Operating and Installation Manual
for Cooker Hoods
LC38S953..

Preface
Thank you for choosing Siemens cooking appliance.
Before using your appliance for the first time, please read these instructions for use
carefully.
They contain important information concerning your personal safety as well as on use
and care of the appliance.
Any failure or losses caused by disregarding the precautions mentioned in this manual
will not be covered under Siemens warranty.
Keep the instructions in a safe place for reference or for the subsequent owner. If in
doubt, kindly contact our service centre or dealer.

1
Table of Contents
Key Information
Product Introduction
Operating Instruction
Installation Instruction
Cleaning, Maintenance
And Repair
Customer Service
Packaging of New Cooker Hood 2
Disposal of Used Cooker Hood 2
Before You Begin 2
Technical Parameters 3
Product Standards 3
Safety Precautions 3
Getting Familiar with Your New Cooker Hood 5
Control Panel 5
Operating Instruction 6
Safety Precautions 9
Installation Position and Height 10
Installation of Fasteners 11
Fixing Cooker Hood 12
Connection of Exhausted Pipe 12
Connection of Adjustable Cover 13
Installation of Oil Collector 13
Test Run 14
Cleaning and Maintaining Your Cooker Hood 14
Trouble Shooting 15
Changing the Halogen Bulb 16
Tips 17
Note:
BSH Electrical Appliances (Jiangsu) Co., Ltd reserves
the right to change the content of this Operating and
Installation Manual without prior notice.

2
Key Information
Packaging of
New Cooker Hood
Disposal of Used
Cooker Hood
Before You Begin
You will receive your new appliance in a protective
shipping carton. All packaging materials are
environment friendly and recyclable. Please contribute
to a better environment friendly manner.
Do not let children play with the appliance or the
packaging material.
You should discard the used cooker hood when it
cannot be used any more. Please pull out the plug of
the power cord and cut off the power cord.
Old appliances are not worthless rubbish. Valuable
raw materials can be reclaimed by recycling old
appliances. Before disposing of your old appliance,
render it unusable.
This appliance is intended for use in the private
household and the home environment only. Use the
appliance only for preparing food, not for heating rooms.
Before using the appliance for the first time, please
read this Operating and Installation Manual carefully.
It contains important information concerning your
personal safety as well as the use and care of the
appliance.
This Operating and Installation Manual applies to
several different models. Accordingly, you may find
descriptions of individual features that do not apply to
your specific appliance.
Check the appliance after unpacking it. Do not connect
the appliance if it has been damaged during transport.
The appliance must be connected to the mains only
by a licensed and trained technician.

3
Product Introduction
The product conforms to the following national
standards:
IEC 60335-1:2001(Fourth Edition+incl.A1:2004+
A2,C1:2006) Household and similar electrical
appliance-safety-part 1 General Requirements
IEC 60335-2-31: 2006 (Ed 4.1) Household and similar
electrical appliances –safety- Part 2-31 Particular
requirements for range hoods and other cooking extractors
Risk of Carbon Monoxide Intoxication!
When the cooker hood is operated in exhaust air
mode simultaneously with a different burner which
also makes use of the same chimney, care must be
taken to ensure that there is an adequate supply of
fresh air which will be needed by the burner for
combustion.
Burn Risk!
NEVER touch the lamp cover when the lamp is
turned on or off immediately as you may get burnt.
Fire Risk!
Gas burners operated without cookware in position
produce a great amount of heat. The appliance or an
extractor hood fitted above it may be damaged or set on
fire. Only operate gas burners with cookware in position.
Technical Parameters
Product Standards
Product Model
Appearance
Rated Voltage
Air Volume / m3/min
Static Pressure / Pa
Noise / dB (A)
Net Weight / kg
Dimension Length
/ mm Width
Height
Input Power Motor
/ W Light
Safety Precautions !
!
!
LC38S953..
Self Cleaning
220-240V～50Hz
150
2×12
14.5±1
≥300(max.)
≤69
20
900
460
600
70

4
Product Introduction
Overheated fat or oil is highly inflammable. Only prepare
food cooked in fat or oil when cooking can be fully
supervised.
Under no circumstances attempt to extinguish burning
fat or oil with water. Choke the fire using a lid or fire
blanket.
Before using for the first time:
Make sure the light bulb, grease filter frame, and oil
collector of the cooker hood have already been
correctly installed.
In Use:
Accumulated oil and grease in the filter and oil collector
increases the risk of fire and influences the efficiency
of the cooker hood.
Adults and children must not operate the appliance
without supervision, if they are physically or mentally
incapable of doing so, or if they lack the knowledge
and experience required to operate the appliance
correctly and safely.
Light bulbs must always be fitted before the cooker
hood is in use. Defective bulbs should be replaced
immediately to prevent the remaining bulbs from
overloading.
NEVER insert or remove an electric plug with wet
hands.
DO NOT drag the wire to remove the electric plug.
After Use:
If the cooker hood is not used for a long time, please
remove the electric plug from power supply for safety.

5
Operating Instruction
Getting Familiar with Your New Cooker Hood
Control Panel
1. Duct 2. Screen 3. Inner frame
4. Filter frame 5. Oil collector 6. Front panel
7. Lamp 8. Switch
This appliance uses advanced touch control. The surface is easy to clean up and it has a
long life time.
1. “Fan Power ” button
To turn on and off the fan power.
2. “Light ” button
To turn on and off the lamp. It can be controlled individually, without influence of
other buttons.
3. The four button “ ”
To set time, alarm, self cleaning, ventilation, and lock function.
4. “Fan Speed ” button
To control the fan speed.
5. “Time-delay ” button
To set delay time to turn off the fan power.
6. “ Gas hob → Cooker hood” Interlink function
The cooker hood can be connected with applicable hob. (this symbol has no
operating function).
The operation of applicable hobs please follow the Operating and Installation Manual for
applicable hob.
LC65S953..
1
3 4 65 7
8
2
134562
LC38S953..

Every time the power is reconnect ,the clock shows
88:88 and flash. Only after adjust the clock and press
“ok/esc” , the flashing shops. All other function can
use at all time.
Set clock: press “ ” till “ ” flash. And press
“ok/esc” enter setting clock status. The hour will flash,
press“+/-” to adjust the hour. Press “ok/esc” again.
The minutes will flash, press “+/-” to adjust the
minutes. After adjust the right value, press “ok/esc”
finish setting clock. Normally display the clock.
When go into the set the process of “+/- ok/esc” for
more than 1 minutes, the setting could be
automatically retreat and the program change to
normal mode .
Turn on the fan: first press switch button “ ” fan
start the 3rd speed, the window display“ ”,
can be adjusted. Press fan speed button“ ”the
speed can be adjusted and show the fan symbol.
Press switch button“ ”again, the fan will be turn off.
Lamp control: Press lamp button“ ”, the lamp turn
on, press again, the lamp turn off.
Delay function: when hood working, press delay button
“ ”,window right top corner show “ ”,press
“+/-” adjust the delay time, max 15 Minutes. If the time
arrives, the display and motor turn off automatically.
If set to “0”, and no adjust in 3 seconds, it will exit the
delay function, the fan will keep running.
If press the switch button“ ”before delay time
arrive, the fan will turn off directly.
Set clock, alarm, ventilation and function: First press
“ ” button, show symbol “ ” and flash. Press
“ ” again, 4 symbol “ ” flash circularly.
When anyone symbol flashing, press “ok/esc” button.
Enter relevant function. Set clock please reference 2nd .
Set alarm function: press “ ” till symbol “ ”
flash, press“ok/esc” display residual time, re-press
“ok/esc” in 5 second, enter setting alarm function. The
minutes, flash, press“+ -” adjust to right hour.
Press “+ -” adjust to right hour. Press “ok/esc” finish
the alarm setting, exit to the clock display, startup the
alarm function and show “ ” till alarm finish , the
buzzer will remind.
6
Operating Instruction
Operation Explain 1.
2.
3.
4.
5.
6.
7.
Normal display clock
03

7
Operating Instruction
If in the setting status, in 1 minute no press “+ -ok/esc”
will exit alarm to “00:00” or press”ok/esc” keep in 3s
in setting status, can cancel the alarm function.
Self cleaning function: When the hood is used for a
certain time, the self cleaning function icon on the
display will flash. It indicates the self cleaning function
should be activated. Any other functions except light
and linkage function should be closed, then press the
“ok/esc” button to start the self-cleaning function.
As the down-counter is shown on right-up corner of
the display. The self cleaning function will keep
running for about 30 minutes. When finished, the
display will automatically close. During self cleaning,
a long-time press on the “ok/esc” button for about 3
seconds will shop self cleaning function ahead of time.
If the self cleaning lasts less than 10 minutes and is
shut off, the “ ” Icon may flash which reminds of
another self cleaning. When “ ” icon is flashing,
users could press “ ” button for 3 seconds to
cancel the reminding compulsively. During self
cleaning, all buttons will not work except the following
buttons- “ ” “ ” and “ok/esc”.
When the displayer doesn’t show the self cleaning
icon and any other functions except light are off,press
“ ” for 3 times till the “ ” icon flashes. Press
“ok/esc” button again to activate the self cleaning
function with the “ ” icon on.If this operation is not
finished in one minute,it will exit the menu
mode.During self cleaning,a long-time press on the
“ok/esc” button for about 3 seconds will halt the self
cleaning function ahead of time.
Attentions:Before self cleaning,clean the grease
collector in case of grease spilling. During self
cleaning, keep an eye on the spot in case of
unexpected problems.
Remarks: please clean up the pil collector, every time
before self cleaning, to prevent overflowing.
During self cleaning,please don’t move away, to
prevent dengerous case.
Ventilation function:when blower is not working
status,press “ ” till “ ” flash, press “ok/esc”
enter the ventilation function.Show “ ” , the fan
will running for 5 minutes in every hour. During the 5
minutes the display will shows the symbol“ ”.

8
Operating Instruction
During the stop 55 minutes, the display shows “ ”
During the fan running, press the “ ” till “ ”
flash. If press “ok/esc”, it will no respond and can not
enter the ventilation function.
Press any key except “ ”, it will cancel ventilation
functional.
Setting lock function: If the fan is stopped, press
“ ” till “ ” flash, press “ ok/esc” to startup the
lock .Except “ ” and “ok/esc”, other key no
function respond. When fan running, press”ok/esc” no
respond. Exit the lock status: press “ ” for 3s till
“ ” .Flashing, press “ok/esc” in 5s to cancel the
lock function.
Gas hob Cooker hood” Interlink function:
(Tips: Symbol “ ” is not an operating function.)
Condition of starting interlink: the installed distance
between cooker hood and gas hob is less than 5 m. A
gas hob can only match one cooker hood.
Matching code for first use: the cooker hood and gas
hob are both electrified. Push “ ” on cooker
hood for 3 sec., it is twinkling with display “ ”
waiting for matching. Then do the operation according
to operating manual of gas hob.
Cooker hood beeps once after matching finish,
display “ ” for 2 sec. so the interlink function of
cooker hood and gas hob is done.
Interlink : when turning on the gas hob, the interlinked
cooker hood starts under speed 3 automatically.
While turning off the gas hob, the cooker hood shuts
down after 3 min. under speed 1.
Light, Fan speed, Time-lapse, Turn on/off cooker
hood, Auto-ventilation and Locked functions can all
operate when interlinked.
Interlink function can not work when self cleaning
function is running.
8.

9
Read these instructions carefully and keep them in a
safe place. Safety during use can only be ensured if
the appliance is fitted correctly according to these
installation instructions. The installer is responsible
for ensuring that the appliance operates perfectly at
the point of installation.
For installation, currently applicable building
regulations and the regulations of local electricity and
gas suppliers must be observed.
The appliance must be connected to the mains only
by a licensed and trained technician.
If your kitchen is under renovation, please do not
expose the cooker hood outside, as building materials,
dusts, paints and volatilized gas can corrode and
stain the surface of the cooker hood. The cooker
hood must be installed only after decoration or
renovation.
To move and install the cooker hood, do not move it
while grasping the glass frame and the front panel
with hands, so as to avoid breaking or loosening the
glass.
If the connecting cable for this appliance is damaged,
the cable must be replaced by the manufacturer or
his customer service or a similarly qualified person in
order to prevent serious injury to the user.
Do not install the cooker hood on a wall made of
inflammable substances such as wood. The wall must
be non-combustible.
Do not let the cooker hood and other gas equipments
(e.g. gas water heater) share the same chimney duct.
The cooker hood follows all the relevant safety
regulations.
The cooker hood must be grounded. A three pin plug
is provided, and this plug must be inserted in a truly
grounded receptacle. In case of current leakage, a
current loop is formed by the grounding to avoid an
electric shock.
Installation Instruction
Safety Precautions
truly grounding

10
Installation Instruction
Install the cooker hood in a dry place and avoid direct
sunlight.
The cooker hood is intended to be mounted onto the
kitchen wall.
Always mount the cooker hood over the centre of the hob.
Ensure that the minimum distance between
- the cooker hood and a gas hob is maintained at 750mm
- the cooker hood and an electric hob is maintained at
650mm.
Each cooker hood is equipped with an adjustable
cover. The adjustable hood is installed in the
decorative cover, which may be drawn upwards to
cater the installation height.
Please read the dimensions shown in the figure before
using the adjustable cover. The adjustable cover is
fixed on the wall by using fixing brackets via screws.
Installation Position
and Height
Minimum 750 mm from gas hob
Minimum 650 mm from electric hob
870
LC38S953..
Dimension A (mm)
Product Model
Adjustable cover
Minimum10mm
MaximumA
Fixing Brackets
Decorative cover
45mm
300mm
375mm
379mm

11
Determine the installation positions of the fasteners
(fixing brackets and mounting rails) on the wall and
follow steps indicated in photo below. If the adjustable
cover is not needed, skip step 5.
Draw a line on the wall from the ceiling to the lower
edge of the hood at the centre of the location where
the hood is going to be mounted.
After determining installation positions of the
fasteners on the wall, use a driller with a diameter of
10 mm to drill holes in the wall.
Insert the accessory wall plug into the drilling holes
and fix the fasteners (fixing brackets and mounting
rails) onto the wall with the accessory fixing screws.
Installation Instruction
Installation of Fasteners
Product Model
Dimension B (mm)
Mounting
Rails
Minimum 750 mm
from gas hob
Minimum 650 mm
from electric hob
Note:
The lower edge of dimension B is the bottom point of
cooker hood (Oil collector is not included).
LC38S953..
485
Fixing
Brackets
347mm
45mm
120mm
220mm
B

12
Installation Instruction
Hang the cooker hood on to the fixing brackets on the
wall. Make sure the cooker hood does not shake or
hook off. Keep the cooker hood horizontal.
Install the accessory fixing screws in the notch as
shown in the figure to prevent the cooker hood falling
off from the mounting rails.
Each cooker hood is equipped with an exhausted
plastic pipe in a diameter of 175mm. The exhausted
pipe is 1.65m long when completely stretched.
Please connect one end of the exhausted pipe to the
outlet duct on the cooker hood and connect the other
end of the exhausted pipe to the common chimney
duct or the drilling hole in the external wall (the
diameter of the drilling hole is 180mm).
For optimum extractor hood efficiency:
Diameter of pipe should be as large as possible and
no tight bends in pipe.
The exhausted pipe can not be bent into a “凹” shape
(as few bends as possible).
Do not connect the exhausted pipe to another pipe
with a diameter smaller than 175mm.
Do not use a pipe with a diameter smaller than
175mm with an intermediate connecting pipe.
Fixing Cooker Hood
Connection of
Exhausted Pipe
Common chimney duct Directly discharge outside the wall
Minimum 30 mm
ø175mm
Maximum 1.65 m
1.
2.
3.
4.
Ø175mm
Ø175mm

13
If you need to connect the exhausted pipe to the
common chimney duct, DO NOT deeply insert the
exhausted pipe into the common chimney duct in
case the resistance increased when exhausting.
If you need to connect the exhausted pipe directly
outside the wall, a shutter (purchase additionally) is
recommended to be mounted at one end of the
exhausted pipe to prevent the external wind from
flowing back inside. Meanwhile, make sure the
exhausted pipe extending outside the wall is at least
30 mm.
The exhausted gas must not enter other hot flue
pipes, also for exhausting smoke of other fuels.
Fix the decorative cover and the adjustable cover on
the cooker hood according to the figure.
Insert the decorative cover into the cooker hood
vertically.
Draw out the adjustable cover from the decorative
cover, and fix it with the fixing brackets via screws.
Install the oil collector into the slot of the grease filter
frame according to the figure.
Installation Instruction
Connection of
Adjustable Cover
Installation of Oil Collector
5.
6.
7.
1.
2.
Connect to a common chimney duct Connect outside the wall
Minimum 30 mm
Ø175mm
Oil Collector

14
Cleaning, Maintenance and Repair
After installation, clean the surface of the cooker hood.
Insert the electric plug of the cooker hood into the
receptacle. Test run operation is performed according
to the “Operating Instruction”.
Pull off the electric plug before cleaning or maintaining
the cooker hood.
Wear protection gloves when cleaning or maintaining
the cooker hood, to prevent injuring yourself.
DO NOT clean the cooker hood directly with water.
The cooker hood should be cleaned regularly
depending on the using frequency and surrounding
environment to keep a good exhausting effect and
have a longer service life.
Clean Filter Frame
Clean the metal grease filter at regular intervals. For
cleaning, a soft cloth can be used to clean the
external surface.
Clean the Inner Frame
A soft wet cloth is used instead of a hard object or
steel wire ball.
Clean the Screen
Use neutral abradant-free detergents to clean the
surface of the outer shell.
Use a detergent special for glass to clean the glass
surface.
DO NOT use grinding sponge, sand cleaner, soda,
acid or chloride to clean the stainless steel surface.
DO NOT use any tool (e.g. steel wire ball) that may
easily damage the surface of cooker hood to wipe on it.
DO NOT use industrial detergents to clean the cooker
hood.
Clean the Filter Layer
Unscrew the screws for fixing the filter screen, take
down the filter screen, and immerse it in water
containing a detergent for over ten minutes. Then
wipe the inner filter screen with cloth.
Test Run
Cleaning and Maintaining
Your Cooker Hood
Filter frame
Filter layer
Grease Filter Frame

Oil Collector
15
When two third of the oil collector is filled up, the oil
collector should be cleaned to avoid any oil spills.
Detach the oil collector according to the figure.
Caution!!!
The cooker hood may cause a fire, if the oil collector
is not cleaned according to the methods mentioned in
the operation instruction.
Caution!!!
Maintenance of the cooker hood should only be done
by qualified technicians.
Refer to the following table for any possible malfunctions
and remedy. If the malfunction is still present, pull out
the plug of the cooker hood and contact our customer
service centre.
If one of the following malfunction occurs, please pull
out the electric plug of the cooker hood at once and
contact our customer service centre.
Irregular operating sounds are heard after turned on.
Vibration occurs during the operation.
Smell, smoke or heat release from the cooker hood.
Cleaning, Maintenance and Repair
Trouble Shooting
Problems
Appliance cannot work.
The motor does not work
and the lamp cannot be
turned on.
The motor works but the
lamp cannot be turned on.
The suction force is not
strong enough.
“E1” shown in screen when
self cleaning is operating.
“E2” shown in screen, fan
can work, discontinuous
beeps and all control
buttons locked when self
cleaning is not operating.
Possible cause
Electromagnetism
disturbance.
The plug is not or
improperly inserted or no
power supply.
The lamp is damaged.
Not adjusted to the
maximum fan speed.
Air convection is strong.
Self cleaning function is
defected.
Self cleaning controlling
components is broken.
Notes/Remedy
Pull out the plug, Re-insert it
after 1 min.
Make sure the plug is
inserted properly. Ask an
electrician to repair.
Replace the lamp.
Adjust the fan speed to the
maximum rank.
Close the window at one side.
Pull out the plug, Re-insert it
after 1 min.
Pull out the plug, Re-insert it
after 1 min. If this problem can
not be removed, please pull out
the plug and contact Siemens
customer service centre.

16
Cleaning, Maintenance and Repair
Steps to change the fluorescent lamp:
1. Switch off the extractor hood and pulling out the
main plug or switching off the fuse on the installation
side.
Caution!!!
When switched on, the fluorescent lamp becomes
very hot. Even for some time after the lamp have
been switched off there is still a risk of burns.
2. Using screw driver to disassembly the lamp
assembly.
3. Push down the lamp assembly then take out the
lamp assembly.
4. Disconnect the lamp wire.
5. Removing adhesive tape
6. Push the lamp canopy top panel and disassembly
the lamp cover and lamp canopy top panel.
7. Circumrotating the fluorescent bulb until the
fluorescent bulb can be move out.
8. Replace the fluorescent lamp (conventional
fluorescent lamp , 220 Volt, max. 12Watt ).
Caution!!!
Risk of breakage !
9. Reassemble all parts according contrary sequence.
Changing the Fluorescent
Lamp
Note:
If the light does not function, check that the bulbs have
been inserted correctly.
1
2
2
3
2
1
1
2
3
1

Considerable injuries may be caused by faulty repairs.
Repairs to the appliance must only be carried out by
a trained technician. If a repair is required, please call
the after-sales service.
When cleaning things around the cooker hood (such
as ceiling, cabinet) which may touch the hood, please
war protection glove or take other protection
measures to prevent injuries.
The manufacturer accepts no responsibility for
damage which arises as a result of disregarding the
instruction manual.
If your cooker hood does not work properly, check the
possible explanations in “Trouble Shooting” page
before calling our customer service. When you call,
please quote the E-Nr. (product number), serial No.
and FD (production date). Information are shown on
the rating label as below:
Customer Service
Tips
LC65S953..
Label Positioning
BSH Electrical Appliances (Jiangsu) Co.,Ltd
Hood Type
E-Number
Type
Input
Elec.Control
Serial No.
Origin
Voltage/Frequency
Color/Material
FD No.
Avoid turning on the gas hob without a pan or with an empty pan, so as
to protect the product.
Select a proper detergent, to avoid the coating peels off the surface of
the product.
The cooker hood needs to be cleaned regularly to remove water and
grease stains on the surface. (make sure no water enter the eletric
components such as switch and motor)
Wear rubber glovers when cleaning the cooker hood, to prevent your
finger from being hurt in cleaning.
Unscrew the screw nut with hands in a clockwise direction.
Pull off the electric plug before cleaning.
Laymen are forbidden to change and detach internal circuits of the
electric appliance.
Attention
17

Material Number: 9000597286
Version: 01
Revised Date: 2011.04
Guarantee: The guarantee conditions for this appliance are as defined by our representative in the country in
which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was
purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee.
