Model S-68H

Headset Instructions

The S-68H series headsets are adjusted at the factory for immediate use with all

standard general aviation radio systems utilizing the U174/U jack. Headsets are

equipped with a coiled cable and a single U174/U plug conguration.

The headband is adjustable through a full range of motion, or the locking nuts

may be tightened to allow you to custom t the headset. Place the headset over

your head, adjust the slides up until minimum pressure is felt on the top of your

head. The headset is now properly adjusted. For maximum noise attenuation, the

clamping pressure has been set at the factory. Releasing the clamping pressure

by bending the headband is not advised, because loss of attenuation will result.

Note: If especially small (children) or large headbands are needed, they may be

ordered from Sigtronics.

The microphone boom is fully adjustable and will rotate 180 degrees for use on

the left or right side of the head. Make sure you are speaking into the side of the

mic labeled “Talk” or substantial loss of gain will occur. Microphone placement

should be at the corner of the mouth, approximately ¼” from the lips.

When you rst connect the headset, turn the volume control on the headset up

to the full clockwise position, then adjust the listening volume with the audio

control of either your radio or intercom as appropriate. Passengers should also

turn their individual headset volumes up fully. Doing this allows for a full range of

adjustment for each passenger, since those with the most acute hearing can turn

their headset volume down, if necessary.

continued on back…

The headset parts may be cleaned with mild soap and water using a soft cloth.

Then dry immediately. Caution: Do Not immerse any part of the headset in water

or any other liquid. Be especially careful not to allow the microphone to become

wet! Exposure to moisture may cause internal corrosion and failure and will void

your manufacturers warranty.

Cleaning will help the headset maintain its “like new” condition for many years.

WINDSCREEN

The microphone windscreen will reduce annoying wind noise and breath pops

picked up by headset microphones. It also protects the microphone element

from dirt and moisture. The windscreen should be washed regularly to maintain

hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thoroughly

and make sure it is completely dry before putting it back on.

To remove the windscreen, carefully grasp the windscreen lightly along its entire

length and remove from the microphone element being careful not to twist the

element itself.

Put the windscreen on the microphone by gently pulling from the open end. Do

not pull it so tightly that it stretches against the end of the microphone.

WARRANTY

Your headset is covered by a limited ve-year parts and labor warranty. Please see

the enclosed warranty card for details.

You may refer to the parts list on the reverse side, if you choose to replace parts

yourself. The parts list describes parts for this particular headset only. Parts lists

for other models are available on our Web Site or can be obtained by contacting

Sigtronics Corporation.

Sigtronics Corporation

178 East Arrow Highway

San Dimas, CA 91773

Phone: 909 305-9399

E-mail: info@sigtronics.com

Web Site: www.sigtronics.com

SIGTRONICS S-68H HEADSET PARTS IDENTIFICATION BREAKDOWN

ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION

1100049 GROMMET, 5/16 INCH, RUBBER 12 100521 SCREW, 8-32 X 3/8, PHILLIPS HEAD, GOLD 23 100606 HEAD BAND EXTRUSION, 6.25 IN., S-68

2100360 KNOB, BLACK, VOLUME 13 100366 WIRE, 2 CONDUCTOR, #24, BLACK, 28 INCHES 24 100258 CLIP, HEADBAND GUIDE, PLASTIC

3100365 POTENTIOMETER, 2K 14 100515 YOKE, EAR CUP MOUNT, METAL, GOLD 25 100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC

4100858 RECEIVER AND MOUNT, 300 OHM, MONO 15 100597 NUT, HEX, 3/8-24, FLEX BOOM ADAPTER 26 100514 HEADBAND, METAL, GOLD, STANDARD

5100108 SCREW, 4-40 X 1/4, THREAD FORMING 16 100402 EAR SEAL, GEL FILLED 27 100516 BRACKET, YOKE SUPPORT WITH TANG, GOLD

6800044 MICROPHONE & FLEX BOOM ASSEMBLY 17 100221 WIRE, JUMPER, #22, 4 INCHES 28 800199 PREAMP, MIC, 8H SERIES

7100520 E-RING, EAR CUP TO YOKE RETAINER, GOLD 18 900111 WINDSCREEN, MIC, 8 SERIES 29 800046 CABLE, HEADSET, HELICOPTER, COILED

8100524 NUT, HEX, 8-32, LOCKING, GOLD 19 100373 SLIDE, YOKE BRACKET, LONG, NYLON 30 100569 STRAIN RELIEF, CABLE

9100614 EAR CUP, PRINTED AND DRILLED, MIC & NON MIC SIDE 20 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 31 100610 CUSHION, HEADBAND, FOAM FILLED

10 100362 CLIP, CROSS-OVER, WIRE, PLASTIC 21 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH 32 100674 OPTIONAL – HEADBAND, METAL, GOLD, LARGE

11 100522 SCREW, 8-32 X 1/2, PHILLIPS HEAD, GOLD 22 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH 33 100369 OPTIONAL – EAR SEAL, FOAM FILLED
