Operating Instructions
Bluetooth Handheld Scanner
SD161BTex SD261BTex 3rd
Type SD.118.0000.0X Type SD.11B.000.00

SD160BTex_BA_en_008.docx

SD160BTex_BA_en_008.docx
Table of contents
1 Product range Bluetooth Scanner Zone 1 3
2 Scanner overview 4
3 Compatible Scanner and Base station overview 5
4 Important Notes on the Operating Instructions 6
4.1. Safety Information ........................................................................................... 6
4.2 Notes on the Operating Instructions ........................................................................................... 7
4.3 General Notes of Caution ........................................................................................... 8
5 Product Information SD161BTex 10
5.1 Explosion Protection .................................................................................. 10
5.2 Technical Data Handheld Scanner .................................................................................. 10
5.3 Technical Data Base Charging Station SDX61BTex Basis .............................................. 11
5.4 Technical Data Base Charging Station SDX61BTex Basis 3rd .............................................. 12
5.5 Type Numbers –1D Scanner SD161BTex .................................................................................. 13
5.6 Serial Number .................................................................................. 13
5.7 Application ................................................................................... 13
6 System Assembly - 1D Scanner SD161BTex 14
6.1 System assembly 1 –Explosion-protected base charging station ................................ 14
6.2 System assembly 2 –Non-explosion-protected base charging station ................................ 15
7 Product Information SD261BTex 3rd 16
7.1 Explosion Protection .............................................. 16
7.2 Technical Data Handheld Scanner .............................................. 16
7.3 Technical Data Base Charging Station SDX61BTex Basis .............................................. 17
7.4 Technical Data Base Charging Station SDX61BTex Basis 3rd .............................................. 18
7.5 Type Numbers –2D Scanner SD261BTex 3rd .............................................. 19
7.6 Serial Number .............................................. 19
7.7 Application .............................................. 19

SD160BTex_BA_en_008.docx
8 System Assembly - 2D Scanner SD261BTex 3rd 20
8.1 System assembly 1 –Explosion-protected base charging station ................................ 21
8.2 System assembly 2 –Non-explosion-protected base charging station ................................ 21
9 Cable range in system assembly 22
9.1 Cable range in system assembly 1 .......................................... 22
9.2 Cable range in system assembly 2 .......................................... 22
10 Step-by-step guide on installation and operation 23
10.1 Preparation SD161BTex / SD261BTex 3rd for System assembly 1 & 2 ................................... 23
10.2 Using base charging station for system 1 ................................... 24
10.3 Using base charging station for system 2 ................................... 25
10.4 Pin assignment power supply SDVM125ex RS232 ................................... 26
10.5 Pin assignment power supply SDVM125ex USB ................................... 28
11 Attachment 30
11.1 EG-Type Examination Certificate SD161BTex and SDX61BTex base charging station .......... 30
11.2 Certificate of Conformity SD161BTex and SDX61BTex base charging station .......... 35
11.3 EG-Type Examination Certificate SDVM125ex .......... 41
11.4 Certificate of Conformity SDVM125ex .......... 45
12 Contact 51

SD160BTex_BA_en_008.docx 3
1Product range Bluetooth scanner Zone 1

4 SD160BTex_BA_en_008.docx
2 Scanner overview
Wired
Bluetooth
1D
PDF
2D
SD160ex





SD160exPDF





SD260ex 3rd





SD161BTex





SD161BTex PDF





SD261BTex 3rd






5 SD160BTex_BA_en_008.docx
Scanner
Typenumber
Scanner
Typenumber
Base station/
Charging station
Description
Connection
cable USB
Connection
cable RS232
Power supply
SDVM125ex
SD161BTex
SD.118.0000.0X
SD.119.0000.00 /
SD.11C.0000.00
Base station for hazardous area
SD.Z10.0011.0X
SD.Z10.0010.0X
SD.Z10.0007.0X
with USB-Connection:
SD.211.X111.00
with RS232-Connection:
SD.211.X011.00
SD.211.X001.00
SD261BTex 3rd
SD.11B.0000.0X
SD.119.0000.00 /
SD.11C.0000.00
SD161BTex
SD.118.0000.0X
SD.Z10.0035.00
Base station for non hazardous area
SD.Z10.0013.0X
SD.Z10.0012.0X
With USB-Connection:
PC USB-Interface
Wtih RS232-Connection:
only 5V-non hazardous
power supply
SD.Z10.0016.00
SD261BTex 3rd
SD.11B.0000.0X
SD.Z10.0035.00
SD161BTex
SD.118.0000.0X
SD.Z10.0034.00
Charging station for non hazardous
area without Bluetooth function
SD.Z10.0013.0X
SD.Z10.0012.0X
With USB-Connection:
PC USB-Interface
With RS232-Connection:
only 5V-non hazardous
power supply
SD.Z10.0016.00
SD261BTex 3rd
SD.11B.0000.0X
SD.Z10.0034.00
3Compatible Scanner and Base station overview

SD160BTex_BA_en_008.docx 6
4Important notes on the Operating Instructions
4.1 Safety information
Warnings are highlighted by a special symbol and a different font colour:
Danger
Non-compliance may result in life-threatening situations.
This warning must be heeded.
Warning
This type of warning concerns dangerous situations that may result in minor injuries.
Info
Important and helpful notes and information.

7 SD160BTex_BA_en_008.docx
4.2 Notes on the Operating Instructions
Before starting up the equipment please read the Manual thoroughly.
The Operating Instructions contain important information on functionality as well as safety rules. If these
are not heeded, normal operations within hazardous areas cannot be guaranteed.
The notes contained in this manual are important for starting up and operating the product.
These instructions may be updated at any time. Sigmann DELTA GmbH reserves the right to make changes to
this document.
Before using the product, users must ensure that they have the most up-to-date version of the operating instruc-
tions.
To be sure this is the case, please check Sigmann DELTA's website at www.Sigmann-DELTA.de or contact one
of the company's staff.
The drawings contained in these operating instructions are for illustration purposes only and may differ somewhat
from the actual design.
No changes may be made to the device that were not intended or approved
by Sigmann DELTA.
If the handheld scanner is not used properly, the operating permission for hazardous areas may lapse for the
device in question.
Non-adherence to the instructions will void any warranty.
For the full commission of the SD161BTex / SD261BTex 3rd handheld scanner the programming information
contained in the manual issued by SICK AG (www.SICK.com) are also required.

SD160BTex_BA_en_008.docx 8
4.3 General notes of caution
Caution / Notes
The devices may only be operated when fully assembled.
In hazardous areas the devices must not be wiped or cleaned with a dry cloth.
The device must be switched off immediately if it is likely that as a consequence
of damaging impact or general peculiarities the device can no longer be safely
operated. (e.g. ingress of water or other fluids, temperatures outside of the
specified range,...)
General statutory requirements or health and safety rules and accident preven-
tion guidelines and environmental laws must be adhered to (e.g. the German
Occupational Health and Safety regulation).
Users must not open the device.
Users must not make any changes to the device. Components may not be ex-
changed or replaced. If non-specified components are used, explosion protec-
tion is no longer guaranteed.
Ensure safe handling with firm footing and sufficient room for movement.
If the enclosure is in any way damaged the device must be removed from the
hazardous area immediately.
In accordance with IEC 60079-19 and IEC 60079-17, operators of electrical
installation in hazardous areas are obliged to have them serviced by qualified
electricians.
Do not insert any sharp objects into the enclosure or any other openings of the
handheld barcode scanner. Any openings at the device may not be covered or
blocked.
The device and any accessories must be properly disposed of, i.e. as legally
specified, for example by a certified company.
Notes on installation
Electrical plants are subject to certain regulations concerning installation and
operation (e.g. RL 99/92/EG, RL 2014/34/EU, or the national rules such as
IEC 60079-14 and VDE 0100).
In the hazardous area it is the operator's responsibility to carry out any repair
and maintenance in compliance with applicable rules.

9 SD160BTex_BA_en_008.docx
Caution
on laser devices
Devices fitted with laser fall under standards US 21 CFR 1040.10 and
EN 60825-1. The laser's classification is stated on a plate affixed to the device.
Class 1 lasers are deemed inherently safe during normal use, but users must
not look directly into the light source. The following declaration is required by
American and international laws:
Usage of control elements, adaptations or the use of procedures that differ from
these instructions may result in a dangerous exposure to laser beams.
Class 2 lasers use a visible low-voltage LED. As with any source of bright light,
such as the sun, the user should avoid looking directly into the light. Brief expo-
sure to a class 2 laser is deemed not dangerous.
Maintenance
Provided the device is operated and assembled according to instructions and
the ambient requirements are being met continuous maintenance is not neces-
sary.
Servicing
Operators of electric equipment in hazardous areas are obliged to have them
serviced by qualified electricians (IEC 60079-19 and IEC 60079-17).
Repairs
Repairs may only be carried out by the manufacturer or by persons trained and
commissioned for this purpose by the manufacturer.
The device is closed ex-factory. It may only be opened in the factory by specifically trained personnel.
Software installation
For instructions on how to install the software at the PC please refer to the
manual issued by SICK.
Operation
Before operating the device you must ensure that all necessary components are
available.

SD160BTex_BA_en_008.docx 10
5Product information - SD161BTex Type SD.118.0000.0X
SD161BTex 1D Bluetooth Scanner
5.1 Explosion
Protection
II 2G Ex ib IIB T4
II 2G Ex ib IIB T4 Gb
II 2D Ex ib IIIC T135C
II 2D Ex ib IIIC T135C Db
Certification
IBExU 12 ATEX 1162
IECEx IBE 15.0017
Manufacturer
Sigmann DELTA GmbH
Hauptstraße 53
74928 Hüffenhardt
Germany
5.2 Technical data
With Battery type SD.Z10.0017.00 3,6 V; 1500 mAh
With Battery type SD.Z10.0018.00 3,6 V; 2250 mAh

11 SD160BTex_BA_en_008.docx
5.3 Technical data
Base charging station SDX61BTexBasis
for SD161BTex
Ambient temperature
Base charging station
-20°C to +50°C
Bluetooth
Base charging station
Bluetooth V 2.1 EDR, Class 2
2,4 ... 2,4835 GHz (ISM Band)
Terminal assignment
(Base charging station)
USB-Cable
USB/D+ green
USB/D- white
GND black
+UB brown
RS 232-Cable
RS 232-TXD white
GND brown
+UB yellow
Operation
Base charging station
The base charching station may be operated in hazardous areas. Its purpose is to re-
ceive data captured by the associated handheld scanner (1D bar codes or 2D stacked
codes) via Bluetooth.
Nominal values of the hazard-
ous base charging
station
maximum input voltage Ui: 4,9 V with cable (SD.Z10.0010.XX /
SD.Z10.0011.XX)
5,6 V with cable (SD.Z.10.0007.XX)
maximum input current Ii: 480 mA
maximum input power Pi: 1,25 W
maximum internal inductance Li: negligible
maximum internal capacitance Ci: 112 µF with cable (SD.Z10.0010.XX/
SD.Z10.0011.XX)
46 µF with cable (SD.Z.10.0007.XX)
Nominal values
of the non hazardous base
charging station
Operating voltage U = 5V
Power requirement I = 85 mA in standby mode
Explosion Protection
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T135 C Gb

SD160BTex_BA_en_008.docx 12
5.4 Technische Daten
Base charging station SDX61BTexBasis 3rd
for SD161BTex
Ambient temperature
Base charging station
-20°C to +50°C
Bluetooth
Base charging station
1D BluetoothTM V2.1 EDR, Klasse 2
Up to 30m radius
2D BluetoothTM V4.0 EDR, Klasse 1
Up to 100m radius
(2,402 ... 2,4835 GHz)
Terminal assignment
(Base charging station)
USB-Cabel
USB/D+ green
USB/D- white
GND black
+UB brown
RS 232-Cabel
RS 232-TXD white
GND brown
+UB yellow
Operation
Base charging station
The base charching station may be operated in hazardous areas. Its purpose is to re-
ceive data captured by the associated handheld scanner (1D bar codes or 2D stacked
codes) via Bluetooth.
Nominal values of the hazard-
ous base charging
station
maximum input voltage Ui: 5,5 V with cable (SD.Z10.0010.XX /
SD.Z10.0011.XX)
5,6 V with cable (SD.Z.10.0007.XX)
maximum input current Ii: 480 mA
maximum input power Pi: 1,25 W
maximum internal inductance Li: negligible
maximum internal capacitance Ci: 191 µF
Nominal values
of the non hazardous base
charging station
Operating voltage U = 5V
Power requirement I = 85 mA in standby mode
Explosion Protection
II 2G Ex ib IIB T4 Gb
II 2D Ex ib IIIC T135 C Gb

13 SD160BTex_BA_en_008.docx
5.5 Type numbers - 1D Scanner SD161BTex
SD.118.0000.00
SD.118.0000.01
Standard 1D
Standard 1D, Stacked PDF
Both are for use with accu SD.Z10.0018.00
and a base charging station of your choice (see below)
Explosion-protected connection cable USB SD.Z10.0011.0X
/ RS232 SD.Z10.0010.0X
or a non-explosion-protected connection cable USB SD.Z10.0013.0X
/ RS232 SD.Z10.0012.0X
and a power supply SDVM125ex, depending on voltage and interface
SD.211.XX11.00
SD.119.0000.00
Explosion-protected base charging station SDx61BTexBasis
SD.11C.0000.00
Explosion-protected base charging station SDx61BTexBasis 3rd
SD.Z10.0035.00
Non-explosion-protected base charging station
SD.Z10.0034.00
Non-explosion-protected charging station without Bluetooth
5.6 Serial numbers
Serial key: year of manufactur serial number
2 numbers 4 numbers
Example: 200001
5.7 Application
The scanner is a handheld device.
Its purpose is the portable capture and direct transfer of data in hazardous areas. The device has been designed
for use in hazardous areas zones 1 and 21.

SD160BTex_BA_en_008.docx 14
6System assembly - 1D Scanner SD161BTex
6.1 System assembly 1
Overview of the complete
system assembly 1,
Bluetooth handheld scanner
SD161BTex
Assembly with base charging sta-
tion and power supply in hazard-
ous area
Description:
The Bluetooth handheld SD161BTex scanner (SD.118.0000.0x) was designed for use in hazardous areas. Normal
operation requires a base charging station (SD.119.0000.00 / SD.11C.0000.00), a connection cable between the
base charging station and the SDVM125ex power supply (SD.211.XX11.00) and a connection cable between the
power supply and a PC.
External connection cable:
Data cable USB: 0,2 - 2,5 mm2, 4-wire or RS232: 0,2 - 2,5 mm23-wire
Power supply cable 0,2 - 2,5 mm23-wire
The Bluetooth handheld scanner, the base charging station and the power supply can be connected and operated
in the hazardous area. The current rating of the connection cables must be checked before use.
The warnings and notes of caution contained in these operating instructions and in the manu-
al issued by SICK AG (www.SICK.com) must be adhered to.
For the professional use of the power supply SDVM125ex the operating instructions of the
manual of the power supply are necessary.

15 SD160BTex_BA_en_008.docx
6.2 System Assembly 2
Overview of the complete
system assembly 2,
Bluetooth handheld scanner
SD161BTex
Assembly with base charging sta-
tion in non-hazardous areas
Description:
The Bluetooth handheld SD161BTex scanner (SD.118.0000.0X) can also be used separately in the hazardous
area.
The base charging station (SD.Z10.0035.00) is then operated in the non-hazardous area.
Use an RS232 cable (SD.Z10.0012.0X) or a USB cable (SD.Z10.0013.0X) to connect the station directly to a
power supply and a PC.
The warnings and notes of caution contained in these operating instructions and in the manu-
al issued by SICK AG (www.SICK.com) must be adhered to!

SD160BTex_BA_en_008.docx 16
7Product information - SD261BTex 3rd Type SD.11B.0000.0X
SD261BTex 3rd 2D Bluetooth Scanner
7.1 Explosion
Protection
II 2G Ex ib op is IIB T4
II 2G Ex ib op is IIB T4 Gb
II 2D Ex ib op is IIIC T135C
II 2D Ex ib op is IIIC T135C Db
Certification
IBExU 12 ATEX 1162
IECEx IBE 15.0017
Manufacturer
Sigmann DELTA GmbH
Hauptstraße 53
74928 Hüffenhardt
Germany
7.2 Technical data
With Battery Type SD.Z10.0017.00 3,6 V; 1500 mAh
With Battery Type SD.Z10.0018.00 3,6 V; 2250 mAh

17 SD160BTex_BA_en_008.docx
7.3 Technical data
Base charging station SDX61BTexBasis
for SD261BTex 3rd
Ambient temperature
Base charging station
-20°C to +50°C
Bluetooth
Base charging station
Bluetooth V 2.1 EDR, Class 2
2,4 ... 2,4835 GHz (ISM Band)
Terminal assignment
(Base charging station)
USB-Cable
USB/D+ green
USB/D- white
GND black
+UB brown
RS 232-Cable
RS 232-TXD white
GND brown
+UB yellow
Operation
Base charging station
The base charching station may be operated in hazardous areas. Its purpose is to re-
ceive data captured by the associated handheld scanner (1D bar codes or 2D stacked
codes) via Bluetooth.
Nominal values of the hazard-
ous base charging station
maximum input voltage Ui: 4,9 V with cable (SD.Z10.0010.XX /
SD.Z10.0011.XX)
5,6 V with cable (SD.Z.10.0007.XX)
maximum input current Ii: 480 mA
maximum input power Pi: 1,25 W
maximum internal inductance Li: negligible
maximum internal capacitance Ci: 112 µF with cable (SD.Z10.0010.XX/
SD.Z10.0011.XX)
46 µF with cable (SD.Z.10.0007.XX)
Nominal values
of the non hazardous base
charging station
Operating voltage U = 5V
Power requirement I = 85 mA in standby mode
Explosion Protection
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T135 C Gb

SD160BTex_BA_en_008.docx 18
Terminal assignment
(Base charging station)
USB-Cabel
USB/D+ green
USB/D- white
GND black
+UB brown
RS 232-Cabel
RS 232-TXD white
GND brown
+UB yellow
Operation
Base charging station
The base charching station may be operated in hazardous areas. Its purpose is to re-
ceive data captured by the associated handheld scanner (1D bar codes or 2D stacked
codes) via Bluetooth.
Nominal values of the hazard-
ous base charging
station
maximum input voltage Ui: 5,5 V with cable (SD.Z10.0010.XX /
SD.Z10.0011.XX)
5,6 V with cable (SD.Z.10.0007.XX)
maximum input current Ii: 480 mA
maximum input power Pi: 1,25 W
maximum internal inductance Li: negligible
maximum internal capacitance Ci: 191 µF
Nominal values
of the non hazardous base
charging station
Operating voltage U = 5V
Power requirement I = 85 mA in standby mode
Explosion Protection
II 2G Ex ib IIB T4 Gb
II 2D Ex ib IIIC T135 C Gb
7.4 Technische Daten
Base charging station SDX61BTexBasis 3rd
for SD261BTex 3rd
Ambient temperature
Base charging station
-20°C to +50°C
Bluetooth
Base charging station
1D BluetoothTM V2.1 EDR, Klasse 2
Up to 30m radius
2D BluetoothTM V4.0 EDR, Klasse 1
Up to 100m radius
(2,402 ... 2,4835 GHz)
