Sigma X-STYLE 36 POINT User manual

We thank you for buying mobile phone X-style 36. This
manual includes description of main mobile phone
functions .
The phone X-style 36 allows to use 2 SIM cards of GSM
standard at dual standby mode, i.e., in standby mode there
are 2 cards in the connection; during the call 1 card works in
active mode, 1 other card are unavailable.
The content of this manual is right. The description of some
functions may differ due to changes in software or provider
services. The company keeps the right to arrange changes in
technical specifications without previous warning.
Key remarks in security technics.
Given phone is assigned for calling and receiving calls,
sending SMS messages, surfing the Internet (may be
unavailable) etc.
Read carefully the below section and strictly keep following
instructions.
The phone doesn't contain any materials harmful for health.
Don't use the phone during the thunderstorm in the open
air.
Keep the battery off from high temperature, explosive and
flammable liquids.
Power the phone off in case if using the phone can cause
the obstacle or danger.
Do not put the prone in heating devices such as microwave
oven, hot plate or heater.

Do not try to open the mobile phone's case. If phone or
any of accessories do not work properly, please contact
the closest authorized service center.
Use only accessories and charging devices assigned to this
model. Do not use defective or second hand chargers.
Do not let the battery short circuit happen.
If you use any personal medical devices, please clarify from
producer whether device has sufficient protection from
radiation in radio-spectrum. Power the phone off in
medical institutions if it is required with inner regulation
rules.
Do not use the phone during driving. Follow mobile phone
using recommendations while driving.
Keep the phone, all its components and accessories in a
place unavailable for kids and pets. They may damage the
device or accidentally choke with small details.
Avoid contacting phone with water.
Do not use potent chemicals, dissolvent or bleaches for
cleaning the phone.
Do not subject the device under the effect of direct sun
rays.
To avoid getting heavy metals, acids, chemicals in water or
ground what cause significant damage to environment,
wasted accumulator battery should be utilized after end of
service term in accordance to the law regulations. Juristic
responsibility occurs in case of failure to comply with
legislation.
Data about safe utilization of lithium-ion batteries may be
obtained in the closest specialized service center.

Specifications
Phone
2 SIM (mini-SIM)
GSM: 850/900/1800/1900 MHZ
Messages
SMS
Display
3.2’’, color LCD, 240x320 pix
Camera
0,3 Мpx
Supporting
formats
MIDI, AAC, MP3, WAV, JPG
FM-radio
87,5-108,0 MHz (built-in antenna)
Micro-SD
till 32 Gb
Battery
Li-Ion, 2500 mAh
Package includes:
•Mobile phone
•Battery
•Charging device
•User manual
•Warranty card

Phone buttons.
1
Receiver
2
Left soft key (LSK)
3
Central (OK) key
4
Calling\receiving call
5
Audio port (3.5mm)
6
microUSB port
7
Right soft key (RSK)

8
Navigation buttons.
9
Rebound\Cancel\End call (long pressing - to
power on or power off phone)
10
Flash light
11
Camera
12
Speaker
Keys specification
0-9
When dial a number, enter
corresponding number.
In input mode, enter different characters
according to input mode, like letter or
number.
Press and hold 2-9 –for speed dial. Press
and hold 0 –for on/off torch.
* key
To enter the characters *, +, w, p. Press
LSK and * alternately to lock / unlock the
keypad. When playing audio - to reduce
the volume
# key
In idle mode, long press # activate or
deactivate silent profile.
When dial a number, press to enter “#”.
When playing audio - to increase the
volume
Left soft
key
Perform the functions indicated on the
left bottom line of the display.
Press left soft key then press * key to
lock/unlock keypad.
Right soft
key
Perform the functions indicated on the
right bottom line of the display.
Press right soft key to return to upper
menu.
In idle mode, press right soft key to
access Phonebook menu.
Central
Key
Menu / OK.

Inserting SIM cards and memory card
Open the back cover.
Insert SIM cards in proper
device slots.
Insert also micro-SD card,
if required.
Insert battery, controlling
that battery contacts fit
phone contacts.
Be careful, broken card or
batteries cards lead to
device breakage and
cancelling warranty.
Close back cover.
Power on the phone long
pressing Cancel button.
It is recommended to
arrange full battery
charge before first use.
Conditional screen marks on phone
Connection signal
Battery charge indicator

New message
Missed call
Silence profile activated
Outdoor profile activated
Meeting profile activated
Alarm clock is active
Bluetooth switched on
Keyboard locked
Power on/off the device
To power on the device press and hold Cancel button until
activation of device display.
To power off press and hold Cancel button until shutdown.
Device locking occurs automatically, or after consequent
pressing left soft button and button «*». Unlocking occurs
through consequent pressing left soft-button and button «*».

Calling
To call - dial number on digital keyboard in local or
international format, or choose number from phone contacts
list, and press calling button. Choose from which SIM-card to
call. To cancel call - press Cancel button.
During call it is also possible to: switch volume in a
speakerphone mode, start conversation record, add more
persons to conference conversation, turn off\switch on
microphone and etc.
Main menu
To access the main device menu you need to press left soft-
button or central navigation button.
Menu includes following section:
Call center: incoming, outgoing and missed calls register;
Profiles: settings volume profiles
Contacts: phone book including phone, SIM cards storage;
Multimedia: device media-functions are concentrated in this
menu: Camera, Gallery, Video recorder, Video player, sound
recorder, FM radio
Messages: to send SMS messages and read received
messages;
Organizer: Calendar, E-reader, Alarm, Torch, Calculator
My files: file manager to manage files
FM-radio: The FM-radio launches in a separate menu
Settings: Phone settings, dual SIM settings, security settings,
network settings, connectivity and Restore settings

Call center
Call center menu contains a register of incoming, outgoing
and missed calls and allows you to: view information, dial a
contact number, send an SMS message, add a new number
to contacts, add a number to the black list, delete call
information and more.
In Settings you can: view and edit the Blacklist, enable /
disable Autodial, enable / disable Automatic call recording,
select Answer mode, configure divert, call barring and more
Profiles
This menu is assigned for setting sound profiles, i.e. volume
characteristics, ringtones, vibrate mode, button sound and
systems for different conditions of phone using, such as:
outdoor, meeting, silent and etc.
Built-in settings are editable.
To activate settings choose profile in menu and press central
button.
Contacts
The Contacts menu is your phone book, which contains
contacts stored in the phone and on SIM cards. The phone
memory is designed to store 500 contacts.
Contacts are in alphabetical order. The search string allows
you to find contacts, the search is organized by the first
letters of the name of the contact. To switch the method /
language of the search press the # key

New contact: Add a new contact. Before creating, you have
to choose a place to save the contact.
To view the contact, select the cursor and press the center
navigation key.
For a call, press the call button.
Additional options open with the left soft key.
Send SMS : Create and send a text or multimedia message to
a contact.
Edit: edit the contact
Delete: delete the selected contact.
Copy: Copy contact between phone and SIM card.
Add to blacklist.
Select multiple: select multiple contacts for further copying /
deleting / grouping SMS.
It is also possible to: view the status of the memory, and
delete all contacts, make backups or restore contacts (only if
there is a memory card)
When backing up contacts in the root of the memory card, a
system file named ~vcard.vcf is created. When restoring
contacts, information is taken from the same file.
Adding a new contact: Choose “Add new contact”, choose a
place to save the contact, enter a name and phone number,
press Options--Save

For one contact, you can add the following information:
Name (line length - 30 characters), Phone number, Caller
picture, Caller Ringtone
Multimedia
Note: It is recommended that you use the following functions
in the Multimedia menu, provided that a memory card is
inserted.
This section contains applications for working with photos,
videos and sound.
Camera - to shoot a photo
Image viewer - to view images.
Video recorder - for recording videos.
Video player - to view video clips.
Audio player –the audio player is intended for listening to
music files. To play / pause, press the center key. To move to
the next / previous file - Right / Left. To create a playlist, copy
the music files to the memory card in the My music folder. To
change the settings, go to List—Options—Settings. To adjust
volume use * key for decrease and # key for increase volume.
Sound recorder - for recording sound.
Messages
This menu contains everything you need to send, store, view
and delete SMS messages.
Write message: Select to write and send (or save) a new
message.
Inbox: Folder with received messages.

Outbox: Folders with sent messages.
Drafts: incomplete messages.
Sent: Messages that have been sent.
Settings: settings for sending SMS
The Settings menu allows you to set the SMS center numbers
for both SIM cards, set the validity period of the message,
configure receipt of the delivery status report, adjust the
settings for saving messages, switch off or enable push
messages.
Organizer
The following programs are available in this menu:
Calculator - for arithmetic calculations.
E-book reader –for reading texts in TXT format (UNICODE
txt files). NB! Files with books must be on the memory card
in the EBOOK folder
Torch on/off
Calendar - for viewing calendar. It is possible to create / edit
/ view events
Alarm - allows to set few alarms simultaneously.
My Files
File manager allows to work with files in phone memory and
in memory card. Following operations are available: copying,
moving, deleting, creating files, or setting melodies as phone
ringtones.
FM radio
To listen to radio stations

NB! FM radio uses built-in antenna. The sound of the FM radio
and audio player is transferred to the external speaker or
wired headset.
To turn on / off, press the center key. To search for radio
stations, press Right / Left. To fine tune the channel
frequency - Up / Down. Use the * (to decrease) and # (to
increase) to adjust the volume. The Options menu has the
ability to automatically and manually search channels, view
saved stations, record in a file and enable/disable
background playback.
Settings
Dual SIM settings: SIM card management - on/off, on/off
flight mode.
Phone: contains date and time settings, interface languages,
settings of dedicated keys. Display: wallpaper settings, screen
and backlight timeout.
Security: set up SIM-card lock and phone security (default
password is 1122).
Connectivity: allows to set up GPRS, choose card to transmit
data by default, network accounts allows to set up data
accounts.
Bluetooth.
Restore settings. Lets you reset your phone to factory
settings.
WARNING. Reset code 1122

Troubleshooting
Following recommendations may help to solve some
problems with phone independently. In case problems
occurs try to solve it yourself with following
recommendations. If problem is not solved, contact to Sigma
mobile service center.
Check whether battery is charged and whether problem
continues after device reset.
Try to restore factory settings through menu «Settings -
phone –Default settings» (password by default – 1122)
Problems with memory card mostly occurs in case of memory
card breakage. Thus, firstly check given card separately. Also
recommended to: take off and insert memory card in port,
check whether card is put in port correctly, reload phone.
Phone does not power on: check battery charge, repeatedly
connect charging device, and wait at least 10 minutes. Press
and keep the button «Power on» not less than 5 second. If
device does not power on contact in service center.
Battery discharges rapidly: reasons for increased battery
charges may be: low air temperature, active using of media
programs, huge distance to cellular tower of connection
operator.
Battery does not charge: check charging adapter connection
to plug. Use only complete charging adapter and cable.
Impossible to call: this problem may be caused by law
connection signal, network overloading, incorrect input of
contact number, activated function of calling prohibition. Try

to change location, check level of connection signal, wipe
phone to factory reset. Contact in service center.
Low receiver volume: during conversation, press button «up»
to increase volume. Set volume during conversation in
profiles. Check signal of cellular connection.
Passwords
Requests to input following passwords may occur during
activating and phone use:
Phone password: request occurs during activating. This is the
password of general locking.
PIN-code: if Pin-code checking is active, it is required to input
code which is given with SIM-card.
PUK code, PIN2 code - also given with SIM card.
Be careful installing blocking passwords: if they are lost, to
renew phone functionality is possible only in service center.
