Signature S40008 User manual

9″
DESK FAN
MODEL S40008
Applicable to all colour variants
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
www.signaturebrand.co

2
Technical data
Description: 9” Desk Fan
Model: S40008 Applicable to all colour variants
Rated Voltage: 220 - 240V ~
Frequency: 50Hz
Power consumption: 20W
Specications:
This box contains:
9” Desk Fan
Guard fastening screw
1. Guard securing clip
2. Guards
3. Oscillation knob (back of unit)
4. Blade
5. Shaft
6. Speed control buttons
7. Base
1
2
3
4
5
6
7

3
WiringsafetyforUKuseonly
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blueneutral[N]Brownlive[L]
PlugFittingDetails(WhereApplicable).
The wire coloured blue is the neutral and must be
connected to the terminal marked [N] or coloured
black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-RewireableMainsPlug.
If your appliance is supplied with a non-rewireable
plug tted to the mains lead and should the fuse
need replacing, you must use an ASTA approved
one (conforming to BS 1362 of the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it from
the mains - and then cut it o the mains lead and
immediately dispose of its safely. Never attempt
to reuse the plug or insert it into a socket outlet as
there is a danger of an electric shock.
WARNING:
This appliance is double insulated. Do not connect any
wire to the earth terminal.
DISPOSALOFTHEUNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled,
rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.

4
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the appliance
unattended while it is
operating.
• Close supervision is
necessary when any
appliance is used by or near
children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Children should not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• Switch off at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer or its
service agent or a similarly
qualified person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:

5
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.
• DO NOT carry the appliance
by the power cord.
• DO NOT use the appliance
outdoors.
• DO NOT run cord under
carpeting. DO NOT cover
cord with throw rugs, runners
or the like. Arrange cord away
from traffic area to avoid
anyone from tripping over.
• DO NOT insert or allow
foreign objects to enter
any ventilation opening as
this may cause an electric
shock, fire, or damage to an
individual or a property.
• To prevent overload and
blown fuses, be sure
that no other appliance is
plugged into the same outlet
(receptacle) or into another
outlet (receptacle) wired into
the same circuit.
• We DO NOT recommend
use of an extension cord as
it may overheat and cause
a risk of fire. However, if you
have to use an extension
cord, the cord should be
No: 14 AWG minimum size
and rated not less than 1875
watts, and has to be used
only for supplying power to
this fan.
• Never insert your fingers,
pencils or other objects
through the cage during
operation.
• The fan should be set up on
a stable and level surface to
avoid it being knocked over.
• DO NOT expose the fan to
excessive heat or humidity
as this can cause damage to
the electrical components.
• The fan should be kept out of
the reach of children.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE ROTATING PARTS

6
InstallingtheBackGuard:
1. Remove the nut at the back of the motor housing
and put it to one side.
2. Once this part has been removed, ax the back
guard to the motor housing. To do this, align the
three pins on the left side, right side and bottom
of the motor housing with the three corresponding
notches on the back guard, so that the handle
on the guard is at the top of the fan, above the
blades.
3. With the back guard in position, replace the nut
onto its slot at the base of the blade shaft, and
turn it clockwise to tighten.
NOTE:Take care to secure the back guard into place
when re-tightening the nut, to prevent it from slipping
out of position.
4. The back guard should now be secured into
place.
InstallingtheFanBlades:
1. Once the back guard has been installed, slot
the fan blades into the shaft and push them into
place.
NOTE:Ensure the blades rotate unimpeded and do not
graze against the back guard. If the fan blades become
stuck or graze against the guard mesh, they will need to
be re-installed. Repeat the steps above as necessary
until the blades move freely and naturally inside the
guard mesh.
InstallingtheFrontGuard:
1. When the blades have been installed, connect
the front guard to the back guard to complete fan
assembly. To do this, align the edges of the two
guards, ensuring the xing bracket on the front
guard is at the top of the fan, directly above the
blades.
2. When the front guard is in place, locate the
locking clips around the rim of the front guard
and push each of these down to secure the front
guard into place.
3. Use a screwdriver to x the screw and locking nut
through the hole at the bottom of the grilles.
4. Your fan is now ready for normal use.
CAUTION!Do not use the fan when the front guard is
not locked into place.
NOTE:Make sure that the fan is on a level surface and
away from any liquids.
Oscillating the fan will create a more uniform cooling
eect in the room.
Usingyourappliance:
1. Press any of the 2 speed buttons on the fan’s
control panel to turn the unit on. The fan will
automatically start operating at the desired speed.
2. Press the 0 button on the fan’s control panel while
it is in operation to turn the unit o.
Speedselection:
1. This fan is equipped with a choice of 2
speed settings: Low (1) or High (2). Press the
corresponding button on the unit’s control panel
to select the desired speed.
CAUTION!Press only one of the speed control buttons
at a time. Permanent damage to the switch housing
may result if two or more of the buttons are pressed
simultaneously.
2. Press the other speed button while the unit is
in operation to change wind speed. The fan will
automatically adjust to the new setting within a
few seconds.
3. Press the 0 button on the fan’s control panel while
it is in operation to turn the unit o. Wind will stop
emitting from the fan grille and the fan blades will
stop rotating after a few seconds to show the unit
has been turned o.
Oscillation:
1. This fan is equipped with an oscillation function,
for more even heat distribution across a room or
area.
2. Push the oscillation knob at the back of the motor
housing down to turn the oscillation function on.
The fan will automatically begin pivoting from side
to side in a xed pattern.
3. Pull the oscillation knob up while the fan is
oscillating to turn this function o. The fan will
automatically remain locked at its current angle,
and the wind ow will be directed that way. To
select a dierent angle or direction for the wind,
turn the oscillation function back on, as described
above, wait until the fan is facing in the required
direction, then pull the oscillation knob up to stop
the oscillation function and lock the fan into place.

7
AdjustingtheAirFlow:
This unit is equipped with a vertical tilt function, which
can be manually adjusted to better direct the air ow.
1. To adjust the vertical tilt angle of the fan, rmly
grip the top half of the motor housing and push it
gently upwards or downwards as required. The
fan will give o a clicking noise to indicate the tilt
mechanism is working.
2. Once the fan has been tilted, it will automatically
remain at the selected angle until manually
adjusted again.
NOTE:The fan’s horizontal angle cannot be manually
adjusted. To change the horizontal angle of the fan,
activate the oscillation function as detailed above,
wait until the fan is at the desired angle, then pull the
oscillation knob up to stop the oscillation function and
lock the fan into place.
Cleaningandcare:
1. Before cleaning always switch o the appliance
and remove the plug from the electrical socket.
2. To clean the outside of the fan, wipe the exterior
with a soft, damp cloth.
3. Never use an abrasive cleaner.
4. When not in use, store the fan (preferably in its
original box) in a cool, clean and dry location.
Cleaningthefanblades:
1. Remove the front guard by unclipping the locking
clips located around the circumference of the
guard. The top lock does not unclip.
2. Use a small spanner to unscrew the nut and bolt
that holds the bottom of the front guard to the
back guard.
3. With both hands, pull the front guard downwards
and away.
4. Clean the fan blades with a soft, damp cloth.
5. Slide the front guard back into place, so it ts into
the top lock clip. Clip all the locks back into place
and screw the nut and bolt back in.
Model Identier(s): S40008 Applicable to all colour variants
Item Symbol Value Unit
Maximum fan ow rate F13.3 m3/min
Fan Power input P 18.2 W
Service Value SV 0.7 (m3/min)/W
Standby power consumption PSB 0.0 W
Seasonal electricity consumption Q5.8 kWh/a
Fan sound power level LWA 5 7.70 dB(A)
Maximum air velocity C 1.6 m/sec
Contact Details: Imported by RK Wholesale LTD, Berryhill Road,
Stoke-on-Trent ST4 2NL

Wehopeyouenjoyyourapplianceformanyyears.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.signaturebrand.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
0121.V2
