Low Profile USB Adapter
Quick Installation Guide
04-0192A
Introducing the Low Profile USB Adapter
The Low Profile USB Adapter conforms to the new PCI card form factor
standard made for space constrained system designs. It is a
high-speed Universal Serial Bus (USB) host adapter that has more
user-friendly features than the current I/O interfaces such as serial/
parallel ports. It works with all types of USB devices including digital
cameras, PC video cameras, scanners, joysticks and more.
Features and Benefits
• Compliant to USB Specification, Version 1.1
• Completely implements OpenHCI Specification, Version 1.0a
• Compliant to PCI Specification, Version 2.1
• Fully compatible with Windows Standard OHCI drivers
• User friendly plug-n-play and hot-swapping features allow
you to attach/remove USB devices without turning your
system off
• Provides 2 downstream ports for USB device connections
• Supports both 12 Mbps and 1.5 Mbps data transfer modes
Dimensions:
• PCB: 119.91 mm (L) x 64.41 mm (H)
• Bracket: 18.42 mm (W) x 79.20 mm (H)
System Requirements
• Pentium or equivalent computer with one available PCI slot
• Windows 98/98 SE/ME/2000
Package Contents
• One Low Profile USB Adapter
• One 5-year warranty card
• This quick installation guide

2
Hardware Installation
General instructions for installing the card are provided below, since
the design of computer cases and motherboards vary. Refer to your
computer’s reference manual for further information, if needed.
Static Electricity Discharge may permanently damage your system.
Discharge any static electricity build up in your body by touching
your computer’s case for a few seconds. Avoid any contact with
internal parts and handle cards only by their external edges.
1. Turn OFF the power to your computer and any other connected
peripheral devices. Unplug the computer's power cord.
2. Remove your computer’s cover and install the card in an
available PCI slot.
3. Push the board down firmly, but gently, until it is well seated.
4. Secure the card and replace the cover.
Software Installation
Windows 98/98 SE:
Windows 98/98 SE will automatically detect the presence of the
Low Profile USB Adapter. Follow the procedures below to install the
host adapter drivers:
1. At the Add New Hardware Wizard, click Next.
2. Choose Search for the best driver for your device
(Recommended) and click Next.
3. Insert Windows 98 CD-ROM and check CD-ROM check box.
4. Click Next, Next, and Finish to complete driver installation.
Windows ME/2000:
Windows ME and Windows 2000 will automatically detect and
install the correct driver for this adapter. No installation is needed.

3
Technical Support
QUESTIONS? SIIG’s Online Support has the answers! Simply
visitourwebsiteatwww.siig.com andclickonONLINE SUPPORT.
Our online support database is updated daily with new drivers
and solutions. The answers to your problems could be just a few
clicks away.
Return Merchandise Authorization (RMA)
SIIGwarrants to theoriginal buyer ofthe product thatthe hardware
is free of defects in materials and workmanship for a period of one,
two or five years from the date of purchase. If your product fails to
be in good working order during the warranty period, you may
return it to SIIG for repair or replacement at SIIG's option.
To return the product, you need to follow these steps.
Step 1: Contact SIIG's RMA Department
Toobtain an RMAnumber, SIIG's RMADepartment can bereached
by phone at [phone] or fax at [phone] or email at
[email protected]. In order to issue an RMA number, the product
serial number is required. This number can be found on the side of
the box and on the back of the product.
Step 2: Complete the RMA form
• Fill out your Return Merchandise Authorization (RMA) form, and
include it in the package with the product.
• Properly pack the product for shipping. All software, cable(s) and
other accessories that came with the original package must be
included.
• ClearlywriteyourRMAnumberonthetopofthereturnedpackage
and on the accompanying RMA form.
SIIG will refuse to accept any shipping package, and will not
beresponsibleforaproduct returned without an RMA number
posted on the outside of the shipping carton.
Step 3: Ship the Product
You are responsible for the cost of shipping back to SIIG at the
following address:
SIIG, Inc. RMA#_______________
6078 Stewart Ave.
Fremont, CA 94538
SIIG will ship the repaired or replaced product via UPS Ground or
US Mail at no cost to you.

PRODUCT NAME MODEL NUMBER
Low Profile USB Adapter LP0402
