SignaMax 065-7940B-WS User manual

24-Port Gigabit Web Smart Switch
with 4 SFP (Mini-GBIC) slots
User Manual
V1.4
(April 2008)

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
2
COPYRIGHT
All rights reserved. No part of this publication may be reproduced, stored in
a retrieval system, or transmitted in any form or by any means, whether
electronic, mechanical, photo copying, recording or otherwise, without the
prior written permission of the publisher.
FCC WARNING
This equipment has been tested and found to comply with the limits
for a class A device, pursuant to part 15 of FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
commercial installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communication.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case, the user will be required to correct the
interference at the user’s own expense.
CE
This is a Class A product. In a domestic environment, this product may
cause radio interference in which case the user may be required to take
adequate measures.
Take special care to read and understand all the content in the warning
boxes.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
3
Table of Contents
UNPACKING INFORMATION...................................... 5
INTRODUCTION........................................................ 5
GENERAL DESCRIPTION..........................................................................5
KEY FEATURES ......................................................................................6
THE FRONT PANEL .................................................................................6
THE REAR PANEL...................................................................................7
INSTALLATION ......................................................... 8
DESKTOP INSTALLATION ........................................................................8
RACK INSTALLATION .............................................................................8
INSTALLING NETWORK CABLES..............................................................8
DESCRIPTION OF SWITCH FUNCTIONS .................. 10
JUMBO FRAME ..................................................................................... 10
FLOW CONTROL AND BACKPRESSURE................................................... 10
MIRROR............................................................................................... 10
VLAN................................................................................................. 10
TRUNK (AGGREGATION)....................................................................... 10
QUALITY OF SERVICE (QOS) ................................................................ 10
SNMP ................................................................................................. 10
MANAGEMENT GUIDE ............................................. 11
ACCESS THE SWITCH............................................................................ 11
HOMEPAGE .......................................................................................... 12
SYSTEM ...............................................................................................13
PORT ................................................................................................... 14
VLAN................................................................................................. 15
PVID................................................................................................... 16

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
4
AGGREGATION/TRUNK CONFIGURATION..............................................17
QUALITY OF SERVICE........................................................................... 18
MIRROR............................................................................................... 22
RATE LIMIT ......................................................................................... 23
SNMP ................................................................................................. 24
DISCOVERY.......................................................................................... 25
STATISTICS OVERVIEW......................................................................... 26
DETAILED STATISTICS .......................................................................... 26
RESTART ............................................................................................. 27
FACTORY DEFAULT.............................................................................. 27
SMART BOOT ....................................................................................... 27
SOFTWARE UPLOAD .............................................................................28
PRODUCT SPECIFICATIONS.................................... 29
APPENDIX- COMMAND LINE INTERFACE ................ 30
START-UP AND TERMINAL CONFIGURATION .......................................... 30
LOGIN/LOGOUT PROCEDURES............................................................... 30
COMMAND HIERARCHY........................................................................31
ENTERING COMMANDS......................................................................... 31
COMMAND DESCRIPTION...................................................................... 32
System Commands...........................................................................32
Console Commands.........................................................................33
Port Commands............................................................................... 34
VLAN Commands............................................................................ 36
Aggregation Commands ..................................................................38
QoS Commands............................................................................... 39
Mirror Commands........................................................................... 40
IP Commands.................................................................................. 41
SNMP Commands ........................................................................... 41
Ratelimit Commands .......................................................................42

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
5
Unpacking Information
Congratulations on purchasing this Signamax 065-7940B-WS 24-port Gigabit Web
Smart Switch with 4 SFP module Combo slots. Before you start, please verify that
your package contains the following items:
1. One Signamax 065-7940B-WS 24-port Gigabit Web Smart Switch with 4 SFP slots
2. One power cord
3. Rack-mounting brackets and screws (optional)
4. User Manual CD
Introduction
General Description
This Switch will instantly boost your networking throughput because it provides
you with 24 Gigabit ports that enable true Gigabit connectivity. Users are now
able to transfer large and bandwidth-hungry files faster and hence get a real
efficiency improvement. This efficiency is further enhanced by the user-friendly
Web-based management interface. In addition to the 24 copper ports, the
Switch offers 4 fiber ports (slots) that can be used in the place of the last 4
copper ports (these are interchangeable or ‘combo’ ports). These SFP
module slots offer the option of a long-distance, fiber-based connection. Use of
a SFP module port automatically disables its corresponding copper port.
The management functions enable efficient network usage. VLAN reduces the
collisions caused by broadcasting. Port Aggregation enlarges the bandwidth of
the backbone connection. QoS secures the bandwidth for some
bandwidth-hungry applications like VoIP and video conferencing. The Switch
also supports 802.3x and backpressure flow control mechanisms to ensure the
correctness of data transmission.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
6
Key Features
24 (twenty-four) 10/100/1000Mbps Gigabit Ethernet ports.
4 (four) SFP slots for optional fiber connection.
Supports auto-detection for SFP module insertion
Auto-discovery function for easy Network management.
8K MAC address entries and 24 groups VLAN table
Supports Port Mirroring.
Supports up to 8 ports and 12 groups port aggregation.
Supports QoS: port-based, tag-based, DSCP priority
Supports full-duplex flow control and half-duplex backpressure
Supports Rate Limit (ICMP Rate, Broadcast Rate, Multicast Rate, and
Ingress/Egress Rate)
Supports Jumbo frame 9K bytes
Supports 500K bytes buffer Memory
Supports Web-based management interface.
Non-blocking wire-speed switching performance
Supports firmware upgrade, SNMP
FCC Class A, CE, VCCI. RoHS-compliant
The Front Panel
The front panel features all the LED indicators and ports:
Device LED:
LED Status Operation
Steady Green The switch is powered on
Power (PWR) Off The switch is powered off
Port LEDs:
LED Status Operation
Green The port is connected at 1000 Mbps
Blinking Green A valid link is established, and there is data being
transmitted/received.
1000M
Off No valid link on this port or the Port is connected at 10/100
Mbps
Steady Green A valid link is established, and there is no data being
transmitted/received.
Blinking Green A valid link is established, and there is data being
transmitted/received.
10/100M
Off No valid link on this port or the port is connected at 1000
Mbps

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
7
Port Operation
The auto-negotiation feature allows ports to run at one of the following operation
modes:
Me ia Spee Duplex Mo e
Full Duplex 10 Mbps
Half Duplex
Full Duplex 100 Mbps
Half Duplex
10/100/1000 Mbps(copper)
1000 Mbps Full Duplex
1000 Mbps(Fiber)
(mini GBIC required)
1000 Mbps Full Duplex
Note: For the interchangeable (combo) ports (the last 4 RJ-45 ports and the fiber
slots), if both the fiber and copper interfaces of an interchangeable pair (combo) are
connected (incorrect set-up), the system automatically accepts the fiber interface and
disables the copper port.
Restore Default Button
You can use this button to reset the switch or restore it to its factory default settings.
To reset the switch, press the button once.
To restore factory default settings, press and hold the button for three seconds.
The Rear Panel
The rear panel:
Power Receptacle
To be compatible with electricity standards around the world, the Switch is designed to
work with voltages between 100 and 240V AC and 50/60Hz. Please make sure that
your region’s electricity supply is within this range.
To power on the Switch, please plug the female end of the power cord firmly into the
receptacle of the Switch and the other (male) end into an electricity outlet (usually a
wall plug). After plugging in the power cord, check if the power LED is lit to indicate
normal power status.
Attention：
：：
：The SFP module (SFP) slots share their LED indicators with their
interchangeable Gigabit RJ-45 (copper) ‘combo’ ports (the last 4 copper ports).
Use of a SFP module slot automatically disables its corresponding copper port.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
8
Installation
This Signamax 065-7940B-WS Switch can be placed on your desktop or mounted in a
rack. Installation is very easy. Users can use all the features of the Switch by simply
attaching the cables and turning the power on.
Before installing the Switch, we strongly recommend that …
1. … the Switch must be placed in an environment that is well ventilated – a
minimum space around the unit of 25mm is recommended.
2. … the Switch and relevant components are far from sources of electrical noise,
such as radios, transmitters and broadband amplifiers
3. … the Switch’s environment is protected from high levels of humidity.
Desktop Installation
1. Install the Switch on a level surface that can support the weight of the unit and the
relevant components.
2. Plug the Switch’s power cord into the power outlet.
Rack Installation
Rack mounting enables orderly installation in cases where many networking devices
have to be installed in the same area. The Switch is supplied with brackets and screws
for rack-mounting purposes.
1. Disconnect all cables from the Switch before mounting it.
2. Place the unit the right way up on a hard, flat surface with the front facing you.
3. Locate a mounting bracket over the mounting holes on one side of the unit.
4. Insert the screws and tighten them with a suitable screwdriver.
5. Repeat this for the other side of the unit.
6. Slide the unit into the rack and secure it with suitable screws.
7. Reconnect all the cables.
Installing Network Cables
1. Crossover or straight-through cable: All the ports on the Switch support
Auto-MDI/MDI-X functionality. Both straight-through and crossover cables can
be used to connect the Switch with PCs and other devices like switches, hubs or
router.
2. Category 3,4,5 or 5eUTP/STP cable: To make a valid connection and obtain
optimal performance, it is vital to use the appropriate cables that correspond to
the different transmitting/receiving speeds.
3. To choose a suitable cable, please refer to the following table:

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
9
Media Speed Wiring
10 Mbps Category 3,4,5 UTP/STP
100 Mbps Category 5 UTP/STP
10/100/1000 Mbps
copper
1000 Mbps Category 5,5e UTP/STP
1000 Mbps Fiber
(SFP module
required)
1000 Mbps The cable type differs according to the SFP
module you choose. Please refer to the
instructions that came with your SFP module.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
10
Description of Switch Functions
Jumbo Frame
The Signamax 065-7940B-WS Switch supports Jumbo Frames, which means that it
can transmit the same data in fewer frames. This helps to ensure fewer overheads,
shorter processing time, and fewer interruptions.
NOTE: To enable Jumbo Frame, Flow Control should be enabled in advance.
Flow Control and Backpressure
Flow Control and Backpressure both help devices with different processing speeds to
communicate with each other. This ensures the correctness of data transmissions.
The 802.3x Flow Control and Backpressure mechanisms work respectively for full-
and half-duplex modes. Flow Control can be enabled or disabled on a per-port basis.
Mirror
The Mirror function enables network administrators to monitor all traffic. By forwarding
a copy of the packets that are transferred by the monitored port, the sniffer port
receives all the packets and hence is able to monitor the traffic through the specified
port.
VLAN
This Switch supports Virtual LAN, which means the network can be segmented into
groups to reduce collisions caused by wide broadcasting. The Switch supports both
port-based VLAN and 802.1q tag-based VLAN. Port-based VLAN directs incoming
packets to VLANs according to their ingress ports. 802.1q-based VLAN adds a tag to
the header of the packet to direct the packet to the right VLAN.
Trunk (Aggregation)
The Trunk function groups several ports into one combined transmission channel.
This increases the bandwidth, which helps to boost backbone connectivity. The
Switch allows a maximum of 4 groups and 8 members for each group.
Quality of Service (QoS)
QoS classifies packets into different precedence classes. The packets are transmitted
and received according to their classified priorities. This mechanism helps
high-bandwidth demanding applications such as VoIP to get an unobstructed
connection.
SNMP
The Switch supports SNMP (Simple Network Management Protocol). It allows the
product to be monitored by an SNMP management station.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
11
Management guide
Access the Switch
This section shows you how to access and use the Signamax 065-7940B-WS
Switch’s advanced management capability, which can be accessed via console
port or Internet Browser over the network (in-band).
Manage via Command Line Interface
To start the Command Line Interface, please connect a PC COM port to the
RS-232 connector and activate terminal emulation software (e.g. Windows’
HyperTerminal).
The terminal emulation software should be started in the following configuration:
1. Data rate: 115200 baud
2. Data format: 8 data bits, 1 stop bit and no parity
3. Flow control: none.
4. Click the property icon, select settings, and make sure that: The Function,
arrow, and ctrl keys act as: Terminal keys, Emulation: VT100
Note: To manage via command line interface, please find the “Appendix” for more
information
Manage via Web Browser
To access the Web-based management interface, you should configure the
management station with an IP address and subnet mask that is compatible with your
switch.
The factory defaults of the Switch:
IP：
：：
：192.168.0.254
Subnet Mask：
：：
：255.255.255.0
1. Run your Web Browser and enter the appropriate IP address in the Address field:
2. Key in the user name and password. he factory default value of User Name and
Password is “a min”.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
12
Homepage
After successful log-in, the “SYSTEM Configuration” page appears (this is also the
Homepage). You can click on the hyperlinks on the left side of each page to get
access to each management function.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
13
System
The System window provides the Switch’s system information and allows users to
configure most of these properties (see table under screenshot for details).
Items Functions
MAC Address The MAC address of this device..
S/W Version The software version of this device.
IP Address Set up the IP address of the switch
Subnet Mask Set up the Subnet Mask of the switch
Gateway Set up the Gateway of the switch
Management VLAN The VLAN group that is allowed to access the
WEB-based management interface.
User Name The Log-in name. (Default: admin)
Password The Log-in password. (Default: admin)
System Name The name of the device.
To save the configuration of the system, click “Apply”.
Note:
After applying a new IP address, a new log-in page will appear automatically. Please
log in again to proceed to other configurations.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
14
Port
This Port Configuration page shows the link status of each port and allows users to
configure speed, flow control and maximum frame size for each port.
Items Functions
Link Shows the link status of each port.
The column lights green and
shows the link speed if there is valid connection on the port.
Mode Select a speed for this port. “Auto Speed” enables
auto-negotiation. “Disable” stops the port from functioning.
Flow Control Mark the checkbox to enable the FDX Flow Control, or unmark
to disable.
Max Frame length Adjust the size of Jumbo Frames. The default is 1518 bytes.
The Maximum value can be up to 9k bytes.
To save the configuration of the system, click “Apply”. You can also click the “Refresh”
button to show the updated statuses of the ports.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
15
VLAN
VLAN divides the network members into groups to reduce packet collisions and
improve the network efficiency. The switch supports 802.1q tag-based VLAN. Please
follow the instructions to configure.
To add new VLAN groups,
1. Fill in a VLAN ID, from 2 to 4094, in the “VLAN\Port” column.
2. Select the ports for each VLAN group.
3. Click the “Apply” button to execute.
To delete a VLAN group
1. Remove the members of the VLAN group by unmarking their marked
checkboxes.
2. Clear the VLAN ID of the VLAN you want to remove in the “VLAN\Port”
column. (Don’t type N/A. Just leave it blank)
3. Click the “Apply” button to execute.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
16
PVID
When the VLAN-enabled Switch receives a tagged packet, the packet will be sent to
the port’s default VLAN according to the PVID (port VLAN ID) of the receiving port.
Items Functions
Port Port Number 1~24
Egress Select “tagged” in the drop menu to enable the PVID checking
and tag inserting of one port, and select “untagged” to cancel.
For example, if an Egress-tagged port receives an untagged
frame, it will be transmitted as a PVID tagged frame. For the detail
tagging status, please refer to the following table.
Untagged Tagged
Packet
Frames In
Packet
Frames Out
Packet Frames In
Packet Frames
Out
Untagged Untagged Untagged Tagged (PVID)
Tagged Untagged Tagged (VID) Tagged (VID)
Pri-tagged Untagged Pri-tagged Tagged (PVID)
PVID Port VLAN ID(1~4094)
Only
tagged
Enable: block all untagged packets from accessing this port.
Disable: All packets are allowed to access this port.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
17
Aggregation/ Trunk Configuration
To set up the port trunk groups, put the selected ports’ numbers into the same
Aggregation group. You can choose up to eight groups. Don’t forget to click “Apply” to
save the settings.
There are three aggregation modes for you to set up, SMAC, DMAC, and XOR.
SMAC mode selects the path of packets according to Source MAC while DMAC mode
selects path according to Destination MAC. XOR mode calculates the result of the
DMAC and SMAC modes to decide the path of the packets.
Note:
1. Settings in VLAN, Port Aggregation, and Mirror are co-dependent. Please
make sure that the settings won’t influence one another.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
18
Quality of Service
QoS enhances communication quality by giving precedence to certain classes of
packets. This switch provides port-based, tag-based and DSCP QoS modes:

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
19
Port-based mode QoS:
Port-based QoS allows users to configure each port as having a high or low priority.
To assign a priority level to each port:
1. Select “Port” in the “Mode” column for those ports that are going to function as
part of port-based QoS. Click the “Apply” button.
2. Click the “Port priority” button. The “Port Priority Setting” appears.
3. Click on the drop menu to specify priority levels.
4. Click “Apply” to execute.

065-7940B-WS 24-Port 10/100/1000 WebSmart Switch with 4 SFP Ports
20
Tag-based QoS:
Tag-based QoS assigns packet priority according to the tags on the packets.
To configure Tag-based QoS:
1. Select “Tagged” in the “Mode” column for those ports that are going to
perform tag-based QoS. Click the “Apply” button.
2. Click the “Tag priority” button. The “Tag Priority Setting” page shows up.
3. Select the port that you are going to configure from the drop menu.
4. Set the priorities as high or low for each Priority Tag type.
5. Click the “Apply” button again to execute your configuration.
