Silverline Derwent Assembly Instructions

1
Derwent 90cm Ceiling Hood
Installation & User Instructions
Please read these instructions carefully before installing and
operating this appliance

2
Contents
1. Introduction
3
2. Health and Safety
3-4
3. Installation
4-9
3.1 Assembly Instructions
4-7
3.2 Ducting Options
5
3.3 Motor Options
5-6
3.4 Electrical Wiring
6-8
3.4.1 Electrical Wiring Diagram
7
3.4.2 Controls
8
4. Use & Maintenance
8
4.1 Cleaning the Metal Filters
8
4.2 Cleaning the Hood
8
5. Technical Data
8
6. Dimensions
9-11
6.1 Derwent 90cm Ceiling Hood
9-10
6.2 1240 T1 Motor
10
6.3 1250 T2 Motor
11

3
1. Introduction
Dear Customer,
We wish to thank you for choosing this Silverline
cooker hood. In order to get the best performance
from your appliance we recommend that you read
this booklet carefully before operating the appliance
for the first time.
Revisions to the publication
In order to improve the product, to keep this
publication up to date the manufacturer reserves the
right to make modification without any advance
notice. Any reproduction, even in part, of this manual
without the consent of the manufacturer is
prohibited.
Care of the manual and how to consult it
Take good care of this manual and keep it in a
place which can be easily and quickly reached.
If this manual should be lost or destroyed, or if it
is in poor condition, ask for a copy from your
retailer, providing product identification data.
Information which is essential or that requires
special attention is shown in bold text.
ATTENTION
This warning sign indicates that the
message to which it refers should be
carefully read and understood, because
failure to comply with what these notices
say can cause serious damage to the
extractor and put the user’s safety at risk.
INFORMATION
This symbol is used to highlight
information which is important for proper
extractor operation. Failure to comply with
these provisions will compromise use of
the boiler and its operation will not be
satisfactory.
MANUAL
Indicates that you should carefully read
this manual or the related instructions.
2. Health and Safety
Installation of the cooker hood, making
electrical connections, checking its operation
and maintenance are all tasks which should be
carried out by qualified and authorised
personnel.
Install the cooker hood in accordance with the
regulations in force in your local area, region and
country.
For the correct use of the appliance and to
prevent accidents, the instructions given in this
booklet must always be followed.
Before beginning any operation, the user, or
whoever is preparing to operate on the
appliance, must have read and understood the
entire contents of this instruction booklet.
All responsibility for improper use is taken
entirely by the user and as such relieves Silverline
of any civil or criminal responsibility.
In view of the fact that it is an electrical appliance,
do not touch the appliance with wet hands.
Before carrying out any cleaning or maintenance
operation, make sure in advance that the
appliance is isolated from the mains electricity
supply.
Incorrect installation or faulty maintenance (not
conforming to the requirements set out in this
booklet) can cause harm to people, animals or
property. In such cases Silverline is absolved from
any civil or criminal responsibility.
This product complies with EU Directive
EU2002/96/EC.
The crossed bin symbol on the appliance indicates
that the product, at the end of its life, must be
disposed of separately from domestic waste, either by
taking it to a separate waste disposal site for electric
and electronic appliances or by returning it to your
dealer when you buy another similar appliance. The
user is responsible for taking the appliance to a special
waste disposal site at the end of its life. If the disused
appliance is collected correctly as separate waste, it
can be recycled, treated and disposed of ecologically.
WARNINGS:
-This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
-Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.

4
-Before cleaning or performing any periodic or
urgent maintenance to the hood, isolate the
mains supply and turn the main switch off.
-Do not connect the hood to any piping used for
combustion appliances, such as burners, boilers
or fire places.
-Check that the main power supply corresponds
to the voltage required by the hood, which is
given on the silver label stuck inside the hood.
Ensure that the electric system is correctly
earthed and that the earth discharge works
correctly.
-When cooking do not use any materials that
could form high or unusual flames. Oil that has
been used twice and fats are very dangerous
and could easily catch fire. Do not prepare
flambé dishes under the hood.
-Once the specialised technician has completed
the installation of the hood equipped with a
remote motor, all the leads, connectors, ground
connections and the remote motor must not be
accessible to the user. Only the installer is
granted access by removing screwed on panel.
-Respect local legislation and regulations issued
by the relative authorities regarding the exhaust
air when the suction is operating. Failure to
respect and perform all maintenance and
cleaning operations described in this handbook
could cause a fire hazard.
ATTENTION: Accessible parts may become hot when
the hood is used with cooking appliance.
3. Installation
The minimum safety distance between the bottom of
the hood and the top of the cooking hob must be
650mm, smaller distances must be previously
authorised by the manufacturer. The maximum is
1.6m.
When the suction function is operating i.e. exhausting
the filtered air on the outside, a suitable
compensation system must be used according to
current standards in force. The diameter of the fume
exhaust pipe must be the same or greater than the
diameter of the hood pipe union.
There must be sufficient ventilation in the room where
the hood is installed, to allow simultaneous use of
other appliances that use gas or other fuels.
3.1 Assembly Instructions
Attention: Before proceeding with the installation,
make sure that the screws and the anchors supplied,
are suitable for the type of wall/ceiling the hood will be
fixed to.
To assemble the hood use the accessories that are
supplied and follow the instructions given in the
enclosed hand book.
Hanger Hooks
The Derwent has 4 hanger hooks at each corner to
secure the hood to the ceiling (Fig 1).
Fig 1
Cut-out dimensions
Fig 2
Ducting Dimensions
Fig 3
445
250

5
1. Pull down on the glass panel to reveal the grease
filters (Fig 4).
Fig 4
2. Remove the grease filters and place the
200/150mm ducting adapter to the back of the
hood (Fig 5).
Fig 5
3. Put the Derwent up into the ceiling (Fig 6).
Fig 6
4. Make sure the hanger hooks are in position and
tighten the screws to clamp the hood to the
ceiling (Fig 7).
Fig 7
3.2 Ducting Options
The Derwent is ducted using either rigid ducting from
the back of the hood (Fig 7 & Fig 8).
Fig 7
Fig 8
3.3 Motor Options
The Derwent ceiling hood can be fitted with either the
1240 T1 750m3/h motor or the 1250 T2 1400m3/h
motor. This can be installed anywhere along the
ducting but no more than 6m away.
1. The motor is fixed to the wall using the L brackets
supplied. Screw the motor to the L brackets and
attach through A & B points to the wall (Fig 9).
Fig 9
445
250
A
B

6
2. Mount the rigid ducting onto the plastic
connector of the hood (Fig 10).
Fig 10
3. Install the ducting work up to the air inlet of the
motor (Fig 11).
Fig 11
4. Install ducting between the air outlet on the
motor and the external vent.
3.4 Electrical Wiring
The electrical wiring must be performed by a
specialised electrician fully respecting current
standards and legislation in force. Check that the
power supply corresponds to the voltage requested
by the hood, which is given on the silver label stuck
inside the hood. Ensure that the wiring system
conforms to current standards and the earth
discharge works efficiently. Pay special attention to
the hood power cable, ensure that it does not pass
through any holes without a cable clamp. For direct
connection to the electrical mains it is necessary to
provide a device that ensures disconnection from the
electrical mains, with an opening distance of the
contacts that allows the complete disconnection
under the conditions of overvoltage category III, in
accordance with the rules of installation. The plug or
Omni polar switch must be accessible when the unit is
installed.
If the power cord is damaged, it must be replaced by
a special cord or assembly available from the
manufacturer or its service agent. The cable must be
of type H05VV-F 3 x 0.75mm2minimum cross-section.
The manufacturer declines all responsibility if the
current accident prevention standards in force are not
respected, which are needed for the wiring system to
operate correctly.

7
3.4.1 Electrical Wiring Diagram
Motor
Brown
Red
White
Yellow
Grey
Black
Lights
To control
buttons on hood
Blue
Brown
Mains
Supply

8
3.4.2 Controls
The Derwent ceiling hood is controlled by remote
control. This allows the user to control the hoods
on/off functions, lights and the 4 motor speeds.
Fig 12
Turns the hood on/off at motor speed 2.
Increases motor speed.
Decreases motor speed.
Turns lights on/off.
4. Use & Maintenance
Before beginning any sort of cleaning or
maintenance work, turn the power off to the hood
by turning the main switch to 0 (OFF).
4.1 Cleaning the Metal Filters
The metal filters fitted in the hood should be washed
every 2-3 months, depending on how much the hood
is used, using hot water and a liquid detergent that is
not too aggressive.
The metal filters can be removed by the special
handle, unhooking the front part of the filter and
pulling it downwards (Fig 13).
Fig 13
4.2 Cleaning the Hood
The surfaces of the hood should be cleaned
frequently, to avoid the risk of having to remove built
up and encrusted deposits and stains.
For painted or copper plated hoods just a soft cloth
with warm water and a neutral detergent. Do not
pour the detergent directly onto the hood or use
powdery or abrasive products.
For stainless steel hood, use special products and
cloths for satin finish stainless steel (not abrasive,
corrosive detergents or detergents containing
chloride), ensuring to clean in the same direction as
the satin finish.
Do not use aggressive products, chemical solvents or
derivatives of oil distillates that could leave oily traces
which could cause oxidation and polymerisation.
The manufacturer accepts no responsibility for
damage to the surface of the hood due to failure to
respect these instructions.
5. Technical Data
Derwent 90cm with 1240 T1 Motor
Control
Remote Control
Colour/finish
Black Glass
Lighting
19w LED
Airflow (m3/h)
700
Noise (db)
54-59
Power (W)
229
Voltage (V)
230
Outlet Width (mm)
150
Weight (kg)
20
Derwent 90cm with 1250 T2 Motor
Control
Remote Control
Colour/finish
Black Glass
Lighting
19w LED
Airflow (m3/h)
1400
Noise (db)
54-69
Power (W)
439
Voltage (V)
230
Outlet Width (mm)
150
Weight (kg)
20
SILVERLINE

9
6. Dimensions
6.1 Derwent 90cm Ceiling Hood
890
115
900
500

10
6.2 1240 T1 Motor
890
486
280

11
6.3 1250 T2 Motor
335.5

12
