SIIG CE-H22W11-S1 Product information sheet

About SIIG, Inc.
Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity
solutions (including Serial ATA and Ultra ATA Controllers, FireWire,
USB, and legacy I/O adapters) that bridge the connection between
Desktop/Notebook systems and external peripherals. SIIG continues to
grow by adding A/V and Digital Signage connectivity solutions to our
extensive portfolio.
SIIG products offer comprehensive user manuals, many user-friendly
features, and are backed by an extensive manufacturer warranty. High
quality control standards are evident by the overall ease of installation
and compatibility of our products, as well as one of the lowest defective
return rates in the industry. SIIG products can be found in computer
retail stores, mail order catalogs, through major distributors, system
integrators, VARs and through e-commerce sites.
PRODUCT NAME
HDMI to DisplayPort 4K Ultra HD Converter
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B
OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
Phone: [phone]
HDMI to DisplayPort 4K Ultra HD Converter is a trademark of SIIG, Inc. SIIG
and the SIIG logo are registered trademarks of SIIG, Inc. All other names used in
this publication are for identification only and may be trademarks of their respective
owners.
October, 2017 Copyright © 2017 by SIIG, Inc. All rights reserved.
04-1103A
Hardware Installation
NOTE: To achieve 4Kx2K output, make sure this
standard is supported by your display.
1. Insert the HDMI connector to an HDMI output source,
and USB to a USB port. (The USB connection is
optional but recommended for power)
2. Connect the monitor's DisplayPort cable (not
included) to the adapter's DisplayPort output.
3. Now, it is ready for use.
Application
HDMI to DisplayPort 4K Ultra HD Converter
User Reference Guide
P/N: CE-H22W11-S1
For power
DP Display
Figure 2: Application diagram
HDMI Source
(desktop or laptop)
DP Cable
(not included)

Layout
DisplayPort Out
USB Type-A
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at
www.siig.com and click Support. Our online support database is updated daily with
new drivers and solutions. Answers to your questions could be just a few clicks
away. You can also submit questions online and a technical support analyst will
promptly respond.
SIIG offers a 1-year manufacturer warranty with this product. This warranty covers
the original purchaser and guarantees the product to be free of any defects in
materials or workmanship for one (1) year from the date of purchase of the product.
This warranty is not transferable and is available only to the original purchaser of the
product.
SIIG will, at our discretion, repair or replace (with an identical product or product
having similar features and functionality) the product if defective in materials or
workmanship. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. Please see our web site for more
warranty details.
If you encounter any problems with this product, please follow the procedures
below.
A) If it is within the store's return policy period, please return the product to the store
where you purchased from.
B) If your purchase has passed the store's return policy period, please follow the
steps below to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACE
MENT to submit a equest to SIIG RMA or fax a request to 510-657-5962. Your
RMA request will be processed, if the product is determined to be defective, an
RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came with the
original package must be included
• Include a copy of your original sales receipt inside the package with date of
purchase and place of purchase circled and clearly visible
• Clearly write your RMA number on the top of the returned package. SIIG will
refuse to accept any shipping package, and will not be responsible for a product
returned without an RMA number posted on the outside of the shipping carton
• You are responsible for the cost of shipping to SIIG. Ship the product to the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer
Introduction
The HDMI to DisplayPort 4K Ultra HD Converter
converts an HDMI output signal to DisplayPort output at
up to 4Kx2K resolution.
Package contents
• HDMI to DisplayPort 4K Ultra HD Converter
• User reference guide
Specifications
• Compliance: HDMI 1.4 / DP 1.2
• Connectors: 1x HDMI, Male & 1x USB Type-A, Male
(Input) / 1x DisplayPort, Female (Output)
• Resolution: Up to 4Kx2K@30Hz
• Audio: Up to 7.1-channel
• Power: USB bus-powered
• Built-in cable length: 7.68" (HDMI & USB)
• Dimensions: 2.20" (W) x 0.59" (H) x 1.30" (D)
• Weight: 0.10 lbs (45g)
• Displayport: Connects to a DisplayPort
monitor/display with a DP cable (not included)
• USB Type-A: Connects to an available USB port for
additional power
• HDMI: Connects to your HDMI output port
Figure 1: HDMI to DisplayPort 4K Ultra HD Converter
HDMI
