Silex technology MNS-300EM Installation instructions

MNS-300EM
Command Manual

Copyright© 2019 silex technology, Inc. All rights reserved.
WA105840XB

Index
1. Introduction...........................................................1
1-1. Introduction ......................................................................................... 2
MNS-300EM User's Manuals ............................................................. 2
Disclaimers.............................................................................................. 2
Trademarks ............................................................................................. 3
1-2. Product Information and Customer Services........................... 4
Product Information............................................................................ 4
Customer Support Center ................................................................. 4
2. How to Access Command Console........................5
3. Network Commands..............................................7
3-1. SET NW WIRED..................................................................................... 8
3-2. SH NW..................................................................................................... 8
3-3. SET NW MOde ..................................................................................... 9
3-4. SH NW RATE.......................................................................................... 9
3-5. SH NW SQ............................................................................................10
3-6. SH NW MAC........................................................................................10
4. Station Commands ............................................. 11
4-1. Wireless LAN Commands...............................................................12
4-1-1. SET NW RADio ............................................................................12

4-1-2. SET NW RTS .................................................................................12
4-1-3. SET NW SSid ................................................................................13
4-1-4. SET NW STARTdelay..................................................................13
4-1-5. SH NW WLLIST ............................................................................14
4-1-6. SH NW PROFILE..........................................................................14
4-1-7. SET NW PROFCFG......................................................................15
4-1-8. SET NW PROFACT ......................................................................15
4-2. Wireless LAN Security Commands .............................................16
4-2-1. SET NW AUTHtype ....................................................................16
4-2-2. DEL NW CERTS............................................................................17
4-2-3. SET NW ENC ................................................................................17
4-2-4. SET NW KEY#...............................................................................18
4-2-5. SET NW KEYNUM.......................................................................18
4-2-6. SET NW KEYVAL .........................................................................18
4-2-7. SET NW WPAPSK ........................................................................19
4-2-8. SET NW ID ....................................................................................19
4-2-9. SET NW PW ..................................................................................20
4-2-10. SET NW PEAPGTC....................................................................20
4-2-11. SET NW PEAPMSchap...........................................................21
4-2-12. SET NW PEAPV0.......................................................................22
4-2-13. SET NW PKPASS .......................................................................22
4-2-14. SET NW CACERT ......................................................................23

4-2-15. SET NW CLCERT .......................................................................23
4-2-16. SET NW CLKEY..........................................................................23
4-2-17. SET NW SSCCITY......................................................................24
4-2-18. SET NW SSCCOMNAME.........................................................24
4-2-19. SET NW SSCCOUNTRY...........................................................25
4-2-20. SET NW SSCKEYSIZE...............................................................25
4-2-21. SET NW SSCORGNAME .........................................................26
4-2-22. SET NW SSCORGUNIT............................................................26
4-2-23. SET NW SSCSTATE...................................................................27
4-2-24. SET NW SSCGEN ......................................................................27
4-3. Wireless LAN Roaming Control....................................................28
4-3-1. SET NW BGSCAN........................................................................28
4-3-2. SET RM...........................................................................................28
4-3-3. SET RM SCAN NORM ................................................................29
4-3-4. SET RM THResh CRITical..........................................................29
4-4. Wireless/Wired Bridge Setting.....................................................30
4-4-1. SET NW BRIDGE..........................................................................30
4-4-2. SH NW BRIDGE ...........................................................................30
4-4-3. SET NW BRACCess.....................................................................31
4-4-4. SET NW BRCLADDR...................................................................31
4-4-5. SET NW BRSTATIC ......................................................................32
4-5. Smart Wireless Setup ......................................................................33

4-5-1. SET NW SWSPINCODE .............................................................33
4-5-2. SET NW SWSPBC........................................................................33
4-5-3. SET NW SWSPBC NOWAIT ......................................................33
4-5-4. SET NW SWSPIN.........................................................................34
4-6. TCP/IP Settings in Station Mode .................................................35
4-6-1. SET IP MEthod ............................................................................35
4-6-2. SET IP ADdress............................................................................35
4-6-3. SET IP SUbnet ............................................................................36
4-6-4. SET IP ROuter ..............................................................................36
4-6-5. SET IP BOot ..................................................................................36
5. Mesh Commands ................................................ 37
5-1. SH MEsh PROFILE [prole_num].................................................38
5-2. SET MEsh PROFSELect [prole_num] .......................................39
5-3. SET MEsh [prole_num] PROFile ................................................39
5-4. SET MEsh [prole_num] MOde ...................................................40
5-5. SET MEsh [prole_num] CHWidth..............................................40
5-6. SET MEsh [prole_num] CHannel...............................................41
5-7. SET MEsh [prole_num] GRoup..................................................41
5-8. SET MEsh [prole_num] KEY ........................................................42
5-9. SET MEsh [prole_num] HOP.......................................................42
5-10. SET MEsh [prole_num] REFresh .............................................43
5-11. SET MEsh [prole_num] REFMethod......................................43

5-12. SET MEsh [prole_num] REFInterval.......................................44
5-13. SET MEsh [prole_num] POWer ...............................................44
5-14. SET MEsh [prole_num] IPMEthod..........................................45
5-15. SET MEsh [prole_num] IPADdress .........................................45
5-16. SET MEsh [prole_num] IPSUbnet...........................................45
5-17. SET MEsh [prole_num] IPROuter ...........................................46
5-18. SET MEsh [prole_num] DNSPRImary....................................46
5-19. SET MEsh [prole_num] DNSSECondary...............................46
5-20. SET MEsh [prole_num] RTMOde............................................47
5-21. SET MEsh [prole_num] TXCTL.................................................47
6. Port Commands .................................................. 49
6-1. Serial Port Commands....................................................................50
6-1-1. SH PORT........................................................................................50
6-1-2. SET PORT S1 CHarsize..............................................................50
6-1-3. SET PORT S2 COnsole ..............................................................51
6-1-4. SET PORT S1 CONSTR...............................................................51
6-1-5. SH PORT S1 CONSTR ................................................................52
6-1-6. SET PORT S1 DTR .......................................................................53
6-1-7. SET PORT S1 FLOW ...................................................................53
6-1-8. CLEAR PORT S1 JOB..................................................................54
6-1-9. SET PORT S1 LATency...............................................................54
6-1-10. SET PORT S1 PArity.................................................................55

6-1-11. SET PORT S1 SPeed ................................................................55
6-1-12. SH PORT S1 STAtus.................................................................56
6-1-13. SET PORT S1 STOP ..................................................................56
6-2. Ecable Port Command....................................................................57
6-2-1. SET PORT S1 ECABLE................................................................57
6-2-2. SH PORT S1 ECABLE..................................................................57
6-2-3. SET PORT S1 ECADDR..............................................................58
6-2-4. SET PORT S1 ECCONN..............................................................58
6-2-5. SET PORT S1 ECLPORT.............................................................59
6-2-6. SET PORT S1 ECNHOST............................................................59
6-2-7. SET PORT S1 ECPORT ...............................................................60
6-2-8. SET PORT S1 ECRADDR ...........................................................60
6-2-9. SET PORT S1 ECRPORT.............................................................61
6-2-10. SET PORT S1 ECTMMSEC......................................................61
6-2-11. SET PORT S1 ECUDP...............................................................62
7. Server Commands .............................................. 63
7.1. SH SERIAL.............................................................................................64
7-2. SH SERVEr............................................................................................64
7-3. SH SERVEr CO.....................................................................................65
7-4. SET SERVEr DEScription ................................................................65
7-5. SH SERVEr FWVER.............................................................................66
7-6. SH SERVEr MODEL............................................................................66

7-7. SET SERVEr NAme ............................................................................67
7-8. SH SERVEr STAtistics........................................................................67
7-9. SH SERVEr QUEue.............................................................................68
7-10. SH SNMP ...........................................................................................68
7-11. SET SNMP CONtact........................................................................69
7-12. SET SNMP GETCOMM...................................................................69
7-13. SET SNMP LOCation......................................................................69
7-14. SET SNMP SETCOMM2 .................................................................70
7-15. SH VErsion.........................................................................................70
8. Service Commands ............................................. 71
8-1. SH SERVI...............................................................................................72
8-2. SET SERVI <service name> BOT ..................................................72
8-3. SET SERVI <service name> EOT ..................................................73
8-4. SH SERVI STRings [string_num]...................................................73
8-5. SET SERVI <service name> FIlter ...............................................74
8-6. SH SERVI FILters ................................................................................74
8-7. SET SERVI <service name> FMS..................................................75
8-8. SET SERVI <service name> FRS ...................................................75
8-9. SET SERVI <service name> IP.......................................................76
8-10. SET SERVI <service name> NAme ...........................................76
8-11. SET SERVI <service name> POrt...............................................77
8-12. SET SERVI <service name> PRIority ........................................77

8-13. SH SERVI PRI [service_num]......................................................78
8-14. SET SERVI <service name> QUEue ..........................................78
8-15. SET SERVI <service name> RECeive ........................................79
8-16. SET SERVI <service name> TCP.................................................79
8-17. SH SERVI SUMmary [service_num]..........................................80
9. String Commands ............................................... 81
9-1. SET STRing .........................................................................................82
9-2. CL STRing ............................................................................................82
9-3. SH STRing............................................................................................83
9-4. SH FILters.............................................................................................84
10. TCP/IP Commands ............................................ 85
10-1. SH IP ...................................................................................................86
10-2. SET IP ACcess...................................................................................87
10-3. SET IP KEepalive .............................................................................87
10-4. SET IP HTTP ......................................................................................88
10-5. SET IP TFTP ......................................................................................88
10-6. SET IP NTP.........................................................................................88
10-7. SET IP TCP .........................................................................................89
10-8. SET IP LPD.........................................................................................89
10-9. SET IP SX_INTERN ..........................................................................89
10-10. SET IP PRObe.................................................................................90
10-11. SET IP TImeout..............................................................................90

10-12. SET IP FTIme..................................................................................91
10-13. SET IP REtry....................................................................................91
10-14. SET IP STATus.................................................................................92
10-15. SET IP WIndow..............................................................................92
10-16. SET IP BAnner................................................................................93
11. DNS Commands ................................................ 95
11-1. SH DNS...............................................................................................96
11-2. SET DNS DOMain ...........................................................................96
11-3. SET DNS PRImary ...........................................................................97
11-4. SET DNS SECondary......................................................................97
12. NTP Commands ................................................ 99
12-1. SET NTP SERVER ...........................................................................100
12-2. SH NTP DATE..................................................................................100
13. GPIO Control Commands ............................... 101
13-1. SET GPIO DIR..................................................................................102
13-2. SH GPIO DIR ...................................................................................103
13-3. SET GPIO DIRM..............................................................................104
13-4. SH GPIO DIRM ...............................................................................104
13-5. SET GPIO SPECial..........................................................................105
13-6. SH GPIO SPECial ...........................................................................106
13-7. SET GPIO SPECM ..........................................................................107

13-8. SH GPIO SPECM ............................................................................107
13-9. SET GPIO DATA..............................................................................108
13-10. SH GPIO DATA.............................................................................109
14. Bluetooth Commands .................................... 111
14-1. SH BT ................................................................................................112
14-2. SET BT...............................................................................................112
14-3. SET BT PASSkey.............................................................................113
15. Firmware Update Commands........................ 115
15-1. SET LOAd XModem .....................................................................116
16. Power Management Commands ................... 117
16-1. SET NW WLIF..................................................................................118
16-2. SET POWER LEVEL........................................................................118
17. Other Commands ........................................... 119
17-1. SET DEFAULT..................................................................................120
17-2. EXIT ...................................................................................................120
17-3. HElp <command> .......................................................................120
17-4. INIT....................................................................................................121
17-5. SET PAssword ................................................................................121
17-6. SAVE..................................................................................................121

1. Introduction
1
1. Introduction
Thank you for purchasing the Intelligent Module MNS-300EM.

2
MNS-300EM Command Manual
Disclaimers
• The unauthorized transfer or copying of the content of this manual, in whole or in part,
without prior written consent is expressly prohibited by law.
• The content of this manual is subject to change without notice.
• Although every eort was made to prepare this manual with the utmost accuracy, Silex
Technology will not be held liable for any damages as a result of errors, setting examples,
or other content.
1-1. Introduction
MNS-300EM has the following user's manuals:
MNS-300EM Command Manual (this document)
This document describes the console commands that can be used on MNS-300EM.
MNS-300EM Setting Manual
This document explains the functions and conguration methods of MNS-300EM.
MNS-300EM Embedded Manual
This document describes the specifications and procedures for embedding MNS-300EM
into the customer's device (hereinafter "target device").
Before using MNS-300EM, please read 1-2. Safety Instructions at "MNS-300EM Setting
Manual" or "MNS-300EM Embedded Manual".
MNS-300EM User's Manuals

1. Introduction
3
Trademarks
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• Wi-Fi, Wi-Fi Protected Access (WPA), WPA2 are either registered trademarks or trademarks of
Wi-Fi Alliance.
• Other brand or product names are registered trademarks or trademarks of their
respective owners.

4
MNS-300EM Command Manual
1-2. Product Information and Customer Services
Product Information
The services below are available from the Silex Technology website. For details, please visit
the Silex Technology website.
• Latest rmware download
• Latest software download
• Latest manual download
• Support information (FAQ)
Customer Support Center
Customer Support is available by e-mail or telephone for any problems that you may
encounter. If you cannot nd the relevant problem in this manual or on our website, or if
the corrective procedure does not resolve the problem, please contact Silex Technology
Customer Support.
Contact Information
USA [phone] [email protected]
Europe [phone] [email protected]
Silex Technology website
URL: https://www.silextechnology.com/
• Refer to the Silex Technology website ( https://www.silextechnology.com/ ) for the latest FAQ and product
information.
Note

2. How to Access Command Console
5
2. How to Access Command Console
MNS-300EM settings can be updated and managed using the command console.
Some function can be congured by the command console only.
Use one of the following ways to access the command console:
• MNS-300EM's serial data port
• Conguration console port
• Linux console port
In addition to the above, the Web console function can be used from MNS-300EM's Web
page. Whichever method is used to access the command console, the setting method is
the same unless otherwise noted.
Capital letters in the following command explanations are minimum essential command
tokens. These characters must be entered for commands to be recognized and cannot be
omitted.
• The following commands can be substituted for each other:
SEt, DEFine, CHange Updating a setting value
DEl, CLear, PUrge Deleting a setting value
• Characters except for command tokens can be omitted.
• The following two commands have the same meaning:
- SET NW PEAPMSchap ENable
- SET NW PEAPMS EN
Note

6
MNS-300EM Command Manual
(Blank page)

3. Network Commands
7
3. Network Commands
This chapter describes the network parameter commands.

8
MNS-300EM Command Manual
Sets the wired LAN link mode.
SET NW WIRED <mode>
Choose one of the followings for <mode>.
AUTO : Auto mode
FD100BASE : 100Base FULL
100BASE : 100Base Half
FD10BASE : 10Base FULL
10BASE : 10Base Half
3-1. SET NW WIRED
Shows the current network information.
SH NW
Sample output:
Local> SH NW
WiFi Mode = STATION
WiFi SSID: server
Regulatory Domain = JP
Authentication type= OPEN SYSTEM
Encryption is Disabled
AP MAC Address = 84 25 3F 00 11 22
Signal Quality = Excellent (100%)
Connected to SSID SQRT on channel 3
3-2. SH NW
