Sihon SO-P20G User manual

SihonElectronicsCo.,Ltd
R
SO-P20G

COMPANY
PROFILE
Sihon Electronics Co., Ltd. Was Established In The Year Of 2007. It Lies In The City Of
Tianchang,china.
We Mainly Produce Ozone Generator And Various Models Of The Ozone Power, Ozone
Ceramic Plate, Ozone Tube And Ozonizer, Etc.
We Also Export The Anion Generator, Charger, And All Kinds Of Ignition For Various
Applications Of High Pressure Generator Different Models Of Anion Power,variety Of
Electronic Anti-riots Etc, For Public Security Agencies And Other Security Units.
We Have Set Up A Strict Test System For Materials And Products. Each Piece Of The
Product Must Pass The Quality Checkout. All Our Products Pass The ISO9001:2000
Standard, Iec And Mil. We Also Passed The Ccc, Ce, Rohs Certification Successfully
In Near Years.

I.Overview
Thank you for purchasing the ozone sterilization anddisinfection
machine. In order to use the ozone sterilization and disinfection
machine correctly, please read the instruction manual carefully
before use.
This product is simple in design, small and portable,easy to
operate, low noise, and durable. (Non-professional maintenance
personnel, please do not disassemble this machine).
II.Introduction
warning
Please make sure the room you need to deal with
Or no people or animals in the place
WORKINGPRINCIPLE
Ozone is produced by ceramic chips, based on the principle of high
frequency and high pressure, the air source is air source,and no other
raw materials are needed.
AIRPURIFIERFUNCTION
Use the broad-spectrum, high-efficiency and rapid sterilization
function of ozone to disinfect indoor air,oxidize and denature
the protein shell of various bacterial cells such as bacteria and
fungi, thereby killing bacterial propagules and spores, viruses,
fungi, etc. There are many Toxic components (such as formaldehyde,
benzene,ammonia, smoke and organic substances with odor)
produce oxidation reactions to eliminate odors and release
their toxicity.Ozone: Ozone is recognized as a broad-spectrum
and highly/effective fungicide in the world. In recent years,it has
been increasingly used in various fields. Ozone has a particularly
R
-1-
Tel&Whatsapp&Wechat : 0086-18098384778
E-mail:[email protected] Web:www.sihon-ozone.com / www.cnxhe.com

PRECAUTIONSFORINSTALLATIONANDUSE
1. The ozone disinfection machine should be placed as high
as possible. The power can be touched by raising the flat
arm. There should be no covering around the host.
2. Do not insert foreign objects into the air outlet of the ozone
disinfection machine to avoid danger.
3. The user shall not modify any device of the original product
by himself.
4. There is high voltage in the machine, do not open the cover
casually, and do not extend your hands or objects into the
swinging leaf to prevent electric shock.
5. In the process of using the product, if there is an abnormal
sit u a tion , y o u s h ould imme d i atel y c u t o ff t he powe r a n d
contact the company's after-sales service.
active chemical property. It is a strong oxidant and can quickly
kill bacteria at a certain conce-ntration. And spores, viruses, fungi,
etc .; and can destroy botulinum, can remove and kill toxic substances
and bacteria in the air, water, food, remove odor, common E. coli,
Streptococcus faecalis, Pseudomonas aeruginosa,golden
Staphylococcus, etc., in an ozone environment,the 15-minute
sterilization rate reaches more than 99%.A certain concentration
of ozone is harmless to the human body, and the human sense
of smell is extremely sensitive.The ozone concentration used for
air sterilization and disinfection is generally 0.25-2.5PPM, while
the human can feel the concentration is 0.01PPM, 0.1PPM
concentration according to national health The Ministry stipulates
that contact for 10 hours will not have any impact and damage to
people (Industrial Hygiene Standard 0.15PPM).At the same time,
ozone sterilization and disinfection remove odors without residues,
because of the instability of ozone, it will be quickly reduced to
oxygen in the air,with no residues and no secondary pollution.
R
-2-
Tel&Whatsapp&Wechat : 0086-18098384778
E-mail:[email protected] Web:www.sihon-ozone.com / www.cnxhe.com

III.ProductParameters
Model :
Voltage:
Power:
Flow Rate:
Ozone Production:
Noise:
Product Size:
Cooling Method:
Gas :
Suit Space:
Product Weight:
IV.ProductPicture
SO-P20G
220V / 50Hz
160W
20g/h
35 dB
415×250×230mm
Air Cooling
Air
340m
5.2Kgs
5.27/6.23（m/min）
3
2
R
-3-
Tel&Whatsapp&Wechat : 0086-18098384778
E-mail:[email protected] Web:www.sihon-ozone.com / www.cnxhe.com
Switch
Timer
Power Jack
Handle
Power Cable
Fan Cover

V.ProductInstructions
1. Make sure there are no people or animals in the roomor place
to be handled;
2. After the power is turned on, the indicator light is on;
3. Set the time of the timer according to the needs of use,rotate
the timer clockwise to set the specific time to work, the time setting
range is 5 minutes to 120 minutes;
4. After the set working time is completed, the machine will
automatically shut down;
5. Please ventilate after the machine is turned off for 40 minutes,
such as opening doors and windows.
6. Timer operation method:
VI.PlaceOfUse
1. Family: used for disinfection and sterilization of living rooms,
kitchens, rooms, carpets, etc. to remove odors;
2. Public places: indoor disinfection and air purification of enterprises
and institutions, hotels, hotels, restaurants,beauty salons, KTV,
mahjong halls, etc .;
3. Internal cleaning, disinfection and sterilization of cars, trains,
yachts, etc .;
4. Air purification and disinfection in hospitals and nursing homes;
5. New buildings, interior decoration pollutants: such as formaldehyde,
benzene, TVOC, preservatives, etc .;
6. Disinfection and sterilization of food workshops,sterile rooms,
R
-4-
Tel&Whatsapp&Wechat : 0086-18098384778
E-mail:[email protected] Web:www.sihon-ozone.com / www.cnxhe.com
Set the machine stop time on the left
10S10S
T1T2
Set the machine working time on the right

VII.Maintenance
When the air purifier is working, the amount of ozone generated
is very small, or when no ozone is generated,a new ozone sheet
needs to be replaced. Normally, a new ozone sheet needs to be
replaced after 5000 hours of operation.
STEPSTOREPLACEOZONETABLETS:
1. Unplug the power cord;
2. Remove the screws around the cover and open the cover;
3. Remove the aging ozone sheet with a screwdriver;
4. Install the new ozone sheet and install the screws.
R
-5-
Tel&Whatsapp&Wechat : 0086-18098384778
E-mail:[email protected] Web:www.sihon-ozone.com / www.cnxhe.com
changing rooms, warehouses and related appliances;
7. Breeding industry: regular disinfection and sterilization of space;
8. Warehouse and cold room: disinfection and sterilization;
9. Others: any place where air needs to be disinfected and sterilized,
any place where odor needs to be eliminated.
