SIIG DP SuperSpeed USB 3.0 2-Port PCIe i/e User manual

1
04-0617B
DP SuperSpeed USB 3.0
2-Port PCIe i/e
Quick Installation Guide
Introducing the USB 3.0 2-Port PCIe i/e
The DP SuperSpeed USB 3.0 2-Port PCIe i/e adds
two USB 3.0 ports (1 internal & 1 external) to
yourPCIe-enableddesktopPCenhancingexisting
systems with the latest USB 3.0 technology.
Key Features and Benefits
• Compliant with Universal Serial Bus 3.0
Specification, Revision 1.0
• Compliant with PCI Express Base
Specification, Revision 2.0
• Supports data rate up to 5Gb/s and
backward compatible with previous
versions of USB devices
• Works with high-bandwidth USB 3.0
devices, such as external hard disks, high
resolution webcams, video surveillance
cameras, digital video cameras, multi-
channel audio and more...

2
System Requirements
• Desktop PC with an available PCIe slot
• Windows®7 (32-/64-bit) / Vista (32-/64-
bit) / XP (32-/64-bit)
Package Contents
•DP SuperSpeed USB 3.0 2-Port PCIe i/e
adapter
• Spare low profile bracket
• Driver CD
• Quick installation guide
Layout
Figure 1: Board Layout
USB 3.0 Port
USB 3.0 Port

3
Hardware Installation
General instructions for installing the card are
provided below. Since the design of computer
cases and motherboards vary, refer to your
computer’s reference manual for further
information, if needed.
Static Electricity Discharge may permanently
damage your system. Discharge any static
electricity build up in your body by touching your
computer’s case for a few seconds. Avoid any
contact with internal parts and handle cards only
by their external edges.
Note: For low profile systems, remove the full
height bracket and install the low profile bracket
now.
1. Turn OFF the power to your computer and
any other connected peripheral devices.
2. Unplug the power cord from the back of the
computer.
3. Remove your computer cover.
4. Remove the slot bracket from an available
PCIe slot.

4
5. Carefully align the card's bus connector
with the selected PCIe slot on the
motherboard. Push the board down firmly,
but gently, until it is well seated.
6. Replace the slot bracket holding screw to
secure the card.
7. Replace the computer cover and reconnect
the power cord.
Driver Installation
Follow the steps below to install the driver.
Windows 7 (32-/64-bit) / Vista (32-/64-bit)
1. Make sure the board is installed, then boot
up Windows.
2. At the Windows desktop.
For Windows 7:Go directly to step 3.
For Windows Vista: At the Found New
Hardware window, click Cancel.
3. Insert the driver CD.
For Windows 7: at the CD AutoPlay box,
click Open folder to view files, then double
click Setup.

5
For Windows Vista: At the CD Autoplay
box, double click Setup.
4. At User Account Control.
For Windows 7: Click Yes.
For Windows Vista: Click Continue.
5. At Welcome, click Next.
6. Select I accept the terms of the license
agreement, click Next.
7. At Ready to Install the Program,clickInstall.
8. Wait while the InstallShield Wizard
configures your system. Depending on
your system hardware this process may
take several minutes to complete.
9. At InstallShield Wizard Complete, click
Finish.
Windows XP (32-/64-bit)
1. Make sure the board is installed, then boot
up Windows.
2. At Found New Hardware, click Cancel.
3. Insert the driver CD. Click Start, Run. Type
D:\Setup.exe, click OK. (Change D: to
match your CD\DVD-ROM drive letter)

6
4. At Welcome, click Next.
5. Select I accept the terms of the license
agreement, click Next.
6. At Ready to Install the Program,clickInstall.
7. Wait while the InstallShield Wizard
configures your system. Depending on
your system hardware this process may
take several minutes to complete.
8. At InstallShield Wizard Complete, click
Finish.
To Verify Successful Installation
1. Go to Device Manager to verify installation.
For Windows 7: Right click Computer, click
Manage, click Device Manager.
For Windows Vista: Right click Computer,
click Manage, click Continue, then click
Device Manager.
For Windows XP: Right click My Computer,
click Manage, click Device Manager.
2. Double click Universal Serial Bus
controllers. A USB 3.0 Host Controller
and a USB 3.0 Root Hub should be
displayed.

7
