Simpli Home AXCRCOS16-MAH User manual

Cosmopolitan / City / Essex
TV Media Stand
Model # AXCRCOS16-MAH
1

Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
üAcvate your 1-year warranty
üAutomac entry to win a $500 gi cerficate
üEarn instant rewards and save simpli-home.com/product-registraon
2

Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Review your product and collect rewards!
Send us images or share them on social and qualify for instant rewards.
You may even receive store credit on your enre purchase!
simpli-home.com/share-images
Share photos and get your cash back!
3

For Fastest Customer Service:
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.
Visit Us
Visit our site directly at
www.simpli-home.com
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
Email Us
customerser[email protected]
Other ways to contact us…
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order informaon and issue.
6. Submit form.
7. A customer service associate will contact you.
4

If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
CAUTION: Injuries and damage can occur from furniture tip over if product is not
properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided
with the product. Consult our assembly instructions for help.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
furniture.
May require 2 people for ease of assembly.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
IMPORTANT: Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Safety Information
5

To help protect your wood furniture, take these steps:
• Don't over-humidify; that can damage wood by causing it to expand and contract
• For soil build-up, wipe with damp cloth & dry
• Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
This furniture is designed for indoor use.
• Dust with soft dry cloth
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• Do not use abrasive cleaners
• If you can avoid it, don't put furniture near heating vents; if you can’t, keep the item 3 to
4 inches away from the wall, giving the heat and air space to circulate
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more
slowly than other finishes.
• Do not use liquid or aerosol products
Care & Maintenance
6

This TV Stand does not come with legible instructions pertaining to the risk of fire
and electric shock that is associated with the use of electrical components such as
operation, user-maintenance, loading, storage and as applicable electrical issues
including grounding or double-insulation.
Any use of this item other than that recommended by the manufacturer in this
manual may cause fire, burns, electric shock and/or serious injuries or death.
WARNING Do not relocate audio and/or video equipment to furniture not
specifically designed to support audio and/or video equipment. Do not move
furniture without shelves or drawers unloaded. Furniture can collapse or tip over
onto a child and cause physical injury or death.
Improper use of furniture to support TVs may result in serious injury or death.
WARNING Do not place a TV that exceeds the weight limits or size guidelines
shown in the instructions specified for the furniture. Do not overload shelves or
place heavy items on top shelves or drawers.
WARNING Do not place toys, food, etc. on the top shelves or upper drawers.
Serious injury or death may occur when children climb on furniture. A remote
control or items placed on the furniture may encourage a child to climb on the
furniture and as a result make it top-heavy and cause it to tip over on the child.
WARNING
The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to 68.58
cm). For use with televisions weighing 150 lbs or less. Using larger or heavier televisions may
cause instability or tip over which can lead to serious injury or even death.
The recommended maximum width of the television intended for use is 55 inch (139.7 cm).
MAXIMUM LOAD 25 LBS
MAXIMUM LOAD 150 LBS
7

A
TOP
QTY 1
BL
LEFT SIDE
QTY 1
BR
RIGHT SIDE
QTY 1
C
BOTTOM SHELF
QTY 1
D
CENTRE SUPPORT
QTY 1
EL
LEFT SHELF
QTY 1
ER
RIGHT SHELF
QTY 1
FL
LEFT DOOR
QTY 1
FR
RIGHT DOOR
QTY 1
G
BACK PANEL
QTY 1
Front / Avant
Front / Avant
Front /
Avant
Front / Avant
Front /
Avant
8
Part Description
Pre-Assembly Information Model # AXCRCOS16-MAH

12 3
45 6
78
ALLEN KEY SCREW
M6 X 30 mm
QTY 12
CAM LOCK PIN
CAM LOCK
QTY 6 SETS
WOOD DOWEL
Ø8 X 30 mm
QTY 8
ALLEN KEY
QTY 1
PHILLIPS SCREW ROUND HEAD
M4 X 15 mm
QTY 13
SHELF SUPPORT
QTY 12
HANDLE
M4 X 25 mm
QTY 2 SETS
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
a. M4 X 25 - QTY 2
( )1 is extra
b. M4 X 15 - QTY 1
c. M4 X 25 - QTY 1
9
Hardware Description
Pre-Assembly Information Model # AXCRCOS16-MAH

A
BL
G
D
EL
BR
ER
C
FL
FR
Front
/
Avant
Front /
Avant
Front / Avant
Front /
Avant
Front
/ Avant
10
Components - Key Diagram Model # AXCRCOS16-MAH

Step 1
1. Insert 2 Wood Dowels 3 into guide holes on Bottom Shelf C .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
5. Insert Cam Locks 2 into guide holes on Bottom Shelf C .
3. Attach 3 Cam Lock Pins 2 into Left Side BL using pre-drilled holes.
6. Using a flathead screwdriver tighten Cam Locks into Pins.
4. Align and insert Cam Lock Pins on Left Side BL into guide holes on Bottom Shelf C .
Dowels should be exposed.
C
BL
3
2
Front
/
Avant
Front
/ Avant
11
Assembly Model # AXCRCOS16-MAH

Step 2
C
BL
BR
D
1
2
3
Dowels should be exposed.
1. Insert 2 Wood Dowels 3 into guide holes on other side of Bottom Shelf C .
4. Align and insert Cam Lock Pins on Right Side BR into guide holes on Bottom shelf C .
through guide holes.
7. Attach Centre Support D to Bottom Shelf C using 3 Allen Key Screws 1
5. Insert 3 Cam Locks 2 into guide holes on Bottom Shelf C .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
3. Attach 3 Cam Lock Pins 2 into Right Side BR using pre-drilled holes.
6. Using a flathead screwdriver tighten Cam Locks into Pins.
Front
/
Avant
Front
/
Avant
Front
/
Avant
Front / Avant
12
Assembly Model # AXCRCOS16-MAH

Step 3
Dowels should be exposed.
1. Insert 2 Wood Dowels 3 into top corners of each Side BL , BR.
4. Using Allen Key Screws 1 attach Top A to Sides BL , BR and to Centre Support D .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
3. Align guide holes on bottom corners of Top A with Dowels 3 in Sides BL , BR.
4
1
3
3
4
1
A
Front /
Avant
Front
/
Avant
Front / Avant
Front
/
Avant
A
AA
Front
/
Avant
Front
/
Avant
Front
/ Avant
C
BR
BL
D
Front
/
Avant
Front /
Avant
13
Assembly Model # AXCRCOS16-MAH

Step 4
3. To adjust the height of wheels up or down, use the Phillips screwdriver to rotate the
2. Pull down the pins on top of each door then place the door to be parallel with the TV
counter clockwise will adjust the wheels lower).
side post. Afterward release the pins. The pins will be inserted into the slots
screw on the wheels (Rotating clockwise will adjust the wheels higher, rotating
underneath of Top A .
1. Slide the wheels on bottom of each door to the slots on Bottom Shelf C .
A
Front
/ Avant
Front /
Avant
FL
FR
First Door
( Right Door FR )
Second Door
( Left Door FL )
C
14
Assembly Model # AXCRCOS16-MAH

Step 5
2. Use Phillips screwdriver to tighten screws.
1. Attach Back Panels G to back of cabinet using Phillips Screws Round Head 6
into guide holes.
5
ER
EL
tipping restraint.
1. Use 4 Shelf Supports 5 for each Shelf EL , ER in desired location.
2. 2 Shelf Supports 5 may be used on back top of each Shelf EL , ER as a
6
G
Step 7
Front
/ Avant
Front /
Avant
Front / Avant
Front /
Avant
Step 6
Front / Avant
Front /
Avant
FL
FR
7
1. Use a Phillips screwdriver to attach Handles 7 to Doors FL , FR .
7
15
Assembly Model # AXCRCOS16-MAH

Step 8
8
8
NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
16
Furniture Tip Over Restraint Assembly

1. Attach one of the mounting brackets securely to the back edge of
the furniture. Use the shorter screw.
● DO NOT let children climb or hang on drawers, doors or shelves
“locked” position.
6. Lace an end of the nylon zip-tie strap down through each bracket.
the wall for mounting bracket screw hole approximately 2 inches
below the bracket mounted to the furniture.
wall surface.
brackets.
hole and gently tap until the flange on the anchor is against the
Bring both ends together and slide the smooth side upright
7. Check to make sure the strap is securely laced and locked to the
securely attach the bracket to the wall.
2. Determine where furniture is to be placed and mark location on
5. Place the furniture so the back edge is in line with the bracket on
● DO NOT place heavy objects in top drawers or on top shelves
3. Drill a 3/16 inch hole in the wall. Press the plastic anchor into the
the wall.
through the square-shaped end and pull through to create the
4. Position the bracket over the anchor and use the longer screw to
17
Furniture Anti-Tipping Restraint Instructions
