User Manual
X-style 17

We thank you for buying mobile phone X-style 17. This
manual includes description of main mobile phone functions .
The phone X-style 17 allows to use 2 SIM cards of GSM
standard at Dual Standby mode, i.e., in standby mode there
are 2 cards in the connection; during the call 1 card works in
active mode, 1 other card are unavailable.
The content of this manual is right. The description of some
functions may differ due to changes in software or provider
services. The company keeps the right to arrange changes in
technical specifications without previous warning.
Key remarks in security technics.
Given phone is assigned for calling and receiving calls,
sending SMS messages, surfing the Internet (may be
unavailable) etc.
Read carefully the below section and strictly keep following
instructions.
The phone doesn't contain any materials harmful for health.
Don't use the phone during the thunderstorm in the open
air.
Keep the battery off from high temperature, explosive and
flammable liquids.
Power the phone off in case if using the phone can cause
the obstacle or danger.
Do not put the prone in heating devices such as microwave
oven, hot plate or heater.

Do not try to open the mobile phone's case. If phone or
any of accessories do not work properly, please contact
the closest authorized service center.
Use only accessories and charging devices assigned to this
model. Do not use defective or second hand chargers.
Do not let the battery short circuit happen.
If you use any personal medical devices, please clarify from
producer whether device has sufficient protection from
radiation in radio-spectrum. Power the phone off in
medical institutions if it is required with inner regulation
rules.
Do not use the phone during driving. Follow mobile phone
using recommendations while driving.
Keep the phone, all its components and accessories in a
place unavailable for kids and pets. They may damage the
device or accidentally choke with small details.
Avoid contacting phone with water.
Do not use potent chemicals, dissolvents or bleaches for
cleaning the phone.
Do not subject the device under the effect of direct sun
rays.
To avoid getting heavy metals, acids, chemicals in water or
ground what cause significant damage to environment,
wasted accumulator battery should be utilized after end of
service term in accordance to the law regulations. Juristic
responsibility occurs in case of failure to comply with
legislation.
Data about safe utilization of lithium-ion batteries may be
obtained in the closest specialized service center.

Specifications
Phone
2 SIM (mini-SIM)
GSM: 850/900/1800/1900 MHZ
Messages
SMS
Mob.
Internet
GPRS
Bluetooth
V3.0
Display
1.77’’, colour LCD, 160*128 pix
Supporting
formats
MIDI, AAC, MP3, WAV, JPG
FM-radio
87,5-108,0 MHz (built-in antenna)
Micro-SD
till 32 Gb
Battery
Li-Ion, 600 mAh
Package includes:
•Mobile phone
•Battery
•Charging device
•USB-micro-USB cable
•User manual
•Warranty card

Phone buttons.
1
Receiver
2
Central (OK) key
3
Left soft key (LSK)
4
Calling\receiving call
5
Navigation buttons

6
Right soft key (RSK)
7
Rebound\Cancel\ (long pressing - to power on
or power off phone)
8
Speaker
9
Torch
10
Audio port (3.5mm).
11
microUSB port
Keys specification
0-9
To dial the number. Press and hold keys
2-9 for speed dial of preset numbers. 0
key - Press and hold - Turn the flashlight
on / off
* key
In idle mode, press * key, cyclically
shows “*”, “＋”, ”P”, ”W”.
Press and hold * key to lock/unlock
keypad.
In input mode, enter punctuation.
# key
In idle mode, long press # activate or
deactivate silent profile.
When dial a number, press to enter “#”.
Left soft
key
Perform the functions indicated on the
left bottom line of the display.
Right soft
key
Perform the functions indicated on the
right bottom line of the display.

Press right soft key to return to upper
menu.
In idle mode, press right soft key to
access Phonebook menu.
Central
Key
Menu / OK.

Inserting SIM cards and memory card
Open the back cover.
Insert SIM cards in proper
device slots.
Insert also micro-SD card, if
required.
Insert battery, controlling
that battery contacts fit
phone contacts.
Be careful, broken card or
batteries cards lead to
device breakage and
cancelling warranty.
Close back cover.
Power on the phone long
pressing button 7 (red
handset).
It is recommended to
arrange full battery charge
before first use.
Conditional screen marks on phone
Connection signal

Battery charge indicator
New message
Missed call
Silence profile activated
Outdoor profile activated
Meeting profile activated
Alarm clock is active
Bluetooth switched on
GPRS Internet is active
Power on\off the device
To power on the device press and keep button «power» until
activation of device display.
To power off press and keep button «power» until shutdown.
Device locking occurs automatically, or after pressing and
holding button «*». Unlocking occurs pressing and holding
button «*».

Calling
To call - dial number on digital keyboard in local or
international format, or choose number from phone contacts
list, and press Call button. Choose from which SIM-card to call.
To cancel call –press 'cancel' button.
During call it is also possible to: switch volume in a
speakerphone mode, start conversation record, add more
persons to conference conversation, turn off\switch on
microphone and etc.
Main menu
To access the device's menu, press the left soft key or the
center navigation key.
The menu has the following sections:
Contacts: phone book of telephone contacts and SIM-cards;
Messaging: for sending SMS / MMS messages and reading
incoming messages;
Multimedia: In this menu, media features of the device are
gathered: gallery, audio player, video player, voice recorder.
Call logs: register incoming, outgoing and missed calls;
FM radio: Launched FM radio on a separate menu
Files. To view the files stored on the memory card
Application: alarm clock, calendar, Internet browser,
flashlight, calculator, Bluetooth, SIM menu

Settings: call settings, display settings, phone settings,
security settings, profiles, network
Games
Contacts
The Contacts menu is your phone book, which contains
contacts stored in the phone and on SIM cards. The phone
memory is designed to store 500 contacts.
Contacts are in alphabetical order. The search bar allows you
to find contacts. To switch the method / language of the
search press the # key
New contact: Add a new contact. Before creating, you have
to choose a place to save the contact.
To view the contact, select the cursor and press the center
navigation key.
For a call, press the call button.
Additional options open with the left soft key.
New message: Create and send a text message to the contact.
Edit: edit the contact
Delete: delete the selected contact.
Copy: Copy contact between phone and SIM card.
It also has the ability to: View memory status and delete all
contacts, make backups - export - or restore contacts - import
- (only if there is a memory card)

When backing up contacts in the root of the memory card, a
system file named vcard.vcf is created. When restoring
contacts, information is taken from the same file.
Adding a new contact: Choose "New" in the options, choose
a place to save the contact, enter a name and phone number,
press "options-save"
For one contact, you can add the following information:
Name (line length - 20 characters), Phone number, Group
Messaging
This menu contains everything you need to send, store, view
and delete SMS messages.
New SMS: Select to write and send (or save) a new message.
Inbox: Folder with received messages.
Outbox: Folders with sent messages.
Drafts: incomplete messages.
Sent: Messages that have been sent.
Settings: settings for sending SMS
The Settings menu allows you to set the SMS center numbers
for both SIM cards, set the validity period of the message,
configure receipt of the delivery status report, adjust the
settings for saving messages, switch off or enable push
messages.
Multimedia

Caution: It is desirable to use the following functions in the
menu "Multimedia" under the condition of the installed
memory card.
This section contains applications for working with photos,
videos and sound.
Images - to view images.
Audio player - for listening to music files
To play / pause, press the center key. To move to the next /
previous file - Right / Left. To create a playlist, copy the music
files to the audio folder on the memory card. To change the
settings, go to List-Options - Settings
Video player - to view video clips.
Voice recorder - for recording sound.
Call logs
Call logs menu contains incoming, outgoing and missed calls
register, counter GPRS traffic and allows: dial contact number,
send SMS-messages, add new number to contacts, add
number to black list, delete information about call and etc.
FM radio
NB! In this model, FM radio operates with a built-in antenna.
To improve the reception quality, you may need to connect a

wired headset as an antenna. The sound of the FM radio and
audio player is transferred to the external speaker and wired
headset.
To turn on / off, press the center key. To search for radio
stations, press Right / Left. Use the Up / Down keys to adjust
the volume. The Options menu has the ability to
automatically and manually search channels, view saved
stations, record files in a file and enable / disable background
playback.
My Files
File manager allows to work with files in phone memory and
in memory card. Following operations are available: copying,
moving, deleting, creating files, or setting melodies as phone
ringtones
Application
The following programs are available in this menu:
Alarm clock - allows you to set up several alarms.
Calendar - to view the calendar. It is possible to create / edit
/ view events
Internet browser
Calculator - for arithmetic calculations.
SIM menu
Bluetooth - setup, device review, device connection

Torch on/off
Settings
Calls. The menu allows you to configure the number of active
SIM cards, divert options, call barring, auto-dialing, auto-
dialing, and more.
Phone: contains date and time settings, interface language,
shortcut key settings, scheduling on / off settings. Also, this
menu allows you to reset to factory settings (WARNING.
Reset code 1122)
Display: Background settings, display contrast, screen
backlighting and keystrokes
Security: Provides the ability to set up SIM card lock, lock the
phone, auto-lock, and lock certain phone functions. This
menu also contains the Blacklist menu.
Profiles: The menu is intended to adjust the sound profiles, ie
volume settings, ringtones, vibrate mode, key sound and
system for different phone usage conditions such as: outdoor,
indoors, silence, and more. It is possible to edit the built-in
settings. To do this, press Options and Settings. To activate
the set of settings, you must select a profile in the menu and
press the center button.
Connections: allows you to set up GPRS, specify a default data
transfer card, set up an account for data transmission,
choose a way to select a network-manual or automatic.

Troubleshooting
Following recommendations may help to solve some
problems with phone independently. In case problems
occurs try to solve it yourself with following
recommendations. If problem is not solved, contact to Sigma
mobile service center.
Check whether battery is charged and whether problem
continues after device reset.
Try to restore factory settings through menu «Settings -
phone –Default settings» (password by default – 1122)
Problems with memory card mostly occurs in case of memory
card breakage. Thus, firstly check given card separately. Also
recommended to: take off and insert memory card in port,
check whether card is put in port correctly, reload phone.
Phone does not power on: check battery charge, repeatedly
connect charging device, and wait at least 10 minutes. Press
and keep the button «Power on» not less than 5 second. If
device does not power on contact in service center.
Battery discharges rapidly: reasons for increased battery
charges may be: low air temperature, active using of media
programs, huge distance to cellular tower of connection
operator.
Battery does not charge: check charging adapter connection
to plug. Use only complete charging adapter and cable.
Impossible to call: this problem may be caused by law
connection signal, network overloading, incorrect input of
contact number, activated function of calling prohibition. Try

to change location, check level of connection signal, wipe
phone to factory reset. Contact in service center.
Low receiver volume: during conversation, press button «up»
to increase volume. Set volume during conversation in
profiles. Check signal of cellular connection.
Passwords
Requests to input following passwords may occur during
activating and phone use :
Phone password: request occurs during activating. This is the
password of general locking.
Password to reset to factory settings - 1122
PIN-code: if Pin-code checking is active, it is required to input
code which is given with SIM-card.
PUK code, PIN2 code - also given with SIM card.
Be careful installing blocking passwords: if they are lost, to
renew phone functionality is possible only in service center.
