PRODUCT INFORMATION
EXPEDITION SERIES
Compasses for experienced users and professionals. The Expedition series has been a global leader
when it comes to accuracy, precision and durability for many years. Now we take the next step in
advanced outdoor navigation with two unique models, Expedition S mirror sighting compass and the
Expedition baseplate compass.
Expedition and Expedition S
KEY FEATURES AND SELLING POINTS
ONE MINUTE DEMO
  Easy
handling
 
– compatible with basically any map
 – permanent
adjustment for local magnetic declination
 – for vertical angle/slope measurement
 – enables night navigation
 – increases precision in map work
 
 – giving accurate
bearings
1. Show the map measuring scales on the base plate and explain how to use the GPS scales to find GPS coordinates on map
2. Demonstrate the SILVA 1-2-3 SYSTEM – explain the advantage with the red/black north/south lines inside the compass housing
3. Point out the importance of the silicon friction feet
4. Show the luminous markings for night navigation (if possible in a dark room)
5. Show the magnifier
6. Show the declination adjustment feature and the adjustment tool inside the detachable lanyard (Expedition S).
7. Show the mirror sighting functionality and the 45º angle assistance

www.silva.se
www.silva.se
www.silva.se
www.silva.sewww.silva.sewww.silva.se
www.silva.se
PRODUCT INFORMATION
EXPEDITION EXPEDITION S

Hiking, Trekking, Mountaineering, GPS users, Military Hiking, Trekking, Mountaineering, GPS users, Military

Type of compass Base plate Mirror Sighting
Mirror sighting No Yes
Magnifying lens Yes Yes
Declination adjustment Declination adjustment Declination adjustment
Clinometer Yes Yes
Night use Yes Yes
Rubber friction feet Yes Ye s
Silva 1-2-3 Yes Yes
Other Perpendicular line, GPS scales Perpendicular line, Mirror angle assistance, GPS scales

Graduation 360 360
Resolution 2 2
Measuring scales 1:25k, 1:40k 1:50k, mm/in 1:25k, 1:50k, mm/in
Accuracy 1 degree 1 degree
IP class IPX8 IPX8
Durability/drop test Whitstand 1m drop into wodden floor Whitstand 1m drop into wodden floor
Temp range -20°C - +60°C -20°C - +60°C
Dimensions 108x64x21 85x54x11
Material Acrylic/PC/ABS/TPU Acrylic/PC/ABS/TPU/Acetal
Net Weight 50g 86g
Instruction manual languages SE, GB, F, DE, DK, FIN, JP, CN, RU, NO, NL, IT, PT, ES SE, GB, F, DE, DK, FIN, JP, CN, RU, NO, NL, IT, PT, ES

Detachable lanyard Detachable lanyard
DEALER INFORMATION
Art. No. 35691-0001 36827-1001
Gross weight (g) 90 135
Qty inner/master pack 10/120 10/120
Weight inner/master pack (kg) 1.026/12.742 1.474/18.128
Dimensions inner/master pack (cm) 18x14x23 / 60x33x50 20x15x26 / 63x34x56
Pgk type: (clam or box) Clam Clam
Country of origin CN CN
Warranty 5 years 5 years
Tariff code 9014100090 9014100090
EAN (barcode and number)
7318860185694 7318860185717
