UG186: Si827x-EVB User's Guide
The Si827x isolated gate drivers are ideal for driving power switches used in a wide vari-
ety of power supply, inverter, and motor control applications, offering longer service life
and dramatically higher reliability compared to opto-coupled gate drivers. The Si827x
isolated gate drivers utilize Silicon Laboratories' proprietary silicon isolation technology
supporting up to 2.5 kVRMS withstand voltage per UL1577 and VDE0884. This technolo-
gy enables industry-leading common-mode transient immunity (CMTI), tight timing spec-
ifications, reduced variation with temperature and age, better part-to-part matching, and
extremely high reliability. It also offers unique features, such as separate pull-up/down
outputs, driver shutdown on UVLO fault, and precise dead time programmability. Driver
outputs can be grounded to the same or separate grounds or connected to a positive or
negative voltage. The TTL level compatible inputs with >400 mV hysteresis are available
in individual control input (Si8271/2/3/5) or PWM input (Si8274) configurations. High in-
tegration, low propagation delay, small installed size, flexibility, and cost-effectiveness
make the family ideal for a wide range of isolated MOSFET/IGBT/SiC/GaN gate drive
applications.
The Si827x evaluation board allows designers to evaluate Silicon Lab's Si827x family of
high CMTI performance ISOdrivers. The boards come populated with the Si8271 and ei-
ther the Si8273, Si8274, or Si8275 version of the family. The board includes screw ter-
minals for quick evaluation of the devices’ key parameters and also includes test points
on each devices’ pins to accommodate direct connection to the designer’s end system.
For more ISOdriver information, visit Silicon Labs web site at www.silabs.com/isolation.
The product data sheet and numerous application notes can be referenced to help facili-
tate designs.
KIT CONTENTS
• Si827x-based evaluation board (Si827x-
EVB)
• Si8271, 1-input, 4 A, 2.5 kVRMS Single
ISOdriver, and one of the following:
•Si8273, 2-input, 4 A, 2.5 kVRMS High-
Side/Low-Side ISOdriver
• Si8274, PWM-input, 4 A, 2.5 kVRMS
High-Side/Low-Side ISOdriver
• Si8275, 2-input, 4 A, 2.5 kVRMS Dual
ISOdriver
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1

1. Required Equipment
The following equipment is required to demonstrate the evaluation board:
•1 digital multimeter
• 1 oscilloscope (at least 2 channel)
• 1 dual dc power supply: 0–5 V and 0–15 V (or 2 single supplies)
• 1 function generator
• Assorted cables, leads and probes as necessary to connect equipment to EVB
• Si827x Evaluation Board (board under test)
• Si827x Evaluation Board User's Guide (this document)
Note: Please note the voltage rating for the prepopulated components in the Si827x BOM section of this document before applying
power to the ISOdriver and customer-specific output power stage. Applying a voltage to a component that is higher than its rating can
cause permanent device damage. If the installed components do not meet the user's requirements, these components need to be re-
placed before proceeding.
UG186: Si827x-EVB User's Guide
Required Equipment
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 1

2. Si827x ISOdriver Board Setup and Demo Test
2.1 EVB Demo/Test
To run the demo, follow the instructions below. Refer to Figure 3.1 Si827x Evaluation Board Primary Silkscreen on page 6 and
Figure 3.2 7 on page 7 as necessary.
2.2 DC Supply Configuration
1. Set one supply to output 5 VDC.
2. Turn OFF the supply and connect the positive lead to VDDI (J1 pin1 or TP1).
3. Connect the negative lead to GNDI (J1 pin 2 or TP2).
4. Turn ON the dc power supply.
5. Ensure that the current draw is less than 25 mA. If it is larger, this indicates that either the board or Si827x has been damaged or
the supply is connected backwards.
6. Set the other supply to output 15 VDC.
7. Turn OFF the supply and connect the positive lead to VDDA (J2 pin 3 or TP3).
8. Connect the negative lead to VSSA (J2 pin 1 or TP15).
9. Turn ON the supply.
10. Ensure that the current draw is less than 100 mA. If it is larger, this indicates that either the board or Si827x has been damaged or
the supply is connected backwards.
2.3 Function Generator
1. Turn ON the function generator with the output disabled.
2. Adjust its output to provide a 500 kHz, 0 to 5 V peak square wave (50 percent duty cycle) to its output.
3. Connect the output of the generator to VIA/PWM (JP1 pin2).
4. If this is a board with VIB, apply a jumper to JP2 between pins 2 and 3.
5. Make sure jumper JP3 has a shunt between pins 1 and 2 to enable the device.
6. Enable the output of the waveform generator.
UG186: Si827x-EVB User's Guide
Si827x ISOdriver Board Setup and Demo Test
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 2

2.4 Oscilloscope Setup
To set up the oscilloscope, perform the following steps:
1. Turn ON the oscilloscope.
2. Set the scope to Trigger on CH1 and adjust the trigger level to approximately 2 V.
3. Set CH1 to 2 V per division and CH2 to 5 V per division.
4. Adjust the seconds/division setting to 500 ns/division.
5. Connect the scope channel 1 probe to VIA/PWM. Ground the probe to GNDI.
6. Connect Channel 2 probe to VOA (J2 pin2 or TP15). Ground the probe to VSSA.
7. Adjust the vertical position of each channel to properly view each channel as shown in the figure below.
A 500 kHz square wave should display on Channel 1 of the scope for the input and a 15 V version should display on Channel 2, as
shown in the following figure.
Figure 2.1. 500 kHz Square Wave
UG186: Si827x-EVB User's Guide
Si827x ISOdriver Board Setup and Demo Test
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 3

2.5 Repeat for Second Channel
1. Disable the function generator output.
2. Turn OFF the 15 V supply.
3. Disconnect 15 V supply from VDDA/VSSA.
4. Connect the 15 V supply to VDDB and VSSB (J3 pins 3 and 1 or TP17 and TP18).
5. Move the channel 2 scope probe to VOB/VSSB (J3 pin 2/1 or TP19/TP18).
6. Move the function generator to VIB (JP2 pin 2 or TP6). NOTE: If this board is populated with the Si8274 device, leave the function
generator connected to VIA/PWM. Otherwise, move the shunt from JP2 to JP1.
7. Turn ON the dc supply.
8. Ensure that the current draw is less than 100 mA. If it is larger, this indicates that either the board or Si827x has been damaged or
the supply is connected backwards.
9. Enable the function generator output.
10. The scope display should show both the input and output waveforms as before. NOTE: If this board is populated with the Si8274
device, the output waveform will be inverted with respect to the input.
2.6 Test the Si8271
1. Disable the function generator output.
2. Turn OFF the 15 V supply.
3. Turn OFF the 5 V supply.
4. Disconnect 15 V supply from VDDA/VSSA.
5. Connect the 15 V supply to VDD and VSS (J5 pins 2 and 1 or TP22 and TP28).
6. Connect the 5 V supply to VDDI2 and GNDI2 (J4 pins 1 and 2 or TP20 and TP21).
7. Short the VOUTPUT+ and VOUTPUT- pins together (J6 pins 1 and 2) and connect them to the channel 2 scope probe.
8. Ground the probe at VSS (J5 pin 1 or TP28).
9. Move the function generator to VI (JP4 pin 2 or TP23).
10. Move the channel 1 scope probe to be connected to the same points as the function generator.
11. Make sure jumper JP5 has a shunt between pins 1 and 2 to enable the device.
12. Turn ON the dc supplies.
13. Ensure that the current draw is less than 100 mA on the 15 V supply and 25 mA on the 5 V supply. If either is larger, this indicates
that either the board or Si827x has been damaged or the supply is connected backwards.
14. Enable the function generator output.
15. The scope display should show both the input and output waveforms as before.
UG186: Si827x-EVB User's Guide
Si827x ISOdriver Board Setup and Demo Test
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 4

3. Si827x-EVB Power and Jumper Connection Descriptions
The power and jumper connections are summarized here:
•J1 Screw terminal block used to connect external power supply for input side of Si827x.
• J2 Screw terminal block used to connect external power supply for output side A as well as bring out output A of Si827x.
• J3 Screw terminal block used to connect external power supply for output side B as well as bring out output B of Si827x.
• J4 Screw terminal block used to connect external power supply for input side of Si8271.
• J5 Screw terminal block used to connect external power supply for output side of Si8271.
• J6 Screw terminal block used to bring out V+ and V– outputs of Si8271.
• JP1 Header to facilitate connection of external signal for VIA/PWM of Si827x.
• JP2 Header to facilitate connection of external signal for VIB of Si827x (not populated for Si8274 version of EVB).
• JP3 Header to facilitate connection of external signal for ENABLE of Si827x.
• JP4 Header to facilitate connection of external signal for VI Si8271.
• JP5 Header to facilitate connection of external signal for ENABLE of Si8271.
• JP6 Header to facilitate evaluation of BOOTSTRAP circuitry.
UG186: Si827x-EVB User's Guide
Si827x-EVB Power and Jumper Connection Descriptions
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 5

3.1 Voltage and Current Sense Test Points
The Si827x evaluation board has several test points. These test points correspond to the respective pins on the Si827x integrated cir-
cuits as well as other useful inspection points. See the figure below for a silkscreen overview. See the schematic drawings for more
details.
Figure 3.1. Si827x Evaluation Board Primary Silkscreen
UG186: Si827x-EVB User's Guide
Si827x-EVB Power and Jumper Connection Descriptions
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 6

Figure 3.2. Si827x Evaluation Board Secondary Silkscreen
UG186: Si827x-EVB User's Guide
Si827x-EVB Power and Jumper Connection Descriptions
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 7

4. Si827x Evaluation Board Schematics
Figure 4.1. Si827x Evaluation Board Schematic (1 of 2)
Figure 4.2. Si827x Evaluation Board Schematic (2 of 2)
UG186: Si827x-EVB User's Guide
Si827x Evaluation Board Schematics
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 8

5. Si827x Evaluation Board Layout
Figure 5.1. Si827x Layer 1: Primary Side
UG186: Si827x-EVB User's Guide
Si827x Evaluation Board Layout
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 9

Figure 5.2. Si827x Layer 2: Ground Plane
UG186: Si827x-EVB User's Guide
Si827x Evaluation Board Layout
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 10

Figure 5.3. Si827x Layer 3: Power Plane
UG186: Si827x-EVB User's Guide
Si827x Evaluation Board Layout
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 11

Figure 5.4. Si827x Layer 4: Secondary Side
UG186: Si827x-EVB User's Guide
Si827x Evaluation Board Layout
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 12

6. Bill of Materials
Table 6.1. Si827x-EVB Bill of Materials
Qty Ref Value Rating Voltage Tol Type PCB Footprint Mfr Part Number Mfr
2 C1, C9 1 µF 50 V ±10% X7R C0805 CL21B105KBFNNNE Samsung
1 C15 200 pF 50 V ±10% C0G C0805 C0805C0G500-201K Venkel
5 C2, C3, C7,
C10, C11
0.1 µF 100 V ±10% X7R C0805 C0805X7R101-104K Venkel
2 C8, C12 10 µF 50 V +80/–
20%
Y5V C1210 GRM32DF51H106ZA0
1L
Murata
1 D1 US1K 1.0 A 800 V Switch,
Ultra-
Fast
DO-214AC US1K-13-F Diodes
Inc.
4 J1, J4, J5, J6 CONN TRBLK 2 Term
Black
CON1X2-1725656 1725656 Phoenix
Contact
2 J2, J3 CONN TRBLK 3 Term,
Black
CON1X3-1725669 1725669 Phoenix
Contact
5 JP1, JP2,
JP3, JP4, JP5
Header 1 x 3 Header CONN1X3 TSW-103-07-T-S Samtec
1 JP6 Jumper Header CONN1X2 TSW-102-07-T-S Samtec
5 JS1, JS2,
JS3, JS4, JS5
Jumper Shunt Shunt N/A SNT-100-BK-T Samtec
1 LB1 OPN:
Si8273ISO-EVB
Poly-
mide,
White
PTL-14-477 LABEL-Si8273ISO-
EVB
Silicon
Labs
4 MH1, MH2,
MH3, MH4
Screw/Standoff HDW NSS-4-4-01/2397 Various
1 PCB1 Si827x_EVB
REV 2.0
Bare
PCB
N/A Si827x_EVB REV 2.0 Silicon
Labs
4 R1, R2, R5,
R6
4.7 1/10W ±5% Thick
Film
R0805 CR0805-10W-4R7J Venkel
1 R3 6.04 k 1/10W ±1% Thick
Film
R0805 CR0805-10W-6041F Venkel
31 TP1, TP2,
TP3, TP4,
TP5, TP6,
TP7, TP8,
TP9, TP11,
TP12, TP13,
TP14, TP15,
TP16, TP17,
TP18, TP19,
TP20, TP21,
TP22, TP23,
TP24, TP25,
TP26, TP27,
TP28, TP29,
TP30, TP31,
TP32
White Loop Testpoint 151-201-RC Kobiconn
UG186: Si827x-EVB User's Guide
Bill of Materials
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 13

Qty Ref Value Rating Voltage Tol Type PCB Footprint Mfr Part Number Mfr
1 U1 Si8273AB-IS1 SO16N6.0P1.27 Si8273AB-IS1 Silicon
Labs
1 U2 Si8271AB-IS SO8N6.0P1.27 Si8271AB-IS Silicon
Labs
Not-Installed Components
4 C5, C6, C13,
C14
200 pF 50 V ±10% C0G C0805 C0805C0G500-201K Venkel
1 TP10 White Loop Testpoint 151-201-RC Kobiconn
UG186: Si827x-EVB User's Guide
Bill of Materials
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 14

7. Ordering Guide
Table 7.1. Si827x ISOdriver EVB Ordering Guide
Ordering Part Number (OPN) Description
Si8273ISO-KIT Si8273 ISOdriver evaluation board kit
Si8274ISO-KIT Si8274 ISOdriver evaluation board kit
Si8275ISO-KIT Si8275 ISOdriver evaluation board kit
UG186: Si827x-EVB User's Guide
Ordering Guide
silabs.com | Smart. Connected. Energy-friendly. Rev. 0.1 | 15

http://www.silabs.com
Silicon Laboratories Inc.
400 West Cesar Chavez
Austin, TX 78701
USA
Smart.
Connected.
Energy-Friendly.
Products
www.silabs.com/products Quality www.silabs.com/quality Support and Community community.silabs.com
Disclaimer
Silicon Laboratories intends to provide customers with the latest, accurate, and in-depth documentation of all peripherals and modules available for system and software implementers using
or intending to use the Silicon Laboratories products. Characterization data, available modules and peripherals, memory sizes and memory addresses refer to each specific device, and
"Typical" parameters provided can and do vary in different applications. Application examples described herein are for illustrative purposes only. Silicon Laboratories reserves the right to
make changes without further notice and limitation to product information, specifications, and descriptions herein, and does not give warranties as to the accuracy or completeness of the
included information. Silicon Laboratories shall have no liability for the consequences of use of the information supplied herein. This document does not imply or express copyright licenses
granted hereunder to design or fabricate any integrated circuits. The products are not designed or authorized to be used within any Life Support System without the specific written consent
of Silicon Laboratories.A"Life Support System" is any product or system intended to support or sustain life and/or health, which, if it fails, can be reasonably expected to result in significant
personal injury or death. Silicon Laboratories products are not designed or authorized for military applications. Silicon Laboratories products shall under no circumstances be used in
weapons of mass destruction including (but not limited to) nuclear, biological or chemical weapons, or missiles capable of delivering such weapons.
Trademark Information
Silicon Laboratories Inc.® , Silicon Laboratories®, Silicon Labs®, SiLabs® and the Silicon Labs logo®, Bluegiga®, Bluegiga Logo®, Clockbuilder®, CMEMS®, DSPLL®, EFM®, EFM32®,
EFR, Ember®, Energy Micro, Energy Micro logo and combinations thereof, "the world’s most energy friendly microcontrollers", Ember®, EZLink®, EZRadio®, EZRadioPRO®, Gecko®,
ISOmodem®, Precision32®, ProSLIC®, Simplicity Studio®, SiPHY®, Telegesis, the Telegesis Logo®, USBXpress® and others are trademarks or registered trademarks of Silicon Laborato-
ries Inc. ARM, CORTEX, Cortex-M3 and THUMB are trademarks or registered trademarks of ARM Holdings. Keil is a registered trademark of ARM Limited. All other products or brand
names mentioned herein are trademarks of their respective holders.

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Silicon Laboratories:
SI8275ISO-KIT Si8273ISO-KIT SI8274ISO-KIT SI8273ISO-KIT
