SIMAG SD Series Manual

SD SERIES AUTOMATIC CUBERS
CLEANING AND SANITIZING PROCEDURES
TOOLS REQUIRED
1Medium Phillips Screwdriver
1Medium Flat Screwdriver
1Pair of Protective Gloves
1Bucket/Container
1Different types of brush
1Clean Cloth
1Ice Machine Cleaner
1Antialgae Cleaner
FREQUENCE
•Cleaning: Every six months
•Sanitizing: Every month
NOTE. THE FOLLOWING PROCEDURE CAN BE
USED FOR EITHER SANITIZING OR DE-SCALING
THE ICE MACHINE.
NEVER MIX THE SANITIZING SOLUTION WITH THE
DE -SCALING SOLUTION.
IN CASE THE MACHINE NEEDS TO BE SANITISED
AND DE-SCALED, CLEAN THE MACHINE
THOROUGHLY, THEN FIRST DE-SCALE, AND AFTER
PROPER WASHING AND RINSING, DO THE
SANITATION.
WARNING. When using any chemical, protection of
hands and eyes should be worn.
NOTE. De-scaling is recommended every 6 months in
average water hardness conditions, while sanitizing
should take place once a month. Under extreme water
hardness conditions we recommend to de-scale every
two – three months, and to sanitize every two weeks.
Sanitizing regularly will reduce bacteria growth, which is
natural in all water circulation systems as ice machines.
NOTE. Always follow approved Sanitizer / De-scaler
manufacturers instructions when preparing the Sanitizer
/De Scaler solutions.
PAGE 1/6

PROCEDURE
1. Remove the Front Panel and….
2. ….Top Panel to again access either to the control
box and the evaporator.
3. Remove also the Bin Door.
4. Wait until the end of defrost cycle then Switch OFF
the machine at unit master switch.
5. Scoop out all the ice cubes stored into the bin in
order to prevent them from being contaminated with
the cleaning solution.
6. Flush out the water from the sump reservoir by
removing the over flow stand pipe.
PAGE 2/6

7. Preparing the cleaning solution by diluting in a
plastic container 2 or 3 liters of warm water ( 45°-
60° C) with a 0,2-0,3 liters of Ice Machine Cleaner
Part Number 00100901.
WARNING. The Ice Machine Cleaner contains
Phosphoric and Hydroxyacetic acids. These
compounds are corrosive and may cause burns if
swallowed, DO NOT induce vomiting. Give large
amounts of water or milk. Call Physician
immediately. In case of external contact flush with
water. KEEP OUT OF THE REACH OF CHILDREN.
8. Remove the evaporator cover and….
9. ….slowly pour onto the evaporator platen the
cleaning solution.
10. With help of a brush dissolve the most resistant and
remote scale deposits in the platen.
11. Set the compressor switch on "O - OFF" position
and …..
PAGE 3/6

12. ….give power to the unit by master switch.( item 4)
NOTA - With the system in CLEANING MODE the
water pump is the only component in operation to
circulate the cleaning solution in the entire water system
13. Let the unit to remain in the CLEANING MODE for
about 20 minutes and switch OFF the machine.
14. Flush out the cleaning solution from the sump
reservoir then…..
15. ….pour onto the evaporator cavity one or two liters
of clean potable water with cc 2 antibacteria
solution (part number 264000 02) to rinse and
sanitize the molds and the spray system.
ON
PAGE 4/6

16. If necessary remove the spray bar and nozzles to
clean them separately then refit them.
17. Set back the master switch to ON. The water pump
is again in operation to circulate the water and the
antibacterial solution in order to rinse the entire
water system .
18. After approx 10 minutes Switch OFF the unit and ….
19. …..fush out the rising water from the sump reservoir.
20. Rotate the Timer so that the microswitches reach
the beginning of the defrost cycle (low part of the
cam) then give power to the unit at master switch.
By doing so the water inlet valve is in this way the
incaming water fill up the water tank.
PAGE 5/6

21. When the water tank is filled up (water flowing out
from the drain) put the compressor switch on I ON
position to restart the machine in the automatic
mode.
22. Re-fit the evaporator cover and the unit service
panels.
23. At completion of the freezing and harvest cycle
make sure of proper texture and clearness of the ice
cubes as well as that, they do not have any acid
taste.
ATTENTION. In case the ice cubes are cloudy , white
and have acid taste, melt them immediately by
pouring on them some warm water.
This to prevent somebody from using them
24. Wipe clean and rinse the inner surfaces of the
storage bin.
REMEMBER. To prevent the accumulation of
undesirable bacteria it is necessary to SANITIZE
THE INTERIOR OF THE STORAGE BIN with an
antialgae disinfectant solution EVERY WEEK
PAGE 6/6
