Sime MURELLE HM 35 R (M) User manual

INSTALLER INSTRUCTIONS
CONTENTS
1 DESCRIPTION OF THE BOILER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 76
2 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 80
3 CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 96
4 USE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 103
IMPORTANT
When carrying out commissioning of the boiler, you are highly recommended to perform the following checks:
–
Make sure that there are no liquids or inflammable materials in the immediate vicinity of the boiler.
– Make sure that the electrical connections have been made correctly and that the earth wire is connected to a
good earthing system.
– Open the gas tap and check the soundness of the connections, including that of the burner.
– Make sure that the boiler is set for operation for the type of gas supplied.
– Check that the flue pipe for the outlet of the products of the combustion is unobstructed and has been properly
installed.
– Make sure that any shutoff valves are open.
– Make sure that the system is charged with water and is thoroughly vented.
– Check that the circulating pump is not locked.
– Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve on the gas
valve inlet.
–
The installer must provide the user with instruction in operation of the boiler and safety devices and hand over the
instruction booklet to the user.
FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the CE
mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of 110°C,
are not subject to application of PED Directive 97/23/CEE as they meet the requirements of article 1 paragraph
3.6 of the Directive.
MURELLE HE 35 R (M) - ENGLISH

76
1.1 INTRODUCTION
MURELLE HM 35 R (M) are premixed gas
condensation for heating only with wide
range of power modulation (from 20% to
100% of power) designed for single installa-
tion and in modular systems with several
generators connected in sequence/casca-
de and independent from each other.
MURELLE HM 35 R (M) are compliant
with European Directives 2009/142/CE,
2004 / 108/C E, 200 6/95 /CE an d
92/42/CE.
For optimum installation and operation,
always follow the instructions provided in
this manual.
1 DESCRIPTION OF THE BOILER
70 70 85100
S3 G M R
44
60
124
701
130
450
350
90
S3
168
G M R
CS CA
Fig. 1
FIXTURES
R C.H. return G 3/4” (UNI - ISO 228/1)
M C.H. flow G 3/4” (UNI - ISO 228/1)
G Gas connection G 3/4” (UNI - ISO 228/1)
S3 Condensation outlet ø 25
CA Inlet ø 80
CS Outlet ø 60
1.2 DIMENSIONS (fig. 1)

MURELLE HE 35 R (M)
Heat output
Nominal (80-60°C) kW 33.8
Nominal (50-30°C) kW 37.2
Reduced G20 (80-60°C) kW 3.2
Reduced G20 (50-30°C) kW 3.7
Reduced G31 (80-60°C) kW 5.5
Reduced G31 (50-30°C) kW 6.4
Heat input nominal kW 34.8
Heat input reduced G20/G31 kW 3.48/6.0
Max/min useful yield (80-60°C) % 92.0/97.2
Max/min useful yield (50-30°C) % 106.3/106.8
Useful yield at 30% of the load (40-30°C) % 107
Termal efficiency (CEE 92/42 directive) ««««
Losses after shutdown to 50°C (EN 483) W 108
Supply voltage V-Hz 230-50
Adsorbed power consumption with fixed/modulating pump (M) W 140/105
Electrical protection grade IP X4D
C.H. setting range °C 20/80
Water content boiler l 2.65
Maximum water head bar 3.5
Maximum temperature °C 85
Capacity of the heating expansion vessel l --
Pressure of the heating expansion vessel bar --
D.H.W. setting range °C --
D.H.W. flow rate (EN 625) l/min --
Continuous D.H.W. flow rate ∆t 30°C l/min --
Minimum D.H.W. flow rate l/min --
D.H.W. pressure min/max bar --
D.H.W. pressure min. nom. power bar --
Exhaust fumes temperature at max flow rate (80-60°C) °C 70
Exhaust fumes temperature at min. flow rate (80-60°C) °C 60
Exhaust fumes temperature at max flow rate (50-30°C) °C 40
Exhaust fumes temperature at min. flow rate (50-30°C) °C 33
Smokes flow min/max kg/h 6/59
CO2at max/min flow rate G20 % 8.4/9.3
CO2at max/min flow rate G31 % 10.0/10.2
CE certification n° 1312CM5630
Category II2H3P
Type B23P-53P/C13-33-43-53-83
NOx emission class 5 (< 30 mg/kWh)
Weight when empty kg 32
Main burner nozzle
Quantity nozzles n° 2
G20 nozzle diameter diversified ø 3.5/4.0
G31 nozzle diameter diversified ø 2.8/3.0
Consumption at maximum/minimum flow rate
Maximum G20 m3/h 3.68
Minimum G20 m3/h 0.39
Maximum G31 kg/h 2.70
Minimum G31 kg/h 0.46
Gas supply pressure
G20/G31 mbar 20/37
1.3 TECHNICAL FEATURES
77
ES
PT
ENG

78
1.4 FUNCTIONAL DIAGRAM (fig. 2)
Fig. 2
KEY
1 Fan
2 Primary exchanger
4 C.H. flow sensor (SM)
5 Gas valve
6 Safety thermostat 100°C
7 Aqua Guard Filter System
8 By-pass
10 Pump with air release vent
11 C.H return sensor (SR)
13 Condensate drain tap
14 Safety valve 3 bar
15 Pressure transducer
16 Boiler discharge
CONNECTIONS
R C.H. return
M C.H. flow
G Gas connection
S3 Condensation outlet

79
ES
PT
ENG
1
2
3
4
5
6
7
89
10
11
12
13
14
Fig. 3
1.5 MAIN COMPONENTS (fig. 3)
KEY
1 Control panel
2 Aqua Guard Filter System
3 Condensate drain tap
4 C.H. flow sensor (SM)
5 Safety thermostat
6 Ignition electrode
7 Primary exchanger
8 Limit thermostat
9 Sensor fumes (SF)
10 Detection electrode
11 Fan
12 C.H return sensor (SR)
13 Automatic air vent
14a Pump system fixed
14b Modulating pump system
15 Air release vent

80
The boiler must be installed in a fixed loca-
tion and only by specialized and qualified
firms in compliance with all instructions
contained in this manual.
Furthermore, the installation must be in
accordance with current standards and
regulations.
2.1 INSTALLATION
2.1.1 Single boiler
– Boilers can be installed in all domestic envi-
ronments without any whatsoever limit in
terms of location and comburent air supply.
–
These boilers can also be installed in par-
tially covered areas, as per EN 297, with a
maximum ambient temperature of 60°C
and a minimum ambient temperature of -
5°C. It is generally advisable to install the
boilers below weathered roofs, on the bal-
cony or in a protected niche, to protect
them from exposure to weathering agents
(rain, hail and snow). All boilers provide a
standard antifreeze function.
2.1.2 Sequence/cascade boilers
(fig. 4/a)
In the event of sequence/cascade installa-
tion, you must modify for every single boiler
of the main unit the following installing
parameters:
- PAR 1 = 4
(for G20 NATURAL GAS boilers)
- PAR 1 = 12
(for G31 PROPANE boilers)
Refer to section 3.3 to access the INSTAL-
LER PARAMETERS section.
ATTENTION: In sequence/cascade instal-
lations, it is mandatory to arrange the
thermal system with the hydraulic sepa-
rator and safety devices.
The boiler is provided with the board RS-
485 that permits to manage up to 8 boilers
in cascade and communication in MODBUS.
The board is placed on the back of the con-
trol panel.
Access the board and chose the desired
operating mode (CASCADE or MODBUS) by
selecting the DIP SWITCH of the board as
indicated in figure 4/a.
CASCADE mode (fig. 4/b)
Electrically connect all the boilers that form
the modular cascade thermal system and
set installer parameters PAR 15 on every
single boiler as indicated in fig. 4/b.
2 INSTALLATION
DIP SWITCH
GESTIONE IN CASCATA
123
CASCADE MANAGEMENT
DIP SWITCH
GESTIONE IN MODBUS
MODBUS MANAGEMENT
12 3
ON
12 3
ON
x 2
Fig. 4/a

81
ES
PT
ENG
SCHEDA CALDAIA (MASTER)
DIP SWITCH
SCHEDINO RS-485
SCHEDA CALDAIA (SLAVE 1)
DIP SWITCH
SCHEDA CALDAIA (SLAVE ...)
DIP SWITCH
123
CONNETTORE
CABLATO CN10
(cod. 6319165
SCHEDINO RS-485
SCHEDINO RS-485
CONNETTORE
CABLATO CN10
(cod. 6319165)
CONNETTOR
E
CABLATO CN10
(
cod. 6319165
)
123 4 5 6
123 4 5 6
123 4 5 6
X5 X5
WIRED
CONNECTOR CN10
(code 6319165)
RS-485 BOARD
RS-485 BOARD
RS-485 BOARD
WIRED
CONNECTOR CN10
(code 6319165)
WIRED
CONNECTOR CN10
(code 6319165)
BOILER BOARD (SLAVE ...)BOILER BOARD (SLAVE 1)BOILER BOARD (MASTER)
Pmin Pm x
TS
KIT SICUREZZE ISPESL
(solo per mercato Italia)
ON
123
ON
123
ON
SONDA ESTERNA (SE) EXTERNAL SENSOR (SE)
SONDA MANDATA CASCATA (SMC) CASCADE SUPPLY PROBE (SMC)
CARATTERISTICHE CAVO:
- 3 fili di sezione almeno AWG24 - Schermato e twistato - Impedenza caratteristica almeno 100 Ω
CHARACTERISTICS
OF ELECTRIC CABLE:
IN CASO DI LUNGHEZZA DEL CAVO L > 100 m, allora inserire 2 resistenze da 120 Ω.
-
3 wires of 24 AWG
- Screened and twisted - Characteristic impedance 100 Ω
IF THE LENGTH OF CABLE L > 100 m, then add 2 resistors of 120 Ω.
Resistenza 120 Ω
Resistor120 Ω
Resistenza 120 Ω
Resistor 120 Ω
–
+
GND
–
+
GND
–
+
GND
–
+
GND
–
+
GND
–
+
GND
Fig. 4/b
INSTALLER PARAMETER SETTING: PAR 15 CASCADE ADDRESS
-- = Not enabled 0 = Master 1...7 = Slave from 1 to 7 (ATTENTION: Avoid assigning the same number to SLAVE boilers)
NOTE: The external temperature sensor (SE) must be connected to the MASTER sensor and the cascade delivery sensor (SMC) to boiler SLAVE 1. The board sensors and connection cables are pro- vided in a kit upon request code 8092250.

82
MODBUS mode (fig. 4/c)
The RS-485 board can be used for MOD-
BUS communication of every MURELLE HE
35 R (M) boiler.
In this case, proceed as follows:
- Set the DIP SWITCH of the RS-485
board and the PAR 16 as indicated in the
figure.
- Choose the communication configuration
suited to the MODBUS network (PAR 17
INST) according to Table PAR 17 INST.
CASCADE+MODBUS mode (fig. 4/d)
This mode allows for MODBUS communica-
tion of at least two boilers in cascade and is
performed by requesting another RS-485
board provided in the kit code 8092244.
SCHEDA CALDAIA
DIP SWITCH
SCHEDINO RS-485
123
CO
NNETT
O
R
E
C
ABLAT
O
C
N1
0
(
cod. 6319165
)
123 4 5 6
WIRED CONNECTOR
CN10
(code 6319165)
COMUNICAZIONE MODBUS
MODBUS COMMUNICATION
RS-485 BOARD
/ BOILER BOARD
ON
–
+
GND
–
+
GND
Fig. 4/c
11200 8No 1
21200 8No 2
31200 8Pari / 1
41200 82
51200 8Dispari / 1
61200 82
72400 8No 1
82400 8No 2
92400 81
10 2400 82
11 2400 81
12 2400 82
13 4800 8No 1
14 4800 8No 2
15 4800 81
16 4800 82
17 4800 81
18 4800 82
19 9600 8No 1
20 9600 8No 2
21 9600 81
22 9600 82
23 9600 81
24 9600 82
25 19200 8No 1
26 19200 8No 2
27 19200 81
28 19200 82
29 19200 81
30 19200 82
PAR 17 INST Baud Rate N° Bit Dati Parità Bit di Stop
Par 17 INST Baud Rate No. Data Bit Parity Stop Bit
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Even
Even
Even
Even
Even
Even
Even
Even
Even
Even
Odd
Odd
Odd
Odd
Odd
Odd
Odd
Odd
Odd
Odd
TABELLA PAR 17 INST/ Tab. PAR 17 INST
INSTALLER PARAMETER SETTING:
PAR 16 MODBUS ADDRESS
-- = Not enabled
1...31 = Slave from 1 to 31
(ATTENTION: Avoid calling the boi-
ler with the same number assigned
to either appliances)
PAR 17 MODBUS CONFIGURATION
-- = Not enabled
1...30 =
Default value: 25
(See Table PAR 17 INST)
ATTENTION: Upon setting the parameters, we
recommend turning the boiler off and then back on
again.

83
ES
PT
ENG
Modbus address
Variable description
Type
Read /Write
U.M.
Min
value
Max
value
Function
Di
g
ital variables
1 Boiler CH Enable/Re
q
uest D R/W - 0 1 Richiesta riscaldamento zona 1
2 Boiler DHW Enable D R/W - 0 1 Abilitazione preparazione ACS
3 Boiler Water Fillin
g
Function D R/W - 0 1 Non usato
32 Boiler CH Mode D R - 0 1 Stato riscaldamento zona 1
33 Boiler DHW Mode D R - 0 1 Stato
p
re
p
arazione ACS
34 Boiler Flame Status D R - 0 1 Stato
p
resenza fiamma
35 Boiler Alarm Status D R - 0 1 Stato
p
resenza allarme
Analo
g
variables
1 Boiler CH Primary Setpoint A R/W 0,1°C 20,0 80,0
Setpoint riscaldamento zona 1.
Se viene ricevuto un valore fuori range
equivale a nessun valore ricevuto e viene
mantenuta la termoregolazione di caldaia
a punto fisso o a curva climatica.
2 Boiler DHW Primary Setpoint A R/W 0,1°C 20,0 80,0
Setpoint circuito primario durante
la preparazione ACS
(al posto di PAR 66 caldaia).
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto e viene utilizzato
il valore di regolazione presente in caldaia.
3 Boiler DHW Setpoint A R/W 0,1°C 10,0 80,0
Setpoint acqua calda sanitaria.
Se viene ricevuto un valore fuori range
equivale a nessun valore ricevuto
e viene utilizzato il valore
di regolazione presente in caldaia.
4 Outside Temperature MB A R/W 0,1°C -55,0 95,0
Valore di temperatura esterna comunicato via ModBus.
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto. Nel caso di conflitto
la caldaia dà la priorità al valore della sonda
ad essa collegata.
5 Boiler CH Curve Slope A R/W 0,1 3,0 40,0
Pendenza della curva climatica della zona 1
(utilizzato al posto della curva impostata in caldaia).
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto e viene utilizzata
la curva climatica presente in caldaia.
6 Boiler CH Curve Displacement A R/W 0,1 -5,0 5,0
Valore di shift del set ambiente della zona 1
(utilizzato al posto dello shift impostato in caldaia).
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto e viene utilizzato
lo shift presente in caldaia.
64 Boiler DHW Water Tem
p
erature A R 0,1°C 0,0 100,0 Temperatura Sonda Acqua calda sanitaria
65 Boiler Primar
y
Water Tem
p
erature A R 0,1°C 0,0 100,0 Temperatura Sonda Circuito Primario (Mandata)
66 Boiler Return Water Tem
p
erature A R 0,1°C 0,0 100,0 Temperatura Sonda Ritorno Circuito Primario
67 Boiler Flue Gas Tem
p
erature A R 0,1°C 0,0 200,0 Temperatura Sonda Fumi
68 Boiler Relative Modulation Level A R 0,1% 0,0 100,0 Livello Modulazione (0%=Minima Potenza Caldaia -
100%=Massima Potenza Caldaia)
69 Boiler Primar
y
Water Pressure A R 0,1 bar 0,0 6,0 Valore Pressione Acqua Circuito Primario
70 Boiler Outside Temperature A R 0,1°C -100,0 100,0 Valore di temperatura esterna letto
dalla caldaia tramite la sonda ad essa collegata.
Inte
g
er variables
129 Boiler Current Minute I R/W - 0 59 Non usato
130 Boiler Current Hour I R/W - 0 23 Non usato
131 Boiler Current Da
y
of the Week I R/W - 1 = Lun 7 = Dom Non usato
132 Boiler Current Da
y
of the Month I R/W - 1 31 Non usato
133 Boiler Current Month I R/W - 1 12 Non usato
134 Boiler Current Year I R/W - 2000 2200 Non usato
192 Boiler Alarm Code I R - 0 100 Codice numerico visualizzato durante
anomalia caldaia (Master se in cascata).
193 Boiler Slave 1 Alarm Code I R - 0 100 Codice numerico visualizzato
durante anomalia caldaia slave 1
194 Boiler Slave 2 Alarm Code I R - 0 100 Codice numerico visualizzato
durante anomalia caldaia slave 2
195 Boiler Slave 3 Alarm Code I R - 0 100 Codice numerico visualizzato
durante anomalia caldaia slave 3
196 Boiler Slave 4 Alarm Code I R - 0 100 Codice numerico visualizzato
durante anomalia caldaia slave 4
197 Boiler Slave 5 Alarm Code I R - 0 100 Codice numerico visualizzato
durante anomalia caldaia slave 5
198 Boiler Slave 6 Alarm Code I R - 0 100 Codice numerico visualizzato
durante anomalia caldaia slave 6
199 Boiler Slave 7 Alarm Code I R - 0 100
Codice numerico visualizzato
durante anomalia caldaia slave 7
200 Boiler Combustion Parameter
(
Par1
)
I R - 0 199 Valore del PAR 1 in caldaia
201 Boiler H
y
draulic Parameter
(
Par2
)
I R - 0 199 Valore del PAR 2 in caldaia
Request CH zone 1
Enable DHW preparation
Not used
State CH zone 1
Descrizione /
State preparation DHW
State presence flame
State presence alarm
Setpoint CH zone 1.
If you receive a value out of range
so the value isn’t received and
the boiler temperature control is
maintained of fixed point or a
temperature curve.
Setpoint CH during ACS preparation
(for PAR 66 installer parameters)
If you receive a value out of range
the value isn’t received and it is used
the boiler value regulation .
Setpoint ACS.
If you receive a value out of range
the value isn’t received and it is used
the boiler value regulation.
External value of temperature by MobBus.
If you receive a value out of range
the value isn’t received. In case of
conflict the boiler will give priority to the value
of the probe connected to it.
Slope of heating curve of zone 1
(it is used instead of the curve set in the boiler).
If you receive a value out of range
the value isn’t received and it is used
the boiler heating curve.
If you receive a value out of range
the value isn’t received and it is used
the boiler heating curve.
Shift value of room zone 1 set
(it is used instead of the shift set in the boiler).
DHW temperature sensor
CH temperature sensor (Delivery)
CH temperature sensor (Return)
Smoke temperature sensor
Modulation level: (0%= minimum boiler power
100%= maximum boiler power)
Pressure value water CH
Outside temperature read from the boiler
through the probe connected to it
Not used
Not used
Not used
Not used
Not used
Not used
Numeric code shown during boiler error
(If Master is in cascade)
Numeric code shown during slave 01 error
Numeric code shown during slave 02 error
Numeric code shown during slave 03 error
Numeric code shown during slave 04 error
Numeric code shown during slave 05 error
Numeric code shown during slave 06 error
Numeric code shown during slave 07 error
PAR 1 value
PAR 2 value
TABELLA DELLE VARIABILI MODBUS /
MODBUS BOILER VARIABLES LIST

84
ATTENTION: Communication will occur
only with the MASTER boiler, (boiler with
PAR 15 = 0), interpreting the cascade as
a single heat capacity generator:
P CASCADE = P BOILER x No. BOILERS.
To install the second board, proceed as fol-
lows:
- Remove the cover and electrically con-
nect the second RS-485 board equipped
with lid to the RS-485 board already
installed in the MASTER boiler (boiler with
PAR 15 = 0) with the wired connector
provided in the kit.
CAUTION: Insert the wired connector
with caution.
- Set the DIP SWITCH of the new board in
MODBUS mode.
- Close the lid of the second board.
- Choose the communication configuration
suited to the MODBUS network (PAR 17
INST) according to Table PAR 17 INST.
RS-485 connection to the INSOL/ZONA
MIX (fig. 4/e)
The RS-485 board can be connected to
optional INSOL kit code 8092254 or ZONA
MIX code 8092252. Both require the
board housing kite code 8092236.
Carry out the electrical connections as indi-
cated in the figure.
CAUTION: For electrically connecting the
INSOL/ZONA MIX board to the boiler
board, refer to the instruction leaflet pro-
vided in the kit.
2.1.3 Anti-freeze function
The boilers are equipped with anti-freeze
function which activates the pumps and the
burner when the temperature of the water
CN10
COMUNICAZIONE
MODBUS
MODBUS
COMMUNICATION
CONNETTORE CABLATO
(cod. 6319173)
WIRED CONNECTOR
(cod 6319173)
123 4 5 6
Fig. 4/d
123
DIP SWITCH
GESTIONE IN MODBUS
MODBUS MANAGEME
N
12 3
ON
CN10
Schedino
INSOL/ZONA MIX e kit
lloggi mento sched
CN10
COMUNICAZIONE
MODBUS
MODBUS
COMMUNICATION
123 4 5 6
Schedino
INSOL/ZONA MIX e kit
lloggi mento sched
Fig. 4/e
Module with 1 RS-485 board Module with 2 RS-485 board
INSOL / ZONA MIX
board and kit board
housing
INSOL / ZONA MIX
board and kit board
housing
INSTALLER PARAMETER SETTING:
PAR 16 MODBUS ADDRESS
-- = Not enabled
1...31 = Slave from 1 to 31
(ATTENTION: Avoid calling the
boiler with the same number
assigned to other appliances)
PAR 17 MODBUS CONFIGURATION
-- = Not enabled
1...30 =
Default value: 25
(See Table PAR 17 INST)

85
ES
PT
ENG
contained inside the appliance drops to
below 6°C. The anti-freeze function is ensu-
red, however, only if:
- the boiler is correctly connected to the
gas and electricity supply circuits;
- the boiler is constantly fed;
- the boiler ignition is not blocked;
- the essential components of the boiler
are all in working order.
In these conditions the boiler is protected
against frost down to an environmental
temperature of -5°C.
ATTENTION: In the case of installation in a
place where the temperature drops below
0°C, the connection pipes must be pro-
tected.
2.2 CONNECTING UP SYSTEM
To protect the heat system from damaging
corrosion, incrustation or deposits, before
installation it is extremely important to
clean the system using suitable products
such as, for example, Sentinel X300 (new
system), X400 and X800 (old system) or
Fernox Cleaner F3. Complete instructions
are provided with the products but, for
further information, you may directly con-
tact SENTINEL PERFORMANCE SOLU-
TIONS LTD or FERNOX COOKSON ELECTRO-
NICS.
For long-term protection agains corrosion
and deposits, the use of inhibitors such as
Sentinel X100 or Fernox Protector F1 is
recommended after cleaning the system. It
is important to check the concentration of
the inhibitor after each system modifica-
tion and during maintenance following the
manufacturer’s instructions (specific tests
are available at your dealer). The safety
valve drain must be connected to a collec-
tion funnel to collect any discharge during
interventions. If the heating system is on a
higher floor than the boiler, install the
on/off taps supplied in kit optional on the
heating system delivery/return pipes.
WARNING: Failure to clean the heat
system or add an adequate inhibitor inva-
lidates the device’s warranty.
Gas connections must be made in accor-
dance with current standards and regula-
tions. When dimensioning gas pipes from
the meter to the module, both capacity
volume (consumption) in m3/h and gas
density must be taken into account.
The sections of the piping making up the
system must be such as to guarantee a
supply of gas sufficient to cover the maxi-
mum demand, limiting pressure loss
between the gas meter and any apparatus
being used to not greater than:
– 1.0 mbar for family II gases (natural gas);
– 2.0 mbar for family III gases (butane or
propane).
An adhesive data plate is sticked inside the
front panel; it contains all the technical data
identifying the boiler and the type of gas for
which the boiler is arranged.
2.2.1 Connection of condensation
water trap
The drip board and its water trap must be
connected to a civil drain through a pipe
with a slope of at least 5 mm per metre to
ensure drainage of condensation water.
The plastic pipes normally used for civil
drains are the only type of pipe which is
appropriate for conveying condensation
to the building’s sewer pipes.
2.2.2 Filter on the gas pipe
The gas valve is supplied ex factory with an
inlet filter, which, however, is not adequate
to entrap all the impurities in the gas or in
gas main pipes.
To prevent malfunctioning of the valve, or in
certain cases even to cut out the safety
device with which the valve is equipped,
install an adequate filter on the gas pipe.
2.3 INITIAL PHASE SYSTEM FILLING
(fig. 5)
The charge pressure, with the system cold,
must be between 1 and 1.5 bar.
The filling is to be done slowly to allow air
bubbles to escape through the air vents.
2.3.1 System draining (fig. 5)
To drain the system, turn off the boiler and
use the discharge valve (5 fig. 5).
2.4 FORCED EXHAUST
TYPE B23P-B53P (fig. 6)
This type of exhaust is made with the sup-
plied adapter or 60/80 provided as optio-
nal (code 8089923) for installation type
B23P-B53P. To set this exhaust configura-
tion, refer to fig. 6. The boiler is provided
also of a rubber gasket Ø 80 to be used as
shown in the figure.
The maximum total length of the exhaust
pipe ø 80 is determined by the load los-
Fig. 5
45
76
KEY
4 Safety valve 3 bar
5 Boiler discharge
6 By-pass (blue)
7 Water pressure transducer
NOTE: They are evidenced in blue/white the members for which are previewed the verification and the control.

86
ses of the individual accessories inserted
and must not be more than 15 mm H2O.
(ATTENTION: the total length of each pipe
should not exceed 50 m, even if the total
loss is below the maximum applicable
loss.)
The exhaust pipe can be connected to exi-
sting chimneys.
When the boiler works at low temperature
is possible to use normal chimneys at the
following conditions:
– The chimney must not be used by other
boilers.
– The inside of the chimney must be pro-
tected from direct contact with the boi-
ler condensation. Combustion products
must be conveyed with a flexible piping
or rigid plastic pipes with a diameter of
about 100-150 mm providing so to the
condensation siphoned drainage at the
end of the pipe. The useful height of the
siphon must be at least 150 mm.
For the accessories load loss refer to
Table 1.
2.5 INSTALLATION OF SEPARATE
DUCTS TYPE C (ø 80)
This type of exhaust is made with ø 80 poly-
propylene accessories and without the use
of gasket or sealant in type C installation.
The maximum overall length, resulting
from the sum of all the suction and
discharge pipes, is determined by the
load losses of the single connected acces-
sories and should not exceed 15 mm H2O
(ATTENTION: the total length of each pipe
should not exceed 50 m, even if the total
loss is below the maximum applicable
loss.)
See Table 2 for information on the load los-
ses of single accessories and the example
of fig. 6/a for information on how to calcu-
late load losses.
2.5.1 Separate ducts kit (fig. 6/b)
The diagrams of figure 6/b show a few
examples of the permitted exhausts confi-
gurations.
2.5.2 Connection to existing flues
The ø 80 exhaust pipe can also be connec-
ted to existing flues.
When the boiler runs at low temperature,
it is possible to use standard flues provided
that:
- The flue is not be used by other boilers.
- The interior of the flue is protected to
prevent a direct contact with condensa-
tion
from the boiler. The products of
combustion must be conveyed through a
flexible or rigid plastic pipe around 100
to 150 mm in diameter, and condensa-
tion must be siphoned off at the foot of
the pipe. The usable height of the water
trap must be at least 150 mm.
Fig. 6
WARNING: Before installing accessories, lubricate the
internal part of gaskets with silicon-based products. Avoid
using oils and greases.
KEY
1 90° MF polypropylene curve (6 pcs.) code 8077450
2 a Polypropylene extension L. 1000 (6 pcs.) code 8077351
2 b Polypropylene extension L. 500 (6 pcs.) code. 8077350
3 Hinged tile code 8091300
4 Roof terminal kit L. 1381 code 8091204
5 ø 60/80 adapter code 8089923
6 45° MF polypropylene curve (6 pcs.) code 8077451
7 Exhaust terminal code 8089501
8 Internal-external ring nut kit code 8091500
11 Rubber gasket ø 80 (supplied as standard)
TABLE 1
Accessory ø 80 Load loss
(mm H2O)
90° MF polypropylene curve 0,40
45° MF polypropylene curve 0,25
Polypropylene extension L. 1000 (horizontal) 0,25
Polypropylene extension L. 1000 (vertical) 0,25
Wall exhaust terminal 0,50
Roof exit terminal L. 1381 0,20
ø 60/80 adapter ---

87
ES
PT
ENG
Example of allowable installation “35” calculation in that the sum of the head losses of the
single fittings is less than 15 mm H2O:
Inlet Outlet
9 m horizontal pipe ø 80 x 0.25 2.25 –
9
m horizontal pipe ø 80 x 0.25 – 2.25
n° 2
90° elbows ø 80 x 0.30 0.60 –
n° 2
90° elbows ø 80 x 0.40 – 0.80
n° 1 terminal ø 80 0.15 0.50
Total head loss 3.00 + 3.55 = 6.55 mm H2O
TABLE 1
Accessories ø 80 Total head loss (
mm H2O)
35
Inlet Outlet
Coaxial duct kit – –
90° elbow MF 0.30 0.40
45° elbow MF 0.25 0.25
Extension L. 1000 (horizontal) 0.25 0.25
Extension L. 1000 (vertical) 0.25 0.25
Wall terminal 0.15 0.50
Wall coaxial exhaust *
Roof outlet terminal * 1.50 0.20
* The loss of the accessorie in aspiration concludes the collector code 8091400/01
Fig. 6/a
9
C53
C33
C43
C83
11
10
3
11
3
3 2
1
26
1
3
11
10
3
7
3
3
3
6
2
3
3
max 0,5 m
max 0,5 m
C13
4
3
2
6
5
3
1
12 12
12
C13
3
2
3
1
14
12
13
12
Fig. 6/b
LIST OF ø 80 ACCESSORIES
1--------
2Additional 90° MF curve code 8077450 (6 pz.)
NOTE
Before connecting accessories, it is always
advisable to lubricate the internal part of the
gaskets with silicon products. Avoid using oils
and greases.
IMPORTANT: In type C53 the outlet
and inlet flues must not come out
on opposite walls.

88
2.6 POSITIONING THE
OUTLET TERMINALS (fig. 7)
The outlet terminals for forced-draught
appliances may be located in the external
perimeter walls of the building.
To provide some indications of possible solu-
tions, Table 3 gives the minimum distances
to be observed, with reference to the type
of building shown in fig. 7.
2.7 ELECTRICAL CONNECTION
The boiler is supplied with an electric cable.
Should this require replacement, it must be
purchased exclusively from SIME.
The electric power supply to the boiler must
be 230V - 50Hz single-phase through a
fused main switch, with at least 3 mm spa-
cing between contacts.
Respect the L and N polarities and the
earth connection.
NOTE: SIME declines all responsibility for
injury or damage to persons, animals or
things, resulting from the failure to provi-
de for proper earthing of the appliance.
2.7.1 Chronothermostat connection
Connect the chronothermostat as indica-
ted in the boiler electrical diagram (see fig.
11) after having removed the existing brid-
ge.
The chronothermostat to be used must be
of a class conforming to the standard EN
607301 (clean electrical contact).
2.7.2 Climatic regulator CR 53
connection (optional)
The boiler is designed for connectio to a cli-
matic regulator, supplied on request (code
8092227), for the management of a hea-
ting circuit. The electronic card will conti-
nue to manage information visualisation,
the setting of the sanitary set and the hea-
ting of the second circuit, and the boiler
parameters by means of the keys on the
control panel. For installation and use of
the climatic regulator, follow the instruc-
Fig. 7
TABLE 3
Siting of terminal Appliances from 7 to 35 kW
(distances in mm)
A - below openable window 600
B - below ventilation opening 600
C - below eaves 300
D - below balcony (1) 300
E - from adjacent window 400
F - from adjacent ventilation opening 600
G - from horizontal or vertical soil or drain pipes (2) 300
H - from corner of building 300
I - from recess in building 300
L - from ground level or other treadable surface 2500
M - between two terminals set vertically 1500
N - between two terminals set horizontally 1000
O - from a surface facing without openings or terminals 2000
P - as above but with openings and terminals 3000
1) Terminals below a practicable balcony must be located in
such a way that the total path of the smoke from its outlet
point from the terminal to its outlet point from the external
perimeter of the balcony, including the height of possible rai-
lings, is not less than 2000 mm.
2) When siting terminals, where materials that may be subject
to the action of the combustion products are present in the
vicinity, e.g., eaves, gutters and downspouts painted or made
of plastic material, projecting timberwork, etc., distances of
not less than 1500 mm must be adopted, unless adequate
shielding is provided to guard these materials.

89
ES
PT
ENG
R
M
SE
TA
CR
TA1
CR
SE
tions included in the packaging.
NOTE: Reset parameter 10 to 2 (PAR 10
= 2).
2.7.3 Remote control CR 73
connection (optional)
The boiler is designed for connection to a
remote control unit, supplied on request
(code 8092226). The remote control unit
CR 73 allows for complete remote control
of the boiler, except release of the boiler.
The boiler display will show the following
message:
For installation and use of the remote con-
trol, follow the instructions in the package.
NOTE: Ensure PAR 10 set to 1 (PAR 10 =
1).
2.7.4 External sensor connection
The boiler is designed for connection to an
external temperature sensor, supplied on
request (code 8094101), which can auto-
matically regulate the temperature value of
the boiler output according to the external
temperature. For installation, follow the
instruction in the package. It is possible to
make corrections to the values read by the
drill acting on the PAR 11.
2.7.5 Use with different
electronic systems
Some examples are given below of boiler
systems combined with different electronic
systems. Where necessary, the parame-
ters to be set in the boiler are given. The
electrical connections to the boiler refer to
the wording on the diagrams (fig. 11). The
zone valve control starts at every demand
for heating of the zone 1 (it is from part of
the TA1 or the CR).
Description of the letters indicating the
components shown on the system dia-
grams from 1 to 14:
M System output
R System return
CR Remote control CR 73
SE External temperature sensor
TA 1-2-3-4 Zone room thermostat
CT 1-2 Zone
chronothermostat
VZ 1-2 Zone valve
RL 1-2-3-4 Zone relay
Sl Hydraulic separator
P 1-2-3-4 Zone pump
SB D.H.W. sensor
PB D.H.W. pump
IP Floor system
EXP Expansion card ZONA MIX (code
8092234)/INSOL (code 8092235)
VM Three-way mixer valve
1 BASIC SYSTEM
SYSTEM WITH A DIRECT ZONE AND ROOM THERMOSTAT, OR WITH A CLIMATIC REGULATOR CR 53
(Code 8092227) OR WITH REMOTE CONTROL CR 73 (Code 8092226) AND EXTERNAL SENSOR (Code
8094101)
PARAMETERS SETTINGS
If using CR 53 set parameter
10 to 2 (PAR 10 = 2)

90
TA1
SE
R
M
SE
TA
VZ
TA1
VZ1
TA2
VZ2
R
M
SE
TA1 TA2
TA1
SE
TA
P2
RL
SI
RL1 RL2
P1
P
TA2
SE
R
M
SE
TA
VZ
TA1
VZ1
TA2
VZ2
CR
CR
2 BASIC SYSTEM
MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTAT AND EXTERNAL SENSOR (Code 8094101)
3 BASIC SYSTEM
MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTAT AND EXTERNAL SENSOR (Code 8094101)
4 BASIC SYSTEM
MULTI-ZONE SYSTEM WITH VALVE, ROOM THERMOSTAT, REMOTE CONTROL CR 73 (Code 8092226) AND EXTERNAL
SENSOR (Code 8094101)
PARAMETERS SETTINGS
To use the remote control
(CR) as remote control panel
for the boiler rather than as
room reference, set:
PAR 7 = 0

91
ES
PT
ENG
TA2
SE
R
M
SE
VZ VZ1
TA2
VZ2
CR
CR
VZ1
TA1
PARAMETER SETTING
To use the remote control (CR)
as room reference for a zone,
set: PAR 7 = 1
Set the opening time of the zone
valve VZ:
PAR 33 = “OPENING TIME”
R
M
SE
CT2
TA1
SE
CT1
TA2
VZ1 VZ2
ZONA
GIORNO
(70°C)
ZONA
NOTTE
(50°C)
DURING NIGHT TIME THE BOILER
USES A LOWER OUTPUT TEMPE-
RATURE IF DIFFERENT TIMES HAVE
BEEN SET FOR DAY AND NIGHT
AREAS:
- with external sensor, set the cli-
matic curve of the day zone 1 with
PAR 25 and the night zone at PAR
26.
- without external sensor, gain
access to setting the day zone 1
by pressing the key and chan-
ge the value with the keys
and . Gain access to setting
the night zone by pressing the key
twice and changing the value
with the keys and .
SI
R
M
SE
TA1 TA2
TA2
SE
TA
P2
RL RL1 RL2
P1
P
CR
CR
PARAMETER SETTING
To use the remote control
(CR) as room reference for a
zone, set:
PAR 7 = 1
5 BASIC SYSTEM
MULTI-ZONE SYSTEM WITH VALVE, ROOM THERMOSTAT, REMOTE CONTROL CR 73 (Code 8092226) AND EXTER-
NAL SENSOR (Code 8094101)
6 BASIC SYSTEM
MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTAT, REMOTE CONTROL CR 73 (Code 8092226) AND EXTER-
NAL SENSOR (Code 8094101)
7 SYSTEM WITH DOUBLE TEMPERATURE OUTPUT
MULTI-ZONE SYSTEM WITH VALVE, CHRONOTHERMOSTAT AND EXTERNAL SENSOR (Code 8094101)
DAY
ZONE
(70°C)
NIGHT
ZONE
(50°C)

92
R
M
SE
TA2
TA1
SE
TA1
SI
RL2
P2
P1
PB
RL1
BOLLITORE
PB
SB
SB
R
M
SE
CT2
TA1
SE
CT1
SI
RL2
P2
P1
TA2
RL1
ZONA
GIORNO
(70°C)
ZONA
NOTTE
(50°C)
8 SYSTEM WITH DOUBLE TEMPERATURE OUTPUT
MULTI-ZONE SYSTEM WITH PUMP, CHRONOTHERMOSTAT AND EXTERNAL SENSOR (Code 8094101)
10 SYSTEM WITH REMOTE BOILING UNIT AFTER THE HYDRAULIC SEPARATOR
DAY
ZONE
(70°C)
NIGHT
ZONE
(50°C)
D.H.W. TANK

93
ES
PT
ENG
R
M
SE
TA2
TA1
SE
TA1
SI
RL2
P2
P1
TA2
CR
CR
EXP
VM
EXP
IP
R
M
SE
TA3
TA1
SE
SI
RL3
P3
P2
TA2
IP
EXP
VM
EXP IP
P4
TA4
RL4
TA1 TA2
11 SYSTEM WITH MIXER VALVE
SYSTEM WITH ONE DIRECT ZONE, ONE MIXED ZONE, ONE KIT ZONA MIX (Code 8092234), REMOTE CONTROL CR
73 (Code 8092226) AND EXTERNAL SENSOR (Code 8094101)
12 SYSTEM WITH MIXER VALVE
SYSTEM WITH TWO DIRECT ZONES, TWO MIXED ZONES, ONE KIT ZONA MIX (Code 8092234) AND EXTERNAL
SENSOR (Code 8094101)
PARAMETERS SETTINGS
To use the remote control
(CR) as remote control panel
for the boiler rather than as
room reference, set:
PAR 7 = 0

94
R
M
SE
TA1
SE
SI
P1
TA2
EXP VM
EXP
IP
TA1
TA2
P2
VM
IP
EXP
S1
SB
R
M
SE
TA1
SE
SI
P1
TA2
EXP VM
EXP
IP
TA1
TA2
P2
VM
EXP
EXP (INSOL)
Murelle HM T / HE R
S2
CR
CR
P3
(CR) (TA2) (TA1)
VENTILCONVETTORE
13 SYSTEM WITH MIXER VALVE
SYSTEM WITH TWO MIXED ZONES INDEPENDENT, TWO KITS ZONA MIX (Code 8092234) AND EXTERNAL SEN-
SOR (Code 8094101)
14 SYSTEM SOLAR
SYSTEM WITH TWO MIXED ZONES INDEPENDENT, ONE DIRECT ZONE, WO KITS ZONA MIX (Code 8092234), ONE
KIT SOLAR INSOL (Code 8092235), REMOTE CONTROL CR 73 (Code. 8092226) AND EXTERNAL SENSOR (Code
8094101)
FAN COIL
