Silvercrest 274299 User manual

TIMER SWITCHES
IAN 274299
ZEITSCHALTUHREN
Bedienungs- und Sicherheitshinweise
TIMER SWITCHES
Operation and Safety Notes
PROGRAMMATEURS
Instructions d‘utilisation et consignes de sécurité
TIJDSCHAKELAAR
Bedienings- en veiligheidsinstructies

GB Operation and Safety Notes Page 5
FR/BE Instructions d‘utilisation et consignes de sécurité Page 17
NL/BE Bedienings- en veiligheidsinstructies Pagina 32
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 46
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Avant de lire le mode d‘emploi, ouvrez la page contenant les illustrations
et familiarisez-vous ensuite avec toutes les fonctions de l‘appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u
vertrouwd met alle functies van het apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

B
4
A
5
67
8
1234

5GB
List of pictograms used........Page 6
Introduction
Intended use ........................................Page 7
Control elements..................................Page 8
Technical Data.....................................Page 8
Safety notices ..............................Page 9
Start-up
Setting switching times ........................Page 10
Selecting the operating mode.............Page 12
Adjusting the time ................................Page 13
Cleaning............................................Page 13
Disposal.............................................Page 14
Warranty and Service..........Page 15
Service address ...................................Page 16
Manufacturer.......................................Page 16

6 GB
List of pictograms used:
Observe the warning and
safety instructions!
Attention! Risk of electric shock!
Do not dispose of electric equip-
ment in the household waste!
Use indoors
AC motor
Micro-switch with a contact
opening width of < 3mm

7GB
Timer Switches
Mechanical – for indoors
Introduction
Intended use
This device is intended as a daily timer switch
for enclosed, dry rooms only and designed
for private use. It is not suitable for commer-
cial use. Only operate the device individu-
ally. Do not connect several timer switches in
series. Any other use is considered improper.
The manufacturer is not liable for damages
due to improper use.
Read the entire instructions for use before
using the device. Keep these instructions for
use. Include the instructions for use when
passing the device on.

8 GB
Control elements (Fig. A)
1Clock ring
2Direction of rotation
3Mark
4Switching pins
5Toggle timer /continuous mode
6Status light
7Safety plug (back)
8Isolated ground receptacle with child
protection
Technical Data
Model designation: MZ 20-1 FR
Operating voltage: 220–240V~50Hz
Switched voltage: 220–240V~
16(2)A
Switching capacity: max. 3500 W
Shortest switching time: approx. 15 minutes

9GB
Power reserve: none
Use
indoors:
CE compliant:
Safety notices
Children are not able to understand the
dangers arising from improper use of
electric devices. Never leave children
unsupervised when using electronic
devices.
Only plug the device into conventional
isolated ground receptacles with an
alternating current of 220–240V and
50Hz.
Only connect loads within the specified
capacities of the device.
Do not cover the device. Heat accumu-
lates when covered. There is a fire hazard.

10 GB
Regularly check the device for damage.
Do not replace damaged parts. Contact
the manufacturer or dispose of the device
in an environmentally responsible way.
Do not touch the device with wet hands.
Disconnect the device from the power
mains to de-energise.
Start-up
Setting switching
times (Fig. B)
Use the switching pins 4to set the times
when you wish the timer to switch the con-
nected device on or off. Using a pointy ob-
ject, e.g. pen, push one or several pins down
to lock into place to set the desired switching
time. Every switching pin corresponds to a
switching time of approx. 15 minutes.

11GB
Device for private use, set times may be off-
set. Not suitable for applications requiring
precise and accurate switching.
In figure B the grey pins mark a switching
time of 8:30 pm to 10:30 pm. A load is
switched on during the time from 8:30 pm
to 10:30 pm.
Setting the switching time
Push down the respective number of
switching pins 4.
Disabling switching time
Push the switching pins 4up again.

12 GB
Selecting the
operating mode
The device will work in switching mode or in
continuous mode.
Activating switching mode
Plug the device into a socket.
Connect and switch on the load.
Slide the toggle 5down until it locks in.
The status light 6will light up when
switched time is activated.
Activating continuous operation
Plug the device into a socket.
Connect and switch on the load.
Slide the toggle 5all the way up until
it locks in.
The status light 6will light up.

13GB
Adjusting the time
Set the current time with the clock ring 1.
You will see the time by the marking 3.
Turn the clock ring 1in the direction of
rotation 2.
Set the marking 3to the current time.
Plug the device into a socket to switch it on.
Connect and switch on the load.
Cleaning
ATTENTION! RISK OF
ELECTRIC SHOCK! Discon-
nect the device from the
mains before cleaning.
ATTENTION! RISK OF
ELECTRIC SHOCK! Do not
allow liquids to enter the

14 GB
device. Liquids entering can result in a
short circuit.
ATTENTION! Danger due to harsh
cleaners.
Never use harsh or scouring cleaners.
Clean the device with a soft, slightly
damped cloth and mild detergent.
Ensure the device is completely dry
before using it again.
Disposal
Do not dispose of electric
equipment in the house-
hold waste!
In accordance with European Directive
2012/ 19/ EC relating to old electrical and
electronic appliances, used electrical equip-
ment must be collected separately and

15GB
recycled in an ecologically compatible way.
Contact your local authorities for information
on how to dispose of the appliance at the
end of product life.
Warranty and Service
This device is covered by a 3 year warranty
from the date of purchase. Please keep your
receipt as proof of purchase. The product
has been produced to the highest standards
and thoroughly checked before dispatch.
The guarantee only applies to faults in mate-
rial or manufacture when used properly. Any
modifications will void the guarantee. This
warranty does not limit your legal rights.
Please phone the service centre for guaran-
tee claims. This is the only way to return your
product free of charge.

16 GB
Service address
BAT
Lindenstraße 35
72074 Tübingen
Germany
E-Mail: [email protected]
Service phone: [phone]
If you need further information, we recom-
mend that you consult Service/FAQ‘s on our
homepage www.dvw-service.com.
IAN 274299
Manufacturer
BAT
Lindenstraße 35
72074 Tübingen
Germany

17FR/BE
Légende des
pictogrammes utilisés...........Page 18
Introduction
Utilisation conforme.............................Page 19
Éléments de réglage............................Page 20
Caractéristiques techniques ................Page 21
Indications de sécurité.........Page 22
Mise en marche
Réglage du temps de commutation....Page 23
Choisir le mode de fonctionnement....Page 25
Réglage de l’heure..............................Page 26
Nettoyage.......................................Page 27
Mise au rebut...............................Page 28
Garantie et service
après-vente....................................Page 29
Adresse du service après-vente ..........Page 30
Fabricant ..............................................Page 31

18 FR/BE
Légende des pictogrammes
utilisés :
Respectez les avertissements
et les consignes de sécurité !
Attention ! Risque de décharge
électrique !
Ne jetez pas les appareils
électriques usés dans les or-
dures ménagères !
Utilisation dans une pièce
fermée
Moteur à courant alternatif
Microrupteur avec une distance
d
‘ouverture des contacts < 3 mm

19FR/BE
Programmateurs
Mécaniques - pour l’intérieur
Introduction
Utilisation conforme
Cet appareil est une horloge programmable
journalière. Son usage est prévu dans une
pièce fermée et sèche et dans un cadre privé.
Il n‘est pas destiné à un usage commercial.
Cet appareil ne peut être utilisé qu‘individuel-
lement. Ne pas installer plusieurs horloges
programmables côte à côte. Toute autre utili-
sation n‘est pas conforme. La responsabilité
du fabricant n‘est pas engagée en cas
d‘utilisation inappropriée.
Veuillez lire intégralement ce mode d‘emploi
avant d‘utiliser l‘appareil. Conservez ce
mode d‘emploi. Si vous transmettez cet

20 FR/BE
appareil à un autre utilisateur, remettez-lui
également ce mode d‘emploi.
Éléments de réglage
(voir ill. A)
1Anneau de l‘horloge
2Sens de rotation
3Repère
4Broches de commutation
5Commutateur du temps de commutation/
fonctionnement continu
6Témoin de fonctionnement
7Prise de prise de courant (verso)
8Prise de courant avec protection enfant
