SilverStone TS10 User manual

Installation Guide
www.silverstonetek.com
Connect hard drive
to the PCB
Collegare il disco rigido
alla PCB
Подключите жесткий диск
кпечатной плате
Festplatte an die Platine
anschließen
하드 드라이브를
PCB에 연결합니다
Conecte el disco duro al PCB
Connectez le disque dur au PCB
ハードディスクドライ
ブをPCBに接続します
將硬碟與電路板(PCB)連接 将硬盘与电路板(PCB)连接
Slide the hard drive into
the aluminium case
Far scorrere il disco rigido
nel case di alluminio
Установите жесткий диск
валюминиевый корпус
Festplatte in das
Aluminiumgehäuse
schieben
하드 드라이브를 알루미늄
케이스에 밀어 넣습니다
Deslice el disco duro en la
carcasa de aluminio
Glissez le disque dur dans le
boîtier en aluminium
ハードディスクドラ
イブをアルミニウム
製ケースに装着します
將硬碟滑入鋁外殼中 将硬盘滑入铝外壳中
Secure the cover
with screws
Fissare il coperchio con le viti
Закрепите крышку винтами
Deckel mit Schrauben
fixieren
나사로 커버를 고정
합니다
Fije la cubierta con tornillos
Fixez le couvercle avec les vis
ネジでカバーを
固定します
用螺絲固定外蓋 用螺丝固定外盖
TS10 TS13 7 mm 2.5” HDD/SSD
USB 3.0 enclosure
9.5 mm 2.5” HDD/SSD
USB 3.0 enclosure

Warranty Information
This product has a limited 1 year warranty in North America, and Australia.
For information on warranty periods in other regions, please contact your reseller or SilverStone authorized distributor.
1. Product component defects or damages resulted from defective production is covered under warranty.
Defects or damages with the following conditions will be fixed or replaced under SilverStone Technology’s jurisdiction.
a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other inappropriate actions.
b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc…)
c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.
d) Warranty mark/stickers are not removed or broken.
Loss or damages resulted from conditions other than ones listed above are not covered under warranty.
2. Under warranty, SilverStone Technology’s maximum liability is limited to the current market value for the product (depreciated value, excluding
shipping, handling, and other fees). SilverStone Technology is not responsible for other damages or loss associated with the use of product.
3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under no circumstances will SilverStone
Technology be liable for damages in connection with the sale, purchase, or use including but not limited to loss of data, loss of business, loss of
profits, loss of use of the product or incidental or consequential damage whether or not foreseeable and whether or not based on breach of
warranty, contract or negligence, even if SilverStone Technology has been advised of the possibility of such damages.
4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and is not transferable to a second hand
purchaser.
5. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty eligibility.
6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone authorized distributors or SilverStone
http://www.silverstonetek.com.
Please note that: (i) You must provide proof of original purchase of the product by a dated itemized receipt; (ii) You shall bear the cost of shipping
(or otherwise transporting) the product to SilverStone authorized distributors. SilverStone authorized distributors will bear the cost of shipping
(or otherwise transporting) the product back to you after completing the warranty service; (iii) Before you send the product, you must be issued a
Return Merchandise Authorization (“RMA”) number from SilverStone. Updated warranty information will be posted on SilverStone’s official
website. Please visit http://www.silverstonetek.com for the latest updates.
Warranty terms & conditions
Additional info & contacts
For North America ([email protected]) SilverStone Technology in North America may repair or replace defective
product with refurbished product that is not new but has been functionally tested.
Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer. All products
should be sent back to the place of purchase if it is within 30 days of purchase, after 30 days, customers need to initiate RMA
procedure with SilverStone Technology in USA by first downloading the “USA RMA form for end-users” form from the below
link and follow its instructions.
http://silverstonetek.com/contactus.php
For Australia only ([email protected])
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Please refer to above “Warranty terms & conditions” for further warranty details.
SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C.
+ 886-2-8228-1238
(standard international call charges apply)
For Europe ([email protected])
For all other regions ([email protected])
NO:G11218331
www.silverstonetek.com
Installation complete Installazione completata
Сборка завершена
Die Installation ist
damit abgeschlossen
설치가 완료 되었습니다
Instalación finalizada
Installation terminée
インストールは完了です 安裝完成 安装完成
1.Connect USB type
A connector to the
computer
2.Connect USB 3.0
micro-B connector
to the enclosure
1.Collegare il connettore
USB di tipo A al computer
2.Collegare il connettore
USB 3.0 Micro-B al box
1.Подключите разъем
USB типа A ккомпьютеру
2.Подключите
микроразъем USB 3.0
типа B кустройству
1.USB-A-Stecker an
den Computer
anschließen
2.Micro-USB 3.0
-B-Stecker an das
Gehäuse anschließen
1.USB 타입 A 커넥터
를 컴퓨터에
연결합니다
2.USB 3.0 마이크로
B 커넥터를 인클로저에
연결합니다
1.Enchufe el conector USB tipo
A al ordenador
2.Enchufe el conector USB 3.0
micro-B a la carcasa
1.Connectez le connecteur USB
de type A à l'ordinateur
2.Connectez le connecteur
micro-B USB 3.0 à l'accessoire
1.USB タイプAコネクタ
をコンピュータに接続
します
2.USB 3.0マイクロBコ
ネクタをエンクロージ
ャーに接続します
1.將USB type A型接頭與電腦連接
2.將USB 3.0 micro-B型接頭與
外接盒連接
1.将USB type A型接头与
计算机连接
2.将USB 3.0 micro-B型接头
与外接盒连接
