Silk'n Lipo H5001 User manual

Lipo
H5001
www.silkn.eu
•[e-mail]
InnoEssentials International
Donk 1b, 2991 LE Barendrecht
The Netherlands
USER MANUAL
MODE D’EMPLOI
MANUAL DEL USUARIO
MANUAL DO UTILIZADOR
ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΤΗ
BRUKERHÅNDBOK
ANVÄNDARMANUAL
BRUGERMANUAL
BEDIENUNGSANLEITUNG
KULLANIM KILAVUZU
MANUALE PER L’UTENTE
NL
ES
PT
GR
NO
FI
SV
DA
RU
DE
EN
EN
EN
DE
FR
NL
ES
PT
GR
TR
NO
IT
SV
DA
GEBRUIKSAANWIJZING
Lipo UM EU124 3545B cover ED296-03 release.indd 1 14/08/2018 11:08:24

100-240 Vac
50-60 Hz
#1
#3
#4
#5
#6
#7
#8
#9
#2
Lipo UM EU124 3545B cover ED296-03 release.indd 2 14/08/2018 11:08:24

1
EN
Table of contents
1. Warnings & contraindications............................................2
2. Safety with Silk'n Lipo ........................................................8
3. Get to know Silk'n Lipo.......................................................8
4. Device controls & settings................................................10
5. Treatment plan..................................................................14
6. What to expect with Silk'n Lipo .......................................15
7. Get started!........................................................................16
8. Cleaning & maintenance ..................................................17
9. Parts & consumables ........................................................19
10. Troubleshooting ...............................................................19
11. Customer service...............................................................20
12. Warranty............................................................................20
13. Disposal .............................................................................20
14. Specications ....................................................................21
15. Signs & symbols ................................................................22
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 1 14/08/2018 10:57:31

2
EN
1. Warnings & contraindications
The user manual is based on the standards
and rules in force in the European Union.
When abroad, you must also observe
country-specic guidelines and laws.
Silk'n Lipo is a powerful electrical device
and should be used with special attention
to safety. Please read all warnings and
contraindicationsbeforeuse.Werecommend
you familiarise yourself with the instructions
in this manual before each treatment.
UDo not use the device while bathing or
taking a shower.
UAlways ensure that your hands are dry
before connecting the stand/charging
cradle to the electricity supply.
UKeep the adapter away from water. The
adapter is not waterproof.
UDo not place or store the treatment
units, stand/charging cradle and adapter
where it can fall or be pulled into a tub,
sink, water or any other liquid.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 2 14/08/2018 10:57:31

3
EN
UDo not reach for the stand/charging
cradle or adapter if they have fallen
into water. Unplug immediately before
retrieving either of them. Failure to
unplug the stand/charging cradle may
result in an electric shock!
UNever use the adapter if it has a damaged
cable or plug, isn’t working properly,
or has been submerged in water. If
that happens, unplug the adapter
immediately.
UIfthe stand/chargingcradlemalfunctions,
unplug immediately.
UDry each treatment unit before charging
or storage.
UDry each electrode pad before storage.
UOnly authorized personnel are permitted
to perform repairs. Do not attempt to
modify, open or repair the device. You
may expose yourself to dangerous
electrical components and may cause
serious harm to yourself.
UChanges or modications to this device
not expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 3 14/08/2018 10:57:31

4
EN
UDo not use if the parts or accessories
are not supplied by the manufacturer as
dened in this manual, or if the device
is damaged or does not appear to be
working properly. In such cases contact
Customer Service.
UDo not clean any of the parts in the
dishwasher.
UChildren must not play with the (plastic)
packaging. They may injure themselves
with the packaging material, or swallow
small parts and choke.
UDo not dispose with household waste!
The WEEE directive requires that you
dispose of this electrical device (including
all accessories and parts) at a designated
recycling collection point for electrical
devices. For details see section "13. Disposal".
UThe battery must be removed from the
appliance before it is scrapped.
UThe appliance must be disconnected from
the supply mains when removing the
battery.
UThe battery is to be disposed of safely.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 4 14/08/2018 10:57:31

5
EN
UAttention should be drawn to the
environmental aspects of battery disposal.
Don’t throw used batteries in a dustbin.
Please contact your retailer in order to
protect the environment.
Battery Removal
To remove the battery, the device must be
broken apart. The device will no longer function
after this procedure, nor can it be repaired.
Any warranty will be void when the device
casing is broken and the battery is removed.
We recommend you wear safety protective
goggles and gloves.
Home Skinovations Ltd is not liable for any
physical or material damages as a result of
performing this procedure.
To remove the battery place each treatment
unit on a hard, strong surface. Use a hammer to
break the outer plastic casing.
Use pliers or a screwdriver to remove the casing.
Unscrew the PCB (printed circuit board) and
remove the battery by disconnecting the plug
from the PCB.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 5 14/08/2018 10:57:31

6
EN
Contraindications
USilk'n Lipo must not be used by children,
adults with limited physical, sensory or
psychological capacities, or those lacking
experience or knowledge in how to use
the device. Keep the device out of the
reach of children.
UUse a lower EMS energy level if you
experience any discomfort.
UStop use immediately if your skin is very
red, or if it blisters or burns.
UUse on clean, dry, healthy skin.
Do not use if you:
Uhave heart disease and you have not
consulted your physician.
Uare on immuno-suppressant drugs such
as corticosteroids without consulting
your physician, or if you have an immuno
deciency disorder.
Uhave any type of active cancer.
Uhave a lymphatic disorder, thyroid
disorder, diabetes or liver disorder, or any
other metabolic condition.
Uhave a pacemaker, internal debrillator,
or any other active electrical implant
anywhere in the body.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 6 14/08/2018 10:57:31

7
EN
Uhave applied topical solutions containing
metal ions on the treatment area.
Uhave epilepsy.
Uhave serious arterial circulatory problems
in the lower limbs.
Uhave an abdominal or inguinal hernia.
Uare pregnant or nursing.
Do not use on these parts of the body:
UNear the heart. The electrodes must
not be placed on any part of the front
ribcage (where the ribs and breastbone
are located), and specically not on the
two large pectorals. This can increase the
risk of ventricular brillation and induce
cardiac arrest.
UThe back ribcage.
UThe head or neck.
UOn the genitals.
UOn or around the eyes.
UAreas with tattoos.
UAreas that have metabolic arthritis or
chronic pain.
UAreas that are swollen, infected, or
inamed; or that have broken or irritated
skin, or where there are skin eruptions
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 7 14/08/2018 10:57:31

8
EN
(e.g. skin rashes, phlebitis, throm-
bophlebitis, varicose veins, or post-
operative scars where the healing
process could be aected etc.).
UParts of the body that have metal staples,
implants or pins; or if you are near metal.
Remove jewellery or other accessories
from the treatment area during a
treatment session.
UAreas that have a history of cancer or
potential skin malignancies.
2. Safety with Silk'n Lipo
With Silk’n safety comes rst. Silk'n Lipo has these safety features:
UProximity sensor: The device works only when it is on, and the
treatment unit is in good contact with your skin.
UAutoshut-down:Although you can stop a treatment whenever you wish,
the device shuts down after a minute or so, when there is no contact with
the skin (the operating light will be constant green). It also shuts down
automatically after 15 minutes of continuous use.
3. Get to know Silk'n Lipo
Silk'n Lipo is a system to help you reduce fat in specic areas, exercise your
muscles and tone specic parts of your body without physical eort, and in the
comfort of your home.
By placing the treatmentunit1on target areas such as the upper arms, abdomen,
buttocks or thighs, fat can be broken down and removed specically from that
area. It can also help you shape individual areas that do not respond to diet or
exercise. Silk'n Lipo is not intended for overall fat reduction or weight loss, and
cannot replace diet or exercise.
1The singular is used to denote both single and multiple items for the product parts
treatment unit, belt and electrode pad.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 8 14/08/2018 10:57:31

9
EN
3.1 Package contents
y1 or more Treatment units * yStand/charging cradle
y2 Connectors yAdapter
y1 or more Body belts * yUser manual
y1 or more Electrode pads * yWarranty card
* Varies according to the option purchased.
3.2 Device description
Silk'n Lipo is a device for home use that utilizes Low Level Laser Technology (LLLT)
and Electrical Muscle Stimulation (EMS). Together these energies help increase
muscle tone and reduce fatty acids and deposits to enhance body toning and
reshaping.
Silk'n Lipo includes a selection of belts suited to the part of the body you
wish to treat. Each treatment unit contains laser diodes and electrodes
that activate the EMS. Each treatment unit is attached to the belt and
then placed on the part of the body you wish to tone and reshape.
Silk'n Lipo uses integrated rechargeable batteries so that each treatment unit
can be charged easily before each use.
Refer to the diagram at the front of the manual to see the location of each feature.
1. Treatment unit 6. Electrode pad
2. Control button 7. Charging indicator lights
3. Indicator lights 8. Stand / charging cradle
4. Connectors 9. Adapter
5. Body belt
3.3 Intended use
Silk'n Lipo is a non-invasive aesthetic device to reduce the circumference of the
waist, arms, thighs and buttocks. The device is also intended to improve muscle
tone and rmness, and strengthen muscles in these areas.
The device is not intended for use in any therapy, or for the treatment of any
medical conditions or diseases. Do not use for any purpose other than as
described in this manual.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 9 14/08/2018 10:57:31

10
EN
4. Device controls & settings
4.1 Connecting the dierent parts
1. Remove the dierent parts from the box.
2. Place the treatment unit on a at surface. If you have more than one
treatment unit, connect them together.
3. Take the female connector and slot it into the left side of the treatment
unit. Then take the male connector and connect it to the right side (see
illustration).
4. Select the belt for the part of the body you are treating, and lay it on a at
surface with the side with the Silk’n logo facing you.
5. Next,fold each sideofthe beltinwards sothat you see the black Velcro pads.
Female Male
Velcro
pad
Velcro
pad
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 10 14/08/2018 10:57:32

11
EN
6. Slide each end of the belt into the connectors and then fold backwards,
so that the Velcro pad sticks to the belt. Your belt will now look like this.
7. Of course, to use Silk'n Lipo you will need to disconnect one side, place the
belt on your body and then reconnect the side you disconnected!
aNote that you can only use the device when:
ythe treatment unit is charged.
yyou have placed a wet electrode pad on each treatment unit (see
section "4.4 Wetting the electrode pads").
yeach treatment unit is in good contact with your skin.
yyou have read this manual, and understand how to use the device.
4.2 Controls and settings
Each treatment unit has a control panel that includes:
Ua control button (#2)
U2 EMS energy level buttons (left and right of the control button)
U2 indicator lights - left and middle (#3)
Battery / Error Operating Not in use
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 11 14/08/2018 10:57:32

12
EN
Control Action Function
Control button Long press yTurns the treatment unit on (or
o). When you turn it on, you will feel
a short vibration. When you turn it
o, you will feel 2 short vibrations.
yThe green operating light (middle)
will be constant green.
+ Button Short press yEach press increases the EMS
level. As you increase levels, the
operating light blinks faster.
Long press yThe same eect as a short press.
-Button Short press yEach press decreases the EMS
level. As you decrease levels, the
operating light blinks more slowly.
Long press ySets the EMS level back to zero.
Battery / Error light
(left) Orange light blinks continuously yBattery low.
Constant orange yDevice error.
Operating light
(middle)
Green light blinks
continuously yThe device is on, and has good
contact with the skin.
yBlinks faster as the EMS level
increases.
Constant green yThere is no contact with the skin but
the device is ready to use.
yThe device will then shut down
automatically after a minute or so if
there is no contact with the skin.
Indicator light
(right) --- yNot in use.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 12 14/08/2018 10:57:32

13
EN
4.3 Energy levels
Silk'n Lipo has multiple levels of Electrical Muscle Stimulation (EMS). This gives you
excellent control of the intensity of muscle stimulation you wish to use for each
part of the body you treat. What's more, you can change levels as often as you like
during a treatment.
UTo increase the EMS level: Short press the + button as many times as
you need to set to the EMS level that is comfortable for you. You will see
that the operating light blinks more quickly as you increase the EMS level.
UTo reduce the EMS level: Short press the - button as many times as you
need (see section "4.2 Controls and settings").
UTo set the EMS level back to zero: Long press the - button.
aYou can only change EMS levels when the treatment unit is in good
contact with your skin. When there is no contact with the skin, the EMS
drops to zero.
4.4 Wetting the electrode pads
The electrode pads are required for the EMS to work, and they must be wet
before you start your treatment.
1. Wet each electrode pad with a wet cloth or with wet ngers.
2. Then place the wet electrode pad onto the back of each treatment
unit. Make sure that it ts rmly around the center rectangle. You might
need to manipulate it slightly, so that the electrode pad lies at on top of
the treatment unit.
aIt is important that you only wet the electrode pad, and not the whole
treatment unit.
Electrode pad Underside of the
treatment unit
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 13 14/08/2018 10:57:32

14
EN
4.5 Device charging
Charge each treatment unit before rst use. The initial charge should take
around 6 hours. Subsequent charges should take around 3 hours. We recommend
you recharge the device before each treatment.
1. Remove the electrode pads before placing the treatment units in the
stand/charging cradle.
2. Connect the empty stand/charging cradle to the electricity supply. The
2 charging indicator lights will be constant green.
3. Place each treatment unit in the cradle so that it sits in the designated
grooves.
yWhen the treatment unit is charging, the orange battery/error
indicator light on the treatment unit will ash on and o.
yWhen fully charged the battery/error indicator light (left) will go
o, and the green operating light (middle) will be constant green.
4. Once charged, disconnect the stand/chargingcradle from the electricity
supply.
5. Treatment plan
CFor use on clean, healthy skin (see section "1. Warnings & contraindications").
UTreat the target area for 15 minutes per treatment session (see illustration).
UFor larger parts of the body, like the stomach or buttocks, you may wish to
move the treatment unit to an adjacent part of the target area, and use
for another 15 minutes. You may keep doing this until you have covered
the target area.
UTry to avoid gaps and overlaps.
UNever use Silk'n Lipo on exactly the same spot during a treatment session.
UFor daily use, but no more than 3 times a week on each specic target area.
Continue until you get the results you want.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 14 14/08/2018 10:57:32

15
EN
6. What to expect with Silk'n Lipo
If you follow the instructions fully and pay attention to all warnings and
contraindications, complications and side eects are uncommon. However,
every energy-based device, including those designed for home use, involves
some degree of risk. Therefore it is important that you understand and accept the
risks and complications that may occur.
Skin redness
You may nd some skin redness in the treated area which should disappear after the
treatment.
Muscle pain
As with all exercise, some muscle soreness may occur after a treatment but it should
go away after a day or two. If this happens, use a low EMS level for a few treatment
sessions until the soreness has gone.
Skin irritation
Although very rare, it is possible to have a prolonged reddening of the skin, or the
appearance of acne. Stop use immediately, and only treat that specic area when the
skin irritation has gone.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 15 14/08/2018 10:57:32

16
EN
Headache
Equally rare, is the possibility that you might feel light-headed when you start using
the device. If this happens, sit down during the treatment, or stop using the device
until you feel OK.
Allergic reaction
If you have an allergic reaction to the device or its accessories, stop using the device.
aStop use immediately if any of these eects are more severe.
aSee your doctor if the eects do not go away within 2 to 3 days.
7. Get started!
Treating with Silk'n Lipo is easy. Just follow these steps for each part of the body
you wish to treat.
1. Use on clean, healthy skin (see section "1. Warnings & contraindications").
2. Check that the batteries are well charged before use. If the battery/error
light is orange and blinks slowly, this indicates that the battery is low.
3. Before each treatment, wet the electrode pad with a wet cloth or with
wet ngers, and place them on each treatment unit (see section "4.4
Wetting the electrode pads"). Next, connect one or more treatmentunits
to the belt (see section "4.1 Connecting the dierent parts").
4. Disconnect one of the connectors on one side, and then place the
belt around the area you wish to treat. Then reconnect the side you just
disconnected.
5. Adjust the tightness of the belt so that the treatment unit is in good
contact with your skin, and that the belt is rm and well secured to
your body.
aIf the belt is not tight against your skin, the EMS energy may disconnect. If
that happens, tighten the belt and press the + button to reselect the EMS
energy level required.
6. Switch on.With the controls in view, press the control button on each
treatment unit.The green and orange indicator lights will go on. The
orange indicator light will go o after a second or so and the treatment
unit will vibrate once. When the treatment unit is in good contact with
the skin, the green operating light will blink slowly, and the laser energy
will start to work.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 16 14/08/2018 10:57:32

17
EN
7. Changing the EMS level:
yTo increase: Short press the + button as many times as you need to
set to the EMS level that is comfortable for you.The operating light
blinks more quickly as you increase the EMS level.
aIf you long press the + button, the EMS level will still only increase
by one increment.
yTo reduce: Short press the - button as many times as you need (see
section "4.2 Controls and settings").
aLong pressing the - button, sets the EMS level back to zero.
8. Treat each area for 15 minutes. Keep the treatment unit in place,
and the device on for up to 15 minutes. Every few minutes you will feel a
vibration. The vibrations are a normal part of the treatment routine. At the
end of 15 minutes, you will feel 3 vibrations, no more energy will be emitted
and the device will shut down automatically.
aTo switch o the device before 15 minutes, long press the control
button. You will feel 2 vibrations, then the device will shut down.
9. If you want to treat another area (next to the area you have just treated
or another part of your body), wet the electrode pad, and move the
treatment unit to the next location.
aTry to avoid gaps and overlaps.
aIf you move the device to another part of your body and the
treatment unit is not in good contact with the skin, the EMS level
will revert to zero. If this happens, make sure the treatment unit is
in good contact with the skin, then short press the control button
to start the device again, and then the + button to increase the EMS
level.
8. Cleaning & maintenance
8.1 Cleaning the treatment units & charging cradle
We recommend that you clean the treatment unit after each use, and the
stand/charging cradle once a month.
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 17 14/08/2018 10:57:32

18
EN
Before cleaning:
UDisconnect the treatment unit from all other parts (belt, electrode
pads, connectors, stand/charging cradle). Disconnect the stand/
charging cradle from the electricity supply.
UDo not use abrasive cleaners or chemicals to clean any parts.
UClean each treatment unit and stand/charging cradle with a damp
cloth using a mild detergent, then wipe it dry with a clean cloth.
CDo not clean any of the parts in the dishwasher.
8.2 Cleaning the electrode pads
UAfter each use, wipe each electrode pad and dry with a cloth.
UDo not store them in a closed box or drawer until they are completely dry.
8.3 Replacing the electrode pads
UDo not use electrode pads if they are damaged. If that happens, replace
with new ones.
8.4 Cleaning the belt
The belt materials are: External: Nylon / Middle layer: SBR / Internal: Nylon.
Please note the cleaning instructions.
Hand wash only Do not dry clean
Do not bleach Do not tumble dry
Do not iron
Lipo UM EU124 3545B inside ALL EU124 ED296-24 release.indd 18 14/08/2018 10:57:33
