Simpli Home AXWELL3-002 User manual

ACADIAN NORMANDY BRUNSWICK//
CONSOLE TABLE/ SOFA
MODEL # AXWELL3-002
1/15

2/15
FOR REPLACEMENT PARTS OR HELP WITH
ASSEMBLY PLEASE CONTACT US AT:
simpli home.com/customer-support-
PLEASE ENSURE TO HAVE THE MODEL #
INSTRUCTION BOOKLETFROM THE PACKAGING OR
TO RETURN THE PRODUCT:
PLEASE CONTACT THE RETAILER
WHERE THE ITEM WAS PURCHASED FROM

Upload an image of our furniture
in your home with a short review
to our facebook page for a chance to
ENTER
TO WIN
Win up to $3000 of
Simpli Home furniture!!!
www.facebook.com/simplihomefurnishings
3/15

IMPORTANT : Please read this manual carefully before beginning
.assembly of this product Keep this manual for future reference.
SAFETY INFORMATION
CARE and MAINTENANCE
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by children
and pets. Keep children and pets away during assembly. To avoid danger of
suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
To clean, use a soft or slightly damp cloth, then wipe with a clean, dry cloth.
Dust with soft dry cloth.
Do not use ammonia-based cleaning products, as they will damage the finish.
Do not leave liquids or damp cloths on this furniture.
To avoid dulling of the finish, do not place furniture in direct sunlight.
Please inspect and tighten all screws or bolts on a regular basis to ensure proper
performance and safety of your item.
4/15

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE ASSEMBLY INFORMATION-
PARTS DESCRIPTION
MODEL # AXWELL3-002
A
TOP
QTY 1
SIDE
QTY 1 PAIR
SHELF SIDE
QTY 1
SHELF PART
QTY 2
DOOR
QTY 2
B C
C1 D
SHELF PANEL
QTY 2
BACK PANEL
QTY 1
F G
SHELF SIDE
QTY 1
E
Front
Front
Front side
5/15

1
PRE ASSEMBLY INFORMATION-
HARDWARE DESCRIPTION
23
4 5
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
ALLEN KEY SCREW
M6 X 30 mm
QTY 16
CAM LOCK PIN
CAM LOCK
QTY 8
HANDLE
QTY 2 SETS
MAGNET and PLATE
QTY 2 SETS
PHILLIPS SHORT SCREW
M3 X 12 mm
QTY 12
PHILLIPS LONG SCREW
M4 X 30 mm
QTY 8
10
6
7 8 9
MODEL # AXWELL3-002
ALLEN KEY
QTY 1
PHILLIPS SCREW
ROUND HEAD
M4 X 15 mm
QTY 8
PHILLIPS SHORT SCREW
M3 X 15 mm
QTY 8
6/15
WOOD DOWEL
Ø8 X 30 mm
QTY 8
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included

COMPONENTS – KEY DIAGRAM MODEL # AXWELL3-002
7/15
C
D
E
F
C1
G
B
A
B
D
F
E

ASSEMBLY
STEP 1
1. Attach Shelf Side C and C1 to Shelf Part D with Allen Key Screw 1 through
pre-drilled holes.
2. Use Allen key 4 to tighten screws. Do not over tighten.
MODEL # AXWELL3-002
Front side
Front side
8/15
D
C
C1
D
CD
1
4

ASSEMBLY
STEP 2
1. Attach Shelf Panels F to Shelf Parts D with Phillips Long Screws 5 through
pre-drilled holes.
2. Use Phillips screwdriver to tighten screws. Do not over tighten.
MODEL # AXWELL3-002
9/15
NOTE: The screwdriver is not
included in the hardware pack.
D
F
D
F
5
5
5

ASSEMBLY
STEP 3
1. Insert Cam Lock Pins 2 and Dowels 3 to Sides B into guild holes.
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
dowels should be expose.
3. Align and insert Cam Lock Pins 2 on Side B into pre-drilled holes on Shelf Part D
4. Insert four Cam Locks 2 into pre-drilled holes on each Shelf Part D .
5. Using a flathead screwdriver tighten Cam Locks into Pins.
MODEL # AXWELL3-002
10/15
D
B
B
3
2
D

ASSEMBLY
STEP 4
1. Using eight Allen Key Screws 1 to attach Top A to Sides B and to Shelf Sides C and C1 .
2. Use Allen Key 4 to tighten screws. Do not over tighten.
MODEL # AXWELL3-002
11/15
B
C1
A
C
1
4
1
4

ASSEMBLY
STEP 5
1. Attach Doors E to Shelf Side C1 using Phillips Short Screws 6 into guide holes.
2. Attach two Magnet Plates 9 to top side of Doors E using Phillips Short Screws 10 into
guide holes on Doors E .
3. Attach two Magnets 9 using Phillips Short Screws 10 into guide holes on Shelf Side C .
4. Use Phillips screwdriver to attach Handles 8 to Doors.
5. Use Phillips screwdriver to snugly tighten screws.
MODEL # AXWELL3-002
B
12/15
NOTE: The screwdriver is not
included in the hardware pack.
E
E
9
8
10
6
10
9

ASSEMBLY
STEP 6
1. Use Phillips Round Head Screws 7 to attach Back Panel G to back of Console Table.
2. Use Phillips screwdriver to snugly tighten screws.
MODEL # AXWELL3-002
13/15
NOTE: The screwdriver is not
included in the hardware pack.
G
G
7

14/15
WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
simpli-home.com/customer-support.
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
