Ballard Designs Newport Demilune Table with Shelf TC352 User manual

PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 4-3-2020 Page 1 of 5
PRODUCT NAME: Newport Demilune Table with Shelf
ITEM NUMBER: TC352
ASSEMBLED DIMENSIONS : 32”H x 38”W x 14 1/4”D
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN CHINA

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 5
Ltr.
A 4
B8
Qty. Hardware Included
Ltr.
2
L
1
1
Qty. Components
C 8
REQUIRED TOOLS:
Phillips Screwdriver,
Allen Wrench (inlcuded)
-Two person assembly suggested.
Remove all parts, hardware and
protective packaging from carton
and carefully arrange on a clean,
level, padded surface.
NOTE: To avoid accidentally
discarding small parts or hardware,
retain all carton contents until
assembly and installation are complete.
D
E
F
H
G
I
J
K
1
1
Shelf (L)
Left Leg (K)
Right Leg (J)
Body (I)
8
Ltr. Qty. Hardware Included
Brackets 8
4
1
Screws
Allen Bolts
Flat Washers
Lock Washers
Dowels
Allen Wrench
Wall Anchoring
(Anti-tip) Kits
See page 5
WARNING
Tip-Over Hazard
Prevent tipping accidents. Anchor your furniture.
ANCHORING HARDWARE INCLUDED
Assemble in location for intended use.

(C) (D) (E)
(G) (C)(D)(E)
Page 3 of 5
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 1: Invert Body (I) onto a soft, level surface and attach Right Leg (J) and Left Leg (K) using Allen
Bolt (C) with Lock Washer (D) and Flat Washer (E) as illustrated below.
NOTE: Assemble components, hand tighten bolts THEN fully tighten all using Allen Wrench (G).
(J)
(K)
(I)
(B)
(A)
(L)
STEP 2: Carefully insert Shelf (L) into notches in Legs. Secure by placing Bracket (A) onto underside
of Shelf as illustrated and connect using Screws (B). Fully tighten using a Phillips Screwdriver.

Page 4 of 5
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 3: Slightly pull out Drawers and insert Dowel (F) drawer stops into pre-drilled holes as illustrated.
(F)

Installation:
Page 5 of 5
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Cleaning & Care:
DO NOT use alcohol based products or spray polisher as
they can damage the finish. Dust with soft cloth.
(B)
(A)
(C)
(C)
(D)
Ltr.
A2
Small Screw
Retention Belt
Qty. Hardware Included
B2
Large Screw
C4 Bracket
D2
ANCHORING HARDWARE (ANTI-TIP)
1. Locate and mark a Wall Stud behind unit at location for installation.
2. Corresponding to Stud location, attach one Bracket (C) to back of unit using Small Screw (B).
3. To keep hardware out of view after installation, attach remaining Bracket (C) INTO WALL STUD
with Large Screw (A) 2 inches below Bracket attached to back of unit.
4. Move unit into place, align Brackets then connect both using Retention Belt (D).
5. Confirm Belt is securely laced and locked.
Serious or fatal crushing injuries can occur from a furniture tip-over
Tip-Over Hazard
Prevent tipping accidents. Anchor your furniture.
WARNING
WALL BRACKET MUST BE ATTACHED TO WALL STUD
WALL
STUD
BACK OF FURNITURE ITEM
