Simplicity 2368 User manual

Rev. 03/2002
TP-400-2368-01-AT-SMA
ATTACHMENT
ILLUSTRATED
PARTS LIST
© Copyright 2002 Simplicity Manufacturing, Inc.All Rights Reserved.
MANUFACTURING, INC.
500 N Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
ATTACHMENT
Mfg. No. Description
1691979 Tiller Adaptor Kit Sovereign to Landlord
1693497 Tiller Adaptor Kit Sovereign to Landlord

2
TP 400-2368-01-AT-SMA
© Copyright 2002 Simplicity Manufacturing, Inc. All Rights Reserved.
36”Tiller Adaptor Kit
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
984263
Must be free
to Pivot
11
17
15
19
12
18
14
16
13
20
1
7
5
9
2
8
4
37
3
10
12
7
21
21
25
29
22
28
24
26
23
30
31
38
35
39
32
34
36
33
40
22
23
22
22
22
22
27
6
6
41
47
45
49
42
48
44
46
43
50
51
52
53
30
25
37
22
25
30
38 39
The above parts group applies to the following Mfg. Nos.:
1691979 Tiller Adaptor Kit Sovereign to Landlord
1693497 Tiller Adaptor Kit Sovereign to Landlord

3
TP 400-2368-01-AT-SMA
Tiller Adaptor Kit
1 1917372 1 NUT-HEX, 5/16-18
2 1917356 1 LOCKWASHER,5/16
3 105359 1 SUPPORT, Rear Belt Guard
4 1707593 1 SPRING, Torsion
5 1707599 1 ANCHOR, Spring
6 105346 2 SPACER
7 1704716 2 SPACER
8 1923141 1 CAPSCREW, Hex Head, 5/16-18 x 2-3/4
9 960171 1 WASHER, Nylon
10 1666106 1 BUSHING
11 1919326 1 WASHER
12 176012 2 RETAINER PIN
13 1707564 1 COVER, Belt
14 1657562 1 ROD
15 1669999 1 SPACER
16 1708352 1 GUARD, Spring
17 157427 1 KEY
18 1960474 1 SCREW,Set Square Head, Cup Point, 3/8-16 x 1/2, G8
19 1706342 1 PULLEY, 9inch OD
20 1721133 1 PULLEY, Idler, 2-3/4 OD
21 1706511 2 PULLEY, Idler, 1-7/8 OD
22 1924940 10 WASHER
23 1921971 2 CAPSCREW,Hex Head, 3/8-16 x 1-3/4
24 1920415 1 CAPSCREWHex Head, 3/8-16 x 1-1/4
25 1916965 6 LOCKWASHER, 3/8
26 1706510 1 PULLEY, Idler, 4 OD
27 1707265 1 ANCHOR, Jackshaft
28 1706512 1 V-BELT
29 1708961 1 SHAFT & SUPPORT ASSEMBLY
30 1960251 4 NUT, Hex Center Lock Jam, 3/8-16
31 1921210 2 CAPSCREW, Hex Head, 3/8-16 x 1
32 1960116 1 PIN, Yoke, Drilled
33 1960033 1 CLIP, Hair Pin
34 1706344 1 CLEVIS & BAR ASSEMBLY, Anchor
35 1921333 1 CAPSCREW, Hex Head, 5/16-18 x 1
36 1706362 1 PULLEY & SHAFT ASSEMBLY
37 1960160 4 WASHER
38 1611789 2 SEAL, Oil
39 171186 2 BEARING
40 912808 1 FITTING, LUBE
41 * 1 CLEVIS ASSEMBLY, (See Ref No. 42)
42 1708180 1 CLEVIS & HOUSING ASSEMBLY, w/ Bearings (Includes Ref. Nos. 39 & 40)
43 159159 1 SPRING, Extension
44 1916950 5 NUT, Hex, 3/8-16
45 1706508 1 ARM & HUB ASSEMBLY
46 1657712 1 PULLEY, Idler, 3-5/8 OD
47 1700059 1 V-BELT
48 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2
49 960403 1 KEY, WOODRUFF, #61
50 1928721 1 SCREW, Set, Square Head Cup Point, 5/16-18 x 1/2, G8
51 1706343 1 PULLEY & HUB ASSEMBLY
52 1708298 1 PIN, Round Head, Drilled
53 1923362 1 NUT, Hex Centerlock, 5/16-18
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691979 Tiller Adaptor Kit Sovereign to Landlord
1693497 Tiller Adaptor Kit Sovereign to Landlord

Torque Specification Chart
FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)
Hardware
Grade
SAE Grade 2 SAE Grade 5 SAE Grade 8
Size Of in/lbs in/lbs in/lbs
Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.
8-32 19 2.1 30 3.4 41 4.6
8-36 20 2.3 31 3.5 43 4.9
10-24 27 3.1 43 4.9 60 6.8
10-32 31 3.5 49 5.5 68 7.7
1/4-20 66 7.6 810.9 12 16.3
1/4-28 76 8.6 10 13.6 14 19.0
5/16-18 11 15.0 17 23.1 25 34.0
5/16-24 12 16.3 19 25.8 27 34.0
3/8-16 20 27.2 30 40.8 45 61.2
3/8-24 23 31.3 35 47.6 50 68.0
7/16-14 30 40.8 50 68.0 70 95.2
7/16-20 35 47.6 55 74.8 80 108.8
1/2-13 50 68.0 75 102.0 110 149.6
1/2-20 55 74.8 90 122.4 120 163.2
9/16-12 65 88.4 110 149.6 150 204.0
9/16-18 75 102.0 120 163.2 170 231.2
5/8-11 90 122.4 150 204.0 220 299.2
5/8-18 100 136 180 244.8 240 326.4
3/4-10 160 217.6 260 353.6 386 525.0
3/4-16 180 244.8 300 408.0 420 571.2
7/8-9 140 190.4 400 544.0 600 816.0
7/8-14 155 210.8 440 598.4 660 897.6
1-8 220 299.2 580 788.8 900 1,244.0
1-12 240 326.4 640 870.4 1,000 1,360.0
Hex Head Capscrew
Hex Nut
Lockwasher
Washer
Carriage Bolt
NOTES
1. These torque values are to be used for all hardware
excluding: locknuts, self-tapping screws, thread forming
screws, sheet metal screws and socket head setscrews.
2. Recommended seating torque values for locknuts:
a. for prevailing torque locknuts - use 65% of grade 5
torques.
b. for flange whizlock nuts and screws - use 135% of
grade 5 torques.
3. Unless otherwise noted on assembly drawings, all torque
values must meet this specification.
Hardware Identification & Torque Specifications
Common Hardware Types
Screw, 1/2 x 2
Body
Diameter
Body
Length
Inside
Diameter
Nut, 1/2”
No
Marks
3/8” Bolt or Nut
Wrench—9/16”
3/8
5/16” Bolt or Nut
Wrench—1/2”
5/16
1/4” Bolt or Nut
Wrench—7/16”
1/4
1/2” Bolt or Nut
Wrench—3/4”
1/2
DIA.
7/16
DIA.
7/16” Bolt or Nut
Wrench (Bolt)—5/8”
Wrench (Nut)—11/16”
Wrench & Fastener Size Guide
Standard Hardware Sizing
When a washer or nut is identified as 1/2”, this is the
Nominal size , meaning the inside diameter is 1/2 inch; if a
second number is present it represent the
threads per inch
When bolt or capscrew is identified as 1/2 - 16 x 2”, this
means the
Nominal size , or body diameter is 1/2 inch; the
second number represents the
threads per inch (16 in this
example, and the final number is the
body length of the
bolt or screw (in this example 2 inches long).
The guides and ruler furnished below are designed to
help you select the appropriate hardware and tools.
01/4 3/4
1/2 11/4 3/4
1/2 21/4 3/4
