Simplicity 2439 Setup guide

Rev. 10/2000
TP 400-2439-00-AT-SMA
Attachment
Illustrated
Parts List
© Copyright 2000 Simplicity Manufacturing, Inc.All Rights Reserved.
MANUFACTURING, INC.
500 N Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA

2
TP 400-2439-00-AT-SMA
© Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved.
Turbo Clean Sweep Twin Catcher - Cover & Bag Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
983952
The above parts group applies to the following Mfg. Nos.:
1691793 Turbo Clean Sweep Twin Catcher
1
2
3
4
5
6
789
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25 26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
11
8
41

3
TP 400-2439-00-AT-SMA
Turbo Clean Sweep Twin Catcher - Cover & Bag Group
1 1704615 1 TUBE ASSEMBLY Support (Incl. Ref. Nos. 2, 3, 4, 5, 6, 8, 9 & 11)
2 1960381 7 RIVET, Pop
3 1704075 1 SUPPORT, Tube
4 1704135 1 SEAL, Cover
5 1704508 3 BRACKET, Seal
6 1960399 1 SCREW, Round Head, #8-32 x 7/8
7 1930642 5 LOCKNUT, Flange, 1/4-20
8 1960096 2 WASHER
9 1704507 1 STRAP, Tube Support
10 1927428 2 SCREW, Taptite, 1/4-20 x 3/8
11 1960077 2 NUT, Hex, Lock, #8-32
12 1960252 5 CARRIAGE BOLT, 1/4-20 x 5/8
13 1703822 1 CROSS ASSEMBLY.
14 1921966 4 CAPSCREW, Hex Head, 3/8-16 x 7/8
15 1928352 4 NUT, Hex, Whizlock, 3/8-16
16 1960221 2 CLIP, Hairpin
17 1703700 1 SCREEN
18 1917372 4 NUT, Hex, 5/16-18
19 1917356 4 LOCKWASHER, 5/16
20 1672023 2 CLAMP
21 1703807 2 HANGER
22 1931333 4 CARRIAGE BOLT, 5/16-18 x 3/4
23 1703855 2 HOOP, Bag
24 1703764 2 BAG, Grass
25 1675707 2 TUBE CLIP, Grass Bag
26 1704057 1 SEAL, Clip
27 1930531 2 SCREW, Truss Head, #10-32 x 1/2
28 1675043 4 RIVET, Pop
29 1703853 1 HANDLE, Latch
30 1928919 2 NUT, Hex, #10-32
31 960367 2 PIN, Round Head
32 1910531 4 WASHER
33 1667248 6 CLIP, Canoe
34 1704405 1 DECAL, Safety
35 1704033 1 COVER
36 1704180 2 WINDOW
37 1933886 1 NUT, Speed
38 1705876 1 CABLE, Double Loop
39 1921319 1 WASHER, 1/4
40 1960400 1 SCREW, Self-tapping, #10-12 x 5/8
41 1704056 1 COVER ASSEMBLY (Incl. Ref. Nos. 17, 26, 28, 32, 37, 38, 39 & 40)
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691793 Turbo Clean Sweep Twin Catcher

4
TP 400-2439-00-AT-SMA
© Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved.
Turbo Clean Sweep Twin Catcher - Hitch Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
984011
The above parts group applies to the following Mfg. Nos.:
1691793 Turbo Clean Sweep Twin Catcher

5
TP 400-2439-00-AT-SMA
Turbo Clean Sweep Twin Catcher - Hitch Group
1 1703745 1 SUPPORT, Upright
2 1920415 2 CAPSCREW, Hex Head, 3/8-16 x 1-1/4
3 102004 1 PIN, Round Head
4 1703744 1 BRACKET, Lower Hitch
5 1924940 8 WASHER
6 1921210 4 CAPSCREW, Hex Head, 3/8-16 x 1
7 1916965 10 LOCKWASHER, Spring, 3/8
8 1916950 10 NUT, Hex, 318-16
9 1703743 2 SUPPORT, Side Hitch
10 1921971 4 CAPSCREW, Hex Head, 3/8-16 x 1-3/4
11 176012 1 CLIP, Safety Pin
12 1665699 4 SPACER
13 1919384 4 WASHER
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691793 Turbo Clean Sweep Twin Catcher

6
TP 400-2439-00-AT-SMA
© Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved.
Turbo Clean Sweep Twin Catcher - Adapter, Blade & Tube Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
984018
The above parts group applies to the following Mfg. Nos.:
1691793 Turbo Clean Sweep Twin Catcher

7
TP 400-2439-00-AT-SMA
Turbo Clean Sweep Twin Catcher - Adapter, Blade & Tube Group
1 1669193 1 SUPPORT
2 1921210 3 CAPSCREW, Hex Head, 3/8-16 x 1
3 1916965 3 LOCKWASHER, 3/8
4 1916950 3 NUT, Hex, 3/8-16
5 1930641 1 NUT, Hex Flange Lock, 1/4-20
6 1960252 1 CARRIAGE BOLT, 1/4-20 x 5/8
7 1705111 1 TUBE ASSEMBLY, Lower (Inc. Ref. Nos. 8, 9, & 14)
8 1705063 1 CLIP, Spring
9 910542 2 RIVET
10 1930531 2 SCREW, Truss Head, #10-32 x 1/2
11 1910531 4 WASHER, #10
12 1928919 2 NUT, Hex, Washer Assembly, #10-32
13 1704283 1 TUBE, Upper
14 1910531 2 WASHER
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691793 Turbo Clean Sweep Twin Catcher

Torque Specification Chart
FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)
Hardware
Grade
SAE Grade 2 SAE Grade 5 SAE Grade 8
Size Of in/lbs in/lbs in/lbs
Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.
8-32 19 2.1 30 3.4 41 4.6
8-36 20 2.3 31 3.5 43 4.9
10-24 27 3.1 43 4.9 60 6.8
10-32 31 3.5 49 5.5 68 7.7
1/4-20 66 7.6 810.9 12 16.3
1/4-28 76 8.6 10 13.6 14 19.0
5/16-18 11 15.0 17 23.1 25 34.0
5/16-24 12 16.3 19 25.8 27 34.0
3/8-16 20 27.2 30 40.8 45 61.2
3/8-24 23 31.3 35 47.6 50 68.0
7/16-14 30 40.8 50 68.0 70 95.2
7/16-20 35 47.6 55 74.8 80 108.8
1/2-13 50 68.0 75 102.0 110 149.6
1/2-20 55 74.8 90 122.4 120 163.2
9/16-12 65 88.4 110 149.6 150 204.0
9/16-18 75 102.0 120 163.2 170 231.2
5/8-11 90 122.4 150 204.0 220 299.2
5/8-18 100 136 180 244.8 240 326.4
3/4-10 160 217.6 260 353.6 386 525.0
3/4-16 180 244.8 300 408.0 420 571.2
7/8-9 140 190.4 400 544.0 600 816.0
7/8-14 155 210.8 440 598.4 660 897.6
1-8 220 299.2 580 788.8 900 1,244.0
1-12 240 326.4 640 870.4 1,000 1,360.0
Hex Head Capscrew
Hex Nut
Lockwasher
Washer
Carriage Bolt
NOTES
1. These torque values are to be used for all hardware
excluding: locknuts, self-tapping screws, thread forming
screws, sheet metal screws and socket head setscrews.
2. Recommended seating torque values for locknuts:
a. for prevailing torque locknuts - use 65% of grade 5
torques.
b. for flange whizlock nuts and screws - use 135% of
grade 5 torques.
3. Unless otherwise noted on assembly drawings, all torque
values must meet this specification.
Hardware Identification & Torque Specifications
Common Hardware Types
Screw, 1/2 x 2
Body
Diameter
Body
Length
Inside
Diameter
Nut, 1/2”
No
Marks
3/8” Bolt or Nut
Wrench—9/16”
3/8
5/16” Bolt or Nut
Wrench—1/2”
5/16
1/4” Bolt or Nut
Wrench—7/16”
1/4
1/2” Bolt or Nut
Wrench—3/4”
1/2
DIA.
7/16
DIA.
7/16” Bolt or Nut
Wrench (Bolt)—5/8”
Wrench (Nut)—11/16”
Wrench & Fastener Size Guide
Standard Hardware Sizing
When a washer or nut is identified as 1/2”, this is the
Nominal size , meaning the inside diameter is 1/2 inch; if a
second number is present it represent the
threads per inch
When bolt or capscrew is identified as 1/2 - 16 x 2”, this
means the
Nominal size , or body diameter is 1/2 inch; the
second number represents the
threads per inch (16 in this
example, and the final number is the
body length of the
bolt or screw (in this example 2 inches long).
The guides and ruler furnished below are designed to
help you select the appropriate hardware and tools.
01/4 3/4
1/2 11/4 3/4
1/2 21/4 3/4
1/2 31/4 3/4
1/2 4
