USB 2.0 Multi Card Reader
Quick Installation Guide
Introducing the USB 2.0 Multi Card Reader
The USB 2.0 Multi Card Reader is the perfect choice for
computer users looking for a flash memory card reader/
writer that's easy to carry and supports multi-format flash
memory cards.
Features and Benefits
• CompliantwithUSB2.0specificationandUSBDevice
Class Definition for Mass Storage, Bulk-Transport
V1.0
• Supports CF, xD, Memory Stick, SD, MMC, M2 and
T-Flash memory cards
• Ultra-slim all-in-one compact design
• Powered by USB port - no power adapter required
System Requirements
• PCorMac®computerwithanavailable USB 2.0 port
• Windows®7 (32-/64-bit) / Vista (32-/64-bit) / XP
(32-/64-bit)/ Server 2003 & 2008 (32-/64-bit) / 2000
SP4
• Mac OS®X v10.4.0 or later
04-0571B

2
Package Contents
•USB 2.0 Multi Card Reader
• USB cable (Type A to mini-USB)
• Quick installation guide
Layout
Figure 1. Layout
Note: 1The Memory Stick slot & M2 slot share
resources and can not be used at the same time. Do
not insert a memory card into both slots at the
same time. 2The SD slot & T-Flash slot share
resources and can not be used at the same time. Do
not insert a memory card into both slots at the
same time.
Memory Stick1
CF
SD/Mini SD/MMC2
Activity LED (blue)
xD
Power LED (red)
Micro SD/T-Flash2
M21
USB cable
connector

3
Installation
Hardware Installation
1. Connect one end of the USB cable to the reader/
writer.
2. Connecttheother end to a USB portofthecomputer.
Software Installation
Windows and Mac OS X automatically detects and installs
the correct drivers for this reader/writer when connected.
No driver installation is needed.
Inserting Memory Cards
Insert all memory cards with the top label facing up and
the gold pins facing down.
Important: The Memory Stick slot & M2 slot share
resources and can not be used at the same time. Do not
insert memory cards into both slots at the same time. The
same is true for the SD slot & Micro SD/T-Flash slot.
Accessing Memory Cards
Windows
When the USB 2.0 Multi Card Reader issuccessfullyinstalled,
four Removable Disk icons appear in Computer or My
Computer. To access any one drive, double click the icon
that corresponds to the memory card. The memory card
slots appear in the following order: SD/T-Flash (shared),
CF, xD, Memory Stick/M2 (shared) respectively.

4
Mac
After a memory card is inserted into the
reader/writer, a disk icon will appear on the desktop. To
access the memory card(s), double click the appropriate
disk icon. A disk icon will appear for each occupied
memory slot.
Removing Memory Cards
Windows
Memory cards can be removed at any time. However, to
prevent data loss, data corruption or memory card failure,
DO NOT remove memory cards while the Activity LED
is flashing.
Mac
Dragthe memory card's drive icon into the Trashcan. Wait
forthe icon to disappear from the desktop before removing
the memory card from the reader/writer.
Unplugging the Reader/Writer
Please follow the steps below to safely remove the USB 2.0
Multi Card Reader from the computer.
Windows 7 / Vista / XP / Server 2003 & 2008
1. Click the Safely Remove Hardware icon located in
the taskbar by the system clock.
2. Click Safely Remove USB Mass Storage Device....
3. When the Safe To Remove Hardware box pops up,
the reader/writer can be removed.

5
Windows 2000
1. Click the Unplug or Eject Hardware icon located in
the taskbar by the system clock.
2. Click Stop USB Mass Storage Device....
3. At the Safe To Remove Hardware box, click OK.
The reader/writer can now be removed.
Mac OS X
1. Dragthe memorycard'sdriveiconinto theTrashcan.
Wait for the icon to disappear from the desktop.
2. The reader/writer can now be removed.
