Siemens Gigaset 2010 User manual

19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-IM1_eng-frz-spa-
Euroset
2010
Keys - Touches - F
unciones de las teclas
/
Redial key
Touche BIS
Repetición de la marca-
ción
a
Shift key
Touche MAJ
Tecla de Shift
2
Enquiry call key
Touche Double appel
Tecla de señalización
"
Set key
Touche Programmation
Tecla de memoria

Special function
Fonction spéciale
Funciones especiales
L
Mute key
Touche Secret (Mute)
Tecla desc. microteléfono
User’s Guide euroset 2010
s
Touches de destination
Mode d’emploi
Instrucciones de manejo
Teclas de destino
Repertory keys

– 2 –
- English -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
Getting started
❏Safety information
For your safety and protection, the phone should not be used in bathrooms
or shower rooms (wet rooms). The phone is not splash-proof.
The phone should only be disposed of in an environmentally friendly man-
ner.
Never give the Euroset 2010 to a third party without the operating instruc-
tions.
❏Telephone installation advice
• Protect the telephone from direct sunlight or other sources of heat.
• Operate at temperatures between +5°C and +40°C.
• Maintain a distance of at least one meter between the telephone and
any radio equipment, e.g. mobile phones, personal pagers or televisions.
Otherwise interference may be experienced during telephone calls.
• Do not install the telephone in dusty rooms, as this will shorten the
service life of the telephone.
• The phone should only be cleaned using a damp cloth or anti-static
wipe; never use a dry cloth (risk of electrostatic charge and discharge)
or abrasive cleaning products.
• Furniture lacquers and polishes may be subject to corrosion if they
come in contact with parts of the unit (e.g. feet).
❏Connection (see diagram)
Attach the handset cord and connect the phone cord to the wall socket.
You telephone is now ready to use.
Cable channel used
– or on the wall:
– on the table:
when telephone is

– 3 –
- English -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
General note on saving phone settings
Various telephone setting have to be confirmed with the set key
"
if they
are to be permanently available.
To cancel the setting procedure (e.g. after an incorrect entry) without sav-
ing, replace the handset instead of pressing
"
. The original setting is then
unchanged.
Saving call numbers
❏Saving repertory numbers
You can save up to 20 call numbers using the two levels of the repertory
keys.
You can store dial pauses of 3 seconds by pressing
/
(a pause should not
occur as the first element in a call number).
Tip: Key sequences for special functions on private PABXs and public tele-
phone systems can also be stored on the repertory keys.
❏Saving with the notebook function
While a call is in progress you can save (note) the number you have dialled
or have been told during the call under a repertory key. However this re-
quires that at least one repertory key is free. This is why we recommend
reserving one key for this function and labelling it "Note".
Saving a dialled call number:
or
Saving a call number which you have been told during the call:
>"
Lift the handset, then press the set key.
(Also press
a
for the 2nd storage level.)
K
Press the repertory key under which the repertory
call number is to be stored.
J
Enter the call number to be stored (max. 32 digits).
"<
Press the set key then replace the handset.
"K
Press the set key followed by the repertory key
under which the call number is to be noted.
/
Press the redial key to note the ddialled call number.
J
Enter the call number which appears on your display
while the call is in progress.
"
Press the set key to confirm the call number entered.

– 4 –
- English -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
❏Saving a DSS number
If a DSS number is programmed, it is dialled automatically when a key
(except the
"
and
L
keys) is pressed. Thus it is useful, for example, as
an "emergency number" function for your child when you are not at home.
Another call number can only be dialled again when the DSS number has
been
deleted.
Incoming calls can still be answered when a DSS number is programmed.
❏Deleting DSS numbers
Other telephone numbers can only be dialled when the DSS number has
been deleted.
Dialing call numbers
❏Dialing call numbers
Dial pauses of 3 seconds can be inserted at any point after the first digit by
pressing
/
.
❏Dialing with the repertory keys
❏Redial
The last call number dialed is automatically saved (max. 32 digits).
❏Dialing a hot key number
Prerequisite: A hot key number has been stored and the telephone is
locked
>"
Lift the handset, and initiate the function.
J
Enter the DSS number (max. 32 digits)
or
Delete the DSS number.
"<
Press the set key and replace the handset.
>
Lift the handset.
J
Dial the call number.
>
Lift the handset.
(If necessary, press
a
for a 2nd level repertory key).
K
Press the repertory key.
>/
Lift the handset, then press the redial key.
>
Lift the handset, then press any key
(except
"
).
Harris

– 5 –
- English -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
Hearing and being heard
❏Setting the volume of tone ringing
There are 3 tone ringer volume settings (factory setting: 3).
Setting while the telephone is in standby:
Setting while the telephone is ringing:
Before lifting the receiver, press the

key. The volume is adjusted each
time the key is pressed. The last level set is saved.
❏Setting the frequency of the ringing tone
There are 3 settings for the frequency (speed) of tone ringing
(factory setting: 3).
Setting while the phone is ringing
Press

before lifting the handset. The frequency changes each time you
press a key (max. 3 levels). The last frequency set is stored.
>"
Lift the handset, then start the function.

...

Press one of the keys1 ... 3:
1= Lowest volume,
3= Highest volume
"<
Press the set key, then replace the handset.
>"
Lift the handset, then start the function.

...

Press one of the keys 1 ... 3:
1= Lowest frequency; 3 = Highest frequency.
"<
Press the set key, then replace the handset.

– 6 –
- English -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
❏Mute
You can deactivate the telephone handset and microphone during a call.
Neither you nor the called party will hear each other. The connection is
maintained and is indicated by the playing of music on-hold.
❏Setting the handset volume
There are 2 handset volume settings (factory setting: level 1).
❏Activating/ deactivating the key confirmation tone
A “confirmation tone” is activated as an acoustic check that the telephone
has registered each individual key pressed. You can activate and deacti-
vate the confirmation tone as you require:
❏Locking/ unlocking the telephone
Call numbers cannot be dialed when the telephone is locked, however in-
coming calls can be received.
Operation at private PABXs
❏Entering/deleting exchange codes
If you are using your telephone on a private PABX, you may need to store
one or more exchange codes. A dialing pause of 3 seconds is automatically
set when the exchange code is saved.
L
Press the mute key during the call.
To reactivate the handset and microphone:
Press the key again.
>"
Lift the handset, then start the function.

or

1=Soft,
2= Loud.
"<
Press the set key, then replace the handset.
>"
Lift the handset, then start the function.

or

0= Confirmation tone off,
1= Confirmation tone on.
"<
Press the set key, then replace the handset.
>"
Lift the handset, then start the function.

or

1=Lock,
0= Unlock
"<
Press the set key, then replace the handset.
>"/
Lift the handset then start the function.
"<
(a) To ddelete all exchange codes:
Press the set key and replace the handset.
J
(b) To eenter an exchange code:
Enter a one- to three-digit exchange code.
/J
If you want to enter another exchange code:
Press the redial key and enter the next exchange
code.
"<
Press the set key, then replace the handset.

– 7 –
- English -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
❏Switching the dialing mode
❏Switching the dialing mode while connected
If your telephone is set to pulse dialing and you want to use functions that
require tone dialing (e.g. remote replay on an answering machine), you can
switch the dialing mode while connected.
Replacing the receiver resets the telephone to the original dialling mode.
❏Recall key (use on private PABXs)
During a trunk call, you can make an enquiry call or transfer a call. To do
this, press the recall key
2
. The next step depends on your PABX. In the
factory setting, the recall key function is set to a flash time (interrupt time)
of 90 ms to permit new features to be used on ppublictelephone systems.
When your telephone is connected to a private PABX, it may be necessary
to change the flash time (e.g. 600 ms). Please check the operating instruc-
tions for your PABX.
Setting the flash time for the recall key
>"
Lift the handset, then start the function.

or

1= Tone dialing,
2= Pulse dialing without flash function.
"<
Press the set key, then replace the handset.

While connected: press the asterisk key.
The dialing mode is switched.
J
Enter the digits for remote control/ data transfer.
>"
Lift the handset then start the function.

...

Enter the required flash time number:
0:90ms(factorysetting); 11: 120 ms,
2: 270 ms; 33:375ms, 44: 600 ms.
"<
Press the set key, then replace the handset.

– 8 –
- English -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
Using functions for additional services on
public telephone systems
Your public telephone system offers a range of additional useful services -
some of them only available on order/application (e.g. call forwarding, call-
back on busy, three-way conferences, etc.). These services can be select-
ed using fixed key combinations obtainable from your network operator.
These key combinations can also be stored on repertory keys.
❏Recall key (on public telephone systems)
This key is required in order to use certain additional services on public
telephone systems.
Note:
Depending on the country where the telephone is used, it may be neces-
sary to set the appropriate flash time (see “Setting the flash time for the re-
call key”):
– Belgium, Netherlands, Switzerland: 120 ms (code 1)
– France, Luxembourg, Portugal, Germany: 270 ms (code 2)
– Argentina 375 ms (code 3).
Additional information
❏If your telephone is not functioning correctly
Handset off-hook, no dial tone: is the connecting cord correctly inserted
in the telephone and the wall socket?
A dial tone is audible, but dialing is not possible: the connection is OK.
Is the dialing mode correctly set? See Switching the dialing mode.
PABXs only: Connection fails or is incorrect when a number is dialed from
memory (e.g. redial, speed dialing): program the exchange code.
Recall key not working: set a suitable flash time.
❏Contacts
Your dealer will be pleased to answer any questions you may have about
how to operate the phone. Questions about the telephone line should be
addressed to your network operator.

– 9 –
- Français -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
Mise en service
❏Consignes de sécurité
Pour votre sécurité et votre protection, nejamais utiliser le téléphone dans
une salle de bains ou une douche (locaux humides). L’appareil n’est pas
protégé contre les projections d’eau
Mettre au rebut le téléphone en respectant les règles de protection de l’en-
vironnement.
Lorsque vous confiez votre Euroset 2010 à un tiers, toujours joindre le mode
d’emploi.
❏Conseils pour l’installation du téléphone
• Ne pas exposer le téléphone aux rayons directs du soleil ou à une sour-
ce de chaleur quelconque.
• Température d’utilisation : +5°C à +40°C.
• Respecter une distance d’au moins un mètre entre le téléphone et les
équipements radio, p. ex. téléphones sans fils, systèmes de recherche
de personnes ou téléviseurs.
Le non-respect de cette règle peut perturber les communications télé-
phoniques.
• Ne pas placer le téléphone dans des locaux avec un fort dégagement
de poussières, cela raccourcit sa durée de vie.
• Pour l’entretien, utiliser un chiffon humide ou antistatique, mais jamais
un chiffon sec (risque de charge ou décharge électrostatiques). Ne pas
employer non plus de produit corrosif !
• Le contact avec certaines parties de l’appareil (par exemple les pieds)
peut endommager la surface des meubles.
❏Raccordement (voir figure)
Raccorder le cordon du combiné et enficher le cordon téléphonique dans
une prise murale. Votre téléphone est prêt à fonctionner.
Rainures pour les,
– pour montage mural :
– pour utilisation sur
cordons, position
bureau :

– 10 –
- Français -
19.04.2000 euroset 2010,IM1, A31008-E2010-B100-2-3S19 2010-
Remarque générale sur l’enregistrement
des réglages du téléphone
Certains réglages du téléphones doivent être validés avec la touche Pro-
grammation
"
pour être enregistrés .
Pour quitter sans enregistrer (p. ex. à la suite d’une entrée incorrecte), rac-
crochez au lieu d’appuyer sur
"
. Le réglage précédent est conservé .
Enregistrer les numéros
❏Enregistrer un numéro de destination
Vous pouvez enregistrer des numéros sur les deux niveaux des touches de
destination (20 numéros au total).
En cours de numérotation, appuyez sur
/
pour insérer une pause de 3 se-
conde (sauf en 1eposition).
Conseil pratique : vous pouvez aussi enregistrer sur les touches de desti-
nation les combinaisons de touches correspondant aux fonctions spécia-
les des installations téléphoniques privées et du système téléphonique pu-
blic.
❏Enregistrer avec la fonction bloc-notes
Vous pouvez, en cours de communication, enregistrer sous une touche no-
minative ("noter") le numéro composé ou un numéro qui vous est commu-
niqué. Pour cela, il faut toutefois qu’au moins une touche de destination
soit libre. Vous devez donc prévoir une touche de destination pour cette
fonction et l’identifier par "Note".
Enregistrer le numéro composé :
ou
Enregistrer un numéro communiqué :
>"
Décrochez le combiné et appuyez sur Programma-
tion.
(Pour accéder au 2eniveau de mémoire, appuyez en
plus sur
a
.)
K
Appuyez sur la touche de destination sur laquelle
vous souhaitez enregistrer le numéro.
J
Entrez le numéro à enregistrer (32 chiffres maxi.).
"<
Appuyez sur Programmation et raccrochez.
"K
Appuyer sur la touche Programmation puis sur la tou-
che de destination sous laquelle le numéro doit être
noté.
/
Appuyer sur la touche BIS pour noter le numéro
composé.
J
Entrer le numéro qui vous est communiqué durant
l’appel en cours .
"
Appuyer sur la touche Programmation pour valider le
numéro entré.
