Silvercrest SAD 12 C2 User manual

AROMA DIFFUSER SAD 12 C2
AROMA DIFFUSER
Operating instructions
AROMA-DIFFUSER
Bedienungsanleitung
IAN 340458_1910
ΣΥΣΚΕΥΗ ΓΙΑ
ΑΡΩΜΑΤΙΣΜΟ ΧΩΡΟΥ
Οδηүίες χρήσης

GB/IE/NI/CY Operating instructions Page 1
GR/CY Οδηүίες χρήσης Σελίδα 19
DE/AT/CH Bedienungsanleitung Seite 37
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειω-
θείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

GB│IE│NI│CY │ 1 ■SAD 12 C2
Table of Contents
Introduction .................................. 2
Information about these operating instructions................2
Intended Use .........................................2
Warnings used ........................................3
Safety....................................... 4
Basic safety instructions .................................4
Operating Elements............................ 7
Setting up and connecting ...................... 7
Items supplied and initial inspection........................8
Unpacking ...........................................8
Disposal of packaging ..................................8
Electrical connection....................................9
Handling and operation ........................ 9
Initial use ............................................9
Functions............................................10
Cleaning/Storage/Disposal .................... 11
Cleaning/descaling the appliance........................11
Storage.............................................12
Disposing of the appliance..............................12
Appendix ................................... 13
Notes on the EU declaration of conformity .................13
Technical data .......................................13
Kompernass Handels GmbH warranty ....................15
Service .............................................18
Importer............................................18
IB_340458_SAD12C2_GB-IE-NI-CY.indb 1 21.02.20 10:43

■ 2 │ GB│IE│NI│CY SAD 12 C2
Introduction
Information about these operating instructions
Congratulations on the purchase of your new appliance. You have
thereby decided in favour of a high quality product. These operat-
ing instructions are a component of the Aroma Diffuser SAD 12 C2
(hereafter referred to as the appliance or product) and they provide
you with important information about the intended use, safety, con-
nection and operation of the appliance. These operating instructions
must be constantly kept available close to the appliance. They are to
be read and applied by everyone assigned to operate the appliance
and to eliminate faults with it. Retain these operating instructions
and pass them on, together with the appliance, to a possible future
owner.
Intended Use
This appliance is intended only for domestic use and for the refresh-
ing and humidification of air in enclosed spaces. This appliance is
not intended for any other use or for uses beyond those mentioned
here.
Claims of any kind resulting from damage caused by improper use,
incompetent repairs, unauthorized modifications or the use of non-
approved spare parts will not be acknowledged.
The operator alone bears liability.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 2 21.02.20 10:43

GB│IE│NI│CY │ 3 ■SAD 12 C2
Warnings used
In these extant operating instructions the following warnings are used:
WARNING
A warning at this risk level indicates a possibly
dangerous situation.
If the dangerous situation is not avoided, it could lead to
personal injury.
► Follow the instructions in this warning to avoid personal
injuries.
IMPORTANT
A warning at this risk level signifies possible
property damage.
If the situation is not avoided it could lead to property damage.
► The directives in this warning are there to avoid property
damage.
NOTICE
► A notice signifies additional information that assists in the
handling of the appliance.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 3 21.02.20 10:43

■ 4 │ GB│IE│NI│CY SAD 12 C2
Safety
In this chapter you will receive important safety information regarding
the handling of the appliance. Incorrect usage can, however, lead to
personal and property damage.
Basic safety instructions
For safe handling of the appliance observe the following safety
information:
■ Before use, check the appliance for signs
of visible external damage. Do not put into
operation an appliance that is damaged or
has been dropped. There is also a risk of
personal injury!
■ This appliance may be used by children of the
age of 8 years or more and by persons with
reduced physical, sensory or mental capabili-
ties or lack of experience and knowledge if
they are supervised or, in regard to the safe
use of the appliance, have been instructed
in its use and understand the potential risks.
Children must not play with the appliance.
Children should not carry out cleaning and
user maintenance tasks without supervision.
■ Operate the appliance only with the supplied
power adapter.
■ The appliance and mains adapter may
only be used in dry interior rooms.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 4 21.02.20 10:43

GB│IE│NI│CY │ 5 ■SAD 12 C2
■ Place the appliance only on flat surfaces, so
that a tipping over is excluded.
■ Repairs should only be carried out by author-
ised specialist companies or by the Customer
Service Department. Incorrect repairs can
result in significant risks for the user. In addi-
tion, warranty claims become void.
■ To avoid risks, arrange for defective power
plugs and/or cables to be replaced at once
by qualified technicians or our Customer
Service Department.
■ This appliance may not be exposed to rain.
Protect the appliance from moisture and the
penetration of liquids and objects into the
housing. NEVER submerse the appliance in
water and do not place objects filled with liq-
uids (such as vases) on the appliance. The ap-
pliance could also be irreparably damaged!
■ Before filling/emptying the water tank and
before cleaning, disconnect the plug from the
mains power socket.
■ Do not operate the appliance close to open
flames (e.g. candles). The appliance could
also be irreparably damaged!
■ Avoid direct solar radiation. The appliance
could be irreparably damaged!
IB_340458_SAD12C2_GB-IE-NI-CY.indb 5 21.02.20 10:43

■ 6 │ GB│IE│NI│CY SAD 12 C2
■ Always disconnect the mains power cable
from the socket by pulling on the plug, do not
pull on the cable itself. Otherwise, the power
cable could be damaged.
■ Use the appliance only with essential oils
(aromatic oils).
■ Only aromatic oils which comply with nation-
al health requirements may be used. The use
of other substances may result in poisoning
or a risk of fire.
■ Keep scented oils out of the reach of children.
■ Always store scented oils under lock and key.
■ Also note the warnings on the labels of the
scented oils:
Symbol Meaning
Read and observe the operating instructions!
Warning! Causes skin irritation.
Can trigger allergic skin reactions.
Causes severe eye irritation.
Warning! Toxic to aquatic organisms,
with long-term effects.
Tactile hazard symbol for people
with impaired vision.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 6 21.02.20 10:43

GB│IE│NI│CY │ 7 ■SAD 12 C2
Operating Elements
(For illustrations see the fold-out side)
1Diffusion cone
2Steam outlet
3Ventilation slot
4 Water tank
5 Ceramic disk
6On/off switch with lighting
7Pouring direction arrow
8Maximum filling level
9Plug socket
0Mains adapter
qMeasuring beaker
wScented oil
Setting up and connecting
WARNING
During the commissioning of the appliance per-
sonal injury and property damage could occur!
Observe the following safety information to avoid these risks:
► Packaging material should not be used by children as a play
thing. There is a risk of suffocation.
► To avoid damage to people and property, pay heed to the
requirements for the installation site and the electrical con-
nection of the appliance.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 7 21.02.20 10:43

■ 8 │ GB│IE│NI│CY SAD 12 C2
Items supplied and initial inspection
The appliance is supplied with the following components as standard:
▯ Aroma Diffuser SAD 12 C2
▯ Mains adapter
▯ Measuring beaker
▯ 2 x 10 ml scented oil (sandalwood and lavender)
▯ Operating Instructions
NOTICE
► Check the contents to ensure everything has been provided,
and for signs of visible damage.
► If the contents are incomplete, or have been damaged due
to defective packaging or transportation, contact the Service
Hotline (see chapter Service).
Unpacking
♦ Remove all parts of the appliance and these operating
instructions from the box.
♦ Remove all packaging materials from the appliance.
Disposal of packaging
The packaging materials have been selected for their
environmental friendliness and ease of disposal and are
therefore recyclable. Dispose of packaging materials
that are no longer needed in accordance with
applicable local regulations.
Dispose of the packaging in an environmentally friendly
manner. Note the labelling on the packaging and
separate the packaging material components for
disposal if necessary. The packaging material is labelled
with abbreviations (a) and numbers (b) with the
following meanings: 1–7: Plastics, 20–22: Paper and
cardboard, 80–98: Composites.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 8 21.02.20 10:43

GB│IE│NI│CY │ 9 ■SAD 12 C2
Electrical connection
IMPORTANT
► Before you connect the appliance to the power supply, check
to ensure that the required input voltage as given on the type
plate tallies with that for the intended power source. To avoid
possible damage to the appliance this data must match.
► Check to ensure that the cable for the power adapter 0
is not damaged and that it does not lead over hot surfaces
and or sharp edges, otherwise it could be damaged.
► Ensure that the cable for the power adapter 0is not over-taut
or kinked.
♦ Connect the power adapter 0to the appliance by inserting the
plug into the plug socket 9on the underside of the appliance.
Handling and operation
Initial use
IMPORTANT
► It is possible that oil drops may cause damage to furniture
surfaces. If necessary, place a cloth under the appliance.
♦ Place the appliance on a level and stable surface.
♦ Remove the diffusion cone 1and fill the water tank 4, by
using the supplied measuring beaker, qwith max. 80 ml of
clean mains water. Pay heed to the maximum filling level 8.
♦ Add 2 to 4 drops of the desired oil to the water.
♦ Then replace the diffusion cone 1onto the water tank 4.
♦ Insert the power adapter 0into the mains power socket.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 9 21.02.20 10:43

■ 10 │ GB│IE│NI│CY SAD 12 C2
Functions
By pressing the on/off switch 6several functions are made possible:
■ 1. Press: The appliance is switched on, the fragrant mist
and LED colour changing sequence starts.
■ 2. Press: Your favourite colour is fixed, the fragrant mist
production continues.
■ 3. Press: The coloured light is switched off completely,
the fragrant mist production continues.
■ 4. Press: All functions are switched off.
NOTICE
► The appliance switches itself off automatically as soon as the
liquid in the water tank 4has been used up.
IMPORTANT
Damage to the appliance!
► NEVER tilt the appliance during operation and do not try to
empty it.
► Be sure to disconnect the power adapter 0from the mains
power socket before filling or emptying the appliance.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 10 21.02.20 10:43

GB│IE│NI│CY │ 11 ■SAD 12 C2
Cleaning/Storage/Disposal
IMPORTANT
Damage to the appliance!
► To avoid irreparable damage, when you are cleaning the
appliance ensure that no moisture can penetrate into it.
► Ensure that you remove the power adapter 0from the
mains power socket before cleaning the appliance.
► To avoid damage, do not empty the appliance through the
ventilation slot 3. When emptying it, take note of the pour-
ing direction arrow 7on the water tank 4.
► Under no circumstances should you try to remove scale
deposits with a pointed or sharp object. The appliance could
be irreparably damaged.
Cleaning/descaling the appliance
♦ Clean the water tank 4after each use so as to remove oil resi-
due as completely as possible. For this, use a soft and slightly
moist cloth. In the case of stubborn stains, place a few drops of
mild detergent on the damp cloth.
NOTICE
► Use common retail sunflower oil to remove discolourations
caused by oils from the water container 4.
♦ Should the steam production diminish, the ceramic disk 5
located at the bottom of the water tank 4must be cleaned.
For this, use a slightly moistened cotton bud.
♦ Clean the surfaces of the appliance with a soft and dry cloth.
♦ To descale the appliance, use a standard commercial liquid
descaling agent. Pay heed also to the manufacturer’s instruc-
tions for your descaler.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 11 21.02.20 10:43

■ 12 │ GB│IE│NI│CY SAD 12 C2
♦ Fill the water tank 4to the maximum filling level 8with
descaler and let it stand until the scale is fully dissolved.
♦ Pour the scale removal away and then clean the water tank 4
with a soft and slightly damp cloth.
Storage
Should you decide to not use the appliance for an extended period,
disconnect it from the mains power supply and store it in a clean
and dry location away from direct sunlight.
Disposing of the appliance
Never dispose of the appliance or the mains
adapter in your normal domestic waste. This
product is subject to the provision of European
Directive 2012/19/EU WEEE (Waste Electrical
and Electronic Equipment).
Dispose of the appliance and the mains adapter via an
approved disposal company or your municipal waste
facility. Observe the currently applicable regulations. In
case of doubt, please contact your waste disposal centre.
Your local community or municipal authorities can
provide information on how to dispose of the worn-out
product.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 12 21.02.20 10:43

GB│IE│NI│CY │ 13 ■SAD 12 C2
Appendix
Notes on the EU declaration of conformity
In regard to conformity with essential requirements and
other relevant provisions, this appliance complies with
the European EMC Directive 2014/30/EU, the Low
Voltage Directive 2014/35/EU and the Eco-design
Directive 2009/125/EC.
The complete EU Declaration of Conformity is available from the
importer.
Technical data
Mains adapter
Manufacturers
HUA XU ELECTRONICS FACTORY
No. 1, Shi Tang Bei Street 2,
ShiJieTown, Dong Guan City,
Guang Dong, P.R. China
Commercial register number:
91441900345342145H
Model HX18H-2400500-AB
Input voltage
100–240 V ~(AC)
Input AC frequency 50/60 Hz
Output voltage 24.0 V (DC)
Output current 0.5 A
Output power 12.0 W
Average operating efficiency 87.7 %
Low load efficiency (10%) 77.0 %
No-load power consumption 0.09 W
Current consumption 0.5 A
IB_340458_SAD12C2_GB-IE-NI-CY.indb 13 21.02.20 10:43

■ 14 │ GB│IE│NI│CY SAD 12 C2
Mains adapter
Protection class II/ (double insulation)
Polarity
(positive inside, negative outside)
Protection type IP 20
Efficiency class 6 VI
Short-circuit proof safety
transformer
Nominal ambient
temperature (ta) 40°C
Switched-mode power supply
Appliance
Input voltage 24 V (DC)
Current consumption 500 mA
Water tank capacity 80 ml
IB_340458_SAD12C2_GB-IE-NI-CY.indb 14 21.02.20 10:43

GB│IE│NI│CY │ 15 ■SAD 12 C2
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase.
If this product has any faults, you, the buyer, have certain statutory
rights. Your statutory rights are not restricted in any way by the
warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your
receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the
date of purchase of the product, we will either repair or replace the
product for you or refund the purchase price (at our discretion). This
warranty service requires that you present the defective appliance and the
proof of purchase (receipt) within the three-year warranty period, along
with a brief written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product will either be
repaired or replaced by us. The repair or replacement of a product
does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the
warranty. This also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be
reported immediately after unpacking. Repairs carried out after
expiry of the warranty period shall be subject to a fee.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 15 21.02.20 10:43

■ 16 │ GB│IE│NI│CY SAD 12 C2
Scope of the warranty
This appliance has been manufactured in accordance with strict
quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty
does not extend to product parts subject to normal wear and tear or
to fragile parts which could be considered as consumable parts such
as switches, batteries or parts made of glass.
The warranty does not apply if the product has been damaged,
improperly used or improperly maintained. The directions in the
operating instructions for the product regarding proper use of
the product are to be strictly followed. Uses and actions that are
discouraged in the operating instructions or which are warned
against must be avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or
improper handling, use of force and modifications/ repairs which
have not been carried out by one of our authorised Service centres.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 16 21.02.20 10:43

GB│IE│NI│CY │ 17 ■SAD 12 C2
Warranty claim procedure
To ensure quick processing of your case, please observe the following
instructions:
■ Please have the till receipt and the item number (e.g.
ΙΑΝ123456) available as proof of purchase.
■ You will find the item number on the type plate on the product,
an engraving on the product, on the front page of the operating
instructions (below left) or on the sticker on the rear or bottom of
the product.
■ If functional or other defects occur, please contact the service
department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service
address that will be provided to you. Ensure that you enclose the
proof of purchase (till receipt) and information about what the
defect is and when it occurred.
You can download these instructions along with many
other manuals, product videos and installation software
at www.lidl-service.com.
This QR code will take you directly to the Lidl service
page (www.lidl-service.com) where you can open your
operating instructions by entering the item number
(IAN) 123456.
IB_340458_SAD12C2_GB-IE-NI-CY.indb 17 21.02.20 10:43
