SIIG ID-US0011-S1 User manual

1
Introduction
The USB to RS-422/485 Converter is designed to convert
USB signals to RS-422/485 compatible signal.
Features and Benefits
• Auto detect between RS-422 or RS-485 signal
• Zero jumper configuration
• 15KV ESD immunity, surge protection and short
circuit protection
• USB port powered; no AC adapter required
System Requirements
• Pentium® II or equivalent PC with an available USB
port
• Windows® 8 (32-/64-bit) / 7 (32-/64-bit) / Vista
(32-/64-bit) / XP (32-/64-bit) / Server 2003 (32-/
64-bit) / Server 2008 (32-/64-bit) / Server 2008 R2 /
2000
• Linux 2.6 / 3.x
Serial Number Sticker
For future product return or exchange, this serial number
is required. Please keep it for your reference.
04-0484B
USB to RS-422/485
Converter
Quick Installation Guide
Serial Number Part Number

2
RS-422/485
Signal to
Target Device
USB
port
Power
LED
Dip switch
Figure 1: Top Layout
PackageContents
•USB to RS-422/485 Converter
• USB cable
• Quick installation guide
Layout
Figure 2: Side Layout
1 2 3 4
Tx LED
Rx LED
DIP Switch
You can change the DIP switch to avoid impedance
mismatched problems.
• For RS-422, move DIP switch 1 down and switch 2
up to ON to enable 120 ohms terminal resistor
• For RS-485, move DIP switch 1 up to ON and switch
2 down to enable 120 ohms terminal resistor
• Move switch 1 & 2 down to disable terminal resistor

3
2-wire RS-485 working model with termination resistor:
Pin Assignment
Refer to Figure 2 for the position of pin 1-4, then refer to
Table 1 below for pin assignment.
Device
Device
Serial Adapter
Serial Adapter
Table 1
RS-422 or 4-wire RS-485 working model with termination
resistor:
󳛜󳛕 󳛚󳚌 󳚝 󳛜󳛕 󳛚󳚌 󳚞 󳛜󳛕 󳛚󳚌 󳚟 󳛜󳛕 󳛚󳚌 󳚠
󳚾󳚿󳚙 󳚌 󳚠󳚞󳚞 󳛀󳚗 󳛀󳚙 󳚾󳚗 󳚾󳚙
󳚾󳚿󳚙 󳚌 󳚠󳚤󳚡 󳚰󳚗 󳚰󳚙 󳛄 󳛄

4
Driver Installation
This section provides information on how to install the
USB to RS-422/485 drivers.
Windows 8 (32-/64-bit) / 7 (32-/64-bit) / Vista (32-/
64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-/
64-bit) / Server 2008 R2
Important: Do not plug the USB to RS-422/485 Converter
into the computer until instructed to do so. Plugging in
theconverterprematurelywillcausethedriverinstallation
to fail. If you have already plugged the converter into the
computer, please unplug it before proceeding to step 1.
1. Insertthe driver CD. Close the CDautoplaywindow
if prompted.
2. Press Windows key and Rkey.
For 32-bit: Type D:\Windows\CP210xVCP
Installer_x86.exe, click Enter.(Change D: to match
your CD-ROM drive letter).
For 64-bit and Server 2008 R2: Type D:\Windows\
CP210xVCPInstaller_x64.exe, click Enter.(Change
D: to match your CD-ROM drive letter).
3. At User Account Control, click Yes or Allow. Skip
this step if not prompted
4. At CP210x USB to UART Bridge Driver Installer,
click Next.
5. Select I accept this agreement,click Next.
6. Click Finish.
7. Insert the USB to RS-422/485 Converter into a USB
port. The driver will install automatically.
8. Restart your system to complete the installation.

5
Windows 2000
Important: Do not plug the USB to RS-422/485 Converter
into the computer until instructed to do so. Plugging in
theconverterprematurelywillcausethedriverinstallation
to fail. If you have already plugged the converter into the
computer, please unplug it before proceeding to step 1.
1. Insertthe driver CD. Close the CDautoplaywindow
if prompted.
2. Click Start and Run, type D:\Windows\Win
2000\setup.exe, click Enter.(Change D: to match
your CD-ROM drive letter).
3. At Silicon Laboratories CP210x VCP Drivers for
Windows, click Next.
4. Select I accept the terms of the license agreement,
click Next.
5. Click Next, Install, Finish.
6. Click Install, OK.
7. Insert the USB to RS-422/485 Converter into a USB
port. The driver will install automatically.
8. Restart your system to complete the installation.

6
To Verify Installation
1. Check Device Manger to verify installation.
For Windows 8 / 7 / XP / Server 2003 / 2000: Right click
Computer or My Computer, click Manage, then
click Device Manager.
For Windows Vista: Right click Computer, click
Manage, click Continue, click Device Manager.
For Server 2008 & 2008 R2: Right click Computer,
clickManage,doubleclick Diagnostics, click Device
Manager.
2. Double click Ports (COM&LPT), Silicon Labs
CP210x USB to UART Bridge should be displayed.

7
