VooPoo DRAG 2 User manual

Manual Instruction
DRAG 2

Parameters :
Size : 88.3 x 51 x 26.5mm
Power Output : 5-177W
Battery : Dual battery 18650 x 2
Program upgradable : Yes
Resistance Range :
Non-TC wire : 0.05-5.0Ω（±5%）
TC wire : 0.05-1.5Ω（±5%）
Product description :
1. Appearance & Main Parameters:
510 Thread
Power Button
Screen
“+” Up Button
“-” Down Button
Micro-USB Port

3.Eight Security Protection :
- Overtime protection
- Over temperature protection
- Output over-current protection
- Overcharge protection
- Low battery protection
- Atomizer short-circuit protection
- Support balance charge with batteries
from different manufacturers
- Battery anti-reverse protection
2.Electric Parameter :
NO.
1
2
3
4
5
6
7
8
Working voltage 6.4～8.5 ±0.1 V
Output voltage range 0～7.5 ±2% V
Overheat protection 80 ±5% ℃
Input charging voltage 5 ±0.25 V
Output charging voltage 1800 ±5%
-
-
mA
Quiescent currency ≤10 uA
Temperature Range 200-600℉
100-315℃
℉
℃
Power conversion efficiency 95% -5%～0 %
Item Range Accuracy Unit

Instructions :
1. Basic Operation
①. Press the fire button for 5 times: Power on/off
Press the fire button for 3 times: Sequently switch
from Power mode → FIT mode → TC mode
②. Press “+” and “-” buttons simultaneously:
Enter function menu
③. Press the fire and “+” buttons simultaneously:
Lock/Unlock
④. Press the fire and “-” buttons simultaneously：
Switch screen orientation.
①
②
④
③

2. Four Mode Settings :
Power Mode FIT Mode
TC Mode Custom Mode
3. Four Mode Operations :
A. Power Mode:
a). Adjust the wattage from 5W to 177W, The
product automatically recommends the
output wattage according to the resistance
of the atomizer when it detects that a new
atomizer has been attached.
b). Press up and down buttons at the same
time，enter function menu：
Power Mode Custom Mode
Series Number Software Version

B. FIT Mode:
a). Boot default , Press “+” or “-” button to
select the three options .
C. TC Mode:
a). Support SS, Ni, Ti, NC, TC, 5 kinds of
heating wire, factory default SS, Ni, Ti,
Connect computer APP to open NC, TC；
b). Temperature control adjustable range ：
200-600℉/ 100-315℃
- When the temperature setting is at 100℃,
keep pressing “-”, it will turn to be 600℉;
- When the temperature setting is at 200℉,
keep pressing “-”, it will turn to be 315°C.
c). To adjust wattage while in TC Mode, press
fire button 4 times rapidly to activate wattage
adjustment. You will see the “W” wattage icon
flashing. The wattage can be adjusted from
5W to 80W.
d). Press “+” and “-”Simultaneously，Enter
function menu ：
TC Mode Custom Mode
Coil Cooling Value Coil Coefficien

D. Custom Mode:
a). Custom mode under Power mode or TC
mode:
- Press “+” and “-”Simultaneously，Enter
function menu , select and Switch
M1 to M5；
- Press fire button 4 times，Switch ：Power
customization (W) → FIT mode →TC
customization (SS, Ni, Ti)；
b). Under Custom Mode, there are 2 ways to
adjust the value：
- Manually switch custom curve per second
(Shortly press fire button 4 times to enter
the curve interface, press UP/DOWN to
adjust, then long press fire button to exit.),
see the chart below:
- Connect to a computer app for custom
settings
e). Coil cooling value range : 0.05～1.50Ω
Power curve—current
watt shown on top right
TC curve—current
temperature shown on top right

More instructions :
A. Sleep Mode:
Screen will auto turn off in 30s without
operations, and will enter standby mode in
30min without operations/usage after screen
is turned off. To activate, press power button.
B. Charging Mode :
The device will enter charging state with the
battery icon running when it’s connected to
5V power supply with USB cable; when the
device is fully charged, the battery icon will
stop running.
Note：It takes 3 hours to fully charge the
device (5V/2A charger required).
C. Computer customization ：
You can do the following customization
operations via the VOOPOO Firmware:
Prompt page, Temperature coefficient,
Temperature curve, Wattage Curve, Increase
/Decrease Coil type and Device Upgrade etc.
Download address：http://www.voopoo.com.
D. Function tips :
TIME OUT CHECK COIL
LOW WATTAGE ATOMIZER SHORT

NO ATOMIZER ATOMIZER RESISTANCE
HIGH
HIGH TEMPERATURE
E. Accommodation coefficient of the
TC wire ：
Note：
1. The higher coil coefficient you set, the higher
coil temperature you get；
2. Because of the different material for the wire,
you may feel the power is not strong enough
when vaping, you can properly adjust the coil
coefficient at a higher rate to get a better
vaping experience；
3. Please adjust the coil coefficient at a low
rate, if too high there is a risk of firing cotton.
Coefficient Range
Ni：6000-7000
Ti：3500-4500
SS：1000-1600
NC：20-600
TC：100-700
6500
4000
1300
400
1000
Standard Default Value

Attention ：
a. Please keep device away from heat, fire and
water.
b. Please do not drop, throw or immerse the
device in water.
c. Please use the proper working mode
according to your atomizer’s material.
d. Please turn off or lock the device to avoid
mis-firing when you take it on the go.
e. Keep the contents of this package out of
reach of children and pregnant women.
f. Please use high rate discharge batteries ,
over 30A is recommended.
g. Please don’t use batteries with broken skin
or which are not completely insulated.
