SIGELEI 213 FOG User manual

Sigelei 213 FOG User Manual
1.Product Parameters
Size：130.37*43.9*29.7mm
Main Material：Zinc alloy + aluminum alloy
Display：0.92 inch TFT screen
Wattage Range：5W~8213W
Temperature Range：100℃~300℃/200℉~570℉
Input Voltage：6.4V~8.4V
Output Voltage：1.0V~8.4V
Support Battery：2*18650
Working Mode：AUTO / MANU / BYPASS
Resistance Range：0.12Ω~3.00Ω
Support Coil Material：Nickel chrome/Titanium /Nickel/Stainless steel
Charging Interface: USB type C
Recommended adapters: 5V/2A
2.Main Features
⑴0.92inch TFT screen (0.92 寸真彩屏显示)
⑵ Free switch among 3 working modes (3 种工作模式可自由却换)
⑶ SMART AUTO mode: intelligent constant power output (AUTO 模式 状态下 SMART 智
能恒功率输出)
⑷ AUTO mode:Automatic configuration of Resistance and wattage （AUTO 模式 阻值
与功率自动配置）
⑸ MANU mode: freely adjustment from 5~213w （MANU 模式 5-213W 自由调节功率）
⑹BYPASS mode:full power output (BYPASS 模式全功率输出)
⑺Support fast charge function（支持快充功能）
⑻Automatic detection of coil’s resistance （雾化芯阻值自动检测）
⑼Battery overcharge protection（电池过充保护）
⑽USB overvoltage protection（USB 过压保护）
⑾Work overtime protection（工作超时保护）
⑿low voltage protection（电池低压保护）
⒀Output short circuit protection (输出短路保护)
⒁High/low resistance protection before output(输出前高阻/低阻保护)
⒂Over temperature protection (温度过高保护)

⒃Can vape while charging (充电时可吸烟)
3、Operation method
1）System turn on/off (开关机操作)：
under the off state, press the fire button 5 times in 3s to display the
startup logo "SIGELEI" and enter the on state.
(在关机状态下，3s 内连续按 5 次吸烟键，显示开机 logo“SIGELEI”，进入开机状态。)
Under the power-on state, press the fire button 5 times in 3s, the shutdown logo
"BYD" is displayed, and it enters the shutdown state.
(在开机状态下，3s 内连续按 5 次吸烟键，显示关机 logo“BYE”，进入关机状态。)
2）operation(复用键操作)：
Child lock function: under the power-on state, press the + and -buttons for 3S
to enter the child lock function. Under this state, you can vape normally, and the
+ and - buttons are locked. Doing Same operation,The child lock function cancelled.
（童锁功能：开机状态，同时按住+键和-键 3S 进入童锁功能，此状态可以正常吸烟，+、-
键锁死，同样操作童锁功能取消）
3）Working mode conversion (工作模式转换)：
Power on, quickly tap the fire button 3 times within 1S,freely Switch among automatic
AUTO mode, RBA mode/BYPASS mode (Power on for the first time/after software reset
Default: AUTO mode)（在开机状态下，1S 内快速点按 3 次点火键，自动转换 AUTO 模式、
MANU 模式/BYPASS 模式（第一次开机和软件复位后默认：AUTO 模式）
4）AUTO mode: display AUTO
In AUTO mode/MAUN mode, press the "+" button to increase the power, increase by 1W,
the maximum power is 213w, long press for rapid increase, increase to the maximum
power 213w And prompt MAX POWER,（在 AUTO 模式/MAUN 模式下，点按“+”键功率增加，
递增 1W,最大功率为 213w , 长按为快速递增，增加到最大功率 213w 并提示 MAX POWER,）
4.1 Vaping Tips(吸烟提示)
1）Turn on & connect atomizer, automatically detect the resistance of the atomizer
and prompt "Seasure X.XX Ω"(开机接入雾化器，自动检测雾化器阻值并提示“Seasure X.XX
Ω”)

2）If one puff exceeds 10s, stop vaping, prompt "OVER FIRE", and stop output(单
次吸烟超过 10s，停止吸烟，提示“OVER FIRE”,并停止输出)
3） Vaping over 0.3S is one effective smoking, and the system automatically
accumulates one time.(吸烟超过 0.3S 为 1 次有效吸烟，系统自动累加 1 次)
4）The interface battery percentage is the current battery level. (界面电池百分
比为当前电池电量。)
5） Enter sleep: Without any operation, enter sleep state within 30 seconds. (进
入休眠：无任何操作，30 秒内进入休眠状态。)
6）under sleep state, vaping/charging/unplugging & stop charging/connecting the
atomizer/removing the atomizer/pressing any button can wake up the body.(休眠状
态，吸烟/充电/拔出充电/接入雾化器/移除雾化器/按任何按键均能唤醒主体。)
4.2 Failure prompt 故障提示
1） Atomizer failure (including: resistance lower than 0.12Ω, atomizer short
circuit)Will prompt "SHORT". (The atomizer resistance is over 3Ω, and the atomizer
cannot be detected) “CHECK POD” will be prompted.
(雾化器故障(包括：雾化器阻值低于 0.12Ω、雾化器短路）会提示“SHORT”。（雾化器大
于 3Ω、检测不到雾化器）会提示“CHECK POD”。)
2） Battery failure(电池故障)
If the power is insufficient (no load is lower than 3.2V, with load lower than 3.0),
the output is prohibited, and the prompt "BATTERY LOW" displayed. (电量不足（空
载低于 3.2V，带载低于 3.0），禁止输出，提示“BATTERY LOW”。)
4.3 Protection Tips(保护提示)
1）High temperature protection tips（高温保护提示）
When the PCBA temperature exceeds 80℃, it will prompt "OVER HEAT" and turn off
the output（持续工作到 PCBA 温度超过 80℃后提示“OVER HEAT”，并关断输出。）
2）vaping overtime protection prompt（吸烟超时保护提示 ）
3） Long press the vaping button to vape for 10 seconds, the display will prompt
"OVER FIRE" and turn off the output.（长按吸烟键吸烟 10S，显示屏提示“OVER FIRE”，

并关断输出。）
4）Key child lock protection prompt（按键童锁保护提示）
When device turned on, press the “+ ”and “-”keys at the same time for 3S, the
display prompts "LOCKED", the main interface shows a red lock icon, and the “+ ”
and “-”keys are locked.At this time，if press the “+ ”or “-”keys, the display
will prompt "LOCKED".（开机状态，同时按住+键和-键 3S，显示屏提示“LOCKED”主界面
界面显示红色锁头图标，+、- 键锁死，此时点按+、 -键显示屏提示“LOCKED”。）
5）Turn on and child lock protection status, press the “+ ”and “-”buttons
at the same time for 3S, the display prompts "UNLOCK" The main interface interface
displays the green lock icon, “+ ”and “-”keys are used normally.（开机童锁保
护状态，同时按住+键和-键 3S，显示屏提示“UNLOCK”主界面界面显示绿色锁头图标，+、
- 键正常使用。）
Tips（温馨提示）:
Please read the instructions carefully before use.（请在使用前仔细阅读
说明书。）
1.This product is not suitable for people under the age of 18, pregnant
or lactating women, or people with heart disease, or high blood pressure
and diabetes, or depression, or people with dangerous diseases such as
asthma.（本产品不适合 18 岁以下的人员以及怀孕或哺乳期的女性，或有心脏疾
病，或有高血压和糖尿病，或有抑郁症，或有哮喘等危险疾病的人群；）
2.This product may include small parts, please keep it out of the reach
of children and pets to avoid danger;（本产品可能包括细小零件，请放在
儿童和宠物接触不到的地方，以免发生危险；）
3.Please do not put this product in an overheated or cold and humid
environment;（请不要将本产品放在过热或过冷以及潮湿的环境中；）
4.Please do not discard or abuse this product;（请不要丢弃或滥用本产品；
5.This product is sold purely for entertainment purposes-it is not a
smoking cessation product;（本产品出售纯粹为了娱乐目的——它不是一个戒
烟产品；）
5.If you want to use an e-liquid atomizer, please set it to work below
the maximum wattage that your atomizer can withstand;（如果您想使用液
体烟油雾化器，请设定在您的雾化器所能承受的最大瓦数以下工作；

）
6. When charging, you must use a genuine charger certified by an authority
to charge the product;（充电时必须使用经过权威机构认证的正品充电器对产
品充电；）
7. Do not disassemble, repair, or modify this product privately.（请勿
私自拆解、维修、改装本产品。）
