Siemens VDO DTCO 1381 Parts list manual

Service only
TD00.1381.00 132 102
DTCO 1381
(Rel. 1.2a)
Digital Tachograph
Technical Description
www.siemensvdo.com

Service only
Imprint
II © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
Dear user,
The information, descriptions, data and illustrations in this technical
description may be changed without prior notice and do not rep-
resent any liability on the part of the Siemens VDO Automotive AG.
The description is based on the most recent operating system and
program versions at the time of printing.
No part of this documentation may be reproduced by photocopying
or other means without the prior written permission of Siemens
VDO Automotive AG.
The purpose of this
documentation
This documentation is intended exclusively for internal use as an aid
when performing service tasks; any other use is prohibited. This
documentation may not be given to third parties without the prior
written consent of Siemens VDO Automotive AG.
In most cases, the names mentioned in this documentation are reg-
istered trademarks and will be used in the following without specific
reference to the holder.
Responsible for the contents Siemens VDO Automotive AG
Commercial Vehicles
P.O. Box 16 40
D-78006 Villingen-Schwenningen
© by Siemens VDO Automotive AG. All rights reserved.
Customer support Siemens VDO Automotive AG
Commercial Vehicles
SV CV Div TCO OEM PLM
Heinrich-Hertz-Straße 45
D-78052 Villingen-Schwenningen
Telephone: [phone] - 67 31 96
Fax: [phone] - 67 27 29

Service only
Overview of changes
Edition 07/2007 Technical Description DTCO 1381 III
TD00.1381.00 132 102
Overview of changes
Date Chapter Page Topic, Measure
12.2005 First edition
04.2006 New edition
DTCO 1381 – Release 1.2
06/2007 New edition
DTCO 1381 – Release 1.2a
Item no. changed to TD00.1381.00 132 102

Service only
IV © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102

Service only
Table of contents
Edition 07/2007 Technical Description DTCO 1381 V
TD00.1381.00 132 102
Table of Contents
Overview of changes ................................................................ III
Conventions in this manual .................................................... VII
Pictographs and their meaning ............................................. VIII
General instructions ................................................................ IX
List of abbreviations .............................................................. XIV
Chapter 1 Product and system overview
1.1 System overview ........................................................... 1-3
1.2 Digital Tachograph DTCO 1381 ..................................... 1-7
1.3 KITAS 2171 .................................................................. 1-11
1.4 Tachograph cards ........................................................ 1-14
Chapter 2 Technical data
2.1 DTCO 1381 .................................................................... 2-3
2.2 KITAS 2171 .................................................................. 2-14
2.3 Connection diagram DTCO 1381 ................................. 2-20
Chapter 3 Operating the DTCO 1381
3.1 General instructions ..................................................... 3-3
3.2 Display variations .......................................................... 3-5
3.3 Menu functions ........................................................... 3-11
3.4 Calibration mode ........................................................ 3-16
3.5 Preparing for data download ...................................... 3-21
Chapter 4 Data handling
4.1 Data handling ............................................................... 4-3
4.2 The flow of data and memory behaviour ..................... 4-4
4.3 Tachograph cards ........................................................ 4-14
4.4 Data download ............................................................ 4-29
4.5 Rights to access saved data ........................................ 4-30
Chapter 5 Installation
5.1 General instructions ..................................................... 5-3
5.2 Instructions on installing the DTCO 1381 ..................... 5-7
5.3 Criteria for the installation site ................................... 5-12
5.4 Tools and installation accessories ............................... 5-15
5.5 Performing the installation ........................................ 5-17
Chapter 6 Installation of the ADR variant
6.1 DTCO 1381 in vehicles used for the carriage
of hazardous goods ....................................................... 6-3
6.2 Performing the installation .......................................... 6-8
6.3 DTCO 1381 (ADR variant) EC type-examination
certificate .................................................................... 6-11
6.4 KITAS 2171 EC type-examination certificate .............. 6-15
Chapter 7 Preprogramming
7.1 General instructions ..................................................... 7-3
7.2 Testing equipment ........................................................ 7-4
7.3 Performing the preprogramming ................................. 7-5

Service only
Table of contents
VI © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
Chapter 8 Installation and functional test
8.1 General instructions ......................................................8-3
8.2 Permissible error limits ..................................................8-5
Chapter 9 Activation
9.1 General instructions ......................................................9-3
9.2 Checking the buffer battery ..........................................9-7
9.3 Performing the activation ..............................................9-8
Chapter 10 First calibration
10.1 General instructions ....................................................10-3
10.2 Calibration instructions ...............................................10-6
10.3 Testing equipment .....................................................10-10
10.4 Checking the buffer battery ......................................10-11
10.5 Performing the first calibration .................................10-12
Chapter 11 Regularly inspection
11.1 General instructions ....................................................11-3
11.2 Calibration instructions ...............................................11-5
11.3 Instructions for the regularly inspection .....................11-9
11.4 Testing equipment .....................................................11-10
11.5 Checking the buffer battery ......................................11-11
11.6 Performing the regularly inspection .........................11-12
Chapter 12 Maintenance and cleaning
12.1 System maintenance ...................................................12-3
12.2 Buffer battery ..............................................................12-4
12.3 Cleaning .......................................................................12-9
12.4 Disposal .....................................................................12-10
Chapter 13 Events and faults
13.1 General information about messages .........................13-3
13.2 Displaying the event and fault memory ......................13-6
13.3 Printing the event and fault memory ..........................13-8
13.4 Messages and troubleshooting measures .................13-10
Chapter 14 Appendix
14.1 Operating conditions of the DTCO 1381 ......................14-3
14.2 Pictograms and pictogram combinations ....................14-8
14.3 Printout examples ......................................................14-12
14.4 Explanation of printout examples .............................14-22
14.5 Memory behaviour during events or faults ...............14-31

Service only
Conventions in this manual
Edition 07/2007 Technical Description DTCO 1381 VII
TD00.1381.00 132 102
Conventions in this manual
Formatting features
The following formatting features will be used in order to help you
more easily use this documentation:
Organisation of the manual
Emphasis in text
Enumeration
Example: Meaning:
Product / system overview = Main chapter
1.1 System overview = Subchapter of 1st level
1.1.1 Brief description = Subchapter of 2nd level
Product versions = Section within a chapter
Example: Meaning:
1. Switch on the ignition. = Handling instructions which must be carried out one after the other
2. Insert tachograph card.
3. Call main menu.
• Activities = Lists within a paragraph
– Driving time = Additional lists within a list
Example: Meaning:
Fig. 1-2: = Figure number:
The number is composed of the current chapter (in this case 1) and a
consecutive number representing the figure (in this case 2).
3-6 = Page numbering in the footer:
The page number is composed of the current chapter (in this case 3)
and a consecutive page number (in this case 6)

Service only
Pictographs and their meaning
VIII © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
Pictographs and their meaning
Marginal column A short keyword to a topic can be used for finding certain infor-
mation in the text quickly.
Caution!
Just as in street traffic, this symbol means "Stop"!
Please pay special attention to information and instructions. In
doing so, you will protect yourself and others from injury.
Attention!
The text next to this symbol contains important instructions which
must be observed to prevent a loss of data or damage to the device
Comment!
Important supplementary information on the product.
Book symbol
Refers to other documentation, e.g. see operating instructions
DTCO 1381.

Service only
General instructions
Edition 07/2007 Technical Description DTCO 1381 IX
TD00.1381.00 132 102
General instructions
The DTCO 1381 digital tachograph with its system components is an
EC recording equipment that complies with the requirements of the
CR (EEC) 3821/85, last amended by the CR (EC) no.1360/2002 and
CR (EC) no. 432/2004, in the following referred to as CR (EEC) 3821/
85, annex I B.
Terminology definitions
Installation of the DTCO 1381 is divided into the following steps:
1. Installation
Mechanical and electrical installation of the DTCO 1381 compo-
nents into the vehicle.
2. Preprogramming
Preprogramming of all known or operationally necessary and
legally required parameters.
3. Installation and functional test
Test and demonstration that the entire system complies with
the permissible error limits concerning distance and speed,
defined by CR (EEC) 3821/85, annex I B.
4. Activation
Activation of the DTCO 1381 to be an EC recording equipment
(with the first insertion of the workshop card).
5. First calibration
First calibration of the EC recording equipment. Part of the first
calibration is, to enter the vehicle registration number.

Service only
General instructions
X© Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
Personnel prerequisites
In the following instructions, the manufacturer assumes that the
personnel possess extensive professional knowledge, securely
master the necessary technical activities, and have been trained in
the use of the DTCO 1381 components as appropriate for the area of
application.
Installation The persons who are charged with the installation of the DTCO 1381
components must complete a training program on the installation
of the DTCO 1381 components.
Activation and calibration The persons who are charged with the activation and calibration of
the DTCO 1381 components must:
• have a valid workshop card.
• complete a training program on the installation, calibration, and
activation of the DTCO 1381 components.
• (in Germany) also fulfil the conditions for executing tasks
according to §57b.
Technical prerequisites
The following requirements must be fulfilled in order to carry out
the assigned tasks:
• The equipment and tools required or recommended by the man-
ufacturer must be available.
• The equipment, testing devices, and furnishings must comply
with the respective valid legal requirements for the country in
which they are used.
When installing the DTCO 1381 please obey the valid legal regula-
tions in your country!

Service only
General instructions
Edition 07/2007 Technical Description DTCO 1381 XI
TD00.1381.00 132 102
Handling the tachograph cards
Please observe the following instructions about using the tacho-
graph cards:
• Handle the tachograph cards carefully in order to avoid loss of
data.
• Do not bend or fold the tachograph cards and do not use them
for anything other than their intended purpose.
• Do not use damaged tachograph cards.
• Keep all contact surfaces clean, dry, and free of grease and oil
(always use the protective cover).
• Protect the card from direct sunlight (do not allow it to lie on the
instrument panel).
• Do not place it in direct proximity to strong electromagnetic
fields.
• Do not use the card beyond its period of validity. Apply for a new
card in a timely manner before expiry.
Attention!
Possession of a tachograph card authorizes the holder to use the
digital tachograph. The tachograph cards are person-specific
(workshop cards are company-specific) and are therefore not trans-
ferrable to others!
An accredited workshop must securely retain, use, and administer
its workshop card and PIN; workshop cards and PIN may not be
made available to third parties!
An accredited workshop must ensure secure communication
between the DTCO 1381 and workshop card!
Loss of the workshop card must be reported immediately to the
issuing authority / institution!
Obey the valid legal regulations in your country surrounding
workshop cards!
Obey the instructions of the issuing authority / institution and the
card manufacturer!

Service only
General instructions
XII © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
Installing the DTCO 1381
Installation of the DTCO 1381 components does not require any
interventions in the vehicle’s safety equipment. When installed cor-
rectly, the vehicle’s equipment and driving characteristics will
neither be changed nor influenced.
Observe the following general instructions for the installation
of the DTCO 1381 components:
• Always observe the manufacturer’s instructions, particularly
when working on the onboard power supply.
• Make sure that the vehicle's ignition is switched off.
• Make sure that the legal regulations regarding installation room
are complied with, that there is sufficient room to operate the
DTCO 1381, and that the display is positioned in a way that
affords optimal readability.
• When installing the DTCO 1381 components, avoid damaging
the existing cables in the vehicle or unintentionally loosening
plug-in connections.
• Before removing covers and similar vehicle parts, obtain infor-
mation on proper dismantling procedures in order to prevent
damage to the parts.
• Refer to the connection diagrams for information on the
location of fuel, hydraulic, compressed air, and electrical lines.
• When separating plug-in connections, do not pull on the cable,
but rather on the plugs or the proper unlocking systems only.
• For mounting tasks, use only original Siemens VDO Automotive
installation parts and accessories. Install undamaged compo-
nents only.
• During installation, be absolutely certain that the DTCO 1381
components do not influence or restrict the vehicle’s function-
ality in an undesirable way.
• Instruct the driver / company in the use of the DTCO 1381 and
transfer to him with the appropriate operating instructions.
Attention! Danger of injury
Working on a motor vehicle can be dangerous. When working,
observe the professional association’s safety instructions and the
regulations for the prevention of accidents.

Service only
General instructions
Edition 07/2007 Technical Description DTCO 1381 XIII
TD00.1381.00 132 102
Proper use The DTCO 1381 is an EC recording equipment that complies with
CR (EEC) 3821/85, annex I B for the registration, saving, display,
printing, and outputting of driver-based and vehicle-based data. It
may be used only for the purpose for which it is designed.
Power supply The DTCO 1381 may only be connected to voltages for which it is
designed and which can be seen in the wiring diagram (label).
Accessories For reasons of operational safety, no alterations may be made to the
accessories. Do not use any accessories other than those recom-
mended or approved by the manufacturer in order to help avoid
accidents and operational disruptions.
Cables Make sure that the cables are undamaged, that other objects or
sources of heat cannot cause damages, and that the lines cannot
cause any undesired interference or disturbances.
General security instructions
While handling a DTCO 1381, which has not yet been activated, the
approved recording equipment manufacturer, vehicle manufacturer,
installer, or a workshop must guarantee the security of the
DTCO 1381.
Maintenance
Cleaning Do not use any volatile solvents, such as alcohol, diluting agents,
naphtha, or abrasive cleaning solutions when cleaning the devices.
When dirty, clean the housing, the display and the function keys
using a slightly moistened cloth.
Operational notes Avoid excessive impacts and vibrations. Do not use sharp or pointed
objects (such as pens) to operate the keys.
Keep the printer drawer closed at all times in order to avoid damages
and contamination.
Caution! Danger of fire due to short circuit
Damaged cables can cause short circuits, undesired interferences, or
disturbances.
Always replace damaged cables immediately!

Service only
List of abbreviations
XIV © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
List of abbreviations
A
ADR European agreement concerning the international
carriage of dangerous goods by road
ATC Wheel rotation test computer
B
BTC Operating test computer
C
CAN Controller area network (vehicle data bus)
D
DIN Deutsche-Industrie-Norm (German industry standard)
DTCO Digital Tachograph
E
EMC Electromagnetic compatibility
F
FM LED Function monitoring LED
I
IEC International electrotechnical commission
IP International protection (protection classification)
ISO International organization for standardization
K
kConstant for the speed and rotational speed
adjustment between vehicle and tachograph
KITAS Kienzle Tachograph Sensor
K-Line Serial asynchronous diagnosis interface
km Kilometer
km/h Kilometers per hour

Service only
List of abbreviations
Edition 07/2007 Technical Description DTCO 1381 XV
TD00.1381.00 132 102
L
LCD Liquid crystal display
M
MTC Mobile test computer
N
nEngine speed [rpm]
Nm Newton meter (unit of torque)
P
p/m Pulses per metre
PIN Personal identity number
PWM Pulse range modulation
R
RMS Root-mean-square
rpm Revolutions per minute
RxD Received data (asynchronous received data)
S
SDS Service diagnosis system
STC Stationary test computer
StVZO Straßenverkehrs-Zulassungs-Ordnung (German Regu-
lation authorizing the use of vehicles for road traffic)
SW Wrench size
T
TCO Tachograph
TD Technical documentation
TxD Transmit data (asynchronous transmitted data)
U
UTC Universal time coordinated

Service only
List of abbreviations
XVI © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
V
vSpeed [km/h]
VIN Vehicle identification number
VRN Vehicle registration number
W
wCharacteristic coefficient (w-value) [p/km]
WTerminal "W" of the electric generator

Service only
Edition 07/2007
TD00.1381.00 132 102
Chapter 1
Product and system overview

Service only
Table of contents Product and system overview
1 - 2 © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
Table of Contents
Chapter 1 Product and system overview
1.1 System overview ........................................................... 1-3
1.1.1 Brief description ................................................. 1-4
1.1.2 Characteristics of the DTCO 1381 ........................ 1-6
1.2 Digital Tachograph DTCO 1381 ..................................... 1-7
1.2.1 DTCO 1381 Device description ............................ 1-7
1.2.2 DTCO 1381 Rear side .......................................... 1-9
1.2.3 DTCO 1381 Product versions ............................. 1-10
1.3 KITAS 2171 .................................................................. 1-11
1.3.1 KITAS 2171 Product variations ........................... 1-11
KITAS 2171 Standard version ............................. 1-11
KITAS 2171 Integrated version .......................... 1-12
KITAS 2171 Customer-specific version ............... 1-12
1.3.2 Characteristics of the KITAS 2171 ...................... 1-13
1.3.3 KITAS Sensor cable ............................................ 1-13
1.4 Tachograph cards ........................................................ 1-14
1.4.1 Valid combinations of tachograph cards ............ 1-16

Service only
Product and system overview 1.1 System overview
Edition 07/2007 Technical Description DTCO 1381 1 - 3
TD00.1381.00 132 102
1.1 System overview
Fig. 1 - 1: DTCO 1381 System overview
The EC recording equipment DTCO 1381 consists of these indi-
vidual components:
• Digital Tachograph DTCO 1381
• Motion sensor KITAS 2171
Download software
Printouts
KITAS 2171
Tachograph cards
DTCO 1381
Display instrument

Service only
1.1 System overview Product and system overview
1 - 4 © Siemens VDO Automotive AG Edition 07/2007
TD00.1381.00 132 102
1.1.1 Brief description
DTCO 1381 The DTCO 1381 digital tachograph is an EC recording equipment
that complies with the requirements of CR (EEC) 3821/85, annex I B.
It is used to register, save, display, print, and output driver-based and
vehicle-based data. The data is saved in the DTCO 1381 device
memory and on inserted tachograph cards.
The standard display provides an overview that shows the time,
current speed, and distance. It also shows the set activities and
symbols of the inserted tachograph cards, see chapter 3.2 "Display
variations", page 3-5.
An internal diagnosis function monitors the system and automati-
cally notifies if events or faults appear.
Events, faults, or warning messages are displayed optically.
KITAS 2171 KITAS 2171 is part of the EC recording equipment, it provides real-
time signals and cryptologically encoded data. The signals serve for
recording the distance and speed.
The DTCO 1381 can detect external interferences and influences by
monitoring the data communication with the KITAS 2171 and com-
paring this to the real-time signal.
Printouts The integrated printer on the DTCO 1381 can print data from the
memory and the tachograph cards. The types of printout, the
format, arrangement, and data contents are defined in CR (EEC)
3821/85, annex I B.
Printer paper The printer paper is approved for use with the DTCO 1381 and
exhibits a corresponding mark of approval. The paper is a special
thermal printing paper.
Display instrument A display instrument is located directly in the driver’s field of vision.
The operational check " " (shown in the color amber or orange)
brings attention to messages from the DTCO 1381.
The display instrument is not part of the EC recording equipment.
Display instruments are designed for specific vehicles and will not be
covered in this documentation.
