Silvercrest STMS 2017 A1 Instruction sheet

STMS 2017 A1
Wireless Keyboard
includes wireless mouse and USB nano receiver
Wireless Keyboard
includes wireless mouse
and USB nano receiver
User manual and service
information
GB
Designer radiostyret tastatur
med radiostyret mus
USB-nano-modtager
Brugervejledning og
serviceinformation
DK
SE
Trådlöst designtangentbord
med trådlös mus och
USB-Nano-mottagare
Bruksanvisning och
serviceinformation

Wireless keyboard with wireless mouse STMS 2017 A1 English
1
Wireless design keyboard with wireless mouse
and USB nano receiver
STMS 2017 A1
Package Contents
A Wireless keyboard STMS 2017 A1
B Wireless Mouse STMS 2017 A1
C USB nano receiver STMS2017A1-R
(inserted into the wireless mouse by default)
D 2 AAA-type batteries, 1.5V (Micro) for wireless keyboard
(not illustrated)
E 2 AAA-type batteries, 1.5V (Micro) for wireless mouse
(not illustrated)
F CD-ROM with software (not shown)
G User's manual (not shown)

English Wireless keyboard with wireless mouse STMS 2017 A1
2
System Requirements
-Intel®Pentium®III / AMD AthlonTM or higher
-1 free USB-2.0 port
-Microsoft®Windows®XP, Windows Vista®or Windows®7
-CD-ROM drive or DVD drive for installing the software
Overview
1 Special buttons (hotkeys)
2 Scroll wheel
3 Volume control
4 Battery level indicator*
* After inserting the batteries into the keyboard, the indicator will flash several
times during automatic synchronisation with the USB receiver. When the
synchronisation is completed, the status indicator will stop lighting.

Wireless keyboard with wireless mouse STMS 2017 A1 English
3
5 Left mouse button
6 Right mouse button
7 Zoom - (default mode)
Play / Pause (media mode)
8 Zoom + (default mode)
Launch Media Player (media mode)
9 Tilt wheel (4-way scroll wheel)
Volume control and mute (media mode)
10 Battery level indicator
11 Back (default)
Previous title (media mode)
12 Forward (default)
Next title (media mode)
13 800/1600 cpi toggle switch (press briefly)
Standard / media mode toggle switch
(keep pressed for 3 seconds)
14 Battery compartment lock (on the back)

English Wireless keyboard with wireless mouse STMS 2017 A1
4
Contents
Package Contents 1
System Requirements 2
Overview 2
Contents 4
Important Safety Information 5
Children and Persons with Disabilities................................................................5
Batteries..............................................................................................................6
R/F Interface........................................................................................................6
Operating Environment.......................................................................................6
Intended Use.......................................................................................................7
Care and Repair..................................................................................................8
Copyright.............................................................................................................8
Storing When Not Using the Product..................................................................8
CE Declaration of Conformity Notice .................................................................. 9
Appliance Disposal..............................................................................................9
Introduction 9
Hardware Installation 10
Inserting the Batteries.......................................................................................10
Connecting the USB Nano Receiver.................................................................12
The Wristpad.....................................................................................................13
Software Installation 14
Task Bar Symbols.............................................................................................16
Configuration 16
Toggling between Operating Modes.................................................................16
Configuring the Wireless Mouse.......................................................................17
Configuring the Wireless Keyboard...................................................................18
Attachment 20
Troubleshooting.................................................................................................20
Technical Data ..................................................................................................21
Warranty Information 22

Wireless keyboard with wireless mouse STMS 2017 A1 English
5
Important Safety Information
Before first using the device read the following instructions carefully and take note
of the safety warnings, even if you are familiar with using electronic devices. Keep
this manual in a safe place for future reference. If you sell or pass on the
appliance, you should absolutely ensure to hand over these instructions as well.
This icon denotes important information for the safe operation of
the product and for the user’s safety.
This icon alerts about a strong light source.
This symbol denotes further information on the topic.
Avoid harm to the eyes. Never look directly into the LED beam.
Children and Persons with Disabilities
Electrical appliances do not belong in the hands of children. Also people with
disabilities shall use electrical devices accordingly. Do not allow children or
persons with disabilities to use electrical devices when not under supervision.
These people may not comprehend the presence of potential risks. Batteries and
small parts represent potential choking hazards. Keep the batteries out of reach.
If a battery is swallowed, seek medical help immediately. Keep the packaging
away from children and persons with disabilities too, as there is danger of
suffocation.

English Wireless keyboard with wireless mouse STMS 2017 A1
6
Batteries
Please always insert the batteries with the poles pointing in the proper direction.
Never attempt to recharge the batteries and under no circumstances try to
incinerate them. Do not use different batteries (e.g. old and new, alkaline and
carbon, etc.) simultaneously. Remove batteries if appliance is not being used for
any longer periods of time. Inappropriate battery use may result in explosion and
leakage risks.
R/F Interface
Please switch off the appliance in airplanes, hospitals, operating theatres and in
the vicinity of medical electronic system. The radio waves transmitted could
impair the functionality of sensitive appliances. Observe a minimum distance of
20 cm between the appliance and any pacemaker as the radio waves could
impair the function of the pacemaker. The transmitted radio waves may create
interference noises in hearing aids. Do not allow the appliance to be introduced in
the vicinity of inflammable gases or in environments subject to a risk of explosion
(e.g. paint shops) as long as the radio component is switched on, because the
transmitted radio waves could trigger an explosion or fire. The coverage/range of
the radio waves varies depending on the surrounding and environmental
conditions. In any data exchange via wireless connections, unauthorized third
parties are also able to receive the data. Targa GmbH is not liable for any radio or
television interference caused by unauthorized modifications of this appliance.
Targa furthermore accepts no liability for the replacement or exchange of
connection cables and appliances not specified by Targa GmbH. The user is
solely responsible for the elimination of interferences caused by such an
unauthorized modification, as well as for the replacement or exchange of the
appliances concerned.
Operating Environment
Position the device on a firm, even surface and do not place any objects on top of
it. The appliance is not designed for operation in spaces subject to high humidity
or temperatures (e.g. bathrooms) or in excessively dusty locations. Operating
temperature and air humidity: 5°C to 40°C, max. relative air humidity 90%.

Wireless keyboard with wireless mouse STMS 2017 A1 English
7
Please ensure that:
-the appliance is not exposed to direct sources of heat (e.g. heating
elements);
-the appliance is not exposed to direct sunlight or artificial light;
-any contact with splashes and/or drips of water and other liquids is avoided
and the device is not operated near water; in particular, the appliance may
never be submerged (do not place water-filled objects such as vases or open
drinks containers on top of or near the appliance);
-the appliance is not placed in the direct vicinity of magnetic fields (e.g.
loudspeakers);
-no sources of open flame (e. g. lighted candles) are placed on top of or near
the appliance;
-the appliance is not penetrated by foreign objects;
-the appliance is not exposed to strong temperature fluctuations;
-the appliance is not subjected to excessive shaking or vibration.
Intended Use
This Keyboard and Mouse Set, consisting of a wireless keyboard, wireless mouse
and USB nano receiver, is an IT device. The device may not be used outdoors or
in tropical climates. This product has not been designed for corporate or
commercial applications. Use the product in domestic environments for private
applications only. Any use other than that mentioned above does not correspond
to the intended use. Only external devices may be used that comply with safety
standards and the electromagnetic compatibility and shielding quality of this
device. This device fulfils all that relates to CE Conformity, relevant norms and
standards. Any modifications to the equipment other than recommended changes
by the manufacturer may result in these directives no longer being met. The
manufacturer is not liable for any damage or interference caused by unauthorized
modifications. Only use the accessories recommended by the manufacturer.
If you are not using the appliance within the Federal Republic of Germany you are
bound by the state regulations and/or legislation applicable in the country of
operation.

English Wireless keyboard with wireless mouse STMS 2017 A1
8
Care and Repair
Repair activities are required if the appliance has been damaged, liquids or
objects have penetrated the casing, the appliance has been exposed to rain or
moisture, the appliance is not working properly or if it has been dropped. If you
notice any smoke developing, unusual noises or scents, please switch off the
appliance immediately. In such cases the appliance may not be operated until a
professional specialist has checked it. Any repairs are only to be performed by
qualified professional technicians. Never open the casing of the appliance or of
any accessories. Only clean the appliance with a clean and dry cloth, never using
any aggressive liquids.
Copyright
The entire content of this User’s Manual is copyrighted and is provided to the
reader for information purposes only.
Copying data and information without the prior written and explicit authorization
from the author is strictly forbidden. This also applies to any commercial use of
the contents and information.
All texts and figures are up-to-date as per the date of print release. We assume
no liability for any changes.
Storing When Not Using the Product
When left unused for a long period of time, remove the batteries from the wireless
keyboard and from the wireless mouse. Remove the USB nano receiver from
your computer’s USB port and insert it into the storage compartment of the
mouse. Also make sure that the storage temperature is maintained between 5 °C
and 40 °C. The humidity must not exceed 90% relative humidity.

Wireless keyboard with wireless mouse STMS 2017 A1 English
9
CE Declaration of Conformity Notice
The mouse and keyboard set complies with the basic and other
relevant requirements of the R&TTE Directive 99/5/EC. The
corresponding Declaration of Conformity can be found at the end of
this User's Manual.
Appliance Disposal
All appliances labelled with this symbol are subject to the European
directive 2002/96/EC. All electrical and electronic appliances need to
be disposed off separately via the facilities provided for this purpose by
the authorities and may not be included in the domestic waste. The
USB nano receiver is also an electronics device and must be properly
disposed of.
The proper disposal of old appliances helps to protect the environment and
prevents risks for your personal health. For further information about proper
disposal, contact your local government, disposal bodies or the shop where you
bought the device.
Also recycle the packaging material properly. Cardboard packaging can be taken
to paper recycling containers or public collection points for recycling. Any films or
plastic contained in the packaging should be taken to your public collection points.
Please take care to protect the environment. Used batteries do not belong in the
domestic waste and need to be handed in at a collection point for used batteries
instead.
Introduction
Thank you for purchasing the wireless design keyboard with wireless mouse and
USB nano receiver STMS 2017 A1. The devices feature a SmartLink technology
that makes any manual synchronisation obsolete. Several special keys and
buttons on both appliances help you adapt the operation of the mouse and
keyboard to your personal wishes. The mouse features a tilt wheel (4-way scroll
wheel) enabling you to scroll horizontally as well as vertically.

English Wireless keyboard with wireless mouse STMS 2017 A1
10
Hardware Installation
Unpack all the devices and use the package contents checklist on page 1 to verify
that you have received all items listed.
Inserting the Batteries
Insert the batteries into the wireless keyboard and wireless mouse as shown in
the following figures. Take care to insert the batteries into the device observing
the correct polarity (+ and – ) The correct polarity is labelled on the batteries and
inside the battery compartment.
Fig.: Detailed view of bottom of the keyboard
Open the battery compartment of the wireless mouse and insert the
batteries. Then close the battery compartment.
Remove the bottom part of the wireless mouse. To do this, press the
unlock button (14) on the back of the wireless mouse. The lock will
release and you can open and remove the bottom part.
Insert the batteries.
Remove the USB nano receiver (C) from its storage compartment (17).
Close the wireless mouse. To do this, insert the noses on the bottom part
into the hole located on the front of the wireless mouse. Then close the
bottom part on the wireless mouse until the unlock button (14) clicks into
place.

Wireless keyboard with wireless mouse STMS 2017 A1 English
11
Press the On/Off switch (15) to position "ON" to power the wireless
mouse on.
15 On/off button of the wireless mouse
16 Optical sensor
17 USB nano receiver storage compartment
The wireless mouse features an automatic standby function.
When not using the wireless mouse for a certain time, it will
power off. Move the wireless mouse or press any mouse button
to power it back on (the drivers must be installed).
The devices feature a battery level indicator (4 and 10). As
soon as they light-up, the batteries of the respective device are
exhausted. When this happens, replace the batteries with new
batteries of the same type.
Fig.: Detailed view of the
opened mouse

English Wireless keyboard with wireless mouse STMS 2017 A1
12
Connecting the USB Nano Receiver
If you still have your old keyboard and mouse connected to the computer, please
shut down your computer, disconnect the corresponding devices from the PC and
restart the computer.
Remove the USB nano receiver from its storage
compartment (see the chapter “Inserting the
Batteries”).
Plug the USB nano receiver into a free USB port on
your powered-on computer.
Fig.: Miniature USB Receiver
The operating system will automatically recognize the new hardware and install
the required drivers. Depending on the operating system installed, the following
screen messages may appear:
Windows®XP
When the receiver is connected for the first time, the operating system
Windows®2000/XP displays the message „New hardware detected“. Wait until
the message „The new hardware has been installed and is now ready for use“ is
displayed before using your mouse and keyboard.
Windows Vista®, Windows®7
When the receiver is connected for the first time, the operating system Windows
Vista®displays the message „Installation of appliance driver software“. Wait until
the message „The appliances are ready for use now“ appears. The mouse and
keyboard are now operational and ready to be used.
If the connection to the nano receiver is interrupted or if it is not
possible to establish a connection, remove the batteries from
the mouse and keyboard and re-insert them.

Wireless keyboard with wireless mouse STMS 2017 A1 English
13
The Wristpad
If necessary, you can attach the supplied wristpad to the bottom of the keyboard.
Turn the wireless keyboard and the wristpad upside down. Preferably lay a cloth
under it to avoid any damage.
Carefully slide one part of the first clip into the hole on the bottom of the
keyboard by applying slight pressure only (see the following figure on the
left).
Release the pressure so that the other side of the clip clicks into the hole
(see the following figure in the middle).
The second clip is now positioned in front of the other hole. Press the clip
of the wristpad carefully into the hole (see the following figure on the
right). The clips will release and click into the hole.
To release the wristpad, turn the wireless keyboard over with the wristpad upside
down. Preferably lay a cloth under it to avoid any damage.
Carefully swivel the wristpad upwards (towards the bottom of the wireless
keyboard) by slightly pulling it at the same time. The clips will release
from their holes.

English Wireless keyboard with wireless mouse STMS 2017 A1
14
Software Installation
In order to be able to use the full function-capabilities of your wireless keyboard
and wireless mouse, you must install the supplied software. Insert the included
CD-ROM in the CD-ROM drive of your computer. The installation process should
start automatically, failing that, start the CD-ROM file "SilverCrest STMS 2017 A1
Driver Setup V1.0.exe" manually by double-clicking it.
Only with the operating system Windows Vista®/ Windows®7 the installation will
initially be stopped by the user account control function with the message: „An
unidentified program is attempting to access the computer”. Click on „OK“ to
continue with the installation.
The following installation illustrations correspond to the operating system
Windows® 7. The windows displayed in the operating systems Windows®
XP/Vista®are slightly different, but their content is the same.
Click on Next to start the installation.
Here you can select the target folder for
the installation via the Change button or
use the suggested folder. Click on Next
to proceed with the installation.

Wireless keyboard with wireless mouse STMS 2017 A1 English
15
Click Finish to finish the setup
programme.
If you are prompted to restart your computer, restart it before
using the software.

English Wireless keyboard with wireless mouse STMS 2017 A1
16
Task Bar Symbols
A double click on this symbol opens the configuration menu for the
optical mouse (see page 17 – “Configuration of the Optical Mouse” for a
description).
A double click on this symbol opens the configuration menu for the
keyboard (see page 18 – “Configuration of the Keyboard” for a
description).
Right-click on the corresponding icon to open a menu showing
the following options:
Open Opens the configuration menu of the corresponding
device.
Info Shows information about the version of the installed
driver.
Exit Exits the function. If necessary, you can open the
applications again from the Start menu of your
operating system.
The operating systems default settings will hide disabled icons
in the task bar. It is recommended to disabled the “Hide inactive
icons” option in task bar properties.
Configuration
Toggling between Operating Modes
Use the CPI button (13) to quickly toggle between 800 cpi and 1600 cpi resolution
for optical tracking. Tracking at 1600 cpi offers a higher accuracy.
If you would like to toggle between standard operation and media operation on
the mouse, press the CPI button (13) and keep it pressed for a minimum of
3 seconds until the power control lamp (10) briefly lights up. Please see the list on
page 3 for information on the functions available in the media operation mode. In

Wireless keyboard with wireless mouse STMS 2017 A1 English
17
media operating mode you can press the tilt wheel (9) to the left or right to adjust
the sound volume. While in standby mode the Windows audio volume can still be
adjusted by turning the scroll wheel, as long as the volume window has been
enabled in the taskbar.
Configuring the Wireless Mouse
Double-click on the icon in the task bar (lower-right corner on your screen,
near the system clock). Or right-click on the icon and select “Open” from the
context menu.
The mouse configuration menu will appear.
Here you can specify functions for
selected mouse buttons. Simply click
on the selection switch next to the
corresponding mouse button and select
a function from the menu by clicking on
it with the left mouse button.
You can restore the mouse to its
original state by clicking the „Restore to
default“ button.
All selected options apply to the default mode. The button
assignments for media mode cannot be modified.
If you would like to apply your changes, please click on the „Apply“ button (the
window will remain open) or the „OK“ button (the window will close).

English Wireless keyboard with wireless mouse STMS 2017 A1
18
Configuring the Wireless Keyboard
The wireless keyboard features 20 hotkeys (quick access keys), a volume
adjustment button and a scroll wheel. Following software installation, the special
keys offer the following standard functions. 17 hotkeys can furthermore be freely
programmed according to your requirements.
Hotkey Description
Standard internet browser (e.g. Internet Explorer)
Standard email programme (e.g. Microsoft®Outlook)
Internet-browser favourites
Update display
Stops loading the page in your Web Browser.
Forward (e.g. Internet Explorer)
Back (e.g. Internet Explorer)
Open desktop
Search
Start pocket calculator
Starts the standard media player (e.g. Microsoft
®
Media
Player)
Previous title
Play / Pause
Next title
Sound on/off
Start Microsoft®Word (needs to be installed)
Start Microsoft®Excel (needs to be installed)
Switch computer on/off *
(Many mainboards feature a BIOS setting such as, for
example, „Boot on USB“, „Power on by USB“, or a
corresponding setting). Activate this function in order to be
able to switch the computer on and off via the keyboard.
Please also consult the documentation of your computer or
main board before activating the BIOS setting.
Initiate sleep mode *
Starting from sleep mode *
* not freely programmable
