True CVM Series User manual

TEC_TM_184 | REV. B | EN 07/25/2023
INSTALLATION MANUAL
CVM
True Manufacturing Co., Inc.
C VM -11 CVM-27
INSTALLATION MANUAL
CVM
Original Instructions
True Manufacturing Co., Inc.
2001 East Terra Lane • O’Fallon, Missouri 63366-4434
[phone] • FAX: [phone]
International FAX: [phone] • (800)-325-6152
Parts Department: (800)-424-TRUE (424-8783)
Parts Department FAX: [phone]
North America – Canada and Caribbean
Warranty Phone [phone]
Warranty Fax [phone]
Warranty Email warranty[email protected]
Technical Phone [phone]
Technical Email [e-mail]
7:00 am–6:00 pm CST Monday–Friday,
8:00 am–12:00 pm Saturday
UK, Ireland, Middle East,
Africa & India
Phone: [phone]
Service-[email protected]
8:30 am–5:00 pm M–F
European Union & Commonwealth
of Independent States
Phone: [phone]
service-[email protected]
8:00 am–5:00 pm M–F
Australia
Phone: [phone]
[email protected]
8:30 am–5:00 pm M–F
Mexico
Phone [phone]
service-mexicocit[email protected]
9:00 am–5:30 pm M–F
Latin America
Phone: [phone]
[email protected]
9:00 am–5:30 pm M–F
USER ACTION!
TRUE tracks the history of your appliance by its serial number.
For easy reference, record your appliances full model name and
serial number below. This information is on your serial label.
Serial label location varies by appliance.
Model Name:
Serial Number:
WARNING!
Be sure to read and fully understand this document
before installing, operating, maintaining or servicing
this appliance. Failure to do so can result in appliance
failure, property damage, serious injury or death.
Appliance failure, injury or property damage due to
improper installation is not covered by warranty.

CVM truemfg.com
TEC_TM_184 | REV. B | EN07/25/2023Page 2 of 32 P#852342
THANK YOU
FOR YOUR PURCHASE
Preface
Signal & Symbol Definitions..............................................................3
Important Safety Information
Basic Safety & Operation Warnings...............................................4
Personal Injury Warnings.....................................................................5
Hydrocarbon Refrigerant Warnings..............................................6
Appliance Disposal Warnings...........................................................6
Electrical Safety Warnings...................................................................7
About Your Appliance & Installation Requirements
Appliance Specifications .....................................................................8
Clearances.....................................................................................................8
Electrical Requirements........................................................................9
Electrical Installation & Safety...........................................................9
Installation & Setup
Uncrating.................................................................................................... 10
Appliance Location..............................................................................12
Leveling Screw, Leg or Castor Installation.............................12
Leveling the Appliance......................................................................15
Sealing the Appliance to the Floor............................................15
Shelf Installation.....................................................................................16
Appliance Operation
Startup..........................................................................................................17
Temperature Control & Light Switch Location...................18
General Sequence of Operation.................................................. 19
Maintenance & Servicing
Component Replacement...............................................................21
Recommended Maintenance .......................................................22
Condenser Coil Cleaning.................................................................. 24
General Surface Care & Cleaning................................................ 26
Stainless Steel Care & Cleaning.................................................... 27
8 Tips to Help Prevent Rust on Stainless Steel....................28
Warranty
Warranty...................................................................................................... 29
Congratulations!
The primary purpose of this document is to assist the installation, maintenance, and servicing of your TRUE
appliance. This document contains information important to safety, operation, maintenance, and servicing. DO NOT
discard this document. TRUE is solely the appliance manufacturer. For assistance finding a qualified technician, please
visit our Service Company Locator at truemfg.com/support/service-locator.
NOTICE!
Your appliance may not exactly match the figures shown in this manual.
Contents

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 3 of 32
truemfg.com
Preface
The warning, guidelines, and recommendations within this document are meant to prevent appliance damage, injury, or death. Please
carefully read all warnings, guidelines, and recommendations before proceeding to ensure the continued safe use and maintenance of
your TRUE appliance.
Signal & Symbol Definitions
Below are symbols you may see in this document. Some symbols may not appear.
Signal Word Definitions
DANGER! An imminently hazardous situation which, if not avoided, will result in serious injury or death.
WARNING! A potentially hazardous situation which, if not avoided, can result in serious injury or death.
CAUTION! A potentially hazardous situation which, if not avoided, may result in minor or moderate injury;
an unsafe practice.
USER ACTION! User action alert, follow all recommendations to avoid appliance or product damage.
NOTICE! Important information not related to hazards or risk of personal injury.
Safety Symbols
Safety alert; alerts reader to potential physical
injury hazards. Obey all safety messages following
this symbol to avoid possible injury or death.
Flammable material; fire hazard.
Electrical shock hazard.
Tipping hazard; tip-over hazard.
Sharp element; cut or sever hazard.
Eye hazard; risk of eye injury.
Exploding pressurized cylinder hazard.
Slippery surface hazard.
Crush or cut hazard.
Additional Symbols
Mandatory action alert symbol; alerts reader
to required or recommended actions. Obey all
messages and recommendations following this
symbol to avoid appliance or product damage.
NOTICE ›Important information not related to hazards or
risk of personal injury.
Review and understand the installation manual
before installing, operating, or servicing.
Wear eye protection.
Wear protective gloves.
Secure gas cylinders to prevent falling cylinders.
DO NOT use extension cord.
DO NOT use adaptor plugs.
DO NOT dispose of with other household waste.

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 4 of 32
Important Safety Information
WARNING!
Be sure to read and fully understand this document before installing, operating, maintaining, or servicing this appliance.
Failure to do so can result in appliance failure, property damage, serious injury, or death. Appliance failure, personal
injury, or property damage due to improper installation is not covered by warranty.
• Failure to install, operate, and maintain the appliance as detailed in this document will negatively affect safety, appliance
performance, component life, and warranty coverage.
• The appliance must be installed in accordance with all applicable laws, codes, and regulations.
• The manufacturer cannot be held responsible for injury or damage resulting from improper, incorrect, and unreasonable
use.
• This appliance is not to be used, cleaned, or maintained by persons (including children) with reduced physical, sensory, or
mental capabilities or lack of experience and knowledge, without proper supervision or instruction.
• DO NOT install or operate equipment that has been misused, abused, neglected, damaged, or altered/modified from
original manufactured specifications.
• DO NOT modify or alter the appliance. Improper alterations can result in electric shock, personal injury, fire, or death.
• DO NOT use electrical appliances inside the food storage compartments of the units unless the appliances are approved by
the manufacturer.
• The appliance owner is responsible for performing a Personal Protective Equipment (PPE) Hazard Assessment and to ensure
adequate protection during maintenance and cleaning procedures.
• Use appropriate tools, safety equipment, and PPE during installation and servicing.
• Only use the appliance for its intended purpose as described in this document. Failure to do so may result in equipment
damage, personal injury, or death.
• Overloading, incorrectly installing, or improperly loading shelves can cause shelf failure (as well as negatively affect the
appliance's operation), resulting in appliance damage, product damage, or personal injury.
• Keep the area surrounding the appliance clean to avoid appliance damage from debris or pests.
Important Safety Information
Basic Safety & Operation Warnings
Follow basic safety precautions, including the following, to reduce risk of personal injury, electric shock, fire, or death.

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 5 of 32
truemfg.com
Important Safety Information (cont.)
DANGER!
DO NOT allow children to play with or in the appliance. Child entrapment or personal injury can occur.
DO NOT store or use the following in the vicinity of this or any other appliance:
• Gasoline or other flammable vapors and liquids
• Combustible or explosive substances, such as aerosol cans with a flammable propellant
• Other volatile or flammable substances
Contact TRUE Manufacturing to locate refrigerant lines and electrical wiring before drilling, cutting or puncturing interior
or exterior walls. Failure to do so could result in damage, personal injury, or death.
WARNING!
Only qualified technicians should install and service the appliance.
• Use appropriate tools, safety equipment, and personal protective equipment (PPE) during installation and servicing.
• DO NOT touch the cold surfaces in the freezer compartment when hands are damp or wet. Skin may stick to extremely cold
surfaces.
This product can expose you to chemicals including Di-(2-Ethyl hexyl) Phthalate (DEHP), which is known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to P65warnings.ca.gov.
Slippery Surfaces! Moisture from improper drainage can create slippery surfaces near the appliance. It is your duty to
immediately warn your customers of, and dry, the slippery surface. All wet floor areas must be marked with a wet floor sign.
Sharp edges! Take care when moving, installing, cleaning, servicing, and maintaining the appliance to avoid cuts. Be sure to
take care when reaching under the appliance or handling metal components.
• Keep fingers out of pinch point areas, such as the space between appliance doors and surrounding cabinetry. Take care
closing doors with children nearby.
Tip over hazard! Appliance may pose a tipping hazard when uncrating, installing, or moving the appliance. Take appropriate
safety precautions. Use of tip over restraints may only reduce (not eliminate) the tipping hazard. Never allow children to climb
or hang on drawers, doors, or shelves.
Crush or cut hazard! Keep clear when uncrating, installing, moving, or servicing the appliance.
Risk of electric shock or burn! See "Electrical Safety Warnings" for more information.
Personal Injury Warnings
Only qualified technicians should install and service the appliance. For assistance finding a qualified technician, please visit our Service
Company Locator at truemfg.com/support/service-locator.TRUE is solely the appliance manufacturer and is not responsible for
installation.

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 6 of 32
Important Safety Information (cont.)
DANGER!
Risk of fire or explosion! Flammable refrigerant used.
• All servicing and maintenance must be performed by qualified technicians. This is to minimize the risk of fire or personal
injury due to incorrect parts or improper service.
• Check the serial label to identify the appliance's refrigerant. Serial label location varies by model.
• DO NOT damage the refrigeration system during transportation and installation.
• If the appliance is damaged, verify the refrigeration system's integrity is not compromised before proceeding.
• Never use sharp objects or tools to remove ice or frost. DO NOT use mechanical devices to accelerate defrost.
• Dispose of in accordance with all applicable laws, codes, and regulations. Follow all safety precautions associated with
handling flammable refrigerant.
• DO NOT use electrical appliances inside the food storage compartments of the units unless the appliances are of the type
recommended by the manufacturer.
DANGER!
Risk of child entrapment!
Children can get trapped inside discarded appliances and suffocate. Never dispose
of your appliance without taking precautions to prevent child entrapment, even
if the appliance only sits unattended for a short period of time.
Child entrapment precautions include the following:
• Remove all doors (or drawers for drawer units).
• Leave all interior drawers and shelving in place to make climbing (and fitting)
inside the appliance more difficult.
Risk of fire or explosion! Flammable refrigerant and insulation used. Dispose of in accordance with all applicable laws, codes,
and regulations. Follow all safety precautions associated with handling flammable refrigerant and insulation.
DO NOT dispose of your appliance with household waste.
Hydrocarbon Refrigerant Warnings
TRUE appliances use hydrocarbon refrigerant (R-290/513A/600a). Check the serial label to identify the appliance's refrigerant. Serial label
location varies by model.
Appliance Disposal Warnings

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 7 of 32
truemfg.com
Important Safety Information (cont.)
WARNING!
Risk of electric shock, burn, or fire!
• It is the appliance owner's responsibility to ensure the electrical connection meets all applicable building codes. Failure
to meet these code requirements can result in appliance damage, fire, electric shock or burns, serious personal injury, or
death.
• Before connecting your appliance to the power supply, verify the supply voltage and circuit rating match the appliance.
Correct improper supply voltage or circuit size immediately.
• Before connecting your appliance to the power supply, verify the power supply is correctly grounded. If the power supply
is not grounded, correct immediately. TRUE recommends hiring a qualified electrician to inspect your wall outlet and circuit
to ensure they are properly grounded
• DO NOT clean appliance with a pressure washer or hose. DO NOT immerse power cord in water.
• Powering off an electronic control or setting temperature controls to 0 (off position) does not remove power from all
components. Unplug the appliance or turn off the power supply before installation or servicing.
• The appliance should receive power from its own individual dedicated electrical circuit. This provides the best performance
and prevents overloading the power supply.
• The original equipment manufacturer (OEM) power cord has a grounding plug to minimize the possibility of electrical
shock.
• Never remove the ground prong from the power cord! For personal safety, this appliance must be properly grounded.
• Never use an extension cord! An extension cord is any component that adds length to the OEM power cord when
connecting the cord to a power source.
• Never use an adapter plug! An adapter plug alters the OEM plug configuration when connecting the plug to a power
source.
• Never use a power cord that shows cracks or abrasion damage along its length or at either end.
• Immediately have a qualified technician replace damaged OEM power cords with OEM components.
• Never unplug your appliance by pulling on the power cord. Always grip the plug and pull the plug straight out of the
outlet.
• Take care to prevent rolling over or damaging the power cord when moving the appliance.
• Never use the power cord to prevent appliance movement. Always use adequate means to keep the appliance in place
without transmitting stress to the power cord.
• Keep power cord away from heated surfaces.
• DO NOT let power cord hang over edge of table or counter.
• DO NOT excessively bend or place heavy articles on the power cord.
NOTICE!
TRUE will not warranty the following:
• Compressor failures due to improper incoming voltage.
• Appliance with tampered OEM power cords.
• Appliance connected to adapters or extension cords.
For more details, see TRUE's full warranty statement.
Electrical Safety Warnings

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 8 of 32
Thank you for choosing TRUE Manufacturing to meet your
refrigeration needs. TRUE highly recommends a qualified
technician and electrician install your appliance to ensure correct
installation. The cost of professional installation is money well
spent. Only qualified technicians should install and service the
appliance.
For assistance finding a qualified technician, please visit our Service
Company Locator at truemfg.com/support/service-locator.TRUE
is solely the appliance manufacturer and is not responsible for
installation.
The appliance owner is responsible for proper installation and
maintaining the appliance as described in this document. Routine
care and maintenance procedures are not covered by TRUE's
warranty. Clearances
MODEL TOP SIDES BACK
CVM-11/13 1"
(25.4 mm)
0"
(0 mm)
1"
(25.4 mm)
CVM-27 0"
(0 mm)
0"
(0 mm)
1"
(25.4 mm)
About Your Appliance & Installation Requirements
About Your Appliance & Installation Requirements
USER ACTION!
TRUE is not responsible for damage incurred during
shipment. Always carefully inspect for freight damage
before receiving and installing your appliance. If
there is damage, note all damage on the delivery
receipt, immediately file a claim with the delivery
freight carrier, and contact TRUE. Do not install the
appliance or put it in service.
Appliance Specifications
Some things to know about your appliance are as follows:
• Appliance is not for the storage and/or display of potentially
hazardous foods when the temperature control is set above
41˚F (5˚C).
• Appliance is not suitable for outdoor use, unless otherwise
stated on the serial label.
• Appliance is not suitable for an area where a pressure washer
or hose may be used.
• Always plug the appliance into its own individual dedicated
electrical circuit!
• DO NOT use extension cords or adapter plugs.
Be sure your unit has the required surrounding clearances for
ventilation purposes. Keep all ventilation openings in the appliance
enclosure or structure housing the appliance clear of obstruction.
NOTICE!
Warranty is void if ventilation is insufficient.
• Before connecting your appliance to the power supply,
verify the incoming voltage (±5%) and the amps match the
operation ratings on the appliance's serial label. Correct
improper incoming voltage or amps immediately. Serial label
location varies by model.
• Before connecting your appliance to the power supply, verify
the power supply is correctly grounded. If the power supply
is not grounded, correct immediately.
• Ensure the installation location will provide adequate
clearances and sufficient airflow for the cabinet. See
"Clearances". (pg. 8)
• Read and follow all warnings and maintenance instructions.
Failure to do so may result in damage and void the warranty
on your appliance.
Clearances

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 9 of 32
truemfg.com
Electrical Requirements
Wire gauge chart (115V)
115
Volts Distance in Feet to Center of Load
AMPS 20 30 40 50 60 70 80 90 100 120 140 160
214 14 14 14 14 14 14 14 14 14 14 14
314 14 14 14 14 14 14 14 14 14 14 12
414 14 14 14 14 14 14 14 14 12 12 12
14 14 14 14 14 14 14 12 12 12 10 10
614 14 14 14 14 14 12 12 12 10 10 10
714 14 14 14 14 12 12 12 10 10 10 8
814 14 14 14 12 12 12 10 10 10 8 8
914 14 14 12 12 12 10 10 10 8 8 8
10 14 14 14 12 12 10 10 10 10 8 8 8
12 14 14 12 12 10 10 10 8 8 8 8 6
14 12 12 12 10 10 10 8 8 8 6 6 6
16 12 12 12 10 10 8 8 8 8 6 6 6
18 12 12 10 10 8 8 8 8 8 8 8 5
20 12 12 10 10 8 8 8 6 6 6 5 5
25 10 10 10 8 8 6 6 6 6 5 4 4
30 10 10 8 8 6 6 6 6 5 4 4 3
Wire gauge chart (230V)
230
Volts Distance in Feet to Center of Load
AMPS 20 30 40 50 60 70 80 90 100 120 140 160
514 14 14 14 14 14 14 14 14 14 14 14
614 14 14 14 14 14 14 14 14 14 14 12
714 14 14 14 14 14 14 14 14 14 12 12
814 14 14 14 14 14 14 14 14 12 12 12
914 14 14 14 14 14 14 14 12 12 12 10
10 14 14 14 14 14 14 14 12 12 12 10 10
12 14 14 14 14 14 14 12 12 12 10 10 10
14 12 12 12 12 12 12 12 12 10 10 10 8
16 12 12 12 12 12 12 12 10 10 10 8 8
18 12 12 12 12 12 12 10 10 10 8 8 8
20 12 12 12 12 10 10 10 10 10 8 8 8
25 10 10 10 10 10 10 10 10 8 8 6 6
30 10 10 10 10 10 10 8 8 8 6 6 6
Fig. 1. Fully insert the power cord into
the receptacle.
Fig. 2. Push the red button to remove
the plug.
Electrical Installation & Safety
NEMA Plug Configurations
60 HZ USE ONLY!
TRUE uses these types of NEMA plugs shown. If you DO NOT have
the proper outlet, have a licensed electrician verify and install the
correct power source.
International (IEC) Plugs Only
International appliances may be supplied with a power cord that
will require installation. Install this cord before connecting the
appliance to a power source.
NOTICE ›International plug configurations will vary by country
and voltage.
Installation
Fully seat the power cord into the appliance receptacle until it
locks in position. See fig. 1.
Removal
Depress the red button. See fig. 2.
Electrical Requirements
USER ACTION!
Find a copy of the wiring diagram with our serial number
lookup at
truemfg.com/support/serial-number-lookup

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 10 of 32
Installation & Setup
Installation & Setup
WARNING!
The appliance owner is responsible for performing
a Personal Protective Equipment (PPE) hazard
Assessment and to ensure adequate protection during
maintenance and cleaning procedures.
Use appropriate tools, safety equipment, and PPE
during installation and servicing.
Sharp edges! Take care when moving, installing,
cleaning, servicing and maintaining the appliance to
avoid cuts. Be sure to take care when reaching under
the appliance or handling metal components. Keep
fingers out of pinch point areas, such as the space
between appliance doors and surrounding appliances.
Take care closing doors with children nearby.
Risk of electrical shock or burn! Powering off an
electronic control or setting temperature controls to
the 0 (off) position does not remove power from all
components. Unplug the appliance or turn off the
power supply before installation or servicing.
Tip over hazard! Appliance may pose a tipping hazard
when uncrating, installing or moving the appliance.
Take appropriate safety precautions. Use of tip over
restraints may only reduce (not eliminate) the tipping
hazard. Never allow children to climb or hang on
drawers, doors or shelves.
Crush or cut hazard! Keep clear when uncrating,
installing, moving, or servicing the appliance.
Uncrating
Required Tools
Required tools include (but may not be limited to) the following:
• Adjustable wrench
• Phillips screwdriver
USER ACTION!
• If the appliance is damaged, note all damage on
the delivery receipt, immediately file a claim with
he delivery freight carrier, and contact TRUE. DO
NOT install the unit or put it in service.
• If the unit laid on its back or side, be sure to leave
the unit upright twice the time it has been laying
down (up to four (4) hours) before plugging the
unit into a power source. If this time exceeds
four (4) hours, let the unit sit upright for 24 hours
before powering the unit.
NOTICE!
Keys for appliances with door locks are located in the
warranty packet.

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 11 of 32
truemfg.com
Installation & Setup (cont.)
Fig. 1. Remove the exterior packaging.
Fig. 2. Example of shipping bolt locations.
Fig. 3. Rotate the appliance on the skid. When lifting the appliance, do not use
countertops, doors/drawers, or grills as lifting points.
Procedure
1. Remove the outer packaging (cardboard and bubble wrap or
Styrofoam corner and clear plastic). See fig. 1.
2. With an adjustable wrench, remove all shipping bolts securing
the wood skid to the bottom of the appliance. See fig. 2.
NOTICE ›Move the appliance as close as possible to
the final location before removing the wooden skid. Your
appliance may require removing the front and/or rear grill/
cover to access the shipping bolts.
3. If leveling legs or castors will not be used, remove the cabinet
from the wood skid and set the skid aside.
If leveling legs or castors will be used, rotate the cabinet on
the skid (see fig. 3) and see leveling leg or castor installation
instructions (pg. 12).
NOTICE ›DO NOT lift the appliance by the counter tops,
doors, drawers, or grills.

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 12 of 32
Leveling screws assist the leveling of the cabinet. Adjustable legs
provide 6" (153 mm) of clearance under cabinet. Castors provide
cabinet mobility. Always use shims when adjusting castors.
Appliance Location
• Ensure that the drain hose or hoses are positioned in the pan.
• Free the plug and cord from inside the lower rear of the
cooler (DO NOT plug in).
• Place the appliance close enough to the electrical supply so
that extension cords are never used.
Leveling Screw, Leg, or Castor Installation
Installation & Setup (cont.)
WARNING!
Tipping hazard! Incorrect installation of leveling legs
or castors can cause a tipping hazard.
ALWAYS be sure leveling legs or castors (and shims)
are snug against the rail assembly or mounting plate.
Fig. 1. Leveling screw.
Fig. 2. Turn the leveling screws clockwise to lower the unit.
Fig. 3. Turn the leveling screws counterclockwise to raise the appliance.
Procedure – Leveling Screws
If leveling screws are not factory installed, then, with access to the
appliance bottom, install the leveling screws into the threaded
holes in the frame rail or appliance bottom. See figs. 1-3.
A
A
B
B

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 13 of 32
truemfg.com
Fig. 5. Screw the leveling legs into the threaded holes.
Fig. 4. Leveling leg diagram.
Fig. 7. Castor diagram.
Fig. 6. Turn the bottom stem to level the appliance.
Lower Rail Assembly
Snug Fit
Here
Rail End
Bottom Stem
Installation & Setup (cont.)
Fig. 8. Screw the castors into the
threaded holes.
Fig. 10. Install multiple shims with offset
slots.
Fig. 9. Insert the castor shim(s). be sure
to tighten the castor stem.
Leveling
Shim
Lower Rail Assembly
Bearing
Race
Snug Fit
Here
Rail End
Castor
Castor
Stem
Procedure – 6" (152 mm) Leveling Legs
1. Access the appliance bottom.
2. If present, remove the leveling screws.
3. Thread the leveling legs into the frame rail or appliance
bottom. See figs. 4 and 5.
4. Verify that the appliance is level. See “Leveling the Appliance”
(pg. 15).
5. If the appliance is not level, gently lift and support the low end
of the appliance. Then, with an adjustable wrench, screw the
leveling leg bottom stems in or out to level and support the
appliance. See fig. 4 and 6.
Castors
USER ACTION!
Install castors with brakes in the front
1. Access the appliance bottom.
2. If present, remove the leveling screws.
3. Thread the castors into the frame rail or appliance bottom. See
figs. 7 and 8.
4. Verify the appliance is level. See “Leveling the Appliance”
(pg. 15).
5. If the unit is not level, on the low end of the appliance, loosen
the castor bolt enough to slide provided castor shims between
the castor bearing and the bottom rail of the appliance. See
fig. 9.
6. Install the desired number of shims. See fig. 9.
• If more than one shim is used, be sure shim slots are offset.
See fig. 10.
• DO NOT use more than four (4) shims on a castor.
• Be sure each shim touches the castor stem.
7. Tighten and secure the shims and castors.
8. Verify the appliance is level.
9. If the appliance is not level, repeat the steps 3-6 until the
appliance is level and supported.

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 14 of 32
Installation & Setup (cont.)
Low Profile Castors (CVM-11/13)
1. Access the appliance bottom.
2. Position the low-profile castor in the rail assembly. See fig. 11.
3. Insert the castor pin through the rail assembly and the low-
profile castor. See fig. 12.
4. Install the retaining ring. See fig. 13.
5. Repeat steps 2-4 for remaining low profile castors.
6. Lower front leveling legs until they contact the floor.
Fig. 11. Position the castor.
Fig. 13. Install retaining ring.
Fig. 12. Insert the pin.
WARNING!
Tipping hazard! Always verify front leveling legs
contact the floor if low profile castors are present.

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 15 of 32
truemfg.com
Installation & Setup (cont.)
Proper leveling of your TRUE appliance is critical to operating
success (for non-mobile appliances). Leveling impacts effective
condensate removal and door operation.
See "Leveling Screw, Leg or Castor Installation" (pg. 12) for level
adjustment and shimming information.
Procedure
Position the appliance in its final installation location. Then, level
the appliance front-to-back and side-to-side. See fig. 1.
1. Position the level on the inside floor of the unit near the doors
(level parallel to appliance front). Level the appliance.
2. Position the level at the inside rear of cabinet (level parallel to
appliance back). Level the appliance.
3. Position the level on the left and right inside floor (level parallel
to appliance sides). Level the appliance.
Leveling the Appliance Sealing the Appliance to the Floor
The following procedure describes sealing a non-mobile appliance
to the floor for NSF standards. This may not be required for your
application.
Procedure
1. Position the appliance in its final installation location. Be sure
to leave adequate clearance between the back and sides per
"Clearances" (pg. 8) to ensure proper ventilation.
2. Level the appliance front-to-back and side-to-side. See
“Leveling the Appliance” (pg. 15).
3. Draw an outline of the appliance base on the floor.
4. Raise and block the front side of the appliance.
5. Apply a bead of NSF-approved sealant (see list below) to the
floor, 1/2" (13 mm) inside the front part of the outline drawn in
step 3. The bead of sealant must be heavy enough to seal the
entire appliance surface when the appliance is lowered on top
of the sealant.
6. Raise and block the rear of the appliance.
7. Apply sealant to the floor on the other three sides, as outlined
in step 5.
8. Examine the appliance to ensure that it is sealed to the floor
around the entire perimeter.
NSF-Approved Sealants
• 3M #ECU800 Caulk
• 3M #ECU2185 Caulk
• 3M #ECU1055 Bead
• 3M #ECU1202 Bead
• Armstrong Cork – Rubber Caulk
• Products Research Co. #5000 Rubber Caulk
• G.E. Silicone Sealer
• Dow Corning Silicone Sealer
USER ACTION!
Asphalt floors are susceptible to chemicals. TRUE
recommends installing a layer of tape between the
asphalt and the sealant to protect the floor.
Fig. 1. Measure the level along the perimeter of the interior floor.

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 16 of 32
Installation & Setup (cont.)
Installation Tips
• Install all the shelf clips before installing any shelves.
• Start at the bottom shelf and work your way up.
• Always lay the back of each shelf down on the rear clips
before the front.
Procedure
1. Hook the shelf clips into the shelf standards. See fig. 1.
2. Push up on the bottom of the clip. See fig. 2.
NOTICE ›You may need to squeeze or twist the bottom of
the shelf clip for proper installation. Position all four shelf clips
equal in distance from the floor for flat shelves.
3. Ensure the shelf clip is not loose or able to wiggle out of the
shelf standard. See figs. 3 and 4.
4. Place the shelves on the shelf clips with the cross support bars
facing down.
NOTICE ›Be sure all shelf corners are properly seated.
Shelf Adjustment
Shelving is adjustable for customer application. This appliance
meets the IEC Shelf Weight Capacity of 47lb/ft²(230kg/m²).
Shelf Installation
Fig. 1. Installing top tab of shelf clip. Fig. 2. The bottom tab of the shelf clip
will fit tightly.
Fig. 3. You may need to squeeze or twist
the bottom of the shelf clip to install.
Fig. 4. Installed shelf clip.
Fig. 5. Installed shelf clip..
Shelf
Clip
Shelf
Shelf
Organizer
Pillaster
(I-beam)
Shelf
Standards
Retainer
Clip
Air ow
Guard
WARNING!
Overloading, incorrectly
installing, or improperly
loading shelves can cause
shelf failure and negatively
affect appliance operation,
resulting in appliance damage,
product damage, or personal injury.
DO NOT use pliers or any crimping tools when
installing shelf clips. Altering shelf clips in any way can
lead to shelving instability.
TrueTrac Organizers
TrueTrac Organizers provide a neat and consistent product
presentation.
Install the provided shelf retainer clips on the side of the organizer
towards the rear. See fig. 5.

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 17 of 32
truemfg.com
Appliance Operation
• The compressor is ready to operate when the appliance is
purchased. All you need to do is plug in the appliance.
• Good air flow inside your TRUE appliance is critical. Take care
to prevent product from pressing against the sides or back
wall and coming within 4" (101.6 mm) of the evaporator
housing. Refrigerated air off the evaporator coil must circulate
throughout the appliance for even product temperatures.
• Excessive tampering with the control could lead to service
difficulties. If replacing the temperature control is ever
needed, be sure to order the replacement from your TRUE
dealer or recommended service agent.
• All covers and access panels must be in place and properly
secured before operating this appliance.
Startup
Appliance Operation
USER ACTION!
Before loading product, run your TRUE appliance
empty for 24 hours to verify proper operation.
Remember, our factory warranty DOES NOT cover
product loss!
WARNING – SPOILAGE!
The owner is solely responsible for
ensuring safe holding temperature
levels for all food items. Failure to do so
may result in unsafe food products. Loss or spoilage
of products in your appliance is not covered by
warranty. In addition to following recommended
installation procedures, run the appliance for 24 hours
prior to usage to verify operation.

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 18 of 32
Temperature Control & Light Switch Location
The light symbol shows the approximate location of the light switch.
ECO°C
°F
ECO°C
°F
Light Switch
Inside the top ceiling.
Electronic Temperature Control
Behind the rear grill.
Appliance Operation
Electronic Temperature Control
On the front of grill.

CVM
TEC_TM_184 | REV. B | EN 07/25/2023 Page 19 of 32
truemfg.com
Appliance Operation
General Sequence of Operation — Refrigerator and Freezer Appliances
When the appliance is plugged in:
• Interior lights will illuminate on glass door models (see Temperature Control & Light Switch location, pg. 18).
• An electronic control with digital display will illuminate (if installed).
• There may be a short delay before the compressor and/or evaporator fan(s) start. This delay may be determined by time or by
temperature, which could be the result of an initial defrost event that will last at least six (6) minutes.
• The temperature control/thermostat may cycle the compressor and evaporator fan(s) on and off together. Every appliance will
require a defrost event to ensure the evaporator coil remains clear of frost and ice buildup. Defrost is initiated by a defrost timer
or by the electronic control.
EXCEPTION – Models TSID, TDBD, TCGG, and TMW do not have an evaporator fan(s).
• The temperature control/thermostat senses either an evaporator coil temperature or air temperature, NOT product temperature.
• An analog thermometer, digital thermometer, or electronic control display may reflect the refrigeration cycle swings of up and
down temperatures, NOT product temperature. The most accurate method to determine a appliance's operation is to
verify the product temperature.
• Refrigerators with mechanical temperature controls will defrost during every compressor off-cycle.
• Freezers with mechanical temperature controls will defrost by time initiation as determined by a defrost timer.
EXCEPTION – Models TFM, TDC, THDC and TMW require a manual defrost. The frequency of this manual defrost will depend
on the appliance's usage and ambient conditions.
• An electronic control with a digital display (if installed) will show dEF during defrost.
NOTICE ›The display may have a short delay before showing a temperature after a defrost event has expired and instead
show dEF during a refrigeration cycle.
• Models with an analog or digital thermometer may show higher than normal temperatures during defrost.
• A refrigerator will use the evaporator fans to clear the coil during defrost.
EXCEPTION – Models TSID, TDBD, and TCGG do not have an evaporator fan(s).
• A freezer will use heaters to clear the evaporator coil during defrost.
NOTICE ›The evaporator coil heater and drain tube heater are only energized during defrost. Defrost is terminated when a
specific evaporator coil temperature is reached or by a time duration.
USER ACTION!
For more information regarding a appliance's temperature control adjustment or general sequence of operation,
please see our Temperature Control Adjustment—Sequence of Operation Manual in our resource library at
truemfg.com/service-manuals/sequence-of-operation or scan the QR code.

CVM truemfg.com
TEC_TM_184 | REV. B | ENP#85234207/25/2023Page 20 of 32
Maintenance & Servicing
WARNING!
• Only qualified technicians should install and
service the appliance. For assistance finding
a qualified technician, please visit our Service
Company Locator at truemfg.com/support/service-
locator.
• Turn off and lockout all utilities (gas, electric,
water) according to approved practices during
maintenance or servicing.
The appliance owner is responsible for performing
a Personal Protective Equipment (PPE) Hazard
Assessment and ensuring adequate protection during
maintenance and cleaning procedures.
Use appropriate tools, safety equipment, and PPE
during installation and servicing.
Sharp Edges!
• Take care when moving, installing, cleaning,
servicing, and maintaining the ice machine to avoid
cuts. Be sure to take care when reaching under the
ice machine or handling metal components.
• Stay clear of pinch point areas, such as the space
between appliance doors and surrounding
cabinetry. Take care closing doors with children
nearby.
WARNING!
Risk of electric shock or burn!
• Powering off an electronic control or setting
temperature controls to the 0 (off) position DOES
NOT remove power from all components. Unplug
the appliance or turn off the power supply before
installation or servicing.
• DO NOT clean appliance with a pressure washer or
hose.
Flammable refrigerant/insulation used! Have a
licensed service provider service your unit to minimize
the risk of possible ignition due to incorrect parts or
improper service and to ensure the operator's health
and safety.
Crush or cut hazard! Keep clear when uncrating,
installing, moving, or servicing the appliance.
Slippery Surfaces! Moisture from improper drainage
can create slippery surfaces near the appliance. It is
your duty to immediately warn your customers of, and
dry, the slippery surface. All wet floor areas must be
marked with a wet floor sign.
Maintenance & Servicing
