Wooden Parts Continued
Qty Assembly Name Size & Material Qty Assembly Name Size & Material
2 Wing Wing Dowel 1/ "x1" Birch Dowel 2 Wing Wing Bolt Plate 1/32"x3/ "x1-1/ " Birch Ply
2 Wing Aileron 0”x1-1/2”x25” Balsa
Trailing Edge
2 Wing Torque Rod Bearing
Block
0”x1-1/2”x3-29/32” Balsa
Trailing Edge
Wing Servo Rails 1/ ”x1/ ”x1-1/ ” Spruce Stick 18 Wing Shear Webs 3/32”x2-7/8”x1-5/32” Balsa
Sheet
2 Tip Float Tip Float Leading
Edge
1/ ”x1-3/ ”x -3/ ” Balsa
Sheet
2 Tip Float Tip Float Trailing
Edge
1/ ”x1/ ”x6” Balsa Stick
12 Tip Float Tip Float Sheet 1/16”x3”x7” Balsa Sheet 3 Pylon Pylon Sheet 3/32”x3”x5” Balsa Sheet
1 Pylon Pylon Tail Block ”x3-1/ ”x -3/ ” Balsa Block 3 Pylon Pylon Engine Fairing
Sheet
1/ ”x3”x -3/ ” Balsa Sheet
1 Tail Surfaces Fin Gussets 1/ ”x1/ ”x12” Balsa Triangle 1 Tail Surfaces Tail Surface
Framework
1/ ”x1/ ”x ” Balsa Stick.
2 Tail Surfaces Tail Surface
Framework
1/ ”x1/2”x36” Balsa Stick 1 Tail Surfaces Tail Surface
Framework
1/ ”x3/ ”x36” Balsa Stick
1 Tail Surfaces Tail Surface
Framework
1/ ”x1”x9” Balsa Stick 1 Tail Surfaces Tail Surface
Framework
1/ ”x1-1/ ”x21-3/ ” Balsa
Stick
Hardware
Qty Assembly Name Size & Material Qty Assembly Name Size & Material
Tip Float Tip Float Attach 8-32 x1-1/2” Pan Head Nylon
Screw
Tip Float Tip Float Attach 8-32 Blind Nut
1 Wing Strip Aileron Horn
Set
Left & Right Torque Rods with
Connectors
2 Wing Aileron Pushrod 2-56 Pushrod 3” Long
5 Wing,
Fuselage &
Pod
Clevis Nylon 2-56 R/C Link Wing &
Fuselage
Clevis 2-56 Solder Link
16 Wing & Tail
Surfaces
Hinge Sig Easy Hinge 2 Fuselage Pushrod Housings 2 ” Nylon Pushrod Housing
2 Fuselage Pushrod 2 ” Nylon Pushrod 2 Fuselage Pushrod End - Elev.
& Rud
2-56 pushrod 7” long
2 Fuselage Pushrod End - @
Servos
2-56 pushrod 1-1/2” long 1 Tail Surfaces Elevator Joiner Bent 3/32” Music Wire
2 Tail Surfaces Nylon Control
Horns
Sig Medium Control Horns - 1
Left & 1 Right
Tail Surfaces Control Horns
Screws
#2 x1/2” Sheet Metal Screw.
2 Wing Wing Attach Bolts 1/ -20 x1-1/2” Pan Head
Nylon Screw
1 Fuselage Switch Pushrod 3/6 ”x5” Music Wire
1 Pylon Pushrod Connector
Body
Brass Pushrod Connector Body 1 Pylon Pushrod Connector
Screw
- 0 x1/8” Socket Head Screw
1 Pylon Pushrod Connector
Retainer
Molded Nylon Retainer 1 Pylon Threaded Brass
Coupler
2-56 Brass Coupler
1 Pylon Throttle Pushrod
Housing
Pushrod Housing 18” 1 Pylon Throttle Pushrod
Cable
Pushrod Cable 18”
Misc. Parts
Qty Assembly Name Size & Material Qty Assembly Name Size & Material
1 Misc Decal Sheet 1 Color Mylar Decal 1 Misc Fuselage Plan 36”x 8” Plan sheet A
1 Misc Wing Plan 36”x 8” Plan sheet B 1 Misc Instruction Manual Instruction Manual
1 Misc Windshield .015”x ”x8-1/2” Clear Plastic
Additional Items (Not included in Kit)
Qty Assembly Name Size & Material Qty Assembly Name Size & Material
1 Pylon Motor Mount Dave Brown Mount to Fit
Engine Used
8 Pylon Mounting Bolts 6-32 x3/ ” Socket Head Cap
Screws
8 Pylon Washers 6-32 Washer Pylon Blind Nuts 6-32 Blind Nut
1 Pylon Fuel Tank Sullivan 8 oz. Round Fuel Tank 1 Pylon Spinner Sig 2-1/ ” Spinner
1 Pylon Fuel Line Sig Medium Fuel Line 2 All Covering
2 Rolls Iron On Covering + Trim
Color
1 Pylon Propeller To Fit Engine Used 1 Pylon Engine . 0 to . 6 2-cycle or . 0 to .50
-cycle
1 All Radio -Channel Radio with
Standard Servos
2 Fuselage Radio Protection 3/8”x3”x8” Foam Rubber
Optional Landing Gear Parts (Not included in Kit)
Qty Assembly Name Size & Material Qty Assembly Name Size & Material
2 Main Landing
Gear
Main Wheels 3” Wheels Main Landing
Gear
Wheel Collars 5/32” Wheel Collars
