SIMAG SP Series Manual

ELECTRONIC MODULAR FLAKERS AND
SUPERFLAKERS SP SERIES
CLEANING AND SANITIZING PROCEDURES
TOOLS REQUIRED
1 Medium Phillips Screwdriver
1 Medium Flat Screwdriver
1 Pair of Protective Gloves
1 Bucket/Container
1 Different types of brush
1 Clean Cloth
1 Ice Machine Cleaner/Sanitiser
1 Antialgae Cleaner
FREQUENCE
• Cleaning: Every six months
• Sanitizing: Every month
NOTE. THE FOLLOWING PROCEDURE CAN BE
USED FOR EITHER SANITIZING OR DE-SCALING
THE ICE MACHINE.
NEVER MIX THE SANITIZING SOLUTION WITH THE
DE -SCALING SOLUTION.
IN CASE THE MACHINE NEEDS TO BE SANITISED
AND DE-SCALED, CLEAN THE MACHINE
THOROUGHLY, THEN FIRST DE-SCALE, AND AFTER
PROPER WASHING AND RINSING, DO THE
SANITATION.
WARNING. When using any chemical, protection of
hands and eyes should be worn.
NOTE. De-scaling is recommended every 6 months in
average water hardness conditions, while sanitizing
should take place once a month. Under extreme water
hardness conditions we recommend to de-scale every
two – three months, and to sanitize every two weeks.
Sanitizing regularly will reduce bacteria growth, which is
natural in all water circulation systems as ice machines.
NOTE. Always follow approved Sanitizer / De-scaler
manufacturers instructions when preparing the Sanitizer
/De Scaler solutions.

PROCEDURE
1. Switch OFF the Master disconnect switch on the
power line….
2. Close water tap on the water supply line
NOTE. Be sure that no other equipment in use can
suffer of the turn OFF of water.
3. Scoop out all ice stored into the bin so to
prevent its contamination.
4. Remove the Front/Top panel and also………
OFF
CLOSED
5. ……Side/Rear Panel to again to access….
Page 2/8

6. ……..to the water reservoir.
7. Remove the metal clamp and disconnect the
water tube from the outlet of the water reservoir.
Collect….
8. …..the water into a bucket then…..
9. ….place again the tube on the outlet port.
10. Prepare the cleaning solution by diluting in
a plastic container two or three liters of warm
water (45°-50°C) with a 0,2-0,3 liters of Ice
Machine Cleaner ( on SPN 1205 double the
quantities.
Page 3/8

WARNING. The Ice Machine Cleaner contains
Phosphoric and Hydroxyacetic acids. These
compounds are corrosive and may cause burns if
swallowed, DO NOT induce vomiting. Give large
amounts of water or milk. Call Physician
immediately. In case of external contact flush with
water. KEEP OUT OF THE REACH OF CHILDREN.
11. Remove the water reservoir cover then…...
12. ….slowly pour onto the water reservoir the
cleaning solution.
13. Leave the machine in mode OFF for
approximately 20 minutes so to have the
cleaning solution melting the scales into the
entire water system.
Page 4/8

14. With the help of a brush dissolve the most
resistant and remote scale deposits into the
plastic tube connecting the water reservoir to the
bottom of the freezer.
15. Jump with a wire the two metal pins of the water
level sensor or……
16. ……with a piece of copper wire short the two
metal pins of the water reservoir.
17. After 20 minutes switch ON the Master switch
to start the unit.
ON
18. Few minutes later the Ice Machine start up to
produce and discharge flaker ice ( slash) into
the storage bin
SP 125 - 255
SP 405 - 605 - 1205
Page 5/8

19. As soon as the level of the water into the water
reservoir is going down, slowly poor the
remaining cleaning solution till empty the bucket.
20. The flaker ice made with the cleaning solution is
slushy and coloured also.
NOTE – In this situation can be heard by the
noise made of the ice. Should this occure it
is recommended to stop for few minutes
the ice machine in order to allow the ice in
the freezer to partially melt then restart
again.
21. When all the cleaning solution has been used
up, open the water shutoff valve to allow new
fresh water to flow into the water reservoir. Let
the unit to continue to run until…..
OPEN
22. ……the flaker ice resumes the normal colour
and hardness .
23. When sure that no more trace of cleaning
solution is left into the water system pour 1 cc of
Sanitiser ( Antialgae part number 264000 02)
then switch the unit ON. Let the unit running for
approx 10 minutes.
Page 6/8

24. Remove the jumper between the two metal pins
or ……
25. …..remove the copper wire used to jump the two
sensors for the water level.
26. Place back the correctly the cover on the float
reservoir.
27. Open the storage bin door in order to have
access to the storage bin and to the bottom of
the metal deflector.
vvvvv
28. Place the bucket with cleaning/sanitizing
solution inside the storage bin (this allow you to
freely clean/sanitize the bin) and with sponge
clean/sanitize the bottom of the metal
deflector…..
29. ….as well as all the inside area of the bin
including its drain..
Page 7/8

30. Clean/sanitize the rear side of the bin door.
31. Re-fit the Side/Rear Panel and also …..
32. …the Front/Top Panel.
REMEMBER – To prevent the accumulation of
undesirable bacteria it is necessary to sanitize the
interior of the storage bin with an antialgae
disinfectant solution EVERY WEEK
NOTE – DO NOT use ice produced with the sanitizig
solution
33. Clean the outside of the Ice Machine and the
Storage Bin using a clean damp cloth with
specifics S.S. cleaning product.
Page 8/8
