Sigma X-style 35 User manual

We thank you for buying mobile phone X-style 35. Given
manual includes description of main mobile phone
functions .
The phone X-style 35 allows to use 2 SIM cards of GSM
standard at dual standby mode, i.e., in standby mode there
are 2 cards in the connection; during the call 1 card works in
active mode, 1 other card are unavailable.
The content of given manual is right. The description of some
functions may differ due to changes in software or provider
services. The company keeps the right to arrange changes in
technical specifications without previous warning.
Key remarks in security technics.
Given phone is assigned for calling and receiving calls,
sending SMS messages, surfing the Internet (may be
unavailable) etc.
Read carefully the below section and strictly keep following
instructions.
The phone doesn't contain any materials harmful for health.
Don't use the phone during the thunderstorm in the open
air.
Keep the battery off from high temperature, explosive and
flammable liquids.
Power the phone off in case if using the phone can cause
the obstacle or danger.
Do not put the prone in heating devices such as microwave
oven, hot plate or heater.

Do not try to open the mobile phone's case. If phone or
any of accessories do not work properly, please contact
the closest authorized service center.
Use only accessories and charging devices assigned to this
model. Do not use defective or second hand chargers.
Do not let the battery short circuit happen.
If you use any personal medical devices, please clarify from
producer whether device has sufficient protection from
radiation in radio-spectrum. Power the phone off in
medical institutions if it is required with inner regulation
rules.
Do not use the phone during driving. Follow mobile phone
using recommendations while driving.
Keep the phone, all its components and accessories in a
place unavailable for kids and pets. They may damage the
device or accidentally choke with small details.
Avoid contacting phone with water.
Do not use potent chemicals, dissolvent or bleaches for
cleaning the phone.
Do not subject the device under the effect of direct sun
rays.
To avoid getting heavy metals, acids, chemicals in water or
ground what cause significant damage to environment,
wasted accumulator battery should be utilized after end of
service term in accordance to the law regulations. Juristic
responsibility occurs in case of failure to comply with
legislation.
Data about safe utilization of lithium-ion batteries may be
obtained in the closest specialized service center.

Specifications
Phone
2 SIM (mini-SIM)
GSM: 850/900/1800/1900 MHZ
Messages
SMS
Mob.
Internet
GPRS
Display
3,5’’, colour LCD, 320x480 pix
Camera
2,0 Мpx
Supporting
formats
MIDI, AAC, MP3, WAV, JPG
FM-radio
87,5-108,0 MHz (built-in antenna)
Micro-SD
till 32 Gb
Battery
Li-Ion, 1750 mAh
Package includes:
•Mobile phone
•Battery
•Charging device
•USB-micro-USB cable
•User manual
•Warranty card

Phone buttons.
1
Receiver
2
Central (OK) key
3
Left soft button
4
Calling\receiving call
5
Camera
6
Flash light
7
Right soft button

8
Navigation buttons.
9
End\Cancel\ (pressing and holding- to power on
or power off phone)
10
Speaker
11
microUSB port
12
Audio port (3.5mm)
Keys specification
0-9
When dial a number, enter
corresponding number.
In input mode, enter different characters
according to input mode, like letter or
number.
Press and hold 2-9 –for speed dial. Press
and hold 0 –to input ＋, P, W .
* key
When dial a number, press to enter “*”.
Press left soft key then press * key to
lock/unlock keypad.
In input mode, * to input special
symbols.
# key
In idle mode, long press # activate or
deactivate silent profile.
When dial a number, press to enter “#”.
Left soft
key
Perform the functions indicated on the
left bottom line of the display.
Press left soft key then press * key to
lock/unlock keypad.

Right soft
key
Perform the functions indicated on the
right bottom line of the display.
Press right soft key to return to upper
menu.
In idle mode, press right soft key to
access Phonebook menu.
Central
Key
Menu / OK. Press and hold in standby
mode - Enable / Disable Torch

Inserting SIM cards and memory card
Open the back cover.
Insert SIM cards in proper
device slots.
Insert also micro-SD card, if
required.
Insert battery, controlling that
battery contacts fit phone
contacts.
Be careful, broken card or
batteries cards lead to device
breakage and cancelling
warranty.
Close back cover.
Power on the phone long
pressing button 9 (red
handset).
It is recommended to arrange
full battery charge before first
use.
Conditional screen marks on phone
Connection signal

Battery charge indicator
New message
Missed call
Silence profile activated
Outdoor profile activated
Meeting profile activated
Alarm clock is active
Bluetooth switched on
GPRS Internet is active
Keyboard locked
Power on\off the device
To power on the device press and hold End button until
activation of device display.
To power off press and hold End button until shutdown.

Device locking occurs automatically, or after consequent
pressing left soft button and button «*». Unlocking occurs
through consequent pressing left soft-button and button «*».
Calling
To call - dial number on digital keyboard in local or
international format, or choose number from phone contacts
list, and press calling button. Choose from which SIM-card to
call. To cancel call - press button 'cancel'.
During call it is also possible to: switch volume in a
speakerphone mode, start conversation record, add more
persons to conference conversation, turn off\switch on
microphone and etc.
Main menu
To access the main device menu you need to press left soft-
button or central navigation button.
Menu includes following section:
Phonebook: phone book including phone and SIM cards
storage;
Messaging: to send SMS messages and read received
messages;
Calls: incoming, outgoing and missed calls register;
Setting: Phone settings, dual SIM settings, font size settings,
security settings, network settings, connectivity and Restore
settings
Audio player: The audio player launches in a separate menu

Multimedia: device media-functions are concentrated in this
menu: Camera, Gallery, Video recorder, Video player, sound
recorder, FM radio
Fun & games
Profiles: settings volume profiles
File manager: to manage files
Organizer: Calendar, Tasks, E-reader, Torch, Calculator
Alarm: Alarm settings launches in a separate menu
Services: Internet Browser, SIM toolkit
Contacts
The Contacts menu is your phone book, which contains
contacts stored in the phone and on SIM cards. The phone
memory is designed to store 500 contacts.
Contacts are in alphabetical order. The search string allows
you to find contacts, the search is organized by the first
letters of the name of the contact. To switch the method /
language of the search press the # key
New contact: Add a new contact. Before creating, you have
to choose a place to save the contact.
To view the contact, select the cursor and press the center
navigation key.
For a call, press the call button.
Additional options open with the left soft key.
Send SMS : Create and send a text or multimedia message to
a contact.
Edit: edit the contact
Delete: delete the selected contact.

Copy: Copy contact between phone and SIM card.
Select multiple: select multiple contacts for further copying /
deleting / grouping SMS.
It is also possible to: view the status of the memory, and
delete all contacts, make backups or restore contacts (only if
there is a memory card)
When backing up contacts in the root of the memory card, a
hidden system file named ~vcard.vcf is created. When
restoring contacts, information is taken from the same file.
Adding a new contact: Choose "New" in the options, choose
a place to save the contact, enter a name and phone number,
press "options-save"
For one contact, you can add the following information:
Name (line length - 20 characters), Phone number, Caller
picture, Caller Ringtone
Messaging
This menu contains everything you need to send, store, view
and delete SMS messages.
New SMS: Select to write and send (or save) a new message.
Inbox: Folder with received messages.
Outbox: Folders with sent messages.
Drafts: incomplete messages.
Sent: Messages that have been sent.
Settings: settings for sending SMS
The Settings menu allows you to set the SMS center numbers
for both SIM cards, set the validity period of the message,
configure receipt of the delivery status report, adjust the

settings for saving messages, switch off or enable push
messages.
Calls
«Calls» menu contains incoming, outgoing and missed calls
register, counter GPRS traffic and allows: dial contact number,
send SMS-messages, add new number to contacts, add
number to black list, delete information about call and etc.
In Settings, you can: view and edit the Blacklist, enable /
disable Auto redial, enable / disable Auto Call recording,
select Answer Mode.
Settings
Dual SIM settings: SIM Card Management - On / Off
Phone: contains date and time settings, interface languages,
settings of dedicated keys. Display: wallpaper settings, screen
and backlight timeout. Flight mode –on/off
Security: set up SIM-card lock, phone lock
Network: allows to set up GPRS, choose card to transmit
data by default, set up network accounts.
Font size: contains 3 font sizes
Connectivity: allows to set up data accounts.
Restore settings. Lets you reset your phone to factory
settings.
WARNING. Reset code 1122
Audioplayer
The audio player is intended for listening to music files. To
play / pause, press the center key. To move to the next /

previous file - Right / Left. To create a playlist, copy the music
files to the memory card in the My music folder. To change
the settings, go to List-Options –Settings
Multimedia
Caution: It is desirable to use the following functions in the
menu "Multimedia" under the condition of the installed
memory card.
This section contains applications for working with photos,
videos and sound.
Camera - to capture a photo
Picture viewer - to view images.
Video recorder - for recording videos.
Video player - to view video clips.
Sound recorder - for recording sound.
FM radio. To listen to radio stations
NB! FM radio uses built-in antenna. The sound of the FM radio
and audio player is transferred to the external speaker or
wired headset.
To turn on / off, press the center key. To search for radio
stations, press Right / Left. To fine tune the channel
frequency - Up / Down. Use the * (to decrease) and # (to
increase) to adjust the volume. The Options menu has the
ability to automatically and manually search channels, view
saved stations, record files in a file and enable / disable
background playback.

User Profiles:
This menu is assigned for setting sound profiles, i.e. volume
characteristics, ringtones, vibrate mode, button sound and
systems for different conditions of phone using, such as:
outdoor, meeting, silent and etc.
Built-in settings are editable as well as custom settings may
be created.
To activate settings choose profile in menu and press central
button.
File manager
File manager allows to work with files in phone memory and
in memory card. Following operations are available: copying,
moving, deleting, creating files, or setting melodies as phone
ringtones.
Organizer
The following programs are available in this menu:
Calendar - for viewing calendar. It is possible to create / edit
/ view events
Tasks –creating and viewing task
Calculator - for arithmetic calculations.
E-book reader –for reading texts in TXT format (UNICODE
txt files). NB! Files with books must be on the memory card
in the EBOOK folder
Torch on/off

Alarm
Alarm - allows to set few alarm clock simultaneously.
Troubleshooting
Following recommendations may help to solve some
problems with phone independently. In case problems
occurs try to solve it yourself with following
recommendations. If problem is not solved, contact to Sigma
mobile service center.
Check whether battery is charged and whether problem
continues after device reset.
Try to restore factory settings through menu «Settings -
phone –Default settings» (password by default – 1122)
Problems with memory card mostly occurs in case of memory
card breakage. Thus, firstly check given card separately. Also
recommended to: take off and insert memory card in port,
check whether card is put in port correctly, reload phone.
Phone does not power on: check battery charge, repeatedly
connect charging device, and wait at least 10 minutes. Press
and keep the button «Power on» not less than 5 second. If
device does not power on contact in service center.
Battery discharges rapidly: reasons for increased battery
charges may be: low air temperature, active using of media
programs, huge distance to cellular tower of connection
operator.
Battery does not charge: check charging adapter connection
to plug. Use only complete charging adapter and cable.

Impossible to call: this problem may be caused by law
connection signal, network overloading, incorrect input of
contact number, activated function of calling prohibition. Try
to change location, check level of connection signal, wipe
phone to factory reset. Contact in service center.
Low receiver volume: during conversation, press button «up»
to increase volume. Set volume during conversation in
profiles. Check signal of cellular connection.
Passwords
Requests to input following passwords may occur during
activating and phone use :
Phone password: request occurs during activating. This is the
password of general locking.
PIN-code: if Pin-code checking is active, it is required to input
code which is given with SIM-card.
PUK code, PIN2 code - also given with SIM card.
Be careful installing blocking passwords: if they are lost, to
renew phone functionality is possible only in service center.
