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 15 of 29
Figure 16 – RMC30 Browser Interface – Main Menu
Click on Serial Protocols to open the tree.

Technical Guidance Notes
Page 16 of 29 ©2007 Siemens Protection Devices Limited
Figure 17 – RMC30 Browser Interface – Serial Protocols Menu
Click on Configure Serial Ports to open the page.

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 17 of 29
Figure 18 – RMC30 Browser Interface – Serial Ports Configuration Page
Click on 1to configure port 1.

Technical Guidance Notes
Page 18 of 29 ©2007 Siemens Protection Devices Limited
Figure 19 – RMC30 Browser Interface – Serial Port 1 Configuration Page
Set the protocol to MODBUS Server, type to RS485, and Baud Rate, Parity etc. to appropriate values.
Click Apply to save the changes, note the confirmation message. Click Back to return to the Main
Menu.
From the Main Menu Serial Protocols tree click Configure Device Address Table to open the page.

Technical Guidance Notes
©2007 Siemens Protection Devices Limited Page 19 of 29
Figure 20 – RMC30 Browser Interface – Empty Device Address Table Page
Click Insert Record to open the editor page.

Technical Guidance Notes
Page 20 of 29 ©2007 Siemens Protection Devices Limited
Figure 21 – RMC30 Browser Interface – Device Address Editor Page
Set the protocol to MODBUS Server, address to the device address (in this example 4), and the port
to 1, the RS422/485 port we configured earlier. Leaving the remote IP address field blank will cause
the address we set earlier to be used. Click apply to save the settings, then back to return to the table.
