SignaMax 065-1176 Operating instructions

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
SignamaxConnectivitySystems
Fast Ethernetmediaconverters
10Base-T/100Base-TXto100Base-FX
series
Model:065-1176
User’sManual

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
FCC Warning
Thisdevicehasbeentestedandfoundtocomplywithlimits
foraClass Adigitaldevice,pursuanttoPart2and Part15of
the FCC Rules.Theselimitsaredesigned toprovide
reasonableprotectionagainstharmfulinterferencewhenthe
equipmentisoperatedinacommercialenvironment.This
equipmentgenerates,usesandradiatesradiofrequency
energyand, if not installedandused inaccordancewiththe
user’smanual,maycauseinterferenceinwhichcaseuser
will be requiredtocorrecttheinterferenceathisown
expense.
NOTICE:
1. The changesormodificationsnotexpressively
approvedbythepartyresponsibleforcompliance
couldvoidthe user'sauthoritytooperatethe
equipment.
2.ShieldedinterfacecablesandACpowercord,ifany,
must beusedinordertocomplywiththeemission
limits.
CISPRACOMPLIANCE:
ThisdevicecomplieswithEMCdirectiveof the European
Communityand meetsorexceedsthe following technical
standard.
EN55022 -LimitsandMethodsofMeasurement ofRadio
InterferenceCharacteristics of InformationTechnology
Equipment. ThisdevicecomplieswithCISPRClassA.
WARNING:
ThisisaClass Aproduct. Inadomesticenvironment,
thisproductmaycauseradiointerferenceinwhich
casethe usermanyberequiredtotakeadequate
measures.

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
Tableofcontents
Chapter
1...........................................
5
Introduction...................................
......5
Product
Features...................................
....6
Technical
Specifications...............................
....7
Chapter
2. ..........................................
8 Package
contents...................................
.....8
Model
information.................................
....9
Chapter
3. ..........................................
11 Installation.................................
.....11

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
The LED
indicators..................................
....12
Chapter
4. ..........................................
12 Application.................................
....12

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
Chapter1.
Introduction
The FastEthernet mediaconvertersseriesaredesignedto
bridgea100Base-TXsignaltoa100Base-FXsignal. It’s
usedtoextendtheconnectiondistancebetweentwoFast
EthernetTwisted-pairdevicesviafibercabletransparently
withnoperformancedegradation.
The converterseriesisbaseonswitchinghubdesign. It’s
supported Auto-negotiation &flowcontrolfunction on
Twisted-pairport. Andprovideddifferenttypesoffiber
connectorssuchasSC,ST,Bi-direction WDM, MT-RJand
LCformulti-modeorsingle-modecables.

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
ProductFeatures
ComplieswithIEEE802.3u10Base-T/100Base-TX,
100Base-FXStandards.
TPport supportAuto-MDIX&Auto-negotiation.
TPportupto100metersforshielded/unshielded twisted
paircable.
SupportsFull-duplex&Half-duplexoperation onTP
baseonAuto-negotiation.
Switchbasedesignsupportflowcontrolcapability.
SupportsFull-duplex&Half-duplexoperationonfiberby
slide switch.
100Base-FXinterfaceforupto5km.(Use50/125 µmor
62.5/125µmMMFopticcable)
100Base-FXinterfaceforupto60km. (Single-mode
9/125µmSMFopticcable)
LEDindicatorsupports.
Multiplefiberconnectorsupports. (SC, ST, Bi-direction
WDM, MT-RJ, LC…etc)
Supportsfaultpropagation.
Canbeinstalledonmediaconverterchassis.

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
TechnicalSpecifications
Standards : EEE 802.3u10Base-T/100Base-TXand100Base-FX
Mediasupport : 10BASE-T EIA/TIA568Cat3,4,5, 5eor6UTP/STP
: 100Base-TXEIA/TIA568Cat5,5eor6UTP/STP
: 100Base-FXMulti-mode50/125 µm&62.5/125µm
MMF
: 100Base-FXSingle-mode9/125µmSMF
Distancessupport : Twisted pairSTPà100meters
: Multi-modefiber:415metersforhalf-duplex.
: Multi-modefiber:5kmforfull duplex.
: Single-modefiber:415metersforhalf-duplex.
: Single-modefiber:60kmforfullduplex.
Wavelength : 1310nmonSingle/Multi-mode, 1310nm/1550nm
Bi-direction WDM
DataTransferRate : 100Mbps/10Mbps
LEDindicators : System-power
:Twisted pairport–Link/Activity,SpeedandFDX/Col
: Fiberport–Link/Activity&FDXLEDs
Temperature : 0 to45 (Operating)
: -20 to90 (Storage)
Humidity : 10% to90%(Non-condensing)
Powerconsumption : 3.4Watts(max)
PowerRequirement : 5VDC 1A
Certifications : FCC Class A, CEMark
Dimensions : 102 mm ×74mm ×22mm (L ×W ×H)
Weight : 230g(Nopoweradapter)

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
Chapter2.
Packagecontents
Beforeyou starttoinstall theSwitch,pleaseverifyyour
packagethatcontainsthe followingitems:
Onemediaconverter
OnePowerAdapter
OneUser’sManual

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
Modelinformation
100Base-FXMulti-Mode1310nmwavelength
ModelDescription
Multimode SC
Connector
100Base-FXfiberport (SCtypeMMF)
Up to415 meters(1360 ft.)forMMF
50/125umor62.5/125umopticcableson
half-duplexoperation.
Up to2, 5km(1.24, 3.1 mi.)forMMF
50/125umor62.5/125umopticcableson
full-duplexoperation.
Multimode ST
Connector
100Base-FXfiberport (ST typeMMF)
Up to415 meters(1360 ft.)forMMF
50/125umor62.5/125umopticcableson
half-duplexoperation.
Up to2, 5km(1.24, 3.1 mi.)forMMF
50/125umor62.5/125umopticcableson
full-duplexoperation.
Multimode MT-RJ
Connector
100Base-FXfiberport(MT-RJ typeMMF)
Up to415 meters(1360 ft.)forMMF
50/125umor62.5/125umopticcableson
half-duplexoperation.
Up to2km(1.24mi.)forMMF50/125um
or
62.5/125umopticcableson full-duplex
operation.
Multimode LC type
Connector
100Base-FXfiberport (LCtypeMMF)
Up to415 meters(1360 ft.)forMMF
50/125umor62.5/125umopticcableson
half-duplexoperation.
Up to 5km(3.1 mi.)forMMF50/125um
or
62.5/125umopticcableson full-duplex
operation.

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
100Base-FXSingle-Mode1310nm/1550nmwavelength
ModelDescription
Singlemode SC
connector
100Base-FXfiberport(
SCtype
SMF).
Up to 10,20,40 or60km forS
MF
9/125umopticcablesonfull-
duplex
operation.
Singlemode LC connector
100Base-FXfiberport(
LCtype
SMF).
Up to 20, 40or60kmforSMF
9/125umopticcableson full-duplex
operation.
Bi-direction WDM
connector-BA
100Base-FXBi-direction fiberport
TX1310nm
RX 1550nm
Bi-direction WDM
Connector-BB
100Base-FX Bi-directionfiberport
TX 1550nm
RX 1310nm

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
Chapter3.
Installation
I. DC input &externalpoweradapter
The externalpowersupplyadapterspecification:
ACinput rangefrom90VACto260VAC.
ACfrequency rangefrom47Hzto63Hz,TUV,CE, UL
Safety.
PoweradapterDC outputis+5VDC 1.5A
ThedeviceDC input+5VDC 1A.
II. The TPport
The deviceTPport supportAuto-MDIX,Auto-negotiation
andFlowcontrolfunctions.The cablelengthupto100
metersforshielded/unshieldedtwistedpaircable.Allow
usersconnect theconverterto10BASE-Tand
100BASE-TXdevices.
III. The Fiberport
The converterprovideddifferenttypesoffiberconnectors
suchasSC,ST, MT-RJand LCformulti-modeor
single-modefibercables.
Full-DuplexorHalf-Duplexoperationon fiberport
The converterprovidedslideswitchat right side of
converter.Thepurposeof the slide switchisforfiber
full-duplexorhalf-duplexoperation.Thefactorydefaultis
full duplexasbelowchart.

SignamaxConnectivitySystem______________________________________________ 065-1176
WWW.SIGNAMAX-US.COM
WWW.SIGNAMAX-CE.COM
TheLEDindicators
LED Color Status Description
Power YellowOn Poweron
On Full-duplex
Off Half-duplex
FDX Green
Flashing Partialcollision
occurs
On Portison the
100Mstatus
10/100M Green
Off
Portison the 10M
status
On 10/100Mbpsport
forconnection
LINK/ACT.Yellow
Flashing 10/100Mbpsfor
dataactivating
Chapter4.
Application
Single-Mode Fiberapplication
